1 - MOTOR CASING WITH INDUCTOR
MAF-084542.A3
084542
|
-
|
|
|
|
1.1 - INDUCTOR WITH COIL
MAF-084540.A1
084540
|
£87.14
|
£104.57
|
|
|
1.2 - MOTOR CASING, EMPTY
MAF-202045.A3
202045
|
-
|
|
|
|
2 - ARMATURE, BALANCED
MAF-088150.A0
088150
|
£135.58
|
£162.69
|
|
|
3 - GUIDE RAIL EXTENSION
MAF-202901.A
202901
|
-
|
|
|
|
3.1 - GUIDE RAIL
MAF-202908.A
202908
|
-
|
|
|
|
3.2 - SPACER PLATE
MAF-202932.A1
202932
|
-
|
|
|
|
3.3 - ADAPTER
MAF-202927.A6
202927
|
-
|
|
|
|
3.4 - CLAMPING DEVICE
MAF-202914.A12
202914
|
-
|
|
|
|
3.5 - CELLULAR RUBBER STRIP
MAF-204029.A14
204029
|
£40.08
|
£48.10
|
|
|
3.6 - TOOTHED BELT SEGMENT
MAF-202930.A
202930
|
-
|
|
|
|
3.8 - FLAT-HEAD SCREW
MAF-053006.A19
053006
|
-
|
|
|
|
3.9 - SPRING DOWEL SLEEVE
MAF-058204.A8
058204
|
-
|
|
|
|
3.10 - CYLINDRICAL PIN
MAF-058200.A2
058200
|
-
|
|
|
|
3.11 - WASHER
MAF-061119.A15
061119
|
-
|
|
|
|
3.12 - SQUARE NUT
MAF-005977.A2
005977
|
-
|
|
|
|
4 - TENSIONING LEVER
MAF-203397.A24
203397
|
-
|
|
|
|
5 - GUIDE PIECE
MAF-202857.A2
202857
|
-
|
|
|
|
6 - DEPTH STOP
MAF-202912.A2
202912
|
-
|
|
|
|
7 - GEAR CASING
MAF-203548.A
203548
|
-
|
|
|
|
8 - BASE PLATE
MAF-202904.A
202904
|
-
|
|
|
|
9 - GEAR CASING COVER
MAF-202851.A0
202851
|
-
|
|
|
|
10 - GUIDE RAIL
MAF-202907.A7
202907
|
-
|
|
|
|
11 - INSERT
MAF-203358.A1
203358
|
-
|
|
|
|
12 - AIR CONDUCTING RING
MAF-200013.A6
200013
|
-
|
|
|
|
13 - FAN
MAF-200015.A4
200015
|
£7.85
|
£9.42
|
|
|
14 - MOTOR COVER
MAF-200183.A7
200183
|
-
|
|
|
|
15 - CAP
MAF-202345.A12
202345
|
£5.74
|
£6.89
|
|
|
16 - LOCKING BOLT
MAF-202436.A11
202436
|
-
|
|
|
|
17 - TERMINAL BOX
MAF-202902.A3
202902
|
-
|
|
|
|
18 - DUST EXTRACTION SHOE
MAF-202928.A0
202928
|
-
|
|
|
|
19 - GUIDE PIECE
MAF-202916.A6
202916
|
-
|
|
|
|
20 - PROTECTIVE COVER
MAF-202934.A
202934
|
-
|
|
|
|
21 - PLUNGE LEVER HANDLE
MAF-202344.A7
202344
|
£5.94
|
£7.13
|
|
|
22 - CLAMPING DEVICE
MAF-202914.A4
202914
|
-
|
|
|
|
23 - CASING, LOWER PART
MAF-202905.A1
202905
|
-
|
|
|
|
24 - CASING COVER
MAF-202906.A3
202906
|
-
|
|
|
|
25 - SLIDING COVER
MAF-202922.A4
202922
|
-
|
|
|
|
26 - COVERING HOOD
MAF-202938.A3
202938
|
-
|
|
|
|
27 - GUIDE BOLT
MAF-039836.A7
039836
|
-
|
|
|
|
28 - HOSE CONNECTOR
MAF-200042.A5
200042
|
