1 - HOUSING SECTION
BSD-2605104972.A1
2605104972
|
-
|
|
|
|
1 - HOUSING SECTION
BSD-2605104973.A2
2605104973
|
-
|
|
|
|
2 - FIELD 220-240V
BSD-2604220423.A68
2604220423
|
£24.45
|
£29.34
|
|
|
3 - ARMATURE 230V
BSD-2604010907.A5
2604010907
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200137.A102
2607200137
|
-
|
|
|
|
6 - GROMMET dia6.9 MM
BSD-2600707059.A486
2600707059
|
£3.72
|
£4.47
|
|
|
6 - GROMMET dia8.8 MM
BSD-2600707061.A243
2600707061
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia11.6-dia12.5x84 MM
BSD-2600707060.A65
2600707060
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-2601035001.A580
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-2601110387.A2
2601110387
|
-
|
|
|
|
10 - CARBON-BRUSH SET
BSD-2604321905.A596
2604321905
|
£11.30
|
£13.56
|
|
|
11 - SUPPRESSION CAPACITOR
BSD-2607329095.A84
2607329095
|
-
|
|
|
|
12 - BRUSH HOLDER
BSD-2604330017.A29
2604330017
|
-
|
|
|
|
15 - KEY CHUCK dia1.5-13 MM. 1/2
BSD-1608571055.A26
1608571055
|
-
|
|
|
|
15/10 - CHUCK WRENCH SG2
BSD-2607950007.A1524
2607950007
|
£6.52
|
£7.83
|
|
|
16 - DRILLING SPINDLE 1/2-UNF-2
BSD-2606135000.A9
2606135000
|
-
|
|
|
|
17 - LOCKING WASHER 0.6 MM
BSD-2600118001.A24
2600118001
|
£1.75
|
£2.10
|
|
|
17 - LOCKING WASHER 0.8 MM
BSD-2600118002.A172
2600118002
|
£1.75
|
£2.10
|
|
|
17 - LOCKING WASHER 1.0 MM
BSD-2600118003.A14
2600118003
|
-
|
|
|
|
17 - LOCKING WASHER 0.3 MM
BSD-2600118006.A23
2600118006
|
-
|
|
|
|
19 - STICKER
BSD-2601110388.A1
2601110388
|
-
|
|
|
|
21 - O-RING 28x3 MM
BSD-1900210129.A16
1900210129
|
£2.61
|
£3.13
|
|
|
22 - MODIFICATION SET
BSD-2607001039.A18
2607001039
|
-
|
|
|
|
23 - CATCH DISK
BSD-2606490040.A6
2606490040
|
£6.52
|
£7.83
|
|
|
24 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A501
1903230010
|
£1.75
|
£2.10
|
|
|
25 - MODIFICATION SET
BSD-2607001039.A17
2607001039
|
-
|
|
|
|
27 - COMPRESSION SPRING
BSD-2604617000.A135
2604617000
|
£2.61
|
£3.13
|
|
|
28 - GROOVE BALL BEARING 6002-Z DIN 625
BSD-1900905102.A139
1900905102
|
-
|
|
|
|
29 - TORX OVAL-HEAD SCREW 3x18
BSD-2603490018.A220
2603490018
|
£1.75
|
£2.10
|
|
|
32 - CYLINDRICAL GEAR Z=40
BSD-2606320035.A6
2606320035
|
-
|
|
|
|
33 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A550
2600905021
|
£8.67
|
£10.41
|
|
|
34 - SOCKET HEAD CAP SCREW DIN 84-BM4x30-8.8
BSD-2910021134.A67
2910021134
|
£1.75
|
£2.10
|
|
|
35 - BEARING BRACKET
BSD-2605807909.A7
2605807909
|
-
|
|
|
|
40 - SCREW 4x16
BSD-2603490022.A1415
2603490022
|
£1.75
|
£2.10
|
|
|
41 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A681
2600917003
|
£2.80
|
£3.36
|
|
|
46 - GROOVE BALL BEARING
BSD-2600905029.A14
2600905029
|
-
|
|
|
|
47 - O-RING 15x2 MM
BSD-1900210012.A43
1900210012
|
£1.75
|
£2.10
|
|
|
50 - DAMPING PLATE
BSD-2601022000.A583
2601022000
|
£1.75
|
£2.10
|
|
|
60 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A885
2912401020
|
£2.16
|
£2.59
|
|
|
61 - FELT WASHER
BSD-2600108002.A66
2600108002
|
£2.16
|
£2.59
|
|
|
62 - CUPPED WASHER
BSD-2600500002.A370
2600500002
|
£1.75
|
£2.10
|
|
|
64 - CLAMP BUSHING
BSD-2600400011.A10
2600400011
|
-
|
|
|
|
74 - SHIM
BSD-2600150005.A51
2600150005
|
£1.75
|
£2.10
|
|
|
75 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A651
2916660008
|
£2.16
|
£2.59
|
|
|
76 - FAN
BSD-2606610047.A6
2606610047
|
-
|
|
|
|
78 - REFERENCE PLATE
BSD-2601105060.A15
2601105060
|
-
|
|
|
|
79 - FELT STRIP 51 MM
BSD-2601005006.A7
2601005006
|
-
|
|
|
|
80 - FELT STRIP 68 MM
BSD-2601005007.A20
2601005007
|
-
|
|
|
|
82 - CONNECTING CABLE L=154 MM
BSD-2604448000.A70
2604448000
|
-
|
|
|
|
83 - CONNECTING CABLE L=184 MM
BSD-2604448001.A69
2604448001
|
£1.95
|
£2.34
|
|
|
84 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A520
2603410001
|
£1.75
|
£2.10
|
|
|
85 - STICKER
BSD-2601110041.A128
2601110041
|
-
|
|
|
|
87 - SUPPRESSION FILTER
BSD-2604465054.A0
2604465054
|
-
|
|
|
|
88 - SUPPRESSION FILTER
BSD-2604465054.A1
2604465054
|
-
|
|
|
|
654 - AUXILIARY HANDLE dia43 MM
BSD-2602025032.A116
2602025032
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1563
160111A3H3
|
£2.61
|
£3.13
|
|
