1 - HOUSING SECTION
BSD-2605104559.A5
2605104559
|
-
|
|
|
|
2 - FIELD 230V
BSD-2604220647.A15
2604220647
|
£21.52
|
£25.83
|
|
|
3 - ARMATURE 230V
BSD-2604011161.A3
2604011161
|
-
|
|
|
|
3/50 - FAN
BSD-2606610029.A361
2606610029
|
£2.61
|
£3.13
|
|
|
4 - ON-OFF SWITCH
BSD-2607200336.A17
2607200336
|
-
|
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A385
2600703012
|
£2.80
|
£3.36
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2070
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118998.A7
2601118998
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A290
2607329114
|
-
|
|
|
|
16 - BRUSH PLATE
BSD-2605807060.A69
2605807060
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1576
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1932
2603490022
|
£1.75
|
£2.10
|
|
|
20 - MANUFACTURER'S NAMEPLATE
BSD-2601118563.A32
2601118563
|
-
|
|
|
|
22 - CONTROL ELEMENT
BSD-2607230053.A5
2607230053
|
-
|
|
|
|
24 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A802
2603490017
|
£2.16
|
£2.59
|
|
|
25 - TORX OVAL-HEAD SCREW 3x30
BSD-2603490019.A43
2603490019
|
£1.75
|
£2.10
|
|
|
27 - TORX OVAL-HEAD SCREW 3x18
BSD-2603490018.A385
2603490018
|
£1.75
|
£2.10
|
|
|
28 - SOCKET HEAD CAP SCREW
BSD-2603429005.A22
2603429005
|
£1.75
|
£2.10
|
|
|
29 - DAMPING PLATE
BSD-2601022000.A411
2601022000
|
£1.75
|
£2.10
|
|
|
30 - DRILLING SPINDLE 1/2-24 UNF-2A
BSD-2606135066.A3
2606135066
|
-
|
|
|
|
31 - LOCKING WASHER 0.6 MM
BSD-2600118001.A191
2600118001
|
£1.75
|
£2.10
|
|
|
31 - LOCKING WASHER 0.3 MM
BSD-2600118006.A176
2600118006
|
-
|
|
|
|
31 - LOCKING WASHER 0.8 MM
BSD-2600118002.A47
2600118002
|
£1.75
|
£2.10
|
|
|
32 - COMPRESSION SPRING
BSD-2604616002.A183
2604616002
|
£1.75
|
£2.10
|
|
|
33 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A232
1900905163
|
£11.30
|
£13.56
|
|
|
34 - CYLINDRICAL GEAR Z=48
BSD-2606317045.A76
2606317045
|
£14.72
|
£17.67
|
|
|
35 - CYLINDRICAL GEAR Z=36
BSD-2606317037.A140
2606317037
|
-
|
|
|
|
36 - SHIM 1.0 MM
BSD-2600101515.A168
2600101515
|
£1.95
|
£2.34
|
|
|
37 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A156
2916650006
|
£1.75
|
£2.10
|
|
|
39 - RETAINING WASHER
BSD-2600101671.A114
2600101671
|
£1.75
|
£2.10
|
|
|
40 - FLAT KEY
BSD-2602300028.A87
2602300028
|
-
|
|
|
|
42 - CATCH DISK
BSD-2600190052.A73
2600190052
|
£7.78
|
£9.33
|
|
|
44 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A157
1903230010
|
£1.75
|
£2.10
|
|
|
45 - INDEXING DISK
BSD-2601990001.A133
2601990001
|
£1.32
|
£1.58
|
|
|
46 - PRESSURE PLATE
BSD-2601074003.A136
2601074003
|
£1.75
|
£2.10
|
|
|
52 - SHIM 0.3 MM
BSD-2600100607.A5
2600100607
|
£1.75
|
£2.10
|
|
|
53 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A0
2600914010
|
£2.80
|
£3.36
|
|
|
54 - BEARING SLEEVE
BSD-2600400027.A73
2600400027
|
£4.26
|
£5.11
|
|
|
56 - CONTROL FORK
BSD-2602033005.A10
