1 - COVER PLATE BL 2 5X240X686
MET-1382218724.A3001
1382218724
|
-
|
|
|
|
3 - MOTOR CARRIER BL 5X285X290
MET-1382218627.A3001
1382218627
|
-
|
|
|
|
5 - COVER MACHINE STAND BL 2
MET-1382218775.A3003
1382218775
|
-
|
|
|
|
9 - WASHER MOTOR PULLEY BL 2
MET-1382218759.A3002
1382218759
|
-
|
|
|
|
14 - FAN COVER ET 2215
MET-1332172448.A3003
1332172448
|
-
|
|
|
|
17 - LOWER CASING MOTOR TERM. BOX
MET-1331409657.A3003
1331409657
|
£8.37
|
£10.04
|
|
|
19 - WORKSTAND HC 410 6920
MET-1382218058.A3001
1382218058
|
-
|
|
|
|
21 - SCALE 1 00X30X238 0
MET-1142219120.A3001
1142219120
|
£7.44
|
£8.93
|
|
|
23 - SIDE DELIMITATION FL 25X4X654 2824
MET-1382218481.A3002
1382218481
|
-
|
|
|
|
25 - COLUMN HEIGHT ADJUSTMENT
MET-1380218514.A3003
1380218514
|
-
|
|
|
|
27 - COLUMN GUIDE HEIGHT ADJUSTMT.
MET-1380218522.A3000
1380218522
|
-
|
|
|
|
29 - GUIDE SHAFT RD 30X320 3530
MET-1485218650.A3003
1485218650
|
£63.36
|
£76.03
|
|
|
31 - SETTING PLATE BL 2 99X84X90
MET-1482218730.A3002
1482218730
|
-
|
|
|
|
33 - BEARING HEIGHT ADJUSTMENT RD 28/20X10
MET-1381218585.A3002
1381218585
|
£2.60
|
£3.12
|
|
|
35 - LOCK BAR RD 16X310 2936
MET-1485218609.A3003
1485218609
|
£22.40
|
£26.88
|
|
|
37 - THREADED ROD M 12/20/16X424 LI 3438
MET-1485218544.A3003
1485218544
|
-
|
|
|
|
39 - DUST CHUTE HC 410 4740
MET-1011219582.A3002
1011219582
|
-
|
|
|
|
41 - CHIP EJECTION HOOD 5842
MET-1011219809.A3001
1011219809
|
-
|
|
|
|
43 - TENSION BRACKET 2444
MET-1380218425.A3000
1380218425
|
-
|
|
|
|
45 - TENSION BRACKET CLAMP BD 1 5X34X47
MET-1382218430.A3001
1382218430
|
-
|
|
|
|
47 - COVER PLATE DRILL CHUCK BL 1
MET-1482219094.A3003
1482219094
|
£8.70
|
£10.44
|
|
|
49 - PRESSURE SPRING RDI 9X89X2
MET-7051218340.A3001
7051218340
|
£2.60
|
£3.12
|
|
|
51 - GUARD EXTRUSION 440 MM 3252
MET-1383219295.A3003
1383219295
|
£32.61
|
£39.13
|
|
|
53 - BEARING BLOCK 1754
MET-1380218263.A3003
1380218263
|
£6.19
|
£7.43
|
|
|
55 - CAP SCREW 1256
MET-141113870.A3002
141113870
|
£3.20
|
£3.84
|
|
|
57 - OUTFEED ROLLER D26/36+-0 15X410/527 GUMM
MET-1385218253.A3001
1385218253
|
£140.20
|
£168.24
|
|
|
59 - SIDE PANEL LINKS 6160
MET-1380218158.A3003
1380218158
|
-
|
|
|
|
61 - PLANER BLADE II HSS 410X25X3 2 EINSTELL
MET-1386220570.A3000
1386220570
|
-
|
|
|
|
63 - FEED ROLLER RD 35 7X527 GERILLT
