DIY model with excellent price-performance ratio
compact and lightweight design
suction port
rip fence, miter gauge and push stick included


motor data
motor power s1 in W 350 W
voltage 230V /50 Hz
speed in min-1 1450
engine type IP 20
measurements
outreach in mm 230
table size in mm 300×300
suction port in mm 54
total dimensions in mm 510x650x810
swivel range 0°- 45°
cutting performance
max. cutting height 90° in mm 90
band saws
saw band in mm 1575 x 6-10
saw band speed in m/min 762
band wheel diameter in mm 230
volume level and vibration
sound power level in dB(A) 94
sound pressure level in dB(A) 81
weight
gross weight in kg 20
net weight in kg 16
packaging
packaging width in mm 270
packaging length in mm 460
packaging height in mm 775
general data
EAN code 9120058376689
