1 - MOTOR HOUSING
BSD-2605105138.A8
2605105138
|
£27.23
|
£32.68
|
|
|
2 - FIELD 230-240V
BSD-1619P08347.A10
1619P08347
|
£54.42
|
£65.30
|
|
|
4 - SWITCH
BSD-2607200675.A2
2607200675
|
£40.80
|
£48.96
|
|
|
5 - POWER SUPPLY CORD GB 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-2604460244.A65
2604460244
|
£27.23
|
£32.68
|
|
|
6 - GROMMET
BSD-2600707072.A37
2600707072
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-2601035004.A196
2601035004
|
£2.16
|
£2.59
|
|
|
9 - MANUFACTURER'S NAMEPLATE GSB 162-2 RE
BSD-2601111402.A0
2601111402
|
£2.61
|
£3.13
|
|
|
19 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A39
2603490021
|
£1.75
|
£2.10
|
|
|
20 - REFERENCE PLATE
BSD-160111C1V2.A1
160111C1V2
|
£3.72
|
£4.47
|
|
|
21 - HANDLE
BSD-2602025178.A11
2602025178
|
£27.23
|
£32.68
|
|
|
24 - DRILLING SPINDLE
BSD-2606135143.A20
2606135143
|
£40.80
|
£48.96
|
|
|
26 - COMPRESSION SPRING
BSD-2604616002.A252
2604616002
|
£1.75
|
£2.10
|
|
|
29 - SPRING RETAINING RING DIN 471 17x1 MM
BSD-2916650008.A91
2916650008
|
£1.75
|
£2.10
|
|
|
33 - DOUBLE GEAR WHEEL
BSD-1600A00L2N.A6
1600A00L2N
|
£14.91
|
£17.89
|
|
|
36 - CATCH DISK
BSD-2600190105.A51
2600190105
|
£2.61
|
£3.13
|
|
|
38 - SHIM WASHER 1.0 MM
BSD-2600000021.A79
2600000021
|
£1.75
|
£2.10
|
|
|
38 - SHIM WASHER
BSD-2600000045.A8
2600000045
|
£1.75
|
£2.10
|
|
|
40 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A223
1903230010
|
£1.75
|
£2.10
|
|
|
41 - SLIDE SWITCH
BSD-2602319030.A1
2602319030
|
£4.26
|
£5.11
|
|
|
42 - PRESSURE PLATE
BSD-2601074009.A18
2601074009
|
-
|
|
|
|
44 - SEAL
BSD-2601015104.A11
2601015104
|
£7.36
|
£8.83
|
|
|
45 - AIR-DEFLECTOR RING
BSD-2600148015.A20
2600148015
|
£5.58
|
£6.70
|
|
|
49 - THRUST NEEDLE RIM
BSD-2600913042.A16
2600913042
|
£3.72
|
£4.47
|
|
|
54 - FRICTION WASHER
BSD-2600114087.A7
2600114087
|
£2.80
|
£3.36
|
|
|
55 - TRANSMISSION
BSD-1600A00L2M.A3
1600A00L2M
|
£59.53
|
£71.44
|
|
|
61 - SHIM
BSD-2600100712.A2
2600100712
|
£2.61
|
£3.13
|
|
|
64 - HEADLESS SCREW
BSD-2603435085.A25
2603435085
|
£1.75
|
£2.10
|
|
|
65 - STRAIGHT PIN
BSD-2603105132.A19
2603105132
|
£2.61
|
£3.13
|
|
|
66 - ADJUSTING SLIDE
BSD-2601099226.A2
2601099226
|
£6.52
|
£7.83
|
|
|
67 - LINK GUIDE
BSD-2602033021.A1
2602033021
|
£11.30
|
£13.56
|
|
|
68 - COILED SPRING
BSD-2604651026.A16
2604651026
|
£1.75
|
£2.10
|
|
|
69 - ROTARY KNOB
BSD-2602026172.A1
2602026172
|
£5.30
|
£6.36
|
|
|
71 - RATCHET CAP
BSD-2600590006.A645
2600590006
|
£1.75
|
£2.10
|
|
|
72 - TORX OVAL-HEAD SCREW 4x30
BSD-2603490025.A10
2603490025
|
£1.75
|
£2.10
|
|
|
73 - SCREW 4x16
BSD-2603490022.A3027
2603490022
