1 - ARMATURE 230V GB
BDE-494036-00.A0
494036-00
|
£44.14
|
£52.97
|
|
|
1 - ARMATURE 115V LX
BDE-494036-01.A2
494036-01
|
£44.14
|
£52.97
|
|
|
2 - FIELD 230V GB
BDE-494038-00.A0
494038-00
|
£30.08
|
£36.10
|
|
|
2 - NO LONGER AVAILABLE LX
BDE-000000-00.A129337
000000-00
|
-
|
|
|
|
3 - NO LONGER AVAILABLE LX
BDE-000000-00.A129338
000000-00
|
-
|
|
|
|
3 - BRUSH HOLDER PLATE GB
BDE-494043-00.A2
494043-00
|
£17.48
|
£20.97
|
|
|
4 - SWITCH 220V GB
BDE-N055693.A0
N055693
|
£17.48
|
£20.97
|
|
|
4 - SWITCH 115V LX
BDE-N055694
N055694
|
-
|
|
|
|
5 - BRUSH PAIR 230V GB
BDE-494040-00.A2
494040-00
|
£7.18
|
£8.62
|
|
|
5 - BRUSH PAIR 115V LX
BDE-494040-01.A0
494040-01
|
£4.69
|
£5.63
|
|
|
6 - BRUSH SPRING
BDE-445860-00.A85
445860-00
|
£1.50
|
£1.80
|
|
|
7 - CORD PROTECTOR
BDE-584090-00.A98
584090-00
|
£1.50
|
£1.80
|
|
|
8 - CORDSET GB
BDE-330060-07.A8
330060-07
|
£17.48
|
£20.97
|
|
|
8 - CORDSET LX
BDE-330061-14.A40
330061-14
|
£93.62
|
£112.35
|
|
|
9 - SCREW
BDE-330019-02.A7
330019-02
|
£1.50
|
£1.80
|
|
|
10 - CORD CLAMP
BDE-821070.A215
821070
|
£1.50
|
£1.80
|
|
|
11 - SCREW
BDE-330065-27.A6
330065-27
|
£1.50
|
£1.80
|
|
|
14 - CAPACITOR GB
BDE-N065873.A0
N065873
|
£3.30
|
£3.96
|
|
|
14 - CAPACITOR LX
BDE-N065873.A1
N065873
|
£3.30
|
£3.96
|
|
|
15 - LEAD RED LX
BDE-N059304
N059304
|
-
|
|
|
|
15 - CHOKE LEAD BLACK GB
BDE-N059906
N059906
|
£1.50
|
£1.80
|
|
|
16 - LEAD BLACK LX
BDE-N059305
N059305
|
-
|
|
|
|
16 - CHOKE LEAD RED GB
BDE-N059905
N059905
|
£1.50
|
£1.80
|
|
|
20 - CLAMSHELL SET
BDE-N064927
N064927
|
£30.08
|
£36.10
|
|
|
21 - SCREEN
BDE-1005041-00.A3
1005041-00
|
£1.50
|
£1.80
|
|
|
22 - CASTING
BDE-494042-00.A2
494042-00
|
£9.41
|
£11.29
|
|
|
23 - SCREW
BDE-330045-09.A32
330045-09
|
£1.50
|
£1.80
|
|
|
24 - CARRIER
BDE-490331-00.A0
490331-00
|
£2.26
|
£2.71
|
|
|
25 - SCREW
BDE-330045-07.A34
330045-07
|
£1.50
|
£1.80
|
|
|
26 - SPRING COMPRESSION
BDE-490457-00.A6
490457-00
|
£1.50
|
£1.80
|
|
|
27 - BEARING
BDE-490330-00.A9
490330-00
|
£1.50
|
£1.80
|
|
|
28 - HOLDER
BDE-582262-00.A22
582262-00
|
£1.50
|
£1.80
|
|
|
29 - FELT SEAL
BDE-487900-00.A4
487900-00
|
£1.50
|
£1.80
|
|
|
30 - BEARING
BDE-490329-00.A2
490329-00
|
£1.50
|
£1.80
|
|
|
31 - COVER GEARCASE
BDE-494044-00.A0
494044-00
|
£12.17
|
£14.60
|
|
|
32 - FELT SEAL
BDE-582263-00.A3
582263-00
|
£1.50
|
£1.80
|
|
|
33 - THRUST PLATE
BDE-494271-00.A0
494271-00
|
£1.50
|
£1.80
|
|
|
40 - SHAFT
BDE-494045-00.A5
494045-00
|
£14.57
|
£17.48
|
|
|
43 - SCREW
BDE-370167.A14
370167
|
£1.50
|
£1.80
|
|
|
44 - BLADE CLAMP
BDE-N542463.A4
N542463
|
£19.90
|
£23.88
|
|
|
45 - SCREW
BDE-324006-00.A109
324006-00
|
£1.50
