1 - MOTOR HOUSING
BSD-1609300004.A0
1609300004
|
-
|
|
|
|
1 - VALVE BUSHING
BSD-1609300006.A0
1609300006
|
-
|
|
|
|
1 - VALVE PLATE
BSD-1609300007.A0
1609300007
|
-
|
|
|
|
1 - SEAL RING
BSD-1609300653.A0
1609300653
|
-
|
|
|
|
1 - COMPRESSION SPRING
BSD-1609300578.A0
1609300578
|
-
|
|
|
|
1 - FITTING
BSD-1609300425.A0
1609300425
|
-
|
|
|
|
1 - O-RING
BSD-1609300664.A0
1609300664
|
-
|
|
|
|
1 - SCREW PLUG R1/4 DIN 906-5.8
BSD-2912140751.A0
2912140751
|
-
|
|
|
|
1 - CONTROL LEVER
BSD-1609300008.A0
1609300008
|
-
|
|
|
|
1 - COILED SPRING PIN
BSD-1609300674.A0
1609300674
|
-
|
|
|
|
2 - HOUSING COVER
BSD-1609300000.A0
1609300000
|
-
|
|
|
|
3 - BEARING FLANGE
BSD-1609300019.A0
1609300019
|
-
|
|
|
|
4 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A481
2600905052
|
£7.36
|
£8.83
|
|
|
5 - STRAIGHT PIN
BSD-1609300014.A0
1609300014
|
-
|
|
|
|
6 - STATOR
BSD-1609300010.A0
1609300010
|
-
|
|
|
|
6 - SLOTTED SPRING PIN
BSD-1609300679.A0
1609300679
|
-
|
|
|
|
7 - ROTOR WITHOUT WINDING
BSD-1609300011.A0
1609300011
|
-
|
|
|
|
8 - ROTOR LAMELLA
BSD-1609300012.A0
1609300012
|
-
|
|
|
|
9 - BEARING FLANGE
BSD-1609300013.A0
1609300013
|
-
|
|
|
|
10 - GROOVE BALL BEARING 6000 DIN 625
BSD-1900900270.A37
1900900270
|
-
|
|
|
|
11 - SEAL RING
BSD-1609300635.A0
1609300635
|
-
|
|
|
|
12 - SEAL RING
BSD-1609300667.A0
1609300667
|
-
|
|
|
|
13 - SEAL RING
BSD-1609300671.A0
1609300671
|
-
|
|
|
|
14 - SPINDLE BEARING
BSD-1609300015.A0
1609300015
|
-
|
|
|
|
14 - BEARING SLEEVE
BSD-1609300022.A0
1609300022
|
-
|
|
|
|
14 - SCREW PLUG
BSD-1609300614.A0
1609300614
|
-
|
|
|
|
14 - O-RING
BSD-1609300664.A1
1609300664
|
-
|
|
|
|
14 - SCREW PLUG
BSD-1609300614.A1
1609300614
|
-
|
|
|
|
15 - MOTOR HOUSING
BSD-1609300059.A0
1609300059
|
-
|
|
|
|
16 - COUPLING HALF
BSD-1609300060.A0
1609300060
|
-
|
|
|
|
17 - STRIKER
BSD-1609300020.A0
1609300020
|
-
|
|
|
|
18 - BEARING BOLT
BSD-1609300021.A0
1609300021
|
-
|
|
|
|
19 - STRIKER SPINDLE
BSD-1609301192.A0
1609301192
|
-
|
|
|
|
19 - O-RING
BSD-1609301193.A0
1609301193
|
-
|
|
|
|
19 - RETAINING SNAP RING
BSD-1609301194.A0
1609301194
|
-
|
|
|
|
20 - SHAFT SEAL B 12x22x7 DIN 3760
BSD-2916730076.A0
2916730076
|
-
|
|
|
|
21 - SEAL
BSD-1609300001.A0
1609300001
|
-
|
|
|
|
22 - HEX SOCKET HEAD CAP SCREW
BSD-1609300898.A0
1609300898
|
-
|
|
|
|
23 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A201
2916680006
|
-
|
|
|
|
24 - NAMEPLATE
BSD-1601104507.A4
1601104507
|
-
|
|
|
|
25 - ROUND-HEAD GROOVED PIN 2x4 DIN 1476 ST
BSD-2917721032.A11
2917721032
|
-
|
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A326
3601119236
|
£3.72
|
£4.47
|
|