|
£1.75
|
£2.10
|
|
|
85 - KEY CHUCK dia3-16MM.5/8
BSD-1608571083.A21
1608571083
|
£72.18
|
£86.62
|
|
|
86 - CONNECTING CABLE
BSD-2604448328.A1
2604448328
|
£1.75
|
£2.10
|
|
|
88 - HOLDING PLATE
BSD-2601328086.A9
2601328086
|
£2.80
|
£3.36
|
|
|
89 - BULB SHIELD
BSD-2605510276.A11
2605510276
|
£8.67
|
£10.41
|
|
|
96 - SEALING COVER
BSD-1600A00L17.A11
1600A00L17
|
£2.80
|
£3.36
|
|
|
97 - SEAL RING
BSD-2605808138.A9
2605808138
|
£1.75
|
£2.10
|
|
|
98 - SEAL
BSD-2601015114.A9
2601015114
|
£5.30
|
£6.36
|
|
|
210 - REFERENCE PLATE
BSD-2601112190.A9
2601112190
|
£2.61
|
£3.13
|
|
|
215 - WARNING PLATE
BSD-160111C1K1.A7
160111C1K1
|
£2.61
|
£3.13
|
|
|
653 - AUXILIARY HANDLE
BSD-2602025205.A0
2602025205
|
£57.05
|
£68.46
|
|
|
653/8 - HEX SCREW
BSD-2911061971.A11
2911061971
|
£8.67
|
£10.41
|
|
|
653/9 - HANDLE
BSD-2602025189.A15
2602025189
|
£31.64
|
£37.97
|
|
|
653/12 - WING SCREW
BSD-2603481021.A1
2603481021
|
£13.12
|
£15.75
|
|
|
653/13 - HEX NUT
BSD-2915051140.A18
2915051140
|
£4.75
|
£5.70
|
|
|
653/820 - SUPPORT CLAMP
BSD-2602025905.A1
2602025905
|
£41.62
|
£49.95
|
|
|
655 - DEPTH-GAUGE
BSD-2600460045.A1
2600460045
|
£5.30
|
£6.36
|
|
|
803 - ARMATURE ASSEMBLY 220-240V
BSD-1600A004L1.A6
1600A004L1
|
£116.15
|
£139.38
|
|
|
803/9 - FAN
BSD-2606610137.A18
2606610137
|
£6.61
|
£7.93
|
|
|
803/13 - GROOVE BALL BEARING 7x19x6
BSD-2600905086.A30
2600905086
|
£5.58
|
£6.70
|
|
|
808 - NAMEPLATE
BSD-160111A4C8.A0
160111A4C8
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321947.A3
2604321947
|
£18.96
|
£22.75
|
|
|
825 - GEAR HOUSING
BSD-2605806879.A10
2605806879
|
£59.53
|
£71.44
|
|
|
825/27 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A163
1900905163
|
£11.30
|
£13.56
|
|
|
825/78 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A7
2916660014
|
£1.75
|
£2.10
|
|
|
843 - BEARING BRACKET
BSD-2605807950.A8
2605807950
|
£93.88
|
£112.65
|
|
|
843/14 - BALL BEARING 9x24x7
BSD-2600905095.A85
2600905095
|
£12.04
|
£14.45
|
|
|
843/37 - CATCH DISK
BSD-2600190121.A19
2600190121
|
£11.30
|
£13.56
|
|
|
843/62 - NEEDLE BEARING
BSD-2600917023.A1
2600917023
|
£4.26
|
£5.11
|
|
|
843/84 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A246
2916660008
|
£2.16
|
£2.59
|
|
|
871 - CHUCK WRENCH SG2
BSD-2607950011.A22
2607950011
|
£11.30
|
£13.56
|
|
|
874 - SWITCH CONTACT
BSD-2601324072.A11
2601324072
|
£7.36
|
£8.83
|
|
|
876 - BRUSH PLATE
BSD-2604337912.A17
2604337912
|
£31.64
|
£37.97
|
|
|
879 - RPM ACTUATOR
BSD-2607230906.A8
2607230906
|
£63.50
|
£76.20
|
|
|
891 - CROSS RECESSED-HEAD SCREW
BSD-2603429010.A12
2603429010
|
£2.61
|
£3.13
|
|
