1 - HOUSING SECTION
BSD-2605104982.A4
2605104982
|
-
|
|
|
|
2 - ARMATURE 240V
BSD-2604010559.A13
2604010559
|
-
|
|
|
|
3 - BEARING BRACKET
BSD-2605807906.A1
2605807906
|
-
|
|
|
|
5 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A180
2600905021
|
£8.67
|
£10.41
|
|
|
6 - SCREW AND WASHER ASSEMBLY DIN7985-M4x18Z1-4.8
BSD-2914500009.A54
2914500009
|
-
|
|
|
|
8 - GUIDE SLEEVE
BSD-2600400024.A85
2600400024
|
£2.80
|
£3.36
|
|
|
9 - SUPPORTING DISC
BSD-2600103013.A24
2600103013
|
£1.32
|
£1.58
|
|
|
10 - FIELD 230V
BSD-2604220392.A49
2604220392
|
£23.86
|
£28.63
|
|
|
11 - BRUSH HOLDER
BSD-2604449017.A0
2604449017
|
-
|
|
|
|
13 - SINTERED-METAL BUSHING
BSD-1600301900.A223
1600301900
|
-
|
|
|
|
13/1 - FELT WASHER
BSD-1600205023.A209
1600205023
|
£1.32
|
£1.58
|
|
|
15 - O-RING 8.0x2.5 MM
BSD-1610210014.A205
1610210014
|
-
|
|
|
|
16 - HOLDING SPRING
BSD-1619P09928.A42
1619P09928
|
£1.75
|
£2.10
|
|
|
17 - ECCENTRIC COG WHEEL Z=39
BSD-2606319070.A8
2606319070
|
-
|
|
|
|
18 - SPRING WASHER
BSD-2600150050.A38
2600150050
|
£1.75
|
£2.10
|
|
|
19 - SHIM 0.5 MM
BSD-2600102658.A63
2600102658
|
£1.32
|
£1.58
|
|
|
19 - SHIM 0.2 MM
BSD-2600102656.A7
2600102656
|
£1.32
|
£1.58
|
|
|
20 - COUNTERWEIGHT
BSD-2601098005.A5
2601098005
|
£3.80
|
£4.56
|
|
|
21 - SHIM 0.3 MM
BSD-2600101083.A24
2600101083
|
-
|
|
|
|
22 - FORK LEVER
BSD-2601923003.A12
2601923003
|
-
|
|
|
|
23 - SHIM 0.3 MM
BSD-2600101654.A38
2600101654
|
£2.33
|
£2.80
|
|
|
24 - LOCKING WASHER DIN 6799-5-FSt
BSD-2916080008.A73
2916080008
|
-
|
|
|
|
25 - FIXING PLATE
BSD-2601030006.A74
2601030006
|
-
|
|
|
|
26 - LIFTING ROD
BSD-2600780038.A16
2600780038
|
-
|
|
|
|
27 - CLAMP SCREW
BSD-2603400000.A115
2603400000
|
£4.26
|
£5.11
|
|
|
28 - SINTERED-METAL BUSHING
BSD-2600302006.A23
2600302006
|
-
|
|
|
|
29 - SWITCH
BSD-2607200084.A80
2607200084
|
£10.10
|
£12.12
|
|
|
29 - SWITCH
BSD-2607200260.A357
2607200260
|
£11.30
|
£13.56
|
|
|
29 - SWITCH
BSD-2607200184.A52
2607200184
|
-
|
|
|
|
30 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1635
2603410001
|
£1.75
|
£2.10
|
|
|
31 - SUPPRESSION CAPACITOR
BSD-2607329120.A8
2607329120
|
-
|
|
|
|
32 - POWER SUPPLY CORD GB 110V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460205.A80
2604460205
|
£27.23
|
£32.68
|
|
|
33 - GROMMET dia6.4-dia7.5x75 MM
BSD-1600703016.A154
1600703016
|
£1.75
|
£2.10
|
|
|
33 - GROMMET dia9.5 MM
BSD-2600703006.A41
2600703006
|
-
|
|
|
|
34 - CABLE CLIP
BSD-2601035001.A2125
2601035001
|
£1.75
|
£2.10
|
|
|
35 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A486
2910611019
|
£2.80
|
£3.36
|
|
|
36 - NAMEPLATE
BSD-2601105051.A36
2601105051
|
-
|
|
|
|
37 - BASE PLATE
BSD-2601016012.A2
2601016012
|
£8.67
|
£10.41
|
|
|
