2 - CYLINDER
MET-1319740666.A0
1319740666
|
-
|
|
|
|
3 - CYLINDER HEAD ET
MET-1319651302.A0
1319651302
|
-
|
|
|
|
5 - COVER CRANKCASE
MET-1313740788.A0
1313740788
|
-
|
|
|
|
6 - VALVE PLATE SET
MET-1319740658.A0
1319740658
|
-
|
|
|
|
8 - CONNECTING ROD
MET-1319740771.A0
1319740771
|
-
|
|
|
|
12 - PISTON RD 60 ET
MET-1319163766.A6
1319163766
|
-
|
|
|
|
14 - GUDGEON PIN
MET-1319740852.A0
1319740852
|
-
|
|
|
|
15 - CIRCLIP FOR BORES
MET-6401740676.A0
6401740676
|
-
|
|
|
|
16 - PISTON RING RD 60X2 ET
MET-1319164100.A6
1319164100
|
£36.59
|
£43.91
|
|
|
17 - PISTON RING RD 60X2 ET
MET-1319164118.A8
1319164118
|
£42.65
|
£51.18
|
|
|
18 - OIL WIPING RING RD 60X3 ET
MET-1319164126.A6
1319164126
|
£48.88
|
£58.66
|
|
|
19 - SPACER WASHER
MET-1319740682.A0
1319740682
|
-
|
|
|
|
22 - OIL SPLASH NEEDLE ET
MET-1319161933.A0
1319161933
|
-
|
|
|
|
23 - FILTER
MET-341161630.A0
341161630
|
£48.88
|
£58.66
|
|
|
24 - AFTERCOOLER
MET-1313740702.A0
1313740702
|
-
|
|
|
|
29 - FLYWHEEL RD 280 ET
MET-1319155828.A0
1319155828
|
£86.42
|
£103.71
|
|
|
30 - DEEP GROOVE BALL BEARING 35X72X17 6207
MET-7100165885.A0
7100165885
|
-
|
|
|
|
33 - DIP STICK ET
MET-1319655839.A0
1319655839
|
-
|
|
|
|
34 - ROTARY SHAFT SEAL 35X47X7 ET
MET-7635638898.A0
7635638898
|
-
|
|
|
|
35 - HEXAGON HEAD SCREW
MET-141114860.A0
141114860
|
£3.20
|
£3.84
|
|
|
36 - WASHER 8 5X30X5 ET
MET-1315166400.A29
1315166400
|
-
|
|
|
|
40 - STUD BOLT
MET-1395740713.A0
1395740713
|
-
|
|
|
|
43 - GEAR COVER
MET-1319740739.A0
1319740739
|
-
|
|
|
|
44 - STUD BOLT
MET-1395740721.A0
1395740721
|
-
|
|
|
|
45 - RETAINING RING
MET-141180370.A12
141180370
|
£1.50
|
£1.80
|
|
|
49 - FAN GRID ET
MET-1319651345.A0
1319651345
|
-
|
|
|
|
50 - FAN COVER ET
MET-1319651353.A0
1319651353
|
-
|
|
|
|
52 - DRAINING VALVE NA 2 2 BAR / 1/4A ET
MET-1319651361.A0
1319651361
|
£26.35
|
£31.62
|
|
|
60 - PACKING HOUSING LID ET
MET-1319651159.A0
1319651159
|
-
|
|
|
|
62 - CYLINDER GASKET ET
MET-1319634890.A0
1319634890
|
£8.37
|
£10.04
|
|
|
63 - CYLINDER FOOT GASKET ET
MET-1319651370.A0
1319651370
|
-
|
|
|
|
64 - CYLINDER HEAD GASKET ET
MET-1319156506.A0
1319156506
|
£14.71
|
£17.65
|
|
|
101 - HANDLE BAR SLEEVE
MET-7008740601.A0
7008740601
|
-
|
|
|
|
102 - HANDLE BAR
MET-1315740599.A0
1315740599
|
-
|
|
|
|
103 - ELBOW TAP CONNECTOR
MET-7872740842.A0
7872740842
|
-
|
|
|
|
104 - Y-FITTING
MET-7805740757.A0
7805740757
|
-
|
|
|
|
105 - TERMINAL BOX ET
MET-343431120.A0
343431120
|
-
|
|
|
|
106 - OVERLOAD PROTECTION
MET-343409680.A0
343409680
|
-
|
|
|
|
107 - THUMB SCREW M 8X25 ET
MET-6150666501.A0
6150666501
|
-
|
|
|
|
108 - PRESSURE GAUGE RD 40 1/8 0/12 ET
MET-7823182621.A4
7823182621
|
£32.88
|
£39.45
|
|
|
109 - QUICK CONNECTION COUPLING EURO 1/4 AG
MET-7802009083.A3
7802009083
|
-
|
|
|
|
110 - CONDENSER 16UF/450V
MET-343254770.A0
343254770
|
-
|
|
|
|
111 - PRESSURE REGULATOR RP-192 1/4I-A ET
MET-7822661968.A20
7822661968
|
-
|
|
|
|
112 - MANOMETER
MET-343440400.A33
343440400
|
£36.59
|
£43.91
|
|
|
113 - SAFETY VALVE R 1/4 11 BAR
MET-7833009618.A1
7833009618
|
£54.94
|
£65.93
|
|
|
114 - AUTOM. PRESSURE CONTROL SWITCH 6-8 BAR 2
MET-8101149782.A0
8101149782
|
-
|
|
|
|
115 - DRAIN VALVE
MET-7830740796.A1
7830740796
|
£13.63
|
£16.36
|
|
|
116 - WHEEL ASSEMBLY
MET-1001740802.A0
1001740802
|
-
|
|
|
|
117 - RETAINING RING SET
MET-1001740748.A0
1001740748
|
-
|
|
|
|
118 - RUBBER FOOT ASSY
MET-1001740861.A0
1001740861
|
-
|
|
|
|
120 - CABLE RUBBER JACKET WITH PLUG A=437.1U
MET-8402094428.A7
8402094428
|
£26.35
|
£31.62
|
|
|
121 - PRESSURE LINE RD 15
MET-1319740631.A0
1319740631
|
-
|
|
|
|
122 - CHECK VALVE
MET-7831740625.A0
7831740625
|
-
|
|
|
|
123 - PRESSURE HOSE
MET-7853740580.A2
7853740580
|
£20.12
|
£24.14
|
|
|
124 - HANDLE BAR SLEEVE
MET-7008740610.A0
7008740610
|
-
|
|
|
