1 - MOTOR CASING WITH INDUCTOR
MAF-084546.A
084546
|
-
|
|
|
|
1.1 - INDUCTOR WITH COIL
MAF-084558.A
084558
|
-
|
|
|
|
2 - ARMATURE, BALANCED
MAF-088168.A
088168
|
-
|
|
|
|
3 - PROTECTIVE COVER
MAF-201019.A6
201019
|
£38.86
|
£46.63
|
|
|
4 - CONTROL MODULE
MAF-077019.A
077019
|
-
|
|
|
|
6 - TABLE
MAF-203254.A0
203254
|
-
|
|
|
|
6.2 - FRONT LEDGE
MAF-202662.A1
202662
|
-
|
|
|
|
6.3 - EDGE PROTECTION, RIGHT
MAF-202653.A1
202653
|
-
|
|
|
|
6.4 - EDGE PROTECTION, LEFT
MAF-202652.A0
202652
|
-
|
|
|
|
6.5 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055157.A6
055157
|
-
|
|
|
|
6.6 - SKALE
MAF-202687.A0
202687
|
-
|
|
|
|
7 - CLICK-IN BRACKET
MAF-039803.A2
039803
|
-
|
|
|
|
8 - TUBULAR FRAME, FRONT
MAF-202655.A1
202655
|
-
|
|
|
|
8.2 - SUPPORTING LEG
MAF-203572.A0
203572
|
-
|
|
|
|
9 - TUBULAR FRAME, REAR
MAF-202656.A1
202656
|
-
|
|
|
|
9.1 - RETRACTING SPRING
MAF-066137.A0
066137
|
-
|
|
|
|
12 - FRONT PLATE
MAF-202644.A1
202644
|
-
|
|
|
|
13 - REAR PLATE
MAF-202645.A1
202645
|
-
|
|
|
|
14 - GEAR CASING
MAF-203258.A0
203258
|
-
|
|
|
|
15 - HEIGHT ADJUSTMENT CASING
MAF-202612.A1
202612
|
-
|
|
|
|
16 - BEARING COVER
MAF-202609.A1
202609
|
-
|
|
|
|
17 - BELT DISK
MAF-202614.A0
202614
|
-
|
|
|
|
18 - BELT DISK
MAF-202616.A1
202616
|
-
|
|
|
|
19 - GUTTER
MAF-203262.A0
203262
|
-
|
|
|
|
20 - TILTING ROD
MAF-203251.A0
203251
|
-
|
|
|
|
21 - SLIDING COVER
MAF-203265.A0
203265
|
-
|
|
|
|
22 - SLIDING COVER
MAF-203264.A0
203264
|
-
|
|
|
|
23 - PROTECTIVE COVER
MAF-203267.A0
203267
|
£66.00
|
£79.20
|
|
|
24 - SAW GUARD COVER
MAF-203266.A0
203266
|
£69.76
|
£83.71
|
|
|
25 - NUT
MAF-202625.A1
202625
|
-
|
|
|
|
26 - GEAR CASING COVER
MAF-202634.A1
202634
|
-
|
|
|
|
27 - TOOTHED SEGMENT
MAF-202637.A1
202637
|
-
|
|
|
|
28 - WORM GEAR
MAF-202639.A1
202639
|
-
|
|
|
|
29 - ROUE DENTÉE
MAF-202647.A0
202647
|
-
|
|
|
|
30 - SLIDING BAR
MAF-202648.A0
202648
|
-
|
|
|
|
31 - RUBBER FOOT
MAF-202654.A1
202654
|
-
|
|
|
|
32 - INDICATOR
MAF-202658.A0
202658
|
-
|
|
|
|
33 - COVERING FRAME
MAF-202665.A1
202665
|
-
|
|
|
|
34 - SKIMMER
MAF-202666.A0
202666
|
-
|
|
|
|
35 - AIR CONDUCTING RING
MAF-202667.A1
202667
|
-
|
|
|
|
36 - CLAMPING LEVER
MAF-202671.A0
202671
|
-
|
|
|
|
37 - HANDLE
MAF-202672.A0
202672
|
-
|
|
|
|
38 - KNOB