38 - ROLLER LEVER
BSD-2601321900.A37
2601321900
|
-
|
|
|
|
39 - ROLLER LEVER
BSD-2601321901.A2
2601321901
|
-
|
|
|
|
41 - HEX NUT DIN 439-BM 4-04
BSD-2915051104.A36
2915051104
|
-
|
|
|
|
42 - HEX NUT
BSD-2603300009.A18
2603300009
|
-
|
|
|
|
42 - FIXING PLATE
BSD-2601030006.A73
2601030006
|
-
|
|
|
|
43 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A370
2910021122
|
£2.16
|
£2.59
|
|
|
44 - PROFILE BEADING
BSD-2602317025.A28
2602317025
|
-
|
|
|
|
46 - STICKER
BSD-2601110206.A2
2601110206
|
-
|
|
|
|
47 - STICKER
BSD-2601110207.A2
2601110207
|
-
|
|
|
|
48 - DAMPING PLATE
BSD-2601022000.A286
2601022000
|
£1.75
|
£2.10
|
|
|
49 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A230
2912401020
|
£2.16
|
£2.59
|
|
|
50 - CROSS RECESSED-HEAD SCREW DIN 7981-ST 3.9x13-F-H
BSD-2910611418.A27
2910611418
|
-
|
|
|
|
51 - CONNECTING CABLE L = 298 MM
BSD-2604448032.A2
2604448032
|
-
|
|
|
|
52 - NEEDLE ROLLER A 3x9.8G2DIN 5402
BSD-1903201041.A40
1903201041
|
-
|
|
|
|
53 - SUPPORT PLATE
BSD-2602316900.A8
2602316900
|
-
|
|
|
|
54 - COMPRESSION SPRING
BSD-2604613000.A74
2604613000
|
£1.75
|
£2.10
|
|
|
56 - GUIDE
BSD-2601000034.A4
2601000034
|
-
|
|
|
|
57 - STRAIGHT PIN DIN 6325-4M6x24
BSD-2917530101.A48
2917530101
|
£2.80
|
£3.36
|
|
|
58 - STRAIGHT PIN 4M6x12DIN6325
BSD-2917530095.A21
2917530095
|
-
|
|
|
|
59 - SHIM 0.5 MM
BSD-2600101612.A344
2600101612
|
£1.75
|
£2.10
|
|
|
62 - NEEDLE BEARING
BSD-2600917900.A121
2600917900
|
£8.67
|
£10.41
|
|
|
63 - CONNECTING CABLE L = 278 MM
BSD-2604448012.A85
2604448012
|
£1.32
|
£1.58
|
|
|
64 - SEALING PLATE
BSD-2601015006.A10
2601015006
|
-
|
|
|
|
65 - SEALING PLATE
BSD-2601015900.A43
2601015900
|
-
|
|
|
|
66 - SWITCH HANDLE
BSD-2602026035.A21
2602026035
|
-
|
|
|
|
67 - RATCHET CAP
BSD-2600590006.A264
2600590006
|
£1.75
|
£2.10
|
|
|
68 - RATCHET CAP
BSD-2600590006.A265
2600590006
|
£1.75
|
£2.10
|
|
|
69 - SHIM 0.5 MM
BSD-2600100568.A4
2600100568
|
£1.75
|
£2.10
|
|
|
69 - SHIM 0.3 MM
BSD-2600100570.A101
2600100570
|
£1.75
|
£2.10
|
|
|
72 - STICKER
BSD-2601110041.A69
2601110041
|
-
|
|
|
|
73 - SPEED GOVERNOR 220-240V
BSD-2607230008.A4
2607230008
|
-
|
|
|
|
74 - BRUSH HOLDER
BSD-2604449010.A0
2604449010
|
-
|
|
|
|
75 - CONNECTING CABLE L=243 MM
BSD-2604448033.A32
2604448033
|
-
|
|
|
|
77 - SUPPORT PLATE
BSD-2601098006.A26
2601098006
|
£1.75
|
£2.10
|
|
|
78 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A830
2603490017
|
£2.16
|
£2.59
|
|
|
80 - REFERENCE PLATE
BSD-2601110307.A3
2601110307
|
-
|
|
|
|
85 - FAN
BSD-2606610047.A128
2606610047
|
-
|
|
|
|
812 - CARBON-BRUSH SET
BSD-2604321904.A211
2604321904
|
£10.10
|
£12.12
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A4538
160111A3H3
|
£2.61
|
£3.13
|
|
