2 - FIELD 240V
BSD-1604220152.A2
1604220152
|
-
|
|
|
|
3 - ARMATURE 240V
BSD-1604010230.A3
1604010230
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200164.A2
2607200164
|
-
|
|
|
|
5 - POWER SUPPLY CORD GB 110V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460205.A82
2604460205
|
£27.23
|
£32.68
|
|
|
6 - GROMMET dia7 MM
BSD-2600703007.A306
2600703007
|
-
|
|
|
|
6 - GROMMET dia9.5 MM
BSD-2600703006.A60
2600703006
|
-
|
|
|
|
6 - GROMMET dia8.2 MM
BSD-2600703008.A26
2600703008
|
£1.75
|
£2.10
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2140
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-2601110648.A1
2601110648
|
-
|
|
|
|
11 - SUPPRESSION CAPACITOR
BSD-2607328004.A2
2607328004
|
-
|
|
|
|
12 - PRESSURE BAR
BSD-2605510008.A15
2605510008
|
-
|
|
|
|
13 - STICKER
BSD-2601110979.A2
2601110979
|
-
|
|
|
|
14 - FAN
BSD-2606610027.A127
2606610027
|
£2.80
|
£3.36
|
|
|
15 - CONNECTING CABLE L=184 MM
BSD-2604448001.A19
2604448001
|
£1.95
|
£2.34
|
|
|
16 - COMPRESSION SPRING
BSD-2604610009.A13
2604610009
|
-
|
|
|
|
17 - NEEDLE BEARING
BSD-2600910005.A44
2600910005
|
-
|
|
|
|
18 - O-RING 8.0x2.5 MM
BSD-1610210014.A191
1610210014
|
-
|
|
|
|
19 - CARB BRUSH HOLD W-SUPR
BSD-2604465081.A43
2604465081
|
-
|
|
|
|
20 - PLAIN WASHER DIN 315-M8-GT-C
BSD-2600100041.A172
2600100041
|
£1.75
|
£2.10
|
|
|
22 - DAMPING PLATE
BSD-2601022000.A297
2601022000
|
£1.75
|
£2.10
|
|
|
24 - ROUND RUBBER dia 11.3x23.5 MM
BSD-1603101018.A27
1603101018
|
-
|
|
|
|
26 - PLAIN WASHER
BSD-1600100020.A12
1600100020
|
-
|
|
|
|
27 - ECCENTRIC DISC
BSD-2602210009.A11
2602210009
|
-
|
|
|
|
28 - GROOVE BALL BEARING 12x28x8
BSD-2600905013.A51
2600905013
|
-
|
|
|
|
29 - BEARING FLANGE
BSD-2600501004.A3
2600501004
|
-
|
|
|
|
30 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A385
1903230004
|
£2.16
|
£2.59
|
|
|
31 - O-RING 28x2.5 MM
BSD-1900210128.A40
1900210128
|
£2.61
|
£3.13
|
|
|
33 - GROOVE BALL BEARING 15x32x9
BSD-2600905068.A25
2600905068
|
£14.91
|
£17.89
|
|
|
34 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1655
2603410001
|
£1.75
|
£2.10
|
|
|
38 - SCREW 4x16
BSD-2603490022.A1763
2603490022
|
£1.75
|
£2.10
|
|
|
39 - SOCKET HEAD CAP SCREW DIN 84-AM5x12-8.8
BSD-2910021154.A301
2910021154
|
£1.75
|
£2.10
|
|
|
40 - SPRING WASHER DIN 137-A5-FST
BSD-2916060006.A326
2916060006
|
£1.32
|
£1.58
|
|
|
41 - SPRING RETAINING RING DIN 472-28x1.2 MM
BSD-2916660011.A144
2916660011
|
£1.75
|
£2.10
|
|
|
653 - SANDING SHEET KORN 120
BSD-1608604140.A9
1608604140
|
-
|
|
|
|
683 - SUCTION FRAME
BSD-1605190018.A11
1605190018
|
-
|
|
|
|
801 - HOUSING SECTION
BSD-2605104997.A17
2605104997
|
-
|
|
|
|
810 - CARBON BRUSH
BSD-1604321900.A148
1604321900
|
-
|
|
|
|
823 - PARTS SET
BSD-1607000902.A14
1607000902
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A4533
160111A3H3
|
£2.61
|
£3.13
|
|