2602033005
|
-
|
|
|
|
57 - ROTARY HEAD
BSD-2602026091.A90
2602026091
|
-
|
|
|
|
58 - RATCHET CAP
BSD-2600590006.A241
2600590006
|
£1.75
|
£2.10
|
|
|
62 - DRIVER PIN
BSD-2601335001.A92
2601335001
|
£2.16
|
£2.59
|
|
|
64 - SHIM WASHER
BSD-2600100618.A33
2600100618
|
£1.75
|
£2.10
|
|
|
70 - CUPPED WASHER
BSD-2600500014.A39
2600500014
|
-
|
|
|
|
71 - O-RING 18x3 MM
BSD-1900210117.A148
1900210117
|
£3.72
|
£4.47
|
|
|
72 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A256
2916660008
|
£2.16
|
£2.59
|
|
|
73 - RECEPTACLE
BSD-2600400008.A616
2600400008
|
£1.75
|
£2.10
|
|
|
75 - O-RING 5.0x1.5 MM
BSD-1900210000.A223
1900210000
|
£1.75
|
£2.10
|
|
|
76 - FELT STRIP
BSD-2601005011.A135
2601005011
|
-
|
|
|
|
77 - FELT STRIP
BSD-2601005016.A35
2601005016
|
£1.32
|
£1.58
|
|
|
82 - COUNTERSUNK-HEAD SCREW M6x27
BSD-2603421226.A404
2603421226
|
£1.75
|
£2.10
|
|
|
85 - REFERENCE PLATE
BSD-2601118670.A8
2601118670
|
-
|
|
|
|
92 - CONNECTING CABLE L=88 MM
BSD-2604448034.A131
2604448034
|
£1.75
|
£2.10
|
|
|
93 - CONNECTING CABLE L=103 MM
BSD-2604448132.A84
2604448132
|
£1.75
|
£2.10
|
|
|
94 - CONNECTING CABLE L=73 MM
BSD-2604448115.A70
2604448115
|
£1.75
|
£2.10
|
|
|
95 - EARTH CONDUCTOR
BSD-2604448170.A118
2604448170
|
-
|
|
|
|
753 - AUXILIARY HANDLE dia43 MM
BSD-1619P10682.A192
1619P10682
|
£12.49
|
£14.99
|
|
|
753/20 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A488
2915011007
|
-
|
|
|
|
753/30 - WING SCREW M6x(15)55
BSD-1613480007.A149
1613480007
|
£1.75
|
£2.10
|
|
|
753/50 - CLAMPING PLATE M6
BSD-2608040014.A115
2608040014
|
-
|
|
|
|
753/60 - WING SCREW M6x20 MM
BSD-1613480008.A284
1613480008
|
£1.75
|
£2.10
|
|
|
755 - DEPTH-GAUGE
BSD-2603001019.A47
2603001019
|
£2.63
|
£3.16
|
|
|
780/1 - KEYLESS CHUCK dia 2-13 MM.1/2
BSD-2608572034.A33
2608572034
|
£30.62
|
£36.74
|
|
|
780/10 - COUNTERSUNK-HEAD SCREW M6x31 MM
BSD-2603421209.A2
2603421209
|
£1.32
|
£1.58
|
|
|
797 - DRILL HOLDER
BSD-2607000122.A31
2607000122
|
-
|
|
|
|
805 - POWER SUPPLY CORD EU 2.65m 2 x 1.0mm H05 RN-F
BSD-1607000388.A213
1607000388
|
£12.04
|
£14.45
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A4682
160111A3H3
|
£2.61
|
£3.13
|
|
|
813 - NEEDLE BEARING
BSD-2600917902.A51
2600917902
|
-
|
|
|
|
814 - GROOVE BALL BEARING 9x24x7
BSD-2600905039.A397
2600905039
|
£12.04
|
£14.45
|
|
|
816/040 - CARBON-BRUSH SET
BSD-2604321916.A20
2604321916
|
-
|
|
|
|
816/060 - SLIDING PIECE
BSD-1619P12767.A92
1619P12767
|
£9.47
|
£11.36
|
|
|
838 - CHANGE-OVER SWITCH
BSD-2607200231.A36
2607200231
|
£16.41
|
£19.69
|
|
|
849 - TOOTHED SHAFT Z= 10/29/22
BSD-2606309913.A27
2606309913
|
-
|
|
|
|
863 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A477
2916080007
|
£2.61
|
£3.13
|
|
|
866 - BEARING BRACKET
BSD-2605807928.A45
2605807928
|
-
|
|
|
|
869 - FELT DISC
BSD-2600108000.A137
2600108000
|
-
|
|
|
