1 - MOTOR CASING WITH INDUCTOR 230 V
MAF-084600.A1
084600
|
-
|
|
|
|
1.1 - INDUCTOR 230 V
MAF-084615.A6
084615
|
£235.95
|
£283.14
|
|
|
1.2 - MOTOR CASING
MAF-204574.A0
204574
|
-
|
|
|
|
2 - ARMATURE, BALANCED
MAF-088191.A1
088191
|
-
|
|
|
|
4 - WING SCREW
MAF-079070.A24
079070
|
-
|
|
|
|
5 - BRAKE LEVER, CPL.
MAF-201122.A31
201122
|
-
|
|
|
|
6 - GUIDE RAIL 3/8 400 FOR 006971, 006974
MAF-204583.A
204583
|
-
|
|
|
|
7 - SAW CHAIN 3/8 400 LX
MAF-006971.A1
006971
|
-
|
|
|
|
8 - CONTROL MODULE
MAF-077147.A9
077147
|
£113.31
|
£135.97
|
|
|
9 - ARBOR, CPL.
MAF-201145.A5
201145
|
-
|
|
|
|
10 - TENSIONING SCREW, CPL.
MAF-201146.A5
201146
|
£33.98
|
£40.78
|
|
|
12 - BASE PLATE
MAF-201101.A0
201101
|
-
|
|
|
|
13 - GEAR CASING
MAF-204185.A2
204185
|
-
|
|
|
|
14 - PART NAME NOT AVAILABLE
MAF-204186.A3
204186
|
-
|
|
|
|
15 - TILTING PLATE
MAF-201107.A7
201107
|
-
|
|
|
|
16 - INTERMEDIATE COVER
MAF-204462.A1
204462
|
-
|
|
|
|
17 - BEARING COVER
MAF-201111.A6
201111
|
-
|
|
|
|
18 - SEGMENT FOR TILTING, FRONT
MAF-204189.A3
204189
|
-
|
|
|
|
19 - PART NAME NOT AVAILABLE
MAF-204217.A13
204217
|
-
|
|
|
|
20 - SWITCH LEVER
MAF-204216.A17
204216
|
-
|
|
|
|
21 - COVER
MAF-201115.A3
201115
|
-
|
|
|
|
22 - OIL TANK
MAF-201116.A9
201116
|
£32.84
|
£39.41
|
|
|
23 - AIR CONDUCTING RING
MAF-201136.A0
201136
|
-
|
|
|
|
24 - FAN, UPPER
MAF-032355.A21
032355
|
£12.50
|
£15.00
|
|
|
25 - SLIDING BAR
MAF-204184.A5
204184
|
-
|
|
|
|
26 - CLAMP
MAF-201130.A5
201130
|
-
|
|
|
|
27 - MOTOR COVER
MAF-203862.A6
203862
|
-
|
|
|
|
28 - LOCKING LEVER
MAF-201745.A42
201745
|
£6.02
|
£7.22
|
|
|
29 - PART NAME NOT AVAILABLE
MAF-204576.A2
204576
|
-
|
|
|
|
30 - COVER
MAF-201128.A6
201128
|
-
|
|
|
|
31 - PART NAME NOT AVAILABLE
MAF-204595.A2
204595
|
£20.52
|
£24.62
|
|
|
32 - GUARD FLAP
MAF-201140.A1
201140
|
-
|
|
|
|
33 - GUARD FLAP
MAF-201141.A0
201141
|
-
|
|
|
|
34 - COVERING RING
MAF-201151.A4
201151
|
-
|
|
|
|
36 - GUARD PLATE
MAF-201156.A4
201156
|
-
|
|
|
|
37 - SHEET METAL COVER
MAF-201740.A6
201740
|
-
|
|
|
|
39 - RIVING KNIFE 400 FOR 006972, 006971, 006974
MAF-204587.A1
204587
|
-
|
|
|
|
40 - SPLINTER GUARD
MAF-204190.A0
204190
|
-
|
|
|
|
41 - HANDLE
MAF-204181.A0
204181
|
-
|
|
|
|
42 - INDICATOR PLATE
MAF-204182.A4
204182
|
-
|
|
|
|
43 - SETTING WHEEL
MAF-203729.A39
203729
|
-
|
|
|
|
44 - HANDLE INSERT
MAF-203860.A8
203860
|
-
|
|
|
|
45 - CLAMPING NUT
MAF-201127.A1
201127
|
£18.31
|
£21.97
|
|
|
