2 - FIELD 230-240V
BSD-2604220447.A4
2604220447
|
£25.05
|
£30.06
|
|
|
3 - ARMATURE 230V
BSD-2604010895.A4
2604010895
|
-
|
|
|
|
3/60 - FAN
BSD-2606610050.A45
2606610050
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200303.A0
2607200303
|
-
|
|
|
|
5 - POWER SUPPLY CORD I 4.15m 2 x 1.0mm H05 VV-F
BSD-2604460131.A4
2604460131
|
£12.64
|
£15.17
|
|
|
6 - GROMMET dia7 MM
BSD-2600703007.A10
2600703007
|
-
|
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118352.A3
2601118352
|
-
|
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-2607329138.A82
2607329138
|
-
|
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A777
2600905021
|
£8.67
|
£10.41
|
|
|
16 - BRUSH PLATE
BSD-2605807060.A169
2605807060
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1114
2603410001
|
£1.84
|
£2.21
|
|
|
27 - SHIM 0.3 MM
BSD-2600101047.A448
2600101047
|
£1.84
|
£2.21
|
|
|
28 - SHIM 0.5 MM
BSD-2600101048.A12
2600101048
|
£1.84
|
£2.21
|
|
|
29 - SHIM 0.5 MM
BSD-2600102614.A84
2600102614
|
£1.38
|
£1.66
|
|
|
30 - SHIM 5.5 MM
BSD-2601098025.A10
2601098025
|
-
|
|
|
|
31 - FORK LEVER
BSD-2601923009.A0
2601923009
|
-
|
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY
BSD-2600913007.A5
2600913007
|
-
|
|
|
|
33 - ECCENTRIC COG WHEEL Z=39
BSD-2606320049.A5
2606320049
|
-
|
|
|
|
35 - INTERMEDIATE RING
BSD-2600200035.A9
2600200035
|
-
|
|
|
|
38 - LIFTING ROD
BSD-2600780060.A5
2600780060
|
-
|
|
|
|
39 - SINTERED-METAL BUSHING
BSD-2600302009.A5
2600302009
|
-
|
|
|
|
40 - SHIM 0.5 MM
BSD-2600101612.A111
2600101612
|
£1.84
|
£2.21
|
|
|
40 - SHIM 0.3 MM
BSD-2600116012.A28
2600116012
|
-
|
|
|
|
41 - SUPPORT PLATE
BSD-2602316011.A5
2602316011
|
-
|
|
|
|
42 - GUIDE BRACKET
BSD-2601322014.A15
2601322014
|
-
|
|
|
|
43 - COMPRESSION SPRING
BSD-2604613000.A282
2604613000
|
£1.84
|
£2.21
|
|
|
44 - OVAL-HEAD SCREW DIN 7985-M4x18-8.8-H
BSD-2910950128.A4
2910950128
|
-
|
|
|
|
45 - CLAMP SCREW
BSD-2603490004.A6
2603490004
|
-
|
|
|
|
46 - COUPLING HALF
BSD-2606491012.A5
2606491012
|
-
|
|
|
|
47 - RATCHET
BSD-2606491010.A4
2606491010
|
-
|
|
|
|
48 - GUIDE SLEEVE
BSD-2600451002.A10
2600451002
|
-
|
|
|
|
49 - ROTARY HANDLE
BSD-2608040073.A4
2608040073
|
-
|
|
|
|
50 - ROLLER LEVER
BSD-2601321049.A1
2601321049
|
-
|
|
|
|
51 - SEALING PLATE
BSD-2601015057.A84
2601015057
|
£3.80
|
£4.56
|
|
|
52 - STRAIGHT PIN
BSD-2609002725.A19
2609002725
|
£1.75
|
£2.10
|
|
|
53 - STRAIGHT PIN DIN 6325-4m6x20
BSD-2917530099.A1
2917530099
|
-
|
|
|
|
54 - SHIM 0.5 MM
BSD-2600100510.A8