MET-1485218242.A3003
1485218242
|
-
|
|
|
|
65 - SCALE 1 00X16X50 0
MET-1142219324.A3000
1142219324
|
-
|
|
|
|
67 - SCALE 1 00X16X50 0-5
MET-1142219111.A3003
1142219111
|
-
|
|
|
|
69 - BEARING BUSH RD 16/20/24X16 1870
MET-7151218576.A3000
7151218576
|
£3.11
|
£3.73
|
|
|
71 - COVER PLATE BL 2X56X62 1372
MET-1382218295.A3003
1382218295
|
£3.11
|
£3.73
|
|
|
73 - HEXAGON FIT BOLT SW19X42 / M 10 RUNDUMBE 2074
MET-1485218706.A3001
1485218706
|
£7.44
|
£8.93
|
|
|
75 - CHAIN SPROCKET RDA 46 2X14/RDI 20 Z=10
MET-7246218280.A3001
7246218280
|
-
|
|
|
|
77 - BRACKET FL 25X4X100 1778
MET-1482218950.A3003
1482218950
|
-
|
|
|
|
79 - ADHESIVE LABEL SILVER/BLACK 38X47 SYMB. 1380
MET-1141218910.A3003
1141218910
|
-
|
|
|
|
81 - BOLT RD 15X75 / SW 24 2782
MET-1385218504.A3003
1385218504
|
£17.95
|
£21.54
|
|
|
83 - BOLT GEAR WHEEL RD 25X66
MET-1485218498.A3000
1485218498
|
£17.07
|
£20.48
|
|
|
85 - FENCE EXTRUSION 1100 MM 4886
MET-1383218868.A3003
1383218868
|
-
|
|
|
|
87 - WASHER RDA 25 RDI 10
MET-1485218633.A3001
1485218633
|
£3.89
|
£4.67
|
|
|
89 - THREADED BOLT RD 25X140 M10/M16 2890
MET-1485218811.A3002
1485218811
|
£20.12
|
£24.14
|
|
|
91 - FENCE CARRIER 5092
MET-1380218808.A3003
1380218808
|
-
|
|
|
|
93 - CUTTERBLOCK GUARD SCHUTZLÄNGE 530 MM 5794
MET-1011170478.A3003
1011170478
|
£129.46
|
£155.35
|
|
|
95 - ANGLE BRACKET BL 5 00X94X236
MET-1482218128.A3002
1482218128
|
-
|
|
|
|
97 - SCALE 1 00X10X55 0
MET-1142219332.A3003
1142219332
|
-
|
|
|
|
99 - SCALE 1 00XRD39
MET-1142219146.A3003
1142219146
|
-
|
|
|
|
101 - SETTING SHAFT RD 25X299/M 20 35102
MET-1485218471.A3003
1485218471
|
£63.36
|
£76.03
|
|
|
103 - HINGE HINTEN 47104
MET-1380218140.A3000
1380218140
|
-
|
|
|
|
105 - HINGE VORNE 47106
MET-1380218115.A3003
1380218115
|
-
|
|
|
|
107 - LIMIT SWITCH PLATE BL 0 88X33X35
MET-1482219191.A3001
1482219191
|
-
|
|
|
|
109 - SWITCH ENCLOSURE UPPER BL 2
MET-1382219356.A3001
1382219356
|
-
|
|
|
|
111 - PLATE CABLE BRACKET BL 2X181X338
MET-1382219941.A3003
1382219941
|
-
|
|
|
|
113 - CLAW PLATE CABLE CONDUIT BL 2
MET-1482218675.A3001
1482218675
|
-
|
|
|
|
115 - SWITCH SSK 5 50 DNB 400/3/50 HC 410 G
MET-8132722278.A3000
8132722278
|
£196.24
|
£235.49
|
|
|
117 - GLIDE PIECE 11120
MET-2391202772.A3003
2391202772
|
£1.50
|
£1.80
|
|
|
121 - SLIP COUPLER ET 37193