46 - GEAR SHAFT
MAF-201135.A1
201135
|
-
|
|
|
|
47 - BRAKE DRUM
MAF-201138.A11
201138
|
-
|
|
|
|
48 - SPROCKET 3/8 FOR 006971, 006974
MAF-204585.A
204585
|
-
|
|
|
|
49 - SPACER SLEEVE
MAF-201137.A0
201137
|
-
|
|
|
|
50 - HEXAGONAL NUT
MAF-201147.A20
201147
|
£7.42
|
£8.91
|
|
|
52 - LOCKING BOLT
MAF-204183.A0
204183
|
-
|
|
|
|
53 - PART NAME NOT AVAILABLE
MAF-204187.A0
204187
|
-
|
|
|
|
54 - SPACER SLEEVE
MAF-204188.A4
204188
|
-
|
|
|
|
55 - CYLINDER-HEAD SCREW
MAF-201743.A2
201743
|
-
|
|
|
|
56 - BEVEL WHEEL
MAF-201123.A0
201123
|
-
|
|
|
|
57 - PINION
MAF-201118.A2
201118
|
-
|
|
|
|
58 - OIL TANK CAP
MAF-201153.A9
201153
|
-
|
|
|
|
59 - OIL TUBE
MAF-201131.A7
201131
|
-
|
|
|
|
62 - BOWDEN CABLE, CPL.
MAF-201748.A2
201748
|
-
|
|
|
|
63 - OIL PUMP, CPL.
MAF-201144.A10
201144
|
£141.90
|
£170.28
|
|
|
66 - BOW HANDLE
MAF-201142.A15
201142
|
-
|
|
|
|
67 - THREADED PIN
MAF-005276.A18
005276
|
£1.81
|
£2.17
|
|
|
69 - FLAT-HEAD SCREW
MAF-053029.A33
053029
|
£2.84
|
£3.41
|
|
|
70 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A80
053020
|
£2.01
|
£2.41
|
|
|
71 - SELF-TAPPING SCREW
MAF-055232.A56
055232
|
£1.68
|
£2.02
|
|
|
73 - CYLINDER-HEAD SCREW
MAF-055038.A6
055038
|
£2.64
|
£3.17
|
|
|
74 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055062.A75
055062
|
-
|
|
|
|
75 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A223
055061
|
£1.71
|
£2.05
|
|
|
76 - CYLINDER-HEAD SCREW
MAF-055172.A13
055172
|
-
|
|
|
|
77 - CYLINDER-HEAD SCREW
MAF-055074.A25
055074
|
£2.12
|
£2.55
|
|
|
78 - OVAL-HEAD SCREW
MAF-055257.A24
055257
|
-
|
|
|
|
79 - CYLINDER-HEAD SCREW
MAF-005591.A1
005591
|
-
|
|
|
|
80 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055091.A26
055091
|
-
|
|
|
|
81 - OVAL-HEAD SCREW
MAF-055101.A32
055101
|
£2.04
|
£2.45
|
|
|
84 - OVAL-HEAD SCREW
MAF-055143.A32
055143
|
-
|
|
|
|
85 - SHOULDER SCREW
MAF-055118.A60
055118
|
£2.41
|
£2.89
|
|
|
88 - SET SCREW
MAF-057041.A2
057041
|
-
|
|
|
|
89 - PRESSURE SPRING
MAF-066082.A7
066082
|
-
|
|
|
|
90 - CUP SPRING
MAF-066016.A23
066016
|
-
|
|
|
|
91 - RIBBED NAIL
MAF-058068.A16
058068
|
-
|
|
|
|
92 - CYLINDRICAL PIN
MAF-058184.A2
058184
|
-
|
|
|
|
93 - LOCKING NUT
MAF-005999.A32
005999
|
-
|
|
|
|
94 - WASHER
MAF-061015.A55
061015
|
-
|
|
|
|
95 - HEXAGONAL NUT
MAF-059008.A5
059008
|
-
|
|
|
|
96 - LOCKING NUT
MAF-005970.A28
005970
|
-
|
|
|
|
97 - HEXAGONAL NUT
MAF-005920.A46
005920
|
-
|
|
|
|
98 - HEXAGONAL NUT