2600100510
|
£2.74
|
£3.29
|
|
|
55 - CHANGE-OVER SWITCH 230V
BSD-2602026055.A9
2602026055
|
-
|
|
|
|
56 - RATCHET CAP
BSD-2600590006.A1379
2600590006
|
£1.84
|
£2.21
|
|
|
57 - SHIM 0.5 MM
BSD-2600100568.A147
2600100568
|
£1.84
|
£2.21
|
|
|
57 - SHIM 0.3 MM
BSD-2600100607.A1119
2600100607
|
£1.75
|
£2.10
|
|
|
57 - SHIM
BSD-2600100572.A5
2600100572
|
-
|
|
|
|
59 - SHIM
BSD-2600400030.A5
2600400030
|
-
|
|
|
|
61 - O-RING 5.0x1.75 MM
BSD-2600210036.A137
2600210036
|
-
|
|
|
|
62 - BEARING BOLT
BSD-2603201020.A98
2603201020
|
£1.84
|
£2.21
|
|
|
63 - ROTARY HANDLE
BSD-2608040074.A4
2608040074
|
-
|
|
|
|
64 - RATCHET
BSD-2606491013.A6
2606491013
|
-
|
|
|
|
65 - PINION Z=8
BSD-2606333029.A4
2606333029
|
-
|
|
|
|
66 - BEVEL GEAR Z=32
BSD-2606333028.A6
2606333028
|
-
|
|
|
|
67 - PROFILE BEADING
BSD-2602317028.A10
2602317028
|
-
|
|
|
|
68 - BASE PLATE
BSD-2601016073.A2
2601016073
|
-
|
|
|
|
69 - SUCTION CHANNEL
BSD-2605730037.A5
2605730037
|
-
|
|
|
|
70 - COVERING HOOD
BSD-2605510149.A5
2605510149
|
-
|
|
|
|
71 - INSERTED PART
BSD-2608040075.A4
2608040075
|
-
|
|
|
|
72 - SEALING CAP
BSD-2608040077.A5
2608040077
|
-
|
|
|
|
73 - CONTACT SPRING
BSD-2601329047.A1
2601329047
|
-
|
|
|
|
75 - LOOP
BSD-2603100055.A0
2603100055
|
-
|
|
|
|
76 - CONNECTING CABLE L=50 MM
BSD-2604448190.A5
2604448190
|
-
|
|
|
|
77 - CONNECTING CABLE L=73 MM
BSD-2604448123.A83
2604448123
|
-
|
|
|
|
80 - SPEED GOVERNOR 230-240V
BSD-2607230024.A3
2607230024
|
-
|
|
|
|
81 - COMPRESSION SPRING
BSD-2604610040.A31
2604610040
|
£1.84
|
£2.21
|
|
|
753 - FITTING
BSD-2600499032.A5
2600499032
|
-
|
|
|
|
801 - HOUSING SECTION
BSD-2605104854.A3
2605104854
|
-
|
|
|
|
801/03 - PRESS-IN SOCKET
BSD-2600506008.A11
2600506008
|
-
|
|
|
|
808 - NAMEPLATE
BSD-2601119266.A0
2601119266
|
-
|
|
|
|
813 - NEEDLE BEARING
BSD-2600917901.A2
2600917901
|
-
|
|
|
|
816/04 - CARBON-BRUSH SET
BSD-2604321905.A365
2604321905
|
£11.87
|
£14.24
|
|
|
816/06 - RATCHET CAP
BSD-2601322013.A239
2601322013
|
£1.84
|
£2.21
|
|
|
816/06 - RATCHET CAP
BSD-2601329051.A131
2601329051
|
£2.33
|
£2.80
|
|
|
825 - BEARING BRACKET
BSD-2605807925.A5
2605807925
|
£14.08
|
£16.89
|
|
|
834 - LOCKING WASHER DIN 6799-6-FST
BSD-2916080909.A12
2916080909
|
£1.84
|
£2.21
|
|
|
836 - NEEDLE BEARING
BSD-2600917900.A442
2600917900
|
£9.11
|
£10.93
|
|
|
858 - LOCKING WASHER DIN 6799-5-FSt
BSD-2916080008.A206
2916080008
|
-
|
|
|
|
874 - TAPPING SCREW DIN 7981-ST3.9x19-C-H
BSD-2910611020.A377
2910611020
|
£1.84
|
£2.21
|
|