|
£1.80
|
|
|
46 - CLAMP
BDE-582261-00.A3
582261-00
|
£1.50
|
£1.80
|
|
|
47 - DRIVE ROLLER
BDE-582257-00.A7
582257-00
|
£7.18
|
£8.62
|
|
|
48 - WASHER SPECIAL
BDE-479820-00.A5
479820-00
|
£1.50
|
£1.80
|
|
|
49 - SCREW
BDE-324007-07.A1
324007-07
|
£1.50
|
£1.80
|
|
|
50 - GEAR SA
BDE-N026207.A1
N026207
|
£37.35
|
£44.82
|
|
|
60 - BEARING
BDE-N332380
N332380
|
£1.50
|
£1.80
|
|
|
61 - ECCENTRIC
BDE-494053-00.A0
494053-00
|
£7.85
|
£9.42
|
|
|
62 - GUARD LH
BDE-491122-00.A1
491122-00
|
£1.50
|
£1.80
|
|
|
63 - GUARD RH
BDE-491123-00.A6
491123-00
|
£1.50
|
£1.80
|
|
|
64 - NOZZLE
BDE-479203-00.A5
479203-00
|
£1.50
|
£1.80
|
|
|
65 - BALANCE WEIGHT
BDE-494055-00.A5
494055-00
|
£16.03
|
£19.24
|
|
|
68 - FORK
BDE-494056-00.A0
494056-00
|
£7.18
|
£8.62
|
|
|
69 - BLADE SUPPORT SA
BDE-493744-00.A2
493744-00
|
£10.85
|
£13.02
|
|
|
70 - THRUST PLATE
BDE-490349-00.A4
490349-00
|
£1.50
|
£1.80
|
|
|
71 - WASHER
BDE-330016-01.A31
330016-01
|
£1.50
|
£1.80
|
|
|
80 - CASTING
BDE-494057-00.A5
494057-00
|
£37.35
|
£44.82
|
|
|
81 - BAFFLE FAN
BDE-490627-00.A3
490627-00
|
£1.50
|
£1.80
|
|
|
82 - BEARING
BDE-N110359.A24
N110359
|
£3.75
|
£4.50
|
|
|
83 - SERVICE KIT
BDE-N061104.A2
N061104
|
£1.42
|
£1.70
|
|
|
84 - DETENT
BDE-326467-00.A252
326467-00
|
£1.50
|
£1.80
|
|
|
85 - LEVER
BDE-479901-00.A2
479901-00
|
£2.78
|
£3.34
|
|
|
86 - CLIP
BDE-571181-00.A35
571181-00
|
£1.50
|
£1.80
|
|
|
87 - PIN
BDE-330041-55.A5
330041-55
|
£1.50
|
£1.80
|
|
|
88 - SHOE SA
BDE-496995-00.A1
496995-00
|
£17.48
|
£20.97
|
|
|
89 - ANTI SPLINTER DEVICE
BDE-479966-00.A0
479966-00
|
£1.50
|
£1.80
|
|
|
90 - COVERPLATE
BDE-1005085-00.A2
1005085-00
|
£1.50
|
£1.80
|
|
|
95 - NUT
BDE-322319.A14
322319
|
£1.50
|
£1.80
|
|
|
96 - SUPPRESSOR GB
BDE-N419846.A1
N419846
|
£2.26
|
£2.71
|
|
|
100 - SCREW
BDE-571056-02.A1
571056-02
|
£1.50
|
£1.80
|
|
|
101 - WASHER
BDE-098197-06.A3
098197-06
|
£1.50
|
£1.80
|
|
|
102 - CLAMP
BDE-479532-00.A3
479532-00
|
£7.18
|
£8.62
|
|
|
105 - VACUUM ADAPTOR
BDE-1006440-00
1006440-00
|
£1.50
|
£1.80
|
|
|
105 - VACUUM ADAPTOR
BDE-1006441-00
1006441-00
|
£1.50
|
£1.80
|
|
|
110 - SCREW
BDE-330019-66.A18
330019-66
|
£1.50
|
£1.80
|
|
|
120 - TORX 50 WRENCH
BDE-571057-01.A5
571057-01
|
£1.50
|
£1.80
|
|
|
800 - GREASE
BDE-870889-03.A12
870889-03
|
£7.85
|
£9.42
|
|
|
817 - BRAND LABEL
BDE-479207-00.A1
479207-00
|
£1.50
|
£1.80
|
|
|
821 - RATING PLATE LX
BDE-N086003
N086003
|
£1.42
|
£1.70
|
|
|
821 - RATING PLATE GB
BDE-N086001
N086001
|
£1.50
|
£1.80
|
|
|
836 - S.T.ASSEMBLY JIG
BDE-559658-99.A4
559658-99
|
£16.03
|
£19.24
|
|
|
861 - KITBOX
BDE-329040-11.A4
329040-11
|
£38.80
|
£46.56
|
|