MAF-005978.A14
005978
|
-
|
|
|
|
99 - CASTEL NUT
MAF-059010.A7
059010
|
-
|
|
|
|
100 - SHIM RING
MAF-061110.A9
061110
|
-
|
|
|
|
101 - WASHER
MAF-061038.A25
061038
|
-
|
|
|
|
102 - WASHER
MAF-006102.A93
006102
|
-
|
|
|
|
103 - WASHER
MAF-006101.A97
006101
|
£1.54
|
£1.85
|
|
|
104 - LOCKING WASHER
MAF-006114.A43
006114
|
-
|
|
|
|
106 - LOCKING WASHER
MAF-007113.A8
007113
|
-
|
|
|
|
107 - SHIM RING
MAF-061154.A2
061154
|
-
|
|
|
|
108 - SHIM RING
MAF-061155.A5
061155
|
-
|
|
|
|
109 - FEDERSCHEIBE
MAF-061156.A4
061156
|
-
|
|
|
|
110 - FEDERSCHEIBE
MAF-061157.A5
061157
|
-
|
|
|
|
111 - WASHER
MAF-061013.A96
061013
|
-
|
|
|
|
112 - RETAINING RING
MAF-006195.A8
006195
|
-
|
|
|
|
113 - RETAINING RING
MAF-007161.A20
007161
|
-
|
|
|
|
114 - GROOVED BALL BEARING
MAF-006231.A25
006231
|
£13.65
|
£16.38
|
|
|
115 - GROOVED BALL BEARING
MAF-006260.A47
006260
|
£18.15
|
£21.78
|
|
|
116 - GROOVED BALL BEARING
MAF-006269.A19
006269
|
-
|
|
|
|
117 - GROOVED BALL BEARING
MAF-062073.A59
062073
|
£14.28
|
£17.14
|
|
|
119 - SEALING RING
MAF-065004.A67
065004
|
£1.63
|
£1.96
|
|
|
120 - SEALING RING
MAF-006591.A31
006591
|
£1.65
|
£1.98
|
|
|
121 - CUP SPRING
MAF-006675.A6
006675
|
£2.41
|
£2.89
|
|
|
122 - BRUSH HOLDER
MAF-063157.A21
063157
|
-
|
|
|
|
123 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063180.A17
063180
|
£15.22
|
£18.26
|
|
|
125 - WING NUT
MAF-065023.A18
065023
|
-
|
|
|
|
126 - PAD
MAF-201872.A69
201872
|
-
|
|
|
|
127 - CABLE CLAMP
MAF-029584.A151
029584
|
-
|
|
|
|
129 - CLAMP
MAF-076499.A2
076499
|
-
|
|
|
|
130 - CABLE PROTECTING SLEEVE
MAF-086065.A79
086065
|
£3.46
|
£4.15
|
|
|
131 - SEALING RING
MAF-065033.A5
065033
|
-
|
|
|
|
132 - PLUG
MAF-076498.A4
076498
|
-
|
|
|
|
133 - RETRACTING SPRING
MAF-066112.A16
066112
|
£5.52
|
£6.63
|
|
|
134 - TORSION SPRING, LEFT
MAF-066114.A6
066114
|
-
|
|
|
|
135 - TORSION SPRING, RIGHT
MAF-066115.A5
066115
|
-
|
|
|
|
136 - PRESSURE SPRING
MAF-066043.A183
066043
|
£3.04
|
£3.65
|
|
|
138 - ANGLE SCALE
MAF-077622.A1
077622
|
-
|
|
|
|
140 - CONNECTING CABLE
MAF-085176.A17
085176
|
£6.70
|
£8.04
|
|
|
141 - 2-POLE SWITCH
MAF-087599.A16
087599
|
£50.76
|
£60.91
|
|
|
142 - MAINS CABLE 10 M (32.8 FT.)
MAF-087612.A45
087612
|
£72.48
|
£86.98
|
|
|
143 - CONNECTING CABLE
MAF-087808.A5
087808
|
-
|
|
|
|
501 - PARALLEL GUIDE FENCE
MAF-204591.A6
204591
|
£133.10
|
£159.72
|
|
|
502 - COMBINATION SCREW DRIVER
MAF-093272.A7
093272
|
-
|
|
|