£14.96
|
£17.95
|
|
|
29 - PART NAME NOT AVAILABLE
MAF-203354.A
203354
|
-
|
|
|
|
30 - SPRING BOLT
MAF-202935.A4
202935
|
-
|
|
|
|
31 - BALL-SHAPED FIXTURE
MAF-203369.A4
203369
|
-
|
|
|
|
32 - ARBOR
MAF-203361.A6
203361
|
-
|
|
|
|
33 - ECCENTRIC ARBOR
MAF-203364.A7
203364
|
-
|
|
|
|
34 - FLANGE, REAR
MAF-200038.A2
200038
|
-
|
|
|
|
35 - SAW SHAFT
MAF-202863.A0
202863
|
-
|
|
|
|
36 - CYLINDRICAL PIN
MAF-058203.A3
058203
|
-
|
|
|
|
37 - CLAMPING PIECE
MAF-202926.A4
202926
|
£24.21
|
£29.05
|
|
|
38 - HEXAGON-HEAD SCREW
MAF-202923.A0
202923
|
-
|
|
|
|
40 - GUIDE BOLT
MAF-203356.A3
203356
|
-
|
|
|
|
41 - SLIDING BLOCK
MAF-039436.A2
039436
|
-
|
|
|
|
42 - SLIDING BLOCK
MAF-202911.A2
202911
|
-
|
|
|
|
43 - COVERING PLATE
MAF-203366.A7
203366
|
-
|
|
|
|
44 - RIVING KNIFE/SPLITTER
MAF-202580.A11
202580
|
£10.26
|
£12.31
|
|
|
45 - FLANGE, FRONT
MAF-200037.A2
200037
|
-
|
|
|
|
46 - SUPPORTING LEVER
MAF-202859.A3
202859
|
-
|
|
|
|
47 - RIVING KNIFE/SPLITTER SUPPORT
MAF-202862.A3
202862
|
-
|
|
|
|
48 - CLICK LEVER
MAF-202913.A7
202913
|
-
|
|
|
|
49 - BOUNDARY DISK
MAF-202919.A8
202919
|
-
|
|
|
|
50 - ADJUSTABLE SHEET METAL
MAF-202937.A7
202937
|
-
|
|
|
|
51 - SMALL PLATE
MAF-203546.A0
203546
|
-
|
|
|
|
52 - PLUNGE LEVER
MAF-203362.A5
203362
|
-
|
|
|
|
53 - CHIP GUARD
MAF-203365.A0
203365
|
-
|
|
|
|
54 - SHEET METAL FIXING PLATE
MAF-203549.A3
203549
|
-
|
|
|
|
55 - SPACER PLATE
MAF-202932.A0
202932
|
-
|
|
|
|
57 - FLAT-HEAD SCREW
MAF-005380.A2
005380
|
-
|
|
|
|
58 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055111.A14
055111
|
-
|
|
|
|
59 - FLAT-HEAD SCREW
MAF-005367.A3
005367
|
-
|
|
|
|
60 - FLAT-HEAD SCREW
MAF-053016.A7
053016
|
-
|
|
|
|
61 - LOCKING SCREW WITH WASHER
MAF-055155.A18
055155
|
-
|
|
|
|
62 - CYLINDER-HEAD SCREW
MAF-005516.A5
005516
|
-
|
|
|
|
63 - CYLINDER-HEAD SCREW
MAF-005536.A29
005536
|
-
|
|
|
|
64 - CYLINDER-HEAD SCREW
MAF-055096.A17
055096
|
£2.11
|
£2.53
|
|
|
65 - CYLINDER-HEAD SCREW
MAF-055234.A19
055234
|
£1.19
|
£1.43
|
|
|
66 - SHOULDER SCREW
MAF-055186.A8
055186
|
-
|
|
|
|
67 - SHOULDER SCREW
MAF-055118.A23
055118
|
£2.41
|
£2.89
|
|
|
68 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A86
055061
|
£1.71
|
£2.05
|
|
|
