1 - MOTOR HOUSING
BSD-3605108145.A103
3605108145
|
£27.23
|
£32.68
|
|
|
3/60 - FAN
BSD-1606610122.A34
1606610122
|
£2.80
|
£3.36
|
|
|
4 - SWITCH
BSD-1607200078.A64
1607200078
|
£40.80
|
£48.96
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A780
3600703011
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A1154
1601302014
|
£2.61
|
£3.13
|
|
|
11 - SUPPRESSION FILTER
BSD-1607328028.A720
1607328028
|
£5.30
|
£6.36
|
|
|
12 - O-RING 74.0x1.5 MM
BSD-1600210030.A1
1600210030
|
-
|
|
|
|
13 - BLADE TERMINAL
BSD-1604477001.A142
1604477001
|
£1.75
|
£2.10
|
|
|
15/2 - INSULATING PLATE 20x20x50 MM
BSD-1602381006.A43
1602381006
|
£1.75
|
£2.10
|
|
|
18 - SPIRAL SPRING
BSD-1604652006.A148
1604652006
|
£1.75
|
£2.10
|
|
|
20 - INTERMEDIATE RING
BSD-1600502011.A92
1600502011
|
£2.61
|
£3.13
|
|
|
21 - BALL BEARING 7x19x6
BSD-2600905032.A156
2600905032
|
£5.30
|
£6.36
|
|
|
23 - AIR-DEFLECTOR RING
BSD-1600502019.A85
1600502019
|
£3.72
|
£4.47
|
|
|
24 - INTERMEDIATE RING
BSD-1600300090.A189
1600300090
|
£3.72
|
£4.47
|
|
|
25 - INTERMEDIATE RING
BSD-1600221003.A4
1600221003
|
£2.61
|
£3.13
|
|
|
28 - GROOVE BALL BEARING 9x26x8
BSD-3600905131.A136
3600905131
|
£11.30
|
£13.56
|
|
|
29 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A437
1600290016
|
£2.61
|
£3.13
|
|
|
30 - PLAIN BEARING
BSD-1600200029.A89
1600200029
|
£4.26
|
£5.11
|
|
|
31 - CYLINDRICAL GEAR Z=36
BSD-3606317041.A2
3606317041
|
£37.27
|
£44.72
|
|
|
33 - SHIM 0.5 MM
BSD-1600102003.A138
1600102003
|
£1.75
|
£2.10
|
|
|
34 - STRAIGHT PIN 5 H 8x18 DIN 7
BSD-2917500121.A85
2917500121
|
£1.75
|
£2.10
|
|
|
36 - SPINDLE 5/8
BSD-3603523028.A4
3603523028
|
£54.42
|
£65.30
|
|
|
37 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A532
2916650006
|
£1.75
|
£2.10
|
|
|
38 - SHIM
BSD-3600100064.A1
3600100064
|
£2.16
|
£2.59
|
|
|
40 - GROOVE BALL BEARING 15x32x9
BSD-1900905162.A15
1900905162
|
£18.96
|
£22.75
|
|
|
42 - LENS HEAD SCREW
BSD-3603435040.A6
3603435040
|
£1.75
|
£2.10
|
|
|
43 - TORX OVAL-HEAD SCREW
BSD-2914201527.A64
2914201527
|
£2.16
|
£2.59
|
|
|
46 - TORX OVAL-HEAD SCREW
BSD-2914201507.A32
2914201507
|
£1.75
|
£2.10
|
|
|
47 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A1905
2910211019
|
£1.75
|
£2.10
|
|
|
49 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A240
2910211018
|
£1.75
|
£2.10
|
|
|
51 - NEEDLE BEARING
BSD-3600917019.A18
3600917019
|
£11.30
|
£13.56
|
|
|
56 - CONNECTING CABLE L=360 MM
BSD-3604460027.A26
3604460027
|
£6.52
|
£7.83
|
|
|
57 - WIRE GUIDE
BSD-3601025003.A77
3601025003
|
£1.75
|
£2.10
|
|
|
58 - COMPRESSION SPRING
BSD-1604613006.A98
1604613006
|
£1.75
|
£2.10
|
|
|
59 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1426
2910021118
|
£1.75
|
£2.10
|
|
|
70 - COMPANY LOGO
BSD-3601110266.A5
3601110266
|
£3.72
|
£4.47
|
|
|
79 - REFERENCE PLATE
BSD-3601110267.A0
3601110267
|
£3.72
|
£4.47
|
|
|
90 - TAB WASHER
BSD-1601030022.A160
1601030022
|
£1.75
|
£2.10
|
|
|
650 - SPLASH GUARD
BSD-3605510037.A3
3605510037
|
£37.27
|
£44.72
|
|
|
650/20 - CLAMPING LEVER
BSD-3602001005.A1
3602001005
|
£21.52
|
£25.83
|
|
|
650/30 - HEX SCREW M 6x55 DIN 931-8.8
BSD-2911011215.A4
2911011215
|
£1.75
|
£2.10
|
|
|
650/40 - HEX SCREW DIN 931-M8x50-8.8
BSD-2911011254.A1
2911011254
|
£1.75
|
£2.10
|
|
|
650/50 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A148
2916011014
|
£1.75
|
£2.10
|
|
|
650/60 - PLAIN WASHER DIN 125-A 8.4-ST
BSD-2916011016.A36
2916011016
|
£1.75
|
£2.10
|
|
|
650/70 - HEX NUT
BSD-3603435044.A35
3603435044
|
£2.16
|
£2.59
|
|
|
651 - AUXILIARY HANDLE
BSD-3601923013.A4
3601923013
|
£30.28
|
£36.33
|
|
|
652 - THREADED FITTING SW22. M14. 5/8
BSD-3609201354.A2
3609201354
|
£12.04
|
£14.45
|
|
|
802 - FIELD 230-240V
BSD-3604220109.A4
3604220109
|
£63.50
|
£76.20
|
|
|
803 - ARMATURE 230-240V
BSD-3607031338.A3
3607031338
|
£156.22
|
£187.46
|
|
|
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A11
1607000227
|
£23.86
|
£28.63
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A1268
160111A3H3
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014126.A73
1607014126
|
£16.41
|
£19.69
|
|
|
814 - SPINDLE WITH GEAR Z=11/33
BSD-3606309046.A4
3606309046
|
£81.81
|
£98.17
|
|
|
815 - HANDLE
BSD-3605133012.A131
3605133012
|
-
|
|
|
|
816 - SPINDLE WITH GEAR Z=11/35
BSD-3606309048.A1
3606309048
|
£156.22
|
£187.46
|
|
|
817 - BRUSH HOLDER
BSD-1604336017.A223
1604336017
|
£7.36
|
£8.83
|
|
|
822 - SEALING CAP
BSD-3605500063.A105
3605500063
|
£4.26
|
£5.11
|
|
|
826 - INTERMEDIATE FLANGE
BSD-3607031539.A1
3607031539
|
£102.57
|
£123.08
|
|
|
832 - SPINDLE BEARING
BSD-3607031540.A4
3607031540
|
£72.18
|
£86.62
|
|
|
835 - RETAINING SNAP RING
BSD-3607030355.A114
3607030355
|
£18.96
|
£22.75
|
|
|
856 - CONNECTING CABLE L=330 MM
BSD-1604438012.A3
1604438012
|
£7.36
|
£8.83
|
|
|
857 - WIRE GUIDE
BSD-1601025001.A27
1601025001
|
£1.75
|
£2.10
|
|