MAF-202675.A1
202675
|
-
|
|
|
|
39 - HOSE CONNECTOR
MAF-202678.A1
202678
|
-
|
|
|
|
40 - PANEL
MAF-202679.A1
202679
|
-
|
|
|
|
41 - MOTOR COVER
MAF-202689.A0
202689
|
-
|
|
|
|
42 - CLICK-IN BUTTON
MAF-202691.A1
202691
|
-
|
|
|
|
43 - PLUG-IN UNIT
MAF-202693.A1
202693
|
-
|
|
|
|
44 - COVER
MAF-202694.A1
202694
|
-
|
|
|
|
45 - HANDWHEEL
MAF-202699.A0
202699
|
-
|
|
|
|
46 - CONICAL HANDLE
MAF-202674.A1
202674
|
-
|
|
|
|
47 - CAP
MAF-202676.A1
202676
|
-
|
|
|
|
48 - SETTING WHEEL
MAF-039183.A0
039183
|
-
|
|
|
|
49 - FAN
MAF-202695.A0
202695
|
-
|
|
|
|
50 - PAD
MAF-201872.A9
201872
|
-
|
|
|
|
51 - SHOCK ABSORBER
MAF-203274.A0
203274
|
-
|
|
|
|
55 - PUSH-BUTTON
MAF-039780.A2
039780
|
-
|
|
|
|
56 - FLANGE, FRONT
MAF-202620.A1
202620
|
-
|
|
|
|
57 - RIVING KNIFE/SPLITTER SUPPORT
MAF-203259.A0
203259
|
-
|
|
|
|
58 - CLAMPING METAL SHEET
MAF-203261.A0
203261
|
-
|
|
|
|
59 - RIVING KNIFE/SPLITTER
MAF-203260.A0
203260
|
-
|
|
|
|
60 - STRUT
MAF-202624.A0
202624
|
-
|
|
|
|
61 - ECCENTRIC DISK
MAF-202608.A0
202608
|
-
|
|
|
|
62 - CRADLE
MAF-203271.A0
203271
|
-
|
|
|
|
64 - CLICK-IN METAL SHEET
MAF-202659.A0
202659
|
-
|
|
|
|
65 - METAL SHEET STOP
MAF-202661.A1
202661
|
-
|
|
|
|
69 - CLAMPING SLEEVE
MAF-202605.A0
202605
|
-
|
|
|
|
70 - LOCKING BOLT
MAF-203268.A0
203268
|
-
|
|
|
|
71 - SAW SHAFT
MAF-202618.A1
202618
|
-
|
|
|
|
72 - FLANGE, REAR
MAF-202619.A1
202619
|
-
|
|
|
|
73 - GEAR SHAFT
MAF-202629.A1
202629
|
-
|
|
|
|
74 - PULL ROD
MAF-203252.A0
203252
|
-
|
|
|
|
75 - SETTING ARBOR
MAF-202668.A0
202668
|
-
|
|
|
|
76 - BEARING BOLT
MAF-202669.A1
202669
|
-
|
|
|
|
77 - ECCENTRIC BOLT
MAF-202670.A0
202670
|
-
|
|
|
|
78 - GUIDE PIECE
MAF-201049.A1
201049
|
£8.38
|
£10.05
|
|
|
80 - SPACER BUSHING
MAF-039800.A5
039800
|
-
|
|
|
|
82 - FIXTURE
MAF-203280.A0
203280
|
-
|
|
|
|
83 - TUBULAR RIVET
MAF-058196.A0
058196
|
-
|
|
|
|
84 - NUT
MAF-202640.A0
202640
|
-
|
|
|
|
87 - SLIDING BAR
MAF-203797.A0
203797
|
-
|
|
|
|
89 - GROOVED BALL BEARING
MAF-006231.A0
006231
|
£13.65
|
£16.38
|
|
|
90 - GROOVED BALL BEARING
MAF-006269.A3
006269
|
-
|
|
|
|
91 - GROOVED BALL BEARING
MAF-006280.A10
006280
|
£13.65
|
£16.38
|
|
|
92 - GROOVED BALL BEARING
MAF-062082.A3
062082
|
£17.88
|
£21.45
|
|
|
93 - GROOVED BALL BEARING
MAF-062073.A20