MET-1010633970.A3003
1010633970
|
£54.44
|
£65.33
|
|
|
500 - THREAD CUTTING SCREW A 11501
MET-6175174166.A3003
6175174166
|
£1.50
|
£1.80
|
|
|
502 - FILLISTER HEAD SCREW 12503
MET-141110640.A3004
141110640
|
-
|
|
|
|
504 - HEXAGON NUT PREV. TORQUE TYPE
MET-6202002305.A3002
6202002305
|
£1.50
|
£1.80
|
|
|
506 - HEXAGON HEAD SCREW 12507
MET-141114860.A3001
141114860
|
£3.20
|
£3.84
|
|
|
508 - FISHBOLT M 8X30 TYP: 0828-30 16510
MET-6143167761.A3003
6143167761
|
£5.38
|
£6.45
|
|
|
511 - WASHER 11513
MET-141151340.A3004
141151340
|
£1.50
|
£1.80
|
|
|
514 - FILLISTER HEAD SCREW 11515
MET-141110570.A3001
141110570
|
£1.50
|
£1.80
|
|
|
516 - CROSS RECD SAUCER-HEAD SCREW 5X20-Z VE 11517
MET-6189011421.A3001
6189011421
|
£1.50
|
£1.80
|
|
|
518 - SERRATED LOCK WASHER 12519
MET-141150410.A3000
141150410
|
£3.20
|
£3.84
|
|
|
520 - TRUSS HEAD SCREW 11521
MET-6110017942.A3005
6110017942
|
£1.50
|
£1.80
|
|
|
522 - HEXAGON HEAD SCREW 11523
MET-141113290.A3003
141113290
|
£1.50
|
£1.80
|
|
|
524 - BEARING BUSH RD 16X18X17 13525
MET-7150015698.A3003
7150015698
|
£3.11
|
£3.73
|
|
|
526 - HEXAGON THIN NUT M 12 VERZ. FORM B 11527
MET-6205055744.A3001
6205055744
|
£1.50
|
£1.80
|
|
|
528 - THRUST NEEDLE COLLAR AXK 1226 22529
MET-7104167661.A3003
7104167661
|
-
|
|
|
|
530 - LUBRICATING NIPPLE CM 6 13531
MET-7152171107.A3003
7152171107
|
-
|
|
|
|
532 - WASHER 11533
MET-141150140.A3003
141150140
|
£1.50
|
£1.80
|
|
|
534 - WOODRUFF KEY 11535
MET-6720008538.A3003
6720008538
|
£1.50
|
£1.80
|
|
|
536 - RATCHET LOCK LEVER FEMALE M 10 IG 18 MM
MET-7006073730.A3006
7006073730
|
£13.63
|
£16.36
|
|
|
538 - CAP SCREW 12539
MET-141114000.A3001
141114000
|
£3.20
|
£3.84
|
|
|
540 - HEXAGONAL NUT 11541
MET-141130100.A3016
141130100
|
£1.50
|
£1.80
|
|
|
542 - GRUB SCREW W.INTERNAL HEXAGON 11543
MET-6164029245.A3002
6164029245
|
£1.50
|
£1.80
|
|
|
544 - CROSS RECD PAN HEAD TAP.SCREW 11545
MET-6172015687.A3002
6172015687
|
£1.50
|
£1.80
|
|
|
546 - PARALLEL PIN 10 H8X50 12547
MET-6500167600.A3003
6500167600
|
-
|
|
|
|
548 - HEXAGONAL NUT 11549
MET-141131010.A3001
141131010
|
£1.50
|
£1.80
|
|
|
550 - WASHER 11551
MET-141150050.A3003
141150050
|
£1.50
|
£1.80
|
|
|
552 - O-RING 52 07X2
MET-7632167711.A3001
7632167711
|
£1.50
|
£1.80
|
|
|
554 - STUD BOLT HEADLESS B M 8X110 VERZ.