69 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055194.A6
055194
|
-
|
|
|
|
70 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055233.A46
055233
|
£1.71
|
£2.05
|
|
|
71 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055058.A25
055058
|
-
|
|
|
|
72 - OVAL-HEAD SCREW
MAF-055093.A9
055093
|
-
|
|
|
|
73 - SELF-TAPPING SCREW
MAF-055230.A23
055230
|
-
|
|
|
|
74 - SELF-TAPPING SCREW
MAF-055232.A17
055232
|
£1.68
|
£2.02
|
|
|
76 - CYLINDER-HEAD SCREW
MAF-055242.A2
055242
|
-
|
|
|
|
77 - CYLINDER-HEAD SCREW
MAF-055228.A5
055228
|
-
|
|
|
|
78 - HEXAGONAL NUT
MAF-005900.A10
005900
|
-
|
|
|
|
79 - HEXAGONAL NUT
MAF-005913.A8
005913
|
-
|
|
|
|
80 - HEXAGONAL NUT
MAF-005915.A27
005915
|
-
|
|
|
|
81 - HEXAGONAL NUT
MAF-005939.A23
005939
|
-
|
|
|
|
82 - SQUARE NUT
MAF-005953.A46
005953
|
-
|
|
|
|
84 - WASHER
MAF-061015.A42
061015
|
-
|
|
|
|
85 - WASHER
MAF-006100.A33
006100
|
£2.01
|
£2.41
|
|
|
86 - WASHER
MAF-006101.A70
006101
|
£1.54
|
£1.85
|
|
|
87 - SHIM RING
MAF-006157.A6
006157
|
-
|
|
|
|
88 - WASHER
MAF-061013.A52
061013
|
-
|
|
|
|
89 - WASHER
MAF-061044.A35
061044
|
£1.65
|
£1.98
|
|
|
90 - LOCKING WASHER
MAF-061005.A6
061005
|
-
|
|
|
|
91 - LOCKING WASHER
MAF-061069.A32
061069
|
£1.49
|
£1.79
|
|
|
92 - RETAINING RING
MAF-006173.A13
006173
|
-
|
|
|
|
93 - RETAINING RING
MAF-061138.A11
061138
|
£2.29
|
£2.75
|
|
|
94 - RETAINING RING
MAF-007159.A7
007159
|
-
|
|
|
|
95 - GROOVED BALL BEARING
MAF-006282.A39
006282
|
£14.68
|
£17.62
|
|
|
96 - GROOVED BALL BEARING
MAF-006288.A23
006288
|
£8.82
|
£10.58
|
|
|
97 - GROOVED BALL BEARING
MAF-062065.A10
062065
|
£34.87
|
£41.84
|
|
|
98 - BRUSH HOLDER
MAF-063160.A13
063160
|
£10.07
|
£12.08
|
|
|
99 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063164.A22
063164
|
£12.41
|
£14.89
|
|
|
100 - CABLE CLAMP
MAF-029584.A57
029584
|
-
|
|
|
|
101 - SPRING DOWEL SLEEVE
MAF-005817.A7
005817
|
-
|
|
|
|
102 - GAS SPRING
MAF-006666.A0
006666
|
£33.91
|
£40.69
|
|
|
103 - PRESSURE SPRING
MAF-006657.A8
006657
|
-
|
|
|
|
104 - BOW SPRING
MAF-006668.A
006668
|
-
|
|
|
|
105 - CLIP CONNECTOR
MAF-006172.A20
006172
|
-
|
|
|
|
106 - RETRACTING SPRING
MAF-066054.A8
066054
|
-
|
|
|
|
107 - RETRACTING SPRING
MAF-066090.A20
066090
|
-
|