062073
|
£14.28
|
£17.14
|
|
|
94 - GROOVED BALL BEARING
MAF-062010.A1
062010
|
£14.52
|
£17.42
|
|
|
95 - GROOVED BALL BEARING
MAF-006260.A9
006260
|
£18.15
|
£21.78
|
|
|
97 - SPRING DOWEL SLEEVE
MAF-058116.A3
058116
|
-
|
|
|
|
98 - THREADED PIN
MAF-005284.A23
005284
|
-
|
|
|
|
99 - CYLINDRICAL PIN
MAF-058198.A0
058198
|
-
|
|
|
|
101 - HEXAGONAL NUT
MAF-005978.A3
005978
|
-
|
|
|
|
103 - HEXAGONAL NUT
MAF-005915.A12
005915
|
-
|
|
|
|
104 - HEXAGONAL NUT
MAF-005966.A0
005966
|
-
|
|
|
|
105 - HEXAGONAL NUT
MAF-059008.A0
059008
|
-
|
|
|
|
106 - SQUARE NUT
MAF-005972.A6
005972
|
£1.93
|
£2.32
|
|
|
107 - LOCKING NUT
MAF-005982.A6
005982
|
£1.76
|
£2.11
|
|
|
108 - LOCKING NUT
MAF-005999.A4
005999
|
-
|
|
|
|
110 - HEXAGON-HEAD SCREW
MAF-005680.A1
005680
|
-
|
|
|
|
111 - CYLINDER-HEAD SCREW
MAF-055172.A1
055172
|
-
|
|
|
|
112 - CYLINDER-HEAD SCREW
MAF-055241.A1
055241
|
-
|
|
|
|
113 - CYLINDER-HEAD SCREW
MAF-055013.A11
055013
|
-
|
|
|
|
114 - CYLINDER-HEAD SCREW
MAF-055059.A4
055059
|
-
|
|
|
|
115 - CYLINDER-HEAD SCREW
MAF-005578.A0
005578
|
-
|
|
|
|
116 - HEXAGON-HEAD SCREW
MAF-005671.A3
005671
|
-
|
|
|
|
117 - CYLINDER-HEAD SCREW
MAF-055138.A0
055138
|
-
|
|
|
|
118 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055187.A25
055187
|
£1.92
|
£2.30
|
|
|
119 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055079.A7
055079
|
£1.32
|
£1.58
|
|
|
120 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055162.A16
055162
|
-
|
|
|
|
121 - CYLINDER-HEAD SCREW
MAF-055108.A1
055108
|
£1.28
|
£1.54
|
|
|
122 - SELF-TAPPING SCREW
MAF-055230.A13
055230
|
-
|
|
|
|
123 - CYLINDER-HEAD SCREW
MAF-055174.A0
055174
|
-
|
|
|
|
124 - FLAT-HEAD SCREW
MAF-055223.A1
055223
|
-
|
|
|
|
125 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055157.A1
055157
|
-
|
|
|
|
126 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055124.A8
055124
|
-
|
|
|
|
127 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055139.A2
055139
|
-
|
|
|
|
128 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A10
055061
|
£1.71
|
£2.05
|
|
|
130 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055233.A4
055233
|
£1.71
|
£2.05
|
|
|
131 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A11
053020
|
£2.01
|
£2.41
|
|
|
132 - OVAL-HEAD SCREW
MAF-055115.A0
