An exploded drawing and listing for the Bosch GRL 300 HVG / 3601K61704 / EU
Ex VAT Inc VAT
1/2 - LENS MOUNT BSD-2610A13995.A1 2610A13995 £59.53 £71.44
1/3 - ROTATING BEACON BSD-2610A14947.A0 2610A14947 £37.27 £44.72
1/4 - ASSEMBLY BSD-2610A12340.A0 2610A12340 £72.18 £86.62
1/5 - BALL SLEEVE BSD-2610A15789.A1 2610A15789 £2.16 £2.59
1/6 - HEX SOCKET HEAD CAP SCREW BSD-2610A12362.A6 2610A12362 £1.75 £2.10
1/7 - HEX SOCKET HEAD CAP SCREW BSD-2610A12284.A23 2610A12284 £1.75 £2.10
1/1/1 - MOTOR HOUSING BSD-2610A12237.A2 2610A12237 £263.33 £316.00
1/1/1/14 - MOTOR-GEARBOX ASSEMBLY BSD-2610A13249.A14 2610A13249 £33.74 £40.49
1/1/1/14/7 - MOTOR PLATE BSD-2610A12302.A9 2610A12302 -
1/1/1/16 - TAPPING SCREW BSD-2610A12301.A12 2610A12301 £1.75 £2.10
1/1/1/17 - HEX SOCKET HEAD CAP SCREW BSD-2610A12275.A13 2610A12275 £1.75 £2.10
1/1/1/18 - EXTENSION SPRING BSD-2610A12283.A2 2610A12283 £1.75 £2.10
1/1/1/19 - EXTENSION SPRING BSD-2610A13065.A5 2610A13065 £1.75 £2.10
1/1/1/20 - BRAKE SPRING BSD-2610A14394.A0 2610A14394 £1.75 £2.10
1/1/3 - LIMIT SWITCH BSD-2610A13397.A1 2610A13397 £1.75 £2.10
1/1/4 - SPECIAL WASHER BSD-2610A12269.A9 2610A12269 £2.61 £3.13
1/1/5 - HEX SOCKET HEAD CAP SCREW BSD-2610A12272.A2 2610A12272 £1.75 £2.10
1/1/6 - HEX SOCKET HEAD CAP SCREW BSD-2610A12284.A25 2610A12284 £1.75 £2.10
1/1/7 - FLEXIBLE PCB BSD-2610A12359.A7 2610A12359 £3.34 £4.01
1/1/8 - TAPPING SCREW BSD-2610A12301.A19 2610A12301 £1.75 £2.10
1/1/10 - LIMIT SWITCH BSD-2610A13399.A14 2610A13399 £1.75 £2.10
1/1/802 - ASSEMBLY BSD-1600A01NM4.A0 1600A01NM4 -
2 - HOUSING BSD-2610A12342.A5 2610A12342 -
3 - HOUSING BSD-2610A12957.A1 2610A12957 £27.23 £32.68
4 - HANDLE BSD-2610A12464.A5 2610A12464 £21.68 £26.01
5 - HANDLE BSD-2610A12309.A5 2610A12309 £21.68 £26.01
6 - BATTERY BOX ASSEMBLY BSD-2610A12327.A5 2610A12327 £14.91 £17.89
7 - CAGE BSD-2610A12311.A4 2610A12311 £27.23 £32.68
8 - THREADED BOLT BSD-2610A12310.A1 2610A12310 £2.80 £3.36
9 - HEX SOCKET HEAD CAP SCREW BSD-2610A12348.A0 2610A12348 £2.16 £2.59
10 - HEX SOCKET HEAD CAP SCREW BSD-2610A12459.A5 2610A12459 £1.75 £2.10
11 - HEX SOCKET HEAD CAP SCREW BSD-2610A12460.A1 2610A12460 £1.75 £2.10
12 - NAMEPLATE BSD-2609135942.A0 2609135942 -
14 - KEYBOARD BSD-2610A13406.A0 2610A13406 £27.31 £32.77
30 - BATTERY PACK BSD-2610A15308.A4 2610A15308 -
33 - BATTERY CHARGER BSD-2610A15290.A5 2610A15290 £23.86 £28.63