|
|
|
108 - LEG SPRING
MAF-066147.A0
066147
|
-
|
|
|
|
109 - KNURLED KNOB
MAF-071010.A
071010
|
-
|
|
|
|
111 - CABLE BINDER
MAF-076492.A10
076492
|
-
|
|
|
|
112 - INTERFERENCE SUPPRESSION CAPACITOR
MAF-076187.A17
076187
|
-
|
|
|
|
113 - STICKER
MAF-078415.A8
078415
|
-
|
|
|
|
114 - STICKER
MAF-078416.A4
078416
|
-
|
|
|
|
115 - HEXAGONAL PROTECTIVE CAP
MAF-077009.A18
077009
|
-
|
|
|
|
116 - WING NUT
MAF-007996.A4
007996
|
-
|
|
|
|
117 - CONNECTING CABLE
MAF-085151.A
085151
|
-
|
|
|
|
120 - CABLE PROTECTING SLEEVE
MAF-086064.A83
086064
|
£3.37
|
£4.04
|
|
|
123 - FEDERSCHEIBE
MAF-061132.A8
061132
|
-
|
|
|
|
124 - SEALING RING
MAF-006581.A3
006581
|
-
|
|
|
|
125 - CONNECTING CABLE
MAF-203368.A
203368
|
-
|
|
|
|
126 - CLAMPING STRIP
MAF-087626.A10
087626
|
-
|
|
|
|
127 - MAINS CABLE 4 M (13.1 FT)
MAF-087594.A0
087594
|
-
|
|
|
|
128 - MOTOR WITH SPUR GEAR
MAF-087918.A1
087918
|
£362.62
|
£435.14
|
|
|
130 - ENERGY CHAIN
MAF-087696.A
087696
|
-
|
|
|
|
132 - SNAP-ACTION SWITCH
MAF-087819.A8
087819
|
-
|
|
|
|
134 - BOW HANDLE
MAF-200650.A3
200650
|
-
|
|
|
|
135 - BOW HANDLE
MAF-201142.A5
201142
|
-
|
|
|
|
136 - SPACER RING
MAF-201159.A2
201159
|
-
|
|
|
|
137 - PRESSURE BIT
MAF-202378.A19
202378
|
-
|
|
|
|
138 - TOOTHED WASHER
MAF-202917.A8
202917
|
-
|
|
|
|
139 - ROLLED SPRING
MAF-202920.A1
202920
|
-
|
|
|
|
140 - ROLLED SPRING
MAF-202925.A1
202925
|
-
|
|
|
|
141 - CONNECTING CABLE
MAF-202921.A
202921
|
-
|
|
|
|
142 - EXTRACTION HOSE
MAF-202924.A
202924
|
-
|
|
|
|
143 - PART NAME NOT AVAILABLE
MAF-202931.A
202931
|
-
|
|
|
|
144 - TOOTHED BELT SEGMENT
MAF-202929.A3
202929
|
-
|
|
|
|
145 - 2-POLE REVERSING SWITCH
MAF-087817.A2
087817
|
-
|
|
|
|
146 - MAINS ADAPTER 230V
MAF-077081.A1
077081
|
£209.48
|
£251.37
|
|
|
147 - POTENTIOMETER WITH PLUG
MAF-087697.A0
087697
|
-
|
|
|
|
148 - KNOB
MAF-065047.A6
065047
|
-
|
|
|
|
149 - CONNECTION CIRCUIT BOARD
MAF-203357.A1
203357
|
-
|
|
|
|
150 - PROTECTIVE LEDGE
MAF-007605.A7
007605
|
£10.60
|
£12.72
|
|
|
151 - STOP BUFFER
MAF-201609.A9
201609
|
-
|
|
|
|
154 - CELLULAR RUBBER STRIP
MAF-204029.A13
204029
|
£40.08
|
£48.10
|
|
|
500 - ALLEN KEY
MAF-093034.A21
093034
|
-
|
|
|
|
501 - SILICONE SPRAY
MAF-007655.A
007655
|
-
|
|
|