055115
|
-
|
|
|
|
133 - SEALING RING
MAF-065043.A0
065043
|
-
|
|
|
|
134 - SEALING RING
MAF-065015.A8
065015
|
£3.01
|
£3.61
|
|
|
137 - CUP SPRING
MAF-006662.A0
006662
|
-
|
|
|
|
138 - RETRACTING SPRING
MAF-066136.A1
066136
|
-
|
|
|
|
139 - PRESSURE SPRING
MAF-066096.A8
066096
|
£4.25
|
£5.10
|
|
|
140 - PRESSURE SPRING
MAF-066084.A0
066084
|
-
|
|
|
|
141 - RETRACTING SPRING
MAF-066092.A1
066092
|
-
|
|
|
|
142 - RETRACTING SPRING
MAF-066145.A0
066145
|
-
|
|
|
|
143 - PRESSURE SPRING
MAF-066043.A2
066043
|
£3.04
|
£3.65
|
|
|
144 - SHIM RING
MAF-061170.A1
061170
|
-
|
|
|
|
145 - SHIM RING
MAF-061067.A1
061067
|
-
|
|
|
|
146 - SHIM RING
MAF-061050.A1
061050
|
£1.92
|
£2.31
|
|
|
147 - RETAINING RING
MAF-071001.A0
071001
|
-
|
|
|
|
148 - RETAINING RING
MAF-061171.A1
061171
|
-
|
|
|
|
149 - RETAINING RING
MAF-061068.A0
061068
|
-
|
|
|
|
150 - RETAINING RING
MAF-061123.A1
061123
|
-
|
|
|
|
151 - RETAINING RING
MAF-006194.A1
006194
|
-
|
|
|
|
152 - RETAINING RING
MAF-007102.A3
007102
|
£2.59
|
£3.11
|
|
|
153 - RETAINING RING
MAF-007141.A1
007141
|
£3.56
|
£4.27
|
|
|
154 - RETAINING RING
MAF-007161.A1
007161
|
-
|
|
|
|
155 - LOCKING WASHER
MAF-061106.A1
061106
|
£2.28
|
£2.74
|
|
|
156 - LOCKING WASHER
MAF-061135.A1
061135
|
-
|
|
|
|
157 - LOCKING WASHER
MAF-006114.A16
006114
|
-
|
|
|
|
158 - WASHER
MAF-061038.A4
061038
|
-
|
|
|
|
159 - WASHER
MAF-006101.A20
006101
|
£1.54
|
£1.85
|
|
|
160 - WASHER
MAF-061172.A0
061172
|
-
|
|
|
|
161 - LOCKING WASHER
MAF-006184.A15
006184
|
£1.50
|
£1.80
|
|
|
162 - WASHER
MAF-061044.A10
061044
|
£1.65
|
£1.98
|
|
|
163 - WASHER
MAF-061013.A2
061013
|
-
|
|
|
|
164 - LOCKING WASHER
MAF-061069.A0
061069
|
£1.49
|
£1.79
|
|
|
166 - ARBOR CLAMPING CAP
MAF-061059.A1
061059
|
-
|
|
|
|
167 - COMPENSATING DISK
MAF-061173.A1
061173
|
-
|
|
|
|
168 - SUPPORTING DISK
MAF-061174.A0
061174
|
-
|
|
|
|
169 - SWITCH
MAF-087847.A0
087847
|
-
|
|
|
|
171 - BRUSH HOLDER
MAF-063148.A5
063148
|
£10.30
|
£12.36
|
|
|
172 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063147.A13
063147
|
£14.72
|
£17.67
|
|
|
175 - SHIM RING
MAF-061176.A1
061176
|
-
|
|
|
|
176 - SHIM RING
MAF-061175.A1
061175
|
-
|
|
|
|
177 - ROLLED SPRING
MAF-202606.A0
202606
|
£12.26
|
£14.71
|
|
|
178 - BEVEL WHEEL
MAF-202630.A1
