1 - MOTOR HOUSING
BSD-3605108091.A36
3605108091
|
£33.74
|
£40.49
|
|
|
3 - ARMATURE
BSD-1619P13608.A10
1619P13608
|
£120.11
|
£144.13
|
|
|
4 - BALL BEARING 7x19x6
BSD-2600905032.A1098
2600905032
|
£5.30
|
£6.36
|
|
|
5 - INTERMEDIATE RING
BSD-1600502011.A174
1600502011
|
£2.61
|
£3.13
|
|
|
7 - BLADE TERMINAL
BSD-1604477001.A132
1604477001
|
£1.75
|
£2.10
|
|
|
8 - SPIRAL SPRING
BSD-1604652006.A21
1604652006
|
£1.75
|
£2.10
|
|
|
11 - SEALING CAP
BSD-3605500063.A4
3605500063
|
£4.26
|
£5.11
|
|
|
12 - CONNECTING CABLE L=290 MM
BSD-1604445006.A46
1604445006
|
£5.58
|
£6.70
|
|
|
14 - STICKER
BSD-3601110368.A5
3601110368
|
£2.16
|
£2.59
|
|
|
15 - SEALING CAP
BSD-3605500062.A27
3605500062
|
£13.12
|
£15.75
|
|
|
19 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A1246
3600703011
|
£2.80
|
£3.36
|
|
|
21 - FASTENING CLAMP
BSD-1601302014.A821
1601302014
|
£2.61
|
£3.13
|
|
|
22 - SWITCH
BSD-1607200075.A32
1607200075
|
£68.42
|
£82.10
|
|
|
24 - SUPPRESSION FILTER
BSD-1607328028.A505
1607328028
|
£5.30
|
£6.36
|
|
|
30 - AIR-DEFLECTOR RING
BSD-1600502019.A120
1600502019
|
£3.72
|
£4.47
|
|
|
31 - INTERMEDIATE RING
BSD-1600221003.A50
1600221003
|
£2.61
|
£3.13
|
|
|
32 - GROOVE BALL BEARING 9x26x8
BSD-3600905131.A82
3600905131
|
£11.30
|
£13.56
|
|
|
36 - INTERMEDIATE RING
BSD-1600300090.A110
1600300090
|
£3.72
|
£4.47
|
|
|
38 - SEALING PLATE
BSD-1601015013.A60
1601015013
|
£1.75
|
£2.10
|
|
|
39 - TOOTHED SHAFT Z=9
BSD-1606309066.A0
1606309066
|
£81.81
|
£98.17
|
|
|
40 - COMPRESSION SPRING
BSD-1604611022.A5
1604611022
|
£1.75
|
£2.10
|
|
|
41 - BALL DIN 5401-5 G28
BSD-1903230009.A92
1903230009
|
£1.75
|
£2.10
|
|
|
42 - CYLINDRICAL GEAR Z=32
BSD-1606317074.A32
1606317074
|
£31.64
|
£37.97
|
|
|
43 - CYLINDRICAL GEAR Z=43
BSD-1606317082.A26
1606317082
|
£37.27
|
£44.72
|
|
|
44 - NEEDLE BEARING
BSD-1600910013.A162
1600910013
|
£5.58
|
£6.70
|
|
|
45 - PINION SHAFT Z=14/24/33
BSD-1606309065.A51
1606309065
|
£81.81
|
£98.17
|
|
|
45/20 - CYLINDRICAL GEAR Z=33
BSD-1606320077.A14
1606320077
|
£23.86
|
£28.63
|
|
|
46 - SHIM 0.5 MM
BSD-1600100631.A220
1600100631
|
£1.75
|
£2.10
|
|
|
47 - SHIM 0.6 MM
BSD-1600101647.A12
1600101647
|
£2.16
|
£2.59
|
|
|
48 - CONTROL SHAFT Z=20
BSD-1606325025.A0
1606325025
|
£2.80
|
£3.36
|
|
|
49 - NOTCHED PLATE
BSD-1601038025.A106
1601038025
|
£1.75
|
£2.10
|
|
|
50 - CONTROL LEVER
BSD-1602026044.A32
1602026044
|
£7.36
|
£8.83
|
|
|
51 - CONTROL SHAFT Z=10
BSD-1606325027.A67
1606325027
|
£8.67
|
£10.41
|
|
|
52 - O-RING 8x2.5 MM
BSD-1900210105.A10
1900210105
|
£1.75
|
£2.10
|
|
|
53 - STICKER
BSD-3601110362.A0
3601110362
|
£2.80
|
£3.36
|
|
|
54 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A713
2600910001
|
£4.26
|
£5.11
|
|
|
56 - DRILLING SPINDLE 5/8
BSD-1603523087.A0
1603523087
|
£48.38
|
£58.06
|
|
|
57 - GROOVE BALL BEARING 15x32x9
BSD-1900905162.A22
1900905162
|
£18.96
|
£22.75
|
|
|
58 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A430
2916650006
|
£1.75
|
£2.10
|
|
|
60 - CYLINDRICAL GEAR Z=39
BSD-3606317009.A4
3606317009
|
£40.80
|
£48.96
|
|
|
63 - COMPRESSION SPRING
BSD-1604613006.A136
1604613006
|
£1.75
|
£2.10
|
|
|
64 - WIRE GUIDE
BSD-3601025003.A136
3601025003
|
