2 - STATOR 265V/200HZ
BSD-3604229092.A3
3604229092
|
£475.72
|
£570.87
|
|
|
3/8 - GROOVE BALL BEARING 12x32x10
BSD-3600905119.A168
3600905119
|
£27.23
|
£32.68
|
|
|
4 - AIR-DEFLECTOR RING
BSD-3600209006.A92
3600209006
|
£5.58
|
£6.70
|
|
|
6 - GROOVE BALL BEARING
BSD-3600905095.A183
3600905095
|
£21.52
|
£25.83
|
|
|
7/1 - BEARING FLANGE
BSD-3605806134.A11
3605806134
|
£81.81
|
£98.17
|
|
|
14 - THREADED RING
BSD-3603344024.A262
3603344024
|
£16.41
|
£19.69
|
|
|
15 - O-RING 38.1x2.2 MM
BSD-1600210037.A125
1600210037
|
£2.61
|
£3.13
|
|
|
21 - THREAD-FORMING TAP. SCREW AM 6x80-ST
BSD-3603410007.A110
3603410007
|
£3.72
|
£4.47
|
|
|
23 - COMPRESSION SPRING
BSD-3604611019.A159
3604611019
|
£2.61
|
£3.13
|
|
|
27 - SEALING DISC
BSD-3600100049.A114
3600100049
|
£3.72
|
£4.47
|
|
|
28 - SEALING DISC
BSD-3600100048.A162
3600100048
|
£2.80
|
£3.36
|
|
|
94 - SET SCREW DIN 915-M4x6-45H
BSD-2912081116.A366
2912081116
|
£2.61
|
£3.13
|
|
|
95 - NAMEPLATE
BSD-3601106053.A1210
3601106053
|
£5.30
|
£6.36
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110047.A75
3601110047
|
£2.80
|
£3.36
|
|
|
97 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A341
3603133001
|
£2.61
|
£3.13
|
|
|
98 - STICKER
BSD-3601110235.A2
3601110235
|
-
|
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A159
3601119236
|
£3.72
|
£4.47
|
|
|
102 - SPINDLE HOUSING
BSD-3605806075.A13
3605806075
|
£195.26
|
£234.31
|
|
|
103 - GRINDING SPINDLE
BSD-3606120003.A0
3606120003
|
-
|
|
|
|
105 - GROOVE BALL BEARING
BSD-3600905060.A89
3600905060
|
£21.52
|
£25.83
|
|
|
106 - GROOVE BALL BEARING
BSD-3600905057.A8
3600905057
|
£21.68
|
£26.01
|
|
|
108 - PINION Z=21
BSD-3606300074.A29
3606300074
|
£72.18
|
£86.62
|
|
|
109 - CLUTCH ELEMENT Z=21
BSD-3606491000.A30
3606491000
|
£6.52
|
£7.83
|
|
|
110 - SPACER SLEEVE
BSD-3600700056.A22
3600700056
|
£40.80
|
£48.96
|
|
|
112 - O-RING 43.0x2.0 MM
BSD-3600210058.A18
3600210058
|
£1.75
|
£2.10
|
|
|
114 - THREADED RING
BSD-3603344024.A263
3603344024
|
£16.41
|
£19.69
|
|
|
115 - O-RING 33.0x2.5 MM
BSD-3600210050.A70
3600210050
|
£2.61
|
£3.13
|
|
|
123 - RETAINING RING 24x2 DIN9045-24
BSD-2916609112.A108
2916609112
|
£2.61
|
£3.13
|
|
|
220 - THREAD-FORMING TAP. SCREW
BSD-2914451079.A20
2914451079
|
£2.61
|
£3.13
|
|
|
230 - CONTROL LEVER
BSD-1602026038.A33
1602026038
|
£5.30
|
£6.36
|
|
|
230/1 - SOCKET HEAD CAP SCREW DIN 84-AM3x10-4.8
BSD-2910001052.A228
2910001052
|
£2.16
|
£2.59
|
|
|