202630
|
£117.08
|
£140.50
|
|
|
179 - PINION
MAF-202631.A1
202631
|
£51.36
|
£61.63
|
|
|
180 - ANGLE SCALE
MAF-202680.A2
202680
|
-
|
|
|
|
183 - TOOTHED BELT
MAF-077002.A1
077002
|
-
|
|
|
|
184 - TCT SAW BLADE
MAF-092465.A0
092465
|
-
|
|
|
|
187 - ELASTIC BUFFER
MAF-076322.A3
076322
|
-
|
|
|
|
188 - PRESSURE BIT, SPRING-LOADED
MAF-052009.A0
052009
|
-
|
|
|
|
189 - STICKER
MAF-203276.A0
203276
|
-
|
|
|
|
190 - STICKER
MAF-203256.A0
203256
|
-
|
|
|
|
192 - ANGLE
MAF-202673.A1
202673
|
-
|
|
|
|
193 - WING SCREW
MAF-079062.A9
079062
|
£6.43
|
£7.72
|
|
|
194 - ROUND CAP
MAF-076430.A0
076430
|
£4.25
|
£5.10
|
|
|
501 - UNIVERSAL GUIDE FENCE
MAF-201611.A6
201611
|
£217.05
|
£260.46
|
|
|
501.1 - STOP PLATE
MAF-202884.A0
202884
|
-
|
|
|
|
501.2 - GUIDE BAR
MAF-038259.A5
038259
|
-
|
|
|
|
501.3 - INDEX PLATE
MAF-038262.A1
038262
|
-
|
|
|
|
501.4 - CLAMPING FENCE SUPPORT, CPL.
MAF-203277.A6
203277
|
-
|
|
|
|
501.5 - SLIDING COVER
MAF-038266.A0
038266
|
-
|
|
|
|
501.6 - WING SCREW
MAF-079062.A3
079062
|
£6.43
|
£7.72
|
|
|
501.7 - SHOULDER SCREW
MAF-200948.A5
200948
|
-
|
|
|
|
501.8 - GUIDE BOLT
MAF-038261.A5
038261
|
-
|
|
|
|
501.9 - GUIDE FENCE EXTENSION
MAF-200878.A0
200878
|
-
|
|
|
|
501.10 - ECCENTRIC ARBOR
MAF-200946.A3
200946
|
-
|
|
|
|
501.11 - PRESSURE SPRING
MAF-066051.A3
066051
|
-
|
|
|
|
501.12 - INDEX PIN
MAF-038264.A6
038264
|
-
|
|
|
|
501.13 - WASHER
MAF-006101.A14
006101
|
£1.54
|
£1.85
|
|
|
501.14 - MUSHROOM-SHAPED COVERING PIECE
MAF-038260.A7
038260
|
-
|
|
|
|
501.15 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055162.A5
055162
|
-
|
|
|
|
501.16 - SQUARE NUT
MAF-005953.A14
005953
|
-
|
|
|
|
501.17 - ARBOR CLAMPING RING
MAF-061075.A4
061075
|
-
|
|
|
|
501.18 - CUP SPRING
MAF-006692.A11
006692
|
-
|
|
|
|
501.19 - ANGLE SCALE
MAF-077533.A0
077533
|
-
|
|
|
|
501.20 - TRACTION ELEMENT
MAF-200947.A0
200947
|
-
|
|
|
|
501.21 - TENSIONING LEVER
MAF-039413.A1
039413
|
-
|
|
|
|
501.26 - SLIDING BLOCK
MAF-202596.A1
202596
|
-
|
|
|
|
501.27 - TORSION SPRING
MAF-066109.A4
066109
|
-
|
|
|
|
501.28 - ARBOR CLAMPING RING
MAF-061181.A1
061181
|
-
|
|
|
|
502 - PUSH STICK
MAF-034901.A4
034901
|
-
|
|
|
|
510 - EXTRACTION HOSE
MAF-093670.A1
093670
|
-
|
|
|
|
511 - BRANCH PIPE
MAF-202698.A0
202698
|
-
|
|
|
