2 - FIELD 240V
BSD-2604220453.A0
2604220453
|
-
|
|
|
|
3 - ARMATURE 240V
BSD-2604011062.A7
2604011062
|
-
|
|
|
|
3/60 - FAN
BSD-2606610055.A44
2606610055
|
£4.26
|
£5.11
|
|
|
4 - ON-OFF SWITCH
BSD-2607200365.A26
2607200365
|
-
|
|
|
|
5 - POWER SUPPLY CORD GB 240V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460124.A42
2604460124
|
-
|
|
|
|
6 - GROMMET dia7 MM
BSD-2600703007.A19
2600703007
|
-
|
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1414
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118657.A2
2601118657
|
-
|
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-2607329138.A80
2607329138
|
-
|
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1900905041.A2
1900905041
|
£13.12
|
£15.75
|
|
|
16 - BRUSH PLATE
BSD-2609992604.A2
2609992604
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1176
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A156
2603490022
|
£1.75
|
£2.10
|
|
|
26 - ECCENTRIC DISC
BSD-2600499040.A3
2600499040
|
-
|
|
|
|
27 - ROUND RUBBER dia 11.3x23.5 MM
BSD-1603101018.A19
1603101018
|
-
|
|
|
|
31 - CLAMPING STRIP
BSD-2601007019.A5
2601007019
|
£1.95
|
£2.34
|
|
|
33 - HEX NUT DIN 985-M6-8
BSD-2603300013.A24
2603300013
|
-
|
|
|
|
35 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A343
2603410048
|
£1.75
|
£2.10
|
|
|
36 - SHEET METAL COVER
BSD-2600034002.A8
2600034002
|
-
|
|
|
|
37 - FITTING
BSD-2605702008.A6
2605702008
|
-
|
|
|
|
38 - TORX OVAL-HEAD SCREW 4x8
BSD-2603490020.A5
2603490020
|
£1.75
|
£2.10
|
|
|
39 - FAN
BSD-2606610026.A2
2606610026
|
-
|
|
|
|
42 - CABLE L=98 MM
BSD-2604448045.A38
2604448045
|
-
|
|
|
|
43 - CONNECTING CABLE L=213 MM
BSD-2604448118.A8
2604448118
|
£1.75
|
£2.10
|
|
|
44 - DAMPING PLATE
BSD-2601022000.A619
2601022000
|
£1.75
|
£2.10
|
|
|
46 - SPACER SLEEVE
BSD-2600322002.A4
2600322002
|
-
|
|
|
|
47 - FELT STRIP
BSD-2601005012.A1
2601005012
|
-
|
|
|
|
49 - CONNECTING CABLE L=115 MM
BSD-2604448109.A28
2604448109
|
£1.75
|
£2.10
|
|
|
53 - SEAL RING
BSD-2600290029.A15
2600290029
|
-
|
|
|
|
54 - O-RING 56.0x1.78 MM
BSD-2600210041.A12
2600210041
|
-
|
|
|
|
55 - CAP-HANDLE
BSD-2600591005.A16
2600591005
|
£2.33
|
£2.80
|
|
|
56 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A10
2603490024
|
£1.75
|
£2.10
|
|
|
57 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1631
2603490023
|
£1.75
|
£2.10
|
|
|
58 - FELT WASHER
BSD-2600005009.A8
2600005009
|
£1.75
|
£2.10
|
|
|
655 - FITTING
BSD-2605702031.A26
2605702031
|
-
|
|
|
|
657 - O-RING 20.0x1.5 MM
BSD-1610210075.A19
1610210075
|
£2.61
|
£3.13
|
|
|
706 - PUNCHING TOOL
BSD-2608190016.A16
2608190016
|
£13.37
|
£16.04
|
|
|
729 - SANDER PLATE
BSD-2608000072.A1
2608000072
|
£13.99
|
£16.79
|
|
|
754 - DUST BAG
BSD-2605411067.A25
2605411067
|
£6.12
|
£7.34
|
|
|
754 - DUST BAG
BSD-2605411068.A9
2605411068
|
£13.99
|
£16.79
|
|
|
754 - DUST BAG
BSD-2605411009.A6
2605411009
|
£8.74
|
£10.49
|
|
|
801 - HOUSING SECTION
BSD-2605104879.A2
2605104879
|
-
|
|
|
|
808 - NAMEPLATE
BSD-2601119219.A0
2601119219
|
-
|
|
|
|
813 - BUSHING
BSD-2600301050.A7
2600301050
|
-
|
|
|
|
816/04 - CARBON-BRUSH SET
BSD-2607014001.A29
2607014001
|
-
|
|
|
|
816/05 - COMPRESSION SPRING
BSD-2604610028.A150
2604610028
|
£1.75
|
£2.10
|
|
|
816/06 - RATCHET CAP
BSD-2601322013.A168
2601322013
|
£1.75
|
£2.10
|
|
|
828 - SWING-PLATE
BSD-2608000170.A6
2608000170
|
-
|
|
|
|
830 - CLAMPING SADDLE
BSD-2608045901.A6
2608045901
|
-
|
|
|