MET-6551116113.A3000
6551116113
|
£3.89
|
£4.67
|
|
|
557 - SHIM RING S 16X22X1
MET-6306009980.A3000
6306009980
|
£1.50
|
£1.80
|
|
|
559 - HEX. SOCKET SET SCREW DOG PT. M 8X12 VE
MET-6163087683.A3001
6163087683
|
£1.50
|
£1.80
|
|
|
561 - FILLISTER HEAD SCREW 11562
MET-6172028215.A3001
6172028215
|
£1.50
|
£1.80
|
|
|
564 - PARALLEL PIN 6 M6X20 11565
MET-6500074440.A3000
6500074440
|
-
|
|
|
|
566 - RETAINING RING 12567
MET-141180390.A3001
141180390
|
£3.20
|
£3.84
|
|
|
568 - PARALLEL KEY 11569
MET-6721059322.A3000
6721059322
|
£1.50
|
£1.80
|
|
|
570 - SHIM RING 16X22X1 VERZ. 11571
MET-6306009760.A3015
6306009760
|
£1.50
|
£1.80
|
|
|
572 - ROLLER CHAIN 74 GLIEDER 1/2 TEILUNG EN 22573
MET-7236167741.A3003
7236167741
|
£9.82
|
£11.79
|
|
|
574 - FLAT BELT 900X12X1 5 GELB
MET-7232167720.A3001
7232167720
|
£28.45
|
£34.14
|
|
|
576 - HEXAGON HEAD SCREW 11577
MET-141124120.A3002
141124120
|
-
|
|
|
|
578 - DEEP GROOVE BALL BEARING 15X35X11 6202-2 20579
MET-7100067433.A3003
7100067433
|
£11.78
|
£14.13
|
|
|
580 - HEX HEAD SCREW 11581
MET-6103001178.A3015
6103001178
|
£1.50
|
£1.80
|
|
|
582 - HEXAGON SOCKET HEAD CAP SCREW 11583
MET-6121121296.A3002
6121121296
|
£1.50
|
£1.80
|
|
|
584 - HEXAGONAL LOCK NUT 12585
MET-141130650.A3002
141130650
|
£3.20
|
£3.84
|
|
|
586 - CLAMPING SLEEVE 8X32 11587
MET-6503167830.A3003
6503167830
|
-
|
|
|
|
588 - CAP SCREW 11589
MET-141114030.A3001
141114030
|
-
|
|
|
|
590 - HEXAGON HEAD SCREW M 10X40 VERZ. 11591
MET-141124500.A3001
141124500
|
-
|
|
|
|
592 - LIMIT SWITCH 41593
MET-8116011850.A3002
8116011850
|
£54.44
|
£65.33
|
|
|
594 - SEAL NIPPLE PG 9 11595
MET-8240167752.A3002
8240167752
|
-
|
|
|
|
596 - CABLE TIE 3 5X180
MET-8490118536.A3002
8490118536
|
-
|
|
|
|
599 - WASHER 11600
MET-141150020.A3002
141150020
|
£1.50
|
£1.80
|
|
|
601 - CUP SPRING 11602
MET-141155660.A3003
141155660
|
£1.50
|
£1.80
|
|
|
603 - STRAIN RELIEF ZEV 9-12/PG 11 14604
MET-8240015090.A3002
8240015090
|
-
|
|
|
|
605 - CROSS RECD PAN HEAD TAP.SCREW ST 4 8X32
MET-6172011150.A3002
6172011150
|
-
|
|
|
|
609 - FEATHER KEY A 8X7X45 ET 11617
MET-6721165319.A3003
6721165319
|
-
|
|
|
|
618 - SPACER SLEEVE 11619
MET-6442059304.A3002
6442059304
|
£1.50
|
£1.80
|
|