£1.75
|
£2.10
|
|
|
65 - CONNECTING CABLE L=375 MM
BSD-3604438027.A30
3604438027
|
£10.10
|
£12.12
|
|
|
66 - CONNECTING CABLE L=330 MM
BSD-1604438012.A35
1604438012
|
£7.36
|
£8.83
|
|
|
67 - CONNECTING CABLE L=470 MM
BSD-3604438025.A2
3604438025
|
£7.36
|
£8.83
|
|
|
68 - TAPPING SCREW 5x30
BSD-3603435027.A65
3603435027
|
£1.75
|
£2.10
|
|
|
69 - TAPPING SCREW DIN 7971-B4.8x19
BSD-2910211234.A52
2910211234
|
£1.75
|
£2.10
|
|
|
71 - LENS HEAD SCREW
BSD-3603435042.A0
3603435042
|
£1.75
|
£2.10
|
|
|
73 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2077
2910211019
|
£1.75
|
£2.10
|
|
|
74 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1713
2910021118
|
£1.75
|
£2.10
|
|
|
75 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2075
2910211019
|
£1.75
|
£2.10
|
|
|
76 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2076
2910211019
|
£1.75
|
£2.10
|
|
|
77 - COUNTERSUNK-HEAD SCREW DIN 63-AM4x10-5.8
BSD-2910501120.A59
2910501120
|
£1.75
|
£2.10
|
|
|
79 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A894
2910211021
|
£1.75
|
£2.10
|
|
|
95 - STICKER
BSD-3601110072.A15
3601110072
|
-
|
|
|
|
100 - BUSHING
BSD-3600328033.A16
3600328033
|
£8.49
|
£10.19
|
|
|
102 - STRAIGHT PIN 5 H 8x18 DIN 7
BSD-2917500121.A168
2917500121
|
£1.75
|
£2.10
|
|
|
650 - AUXILIARY HANDLE dia 43 MM
BSD-3602025012.A0
3602025012
|
£27.23
|
£32.68
|
|
|
650/20 - SUPPORT CLAMP
BSD-1618040077.A147
1618040077
|
-
|
|
|
|
650/30 - STUD BOLT M8
BSD-1613521001.A119
1613521001
|
£5.58
|
£6.70
|
|
|
650/40 - CLAMPING BAND dia43 MM
BSD-3601038048.A17
3601038048
|
£18.96
|
£22.75
|
|
|
650/50 - STRAIGHT PIN
BSD-1613100012.A193
1613100012
|
£2.61
|
£3.13
|
|
|
651 - MIXER ATTACHMENT dia 140 MM. M14
BSD-3609201036.A6
3609201036
|
£81.81
|
£98.17
|
|
|
652 - THREADED FITTING 215 MM. 5/8. M14
BSD-3609201353.A0
3609201353
|
£16.41
|
£19.69
|
|
|
802 - FIELD 230V
BSD-3604220148.A4
3604220148
|
£54.42
|
£65.30
|
|
|
806 - BRUSH HOLDER
BSD-3604336012.A34
3604336012
|
£5.58
|
£6.70
|
|
|
810 - CARBON-BRUSH SET
BSD-3607014012.A4
3607014012
|
£23.86
|
£28.63
|
|
|
818 - HANDLE
BSD-3605132031.A32
3605132031
|
£31.64
|
£37.97
|
|
|
820 - POWER SUPPLY CORD
BSD-1607000391.A13
1607000391
|
£18.96
|
£22.75
|
|
|
831 - INTERMEDIATE RING
BSD-1600206026.A58
1600206026
|
£1.75
|
£2.10
|
|
|
833 - RETAINING RING DIN 9045 - dia 30MM
BSD-2916600016.A19
2916600016
|
£1.75
|
£2.10
|
|
|
834 - SUPPORTING DISC
BSD-1600102680.A13
1600102680
|
£1.75
|
£2.10
|
|
|
835 - ROTARY SHAFT LIP SEAL
BSD-3600290070.A17
3600290070
|
£12.04
|
£14.45
|
|
|
836 - INTERMEDIATE RING
BSD-1600300090.A112
1600300090
|
£3.72
|
£4.47
|
|
|
837 - INTERMEDIATE BEARING
BSD-3607030436.A2
3607030436
|
£93.88
|
£112.65
|
|
|
855 - SPINDLE BEARING M14
BSD-1605806368.A0
1605806368
|
£72.18
|
£86.62
|
|
|
861 - RETAINING SNAP RING
BSD-3607030355.A44
3607030355
|
£18.96
|
£22.75
|
|
|
864 - WIRE GUIDE
BSD-1601025001.A40
1601025001
|
£1.75
|
£2.10
|
|
|
865 - CONNECTING CABLE L=345 MM
BSD-1604438013.A31
1604438013
|
£7.36
|
£8.83
|
|
|
867 - CONNECTING CABLE L=450 MM
BSD-3604460009.A12
3604460009
|
£6.52
|
£7.83
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2741
160111A3H3
|
£2.61
|
£3.13
|
|
