1 - MOTOR CASING WITH INDUCTOR 230 V
MAF-084509.A2
084509
|
-
|
|
|
1.1 - INDUCTOR WITH COIL
MAF-084510.A4
084510
|
-
|
|
|
1.2 - MOTOR CASING, EMPTY
MAF-203636.A2
203636
|
£82.02
|
£98.43
|
|
2 - ARMATURE, BALANCED
MAF-088155.A2
088155
|
-
|
|
|
3 - TACHOMETER CARRIER
MAF-038975.A55
038975
|
£20.14
|
£24.17
|
|
4 - WING SCREW
MAF-079070.A2
079070
|
-
|
|
|
5 - BRAKE LEVER, CPL.
MAF-201122.A17
201122
|
-
|
|
|
6 - GUIDE RAIL 260 HM FOR 006968
MAF-204581.A2
204581
|
-
|
|
|
7 - FINE-CUT SAW CHAIN
MAF-006955.A2
006955
|
-
|
|
|
8 - CONTROL MODULE
MAF-077142.A5
077142
|
£181.20
|
£217.44
|
|
9 - ARBOR, CPL.
MAF-201145.A6
201145
|
-
|
|
|
10 - TENSIONING SCREW, CPL.
MAF-201146.A8
201146
|
£33.98
|
£40.78
|
|
12 - BASE PLATE
MAF-201101.A7
201101
|
-
|
|
|
13 - GEAR CASING
MAF-201750.A
201750
|
£563.96
|
£676.75
|
|
14 - SEGMENT FOR TILTING
MAF-201105.A1
201105
|
-
|
|
|
15 - TILTING PLATE
MAF-201107.A1
201107
|
-
|
|
|
16 - INTERMEDIATE COVER, CPL.
MAF-201751.A3
201751
|
-
|
|
|
17 - BEARING COVER
MAF-201111.A3
201111
|
-
|
|
|
19 - HANDLE SHELLS (PAIR)
MAF-202518.A6
202518
|
-
|
|
|
20 - SWITCH LEVER
MAF-201114.A35
201114
|
£13.23
|
£15.88
|
|
21 - COVER
MAF-201115.A4
201115
|
-
|
|
|
22 - OIL TANK
MAF-201116.A10
201116
|
£32.84
|
£39.41
|
|
23 - AIR CONDUCTING RING
MAF-201136.A3
201136
|
-
|
|
|
24 - FAN, UPPER
MAF-032355.A27
032355
|
£12.50
|
£15.00
|
|
25 - SLIDING BLOCK
MAF-201129.A9
201129
|
-
|
|
|
26 - CLAMP
MAF-201130.A1
201130
|
-
|
|
|
27 - MOTOR COVER
MAF-039174.A15
039174
|
-
|
|
|
28 - LOCKING LEVER
MAF-201745.A33
201745
|
£6.02
|
£7.22
|
|
29 - INTERMEDIATE RING
MAF-202119.A0
202119
|
-
|
|
|
30 - COVER
MAF-201128.A3
201128
|
-
|
|
|
31 - CHIP DEFLECTOR
MAF-201139.A2
201139
|
£11.24
|
£13.49
|
|
32 - GUARD FLAP
MAF-201140.A5
201140
|
-
|
|
|
33 - GUARD FLAP
MAF-201141.A2
201141
|
-
|
|
|
34 - COVERING RING
MAF-201151.A1
201151
|
-
|
|
|
36 - GUARD PLATE
MAF-201156.A6
201156
|
-
|
|
|
37 - SHEET METAL COVER
MAF-201740.A1
201740
|
-
|
|
|
39 - RIVING KNIFE 260 FOR 006968
MAF-204586.A0
204586
|
-
|
|
|
45 - CLAMPING NUT
MAF-201127.A2
201127
|
£18.31
|
£21.97
|
|
46 - GEAR SHAFT
MAF-201135.A7
201135
|
-
|
|
|
47 - BRAKE DRUM
MAF-201138.A14
201138
|
-
|
|
|
48 - SPROCKET HM FOR 006968
MAF-204584.A2
204584
|
-
|
|
|
49 - SPACER SLEEVE
MAF-201137.A4
201137
|
-
|
|
|
50 - HEXAGONAL NUT
MAF-201147.A29
201147
|
£7.42
|
£8.91
|
|
51 - GUIDE PIECE
MAF-201149.A15
201149
|
-
|
|
|
54 - SPACER BUSHING
MAF-025157.A1
025157
|
-
|
|
|
55 - CYLINDER-HEAD SCREW
MAF-201743.A6
201743
|
-
|
|
|
56 - BEVEL WHEEL
MAF-201123.A1
201123
|
-
|
|
|
57 - PINION
MAF-201118.A6
201118
|
-
|
|
|
58 - OIL TANK CAP
MAF-201153.A10
201153
|
-
|
|
|
59 - OIL TUBE
MAF-201131.A9
201131
|
-
|
|
|
62 - BOWDEN CABLE, CPL.
MAF-201748.A5
201748
|
-
|
|
|
63 - OIL PUMP, CPL.