231 - SEALING PLATE
BSD-1600113003.A272
1600113003
|
£2.80
|
£3.36
|
|
|
232 - GROMMET
BSD-1600306000.A143
1600306000
|
£1.95
|
£2.34
|
|
|
233 - PROTECTIVE COVER
BSD-1600502004.A132
1600502004
|
£4.26
|
£5.11
|
|
|
234 - SPRING WASHER DIN 137-A4
BSD-1600150006.A458
1600150006
|
-
|
|
|
|
235 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A610
2910021118
|
£1.75
|
£2.10
|
|
|
236 - FELT WASHER
BSD-1600205027.A24
1600205027
|
£1.75
|
£2.10
|
|
|
237 - SEAL
BSD-1601015011.A157
1601015011
|
£3.80
|
£4.56
|
|
|
238 - SOCKET HEAD CAP SCREW DIN 84-BM6x40-8.8
BSD-2910021209.A28
2910021209
|
-
|
|
|
|
256 - ON-OFF SWITCH
BSD-1607200017.A40
1607200017
|
£102.57
|
£123.08
|
|
|
256/20 - FIXING PLATE
BSD-3601023015.A24
3601023015
|
£21.68
|
£26.01
|
|
|
258 - HANDLE
BSD-3605132035.A89
3605132035
|
£40.80
|
£48.96
|
|
|
259 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A176
1600703009
|
£5.58
|
£6.70
|
|
|
264 - FASTENING CLAMP
BSD-3601303012.A20
3601303012
|
-
|
|
|
|
266 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A609
2910021118
|
£1.75
|
£2.10
|
|
|
650 - SINGLE-HEAD ENG. WRENCH SW32
BSD-3607950010.A48
3607950010
|
£27.23
|
£32.68
|
|
|
651 - PIN-TYPE FACE-WRENCH
BSD-1607950061.A739
1607950061
|
£5.42
|
£6.50
|
|
|
655 - PROTECTIVE COVER dia 125 MM
BSD-3605510030.A8
3605510030
|
£27.23
|
£32.68
|
|
|
656 - CLAMPING-FLANGE
BSD-3605703112.A35
3605703112
|
£48.38
|
£58.06
|
|
|
656/10 - CLAMPING-FLANGE
BSD-3605703071.A16
3605703071
|
-
|
|
|
|
657 - CLAMPING RING
BSD-3605703077.A7
3605703077
|
£37.27
|
£44.72
|
|
|
657/10 - CLAMPING RING
BSD-3605703075.A15
3605703075
|
£27.23
|
£32.68
|
|
|
658 - RETAINING RING 24x2 DIN9045-24
BSD-2916609112.A109
2916609112
|
£2.61
|
£3.13
|
|
|
801 - MOTOR HOUSING GR.88
BSD-3605108160.A63
3605108160
|
£179.37
|
£215.24
|
|
|
802 - STATOR 265V/200HZ
BSD-3607031255.A1
3607031255
|
-
|
|
|
|
803 - ROTOR
BSD-3604080024.A69
3604080024
|
£306.65
|
£367.98
|
|
|
803 - ROTOR
BSD-3604080025.A13
3604080025
|
£283.50
|
£340.20
|
|
|
810 - BEARING FLANGE
BSD-3607020109.A7
3607020109
|
£283.50
|
£340.20
|
|
|
810/077 - SET OF EARTLING MATERIAL
BSD-3607031299.A127
3607031299
|
£8.67
|
£10.41
|
|
|
811 - FASTENING PARTS KIT
BSD-3607031290.A17
3607031290
|
£120.11
|
£144.13
|
|
|
823 - SPRING SET
BSD-3607031296.A152
3607031296
|
£16.41
|
£19.69
|
|
|
858/1 - HANDLE
BSD-1605132067.A49
1605132067
|
-
|
|
|
|
860 - CABLE
BSD-3607030239.A5
3607030239
|
£68.42
|
£82.10
|
|
