2 - FIELD 220-240V
BSD-2604220423.A70
2604220423
|
£24.45
|
£29.34
|
|
|
4 - SWITCH
BSD-2607200209.A72
2607200209
|
£40.80
|
£48.96
|
|
|
4 - ON-OFF SWITCH
BSD-2607200137.A104
2607200137
|
-
|
|
|
|
6 - GROMMET dia6.9 MM
BSD-2600707059.A488
2600707059
|
£3.72
|
£4.47
|
|
|
7 - CABLE CLIP
BSD-2601035001.A584
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-2601110604.A1
2601110604
|
-
|
|
|
|
11 - SUPPRESSION FILTER
BSD-2607329096.A1
2607329096
|
£7.36
|
£8.83
|
|
|
12 - BRUSH HOLDER
BSD-2604330017.A26
2604330017
|
-
|
|
|
|
15 - CHUCK dia1.5-13 MM. 1/2
BSD-1608571069.A36
1608571069
|
£23.86
|
£28.63
|
|
|
15/10 - CHUCK WRENCH SG2. SW4
BSD-1607950044.A13
1607950044
|
£6.12
|
£7.34
|
|
|
16 - DRILLING SPINDLE 1/2-UNF-2
BSD-2606135016.A7
2606135016
|
-
|
|
|
|
17 - LOCKING WASHER 0.6 MM
BSD-2600118001.A22
2600118001
|
£1.75
|
£2.10
|
|
|
17 - LOCKING WASHER 0.3 MM
BSD-2600118006.A25
2600118006
|
-
|
|
|
|
19 - STICKER
BSD-2601110645.A4
2601110645
|
-
|
|
|
|
21 - RUBBER PLUG
BSD-2603239010.A34
2603239010
|
-
|
|
|
|
22 - MODIFICATION SET
BSD-2607001039.A27
2607001039
|
-
|
|
|
|
23 - CATCH DISK
BSD-2606490040.A10
2606490040
|
£6.52
|
£7.83
|
|
|
24 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A498
1903230010
|
£1.75
|
£2.10
|
|
|
27 - COMPRESSION SPRING
BSD-2604617000.A141
2604617000
|
£2.61
|
£3.13
|
|
|
28 - GROOVE BALL BEARING 15x32x9
BSD-1900905122.A14
1900905122
|
£10.10
|
£12.12
|
|
|
29 - TORX OVAL-HEAD SCREW 3x18
BSD-2603490018.A226
2603490018
|
£1.75
|
£2.10
|
|
|
32 - CYLINDRICAL GEAR Z=40
BSD-2606320035.A10
2606320035
|
-
|
|
|
|
33 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A556
2600905021
|
£8.67
|
£10.41
|
|
|
34 - SOCKET HEAD CAP SCREW DIN 84-BM4x30-8.8
BSD-2910021134.A72
2910021134
|
£1.75
|
£2.10
|
|
|
40 - SCREW 4x16
BSD-2603490022.A1409
2603490022
|
£1.75
|
£2.10
|
|
|
41 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A686
2600917003
|
£2.80
|
£3.36
|
|
|
46 - GROOVE BALL BEARING
BSD-2600905029.A7
2600905029
|
-
|
|
|
|
47 - O-RING 15x2 MM
BSD-1900210012.A46
1900210012
|
£1.75
|
£2.10
|
|
|
50 - DAMPING PLATE
BSD-2601022000.A577
2601022000
|
£1.75
|
£2.10
|
|
|
60 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A887
2912401020
|
£2.16
|
£2.59
|
|
|
61 - FELT WASHER
BSD-2600108009.A0
2600108009
|
-
|
|
|
|
62 - CUPPED WASHER
BSD-2600500002.A367
2600500002
|
£1.75
|
£2.10
|
|
|
64 - CLAMP BUSHING
BSD-2600400011.A11
2600400011
|
-
|
|
|
|
73 - O-RING 18x3 MM
BSD-1900210117.A53
1900210117
|
£3.72
|
£4.47
|
|
|
74 - BACKUP RING
BSD-2600220014.A7
2600220014
|
-
|
|
|
|
75 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A647
2916660008
|
£2.16
|
£2.59
|
|
|
76 - FAN
BSD-2606610022.A175
2606610022
|
£4.26
|
£5.11
|
|
|
78 - REFERENCE PLATE
BSD-2601105060.A9
2601105060
|
-
|
|
|
|
79 - FELT STRIP 51 MM
BSD-2601005006.A0
2601005006
|
-
|
|
|
|
80 - FELT STRIP 68 MM
BSD-2601005007.A27
2601005007
|
-
|
|
|
|
82 - CONNECTING CABLE L=154 MM
BSD-2604448000.A72
2604448000
|
-
|
|
|
|
83 - CONNECTING CABLE L=184 MM
BSD-2604448001.A67
2604448001
|
£1.95
|
£2.34
|
|
|
84 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A519
2603410001
|
£1.75
|
£2.10
|
|
|
85 - STICKER
BSD-2601110230.A65
2601110230
|
-
|
|
|
|
86 - COUNTERSUNK-HEAD SCREW M6x27
BSD-2603421226.A63
2603421226
|
£1.75
|
£2.10
|
|
|
87 - CARB BRUSH HOLD W-SUPR
BSD-2604465085.A5
2604465085
|
-
|
|
|
|
89 - CONNECTING CABLE L=74MM
BSD-2604448035.A7
2604448035
|
-
|
|
|
|
90 - CABLE
BSD-2604448003.A153
2604448003
|
-
|
|
|
|
91 - CHANGE-OVER SWITCH
BSD-2607200198.A11
2607200198
|
-
|
|
|
|
91 - CHANGE-OVER SWITCH
BSD-2607200206.A56
2607200206
|
-
|
|
|
|
654 - AUXILIARY HANDLE
BSD-3602025009.A50
3602025009
|
£18.96
|
£22.75
|
|
|
802 - HOUSING SECTION
BSD-2605104990.A7
2605104990
|
-
|
|
|
|
803 - BEARING BRACKET
BSD-2605807913.A1
2605807913
|
-
|
|
|
|
804 - MODIFICATION SET
BSD-2607001039.A26
2607001039
|
-
|
|
|
|
805 - ARMATURE 230-240V
BSD-2604010905.A4
2604010905
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A599
2604321905
|
£11.30
|
£13.56
|
|
|
835 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A200
1607000386
|
£21.52
|
£25.83
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1565
160111A3H3
|
£2.61
|
£3.13
|
|