MAF-201144.A2
201144
|
£141.90
|
£170.28
|
|
65 - GUIDING SEGMENT
MAF-201148.A1
201148
|
-
|
|
|
66 - BOW HANDLE
MAF-201142.A12
201142
|
-
|
|
|
67 - THREADED PIN
MAF-005276.A14
005276
|
£1.81
|
£2.17
|
|
70 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A90
053020
|
£2.01
|
£2.41
|
|
72 - CYLINDER-HEAD SCREW
MAF-005505.A38
005505
|
-
|
|
|
73 - CYLINDER-HEAD SCREW
MAF-055038.A22
055038
|
£2.64
|
£3.17
|
|
74 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055062.A100
055062
|
-
|
|
|
75 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A216
055061
|
£1.71
|
£2.05
|
|
76 - CYLINDER-HEAD SCREW
MAF-055172.A20
055172
|
-
|
|
|
77 - CYLINDER-HEAD SCREW
MAF-055074.A28
055074
|
£2.12
|
£2.55
|
|
78 - OVAL-HEAD SCREW
MAF-055069.A36
055069
|
£2.16
|
£2.59
|
|
79 - CYLINDER-HEAD SCREW
MAF-005591.A0
005591
|
-
|
|
|
80 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055091.A30
055091
|
-
|
|
|
81 - OVAL-HEAD SCREW
MAF-055101.A54
055101
|
£2.04
|
£2.45
|
|
82 - OVAL-HEAD SCREW
MAF-055093.A14
055093
|
-
|
|
|
83 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055124.A52
055124
|
-
|
|
|
84 - OVAL-HEAD SCREW
MAF-055143.A28
055143
|
-
|
|
|
85 - SHOULDER SCREW
MAF-055118.A59
055118
|
£2.41
|
£2.89
|
|
87 - CYLINDER-HEAD SCREW
MAF-055037.A19
055037
|
-
|
|
|
88 - SET SCREW
MAF-057036.A0
057036
|
-
|
|
|
90 - CYLINDRICAL PIN
MAF-058010.A2
058010
|
-
|
|
|
91 - RIBBED NAIL
MAF-058068.A23
058068
|
-
|
|
|
92 - CYLINDRICAL PIN
MAF-058184.A7
058184
|
-
|
|
|
95 - HEXAGONAL NUT
MAF-059008.A9
059008
|
-
|
|
|
96 - LOCKING NUT
MAF-005970.A20
005970
|
-
|
|
|
97 - HEXAGONAL NUT
MAF-005920.A71
005920
|
-
|
|
|
98 - HEXAGONAL NUT
MAF-005978.A9
005978
|
-
|
|
|
99 - CASTEL NUT
MAF-059010.A2
059010
|
-
|
|
|
100 - SHIM RING
MAF-061110.A11
061110
|
-
|
|
|
101 - WASHER
MAF-061038.A16
061038
|
-
|
|
|
102 - WASHER
MAF-006102.A97
006102
|
-
|
|
|
103 - LOCKING WASHER
MAF-006113.A46
006113
|
£1.92
|
£2.31
|
|
104 - LOCKING WASHER
MAF-006114.A33
006114
|
-
|
|
|
105 - LOCKING WASHER
MAF-006184.A52
006184
|
£1.50
|
£1.80
|
|
106 - LOCKING WASHER
MAF-007113.A4
007113
|
-
|
|
|
107 - SHIM RING
MAF-061154.A0
061154
|
-
|
|
|
108 - SHIM RING
MAF-061155.A4
061155
|
-
|
|
|
109 - FEDERSCHEIBE
MAF-061156.A2
061156
|
-
|
|
|
110 - FEDERSCHEIBE
MAF-061157.A4
061157
|
-
|
|
|
113 - RETAINING RING
MAF-007161.A15
007161
|
-
|
|
|
114 - GROOVED BALL BEARING
MAF-006231.A15
006231
|
£13.65
|
£16.38
|
|
115 - GROOVED BALL BEARING
MAF-006260.A43
006260
|
£18.15
|
£21.78
|
|
116 - GROOVED BALL BEARING
MAF-006269.A12
006269
|
-
|
|
|
117 - GROOVED BALL BEARING
MAF-062073.A64
062073
|
£14.28
|
£17.14
|
|
119 - SEALING RING
MAF-065004.A58
065004
|
£1.63
|
£1.96
|
|
120 - CUP SPRING
MAF-066016.A19
066016
|
-
|
|
|
121 - CUP SPRING
MAF-006675.A8
006675
|
£2.41
|
£2.89
|
|
122 - BRUSH HOLDER
MAF-063148.A77
063148
|
£10.30
|
£12.36
|
|
123 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063147.A47
063147
|
£14.72
|
£17.67
|
|
125 - STAR-SHAPED HANDLE
MAF-079046.A4
079046
|
-
|
|
|
126 - PAD
MAF-201872.A97
201872
|
-
|
|
|
127 - CABLE CLAMP
MAF-029584.A137
029584
|
-
|
|
|
130 - CABLE PROTECTING SLEEVE
MAF-086065.A67
086065
|
£3.46
|
£4.15
|
|
131 - SEALING RING
MAF-065033.A7
065033
|
-
|
|
|
133 - RETRACTING SPRING
MAF-066112.A18
066112
|
£5.52
|
£6.63
|
|
134 - TORSION SPRING, LEFT
MAF-066114.A4
066114
|
-
|
|
|
135 - TORSION SPRING, RIGHT
MAF-066115.A3
066115
|
-
|
|
|
136 - PRESSURE SPRING
MAF-066043.A134
066043
|
£3.04
|
£3.65
|
|
139 - ADHESIVE LABEL
MAF-070468.A0
070468
|
-
|
|
|
140 - INTERFERENCE SUPPRESSION CAPACITOR
MAF-087816.A7
087816
|
£17.15
|
£20.58
|
|
141 - 2-POLE SWITCH
MAF-087599.A14
087599
|
£50.76
|
£60.91
|
|
142 - MAINS CABLE 10 M (32.8 FT.)
MAF-087612.A34
087612
|
£72.48
|
£86.98
|
|
143 - CONNECTING CABLE
MAF-087808.A1
087808
|
-
|
|
|
501 - PARALLEL GUIDE FENCE
MAF-033030.A3
033030
|
-
|
|
|
502 - COMBINATION SCREW DRIVER
MAF-093272.A2
093272
|
-
|
|
|
