1 - MOTOR HOUSING
BSD-3600760013.A6
3600760013
|
£93.88
|
£112.65
|
|
|
2 - STATOR 740W
BSD-3604090023.A10
3604090023
|
£156.22
|
£187.46
|
|
|
3 - ROTOR
BSD-3604220021.A14
3604220021
|
£102.57
|
£123.08
|
|
|
5 - BEARING FLANGE
BSD-3605700014.A58
3605700014
|
£59.53
|
£71.44
|
|
|
6 - GROOVE BALL BEARING 10x26x8
BSD-1900905127.A8
1900905127
|
£27.23
|
£32.68
|
|
|
7 - BEARING FLANGE
BSD-3605700011.A1
3605700011
|
£68.42
|
£82.10
|
|
|
8 - BALL BEARING 8x22x7
BSD-1900905029.A164
1900905029
|
£21.52
|
£25.83
|
|
|
9 - SPACER RING
BSD-2600200007.A53
2600200007
|
£10.10
|
£12.12
|
|
|
10 - SPACER RING
BSD-3600202004.A39
3600202004
|
£11.30
|
£13.56
|
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A76
2916011012
|
£1.75
|
£2.10
|
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A168
2911061150
|
£2.61
|
£3.13
|
|
|
26 - PINION Z=14
BSD-3606300048.A1
3606300048
|
£48.38
|
£58.06
|
|
|
27 - STOP DISC
BSD-3600101004.A76
3600101004
|
£2.61
|
£3.13
|
|
|
28 - RING GEAR Z=46/35
BSD-3606334013.A11
3606334013
|
£410.78
|
£492.94
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337048.A2
3606337048
|
£120.11
|
£144.13
|
|
|
30 - CYLINDRICAL GEAR Z=16
BSD-3606316091.A15
3606316091
|
£2.80
|
£3.36
|
|
|
31 - NEEDLE-ROLLER ASSEMBLY
BSD-3600910000.A50
3600910000
|
£4.26
|
£5.11
|
|
|
32 - NEEDLE ROLLER
BSD-3603201005.A49
3603201005
|
£2.80
|
£3.36
|
|
|
34 - NEEDLE ROLLER
BSD-3603201031.A34
3603201031
|
£2.61
|
£3.13
|
|
|
35 - GROOVE BALL BEARING 25x37x7
BSD-3600905001.A55
3600905001
|
£31.64
|
£37.97
|
|
|
36 - PLANETARY-GEAR CARRIER
BSD-3606337044.A5
3606337044
|
£306.65
|
£367.98
|
|
|
37 - CYLINDRICAL GEAR
BSD-3606316105.A11
3606316105
|
£37.27
|
£44.72
|
|
|
38 - SPACER RING
BSD-3600101012.A13
3600101012
|
£18.96
|
£22.75
|
|
|
39 - GROOVE BALL BEARING 17x47x14
BSD-1900900382.A6
1900900382
|
£33.74
|
£40.49
|
|
|
40 - THREADED RING
BSD-3603344060.A2
3603344060
|
£23.86
|
£28.63
|
|
|
41 - RADIAL SEAL
BSD-3600283010.A15
3600283010
|
£18.96
|
£22.75
|
|
|
42 - SPRING RETAINING RING DIN 471 17x1 MM
BSD-2916650008.A328
2916650008
|
£1.75
|
£2.10
|
|
|
44 - CYLINDRICAL GEAR Z=16
BSD-3606316091.A16
3606316091
|
£2.80
|
£3.36
|
|
|
45 - PLANETARY-GEAR CARRIER
BSD-3606337043.A1
3606337043
|
£156.22
|
£187.46
|
|
|
47 - THRUST BEARING DISC
BSD-1610101608.A64
1610101608
|
£2.16
|
£2.59
|
|
|
48 - STOP DISC
BSD-3600100006.A12
3600100006
|
£5.58
|
£6.70
|
|
|
49 - NEEDLE ROLLER
BSD-3603201030.A12
3603201030
|
£2.80
|
£3.36
|
|
|
50 - GROOVE BALL BEARING
BSD-3600905103.A11
3600905103
|
£23.86
|
£28.63
|
|
|
56 - CONNECTION HOUSING
BSD-3605190052.A5
3605190052
|
£195.26
|
£234.31
|
|
|
57 - PROTECTION SLEEVE
BSD-3600400003.A1
3600400003
|
£45.67
|
£54.80
|
|
|
59 - STRAINER
BSD-3600002000.A289
3600002000
|
£3.72
|
£4.47
|
|
|
66 - STRAIGHT PIN
BSD-3604710006.A48
3604710006
|
£8.67
|
£10.41
|
|
|
77 - HOLDING PIN
BSD-3603203006.A9
3603203006
|
£5.58
|
£6.70
|
|
|
78 - BALL
BSD-3603230012.A1
3603230012
|
£14.91
|
£17.89
|
|
|
95 - NAMEPLATE
BSD-3601100430.A12
3601100430
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110331.A78
3601110331
|
£3.72
|
£4.47
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A35
3603133000
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1846
3601119236
|
£3.72
|
£4.47
|
|
|
100 - DETENT PIN
BSD-1603124085.A49
1603124085
|
£3.72
|
£4.47
|
|
|
101 - GUIDE SLEEVE
BSD-1600506009.A57
1600506009
|
£7.36
|
£8.83
|
|
|
102 - COMPRESSION SPRING
BSD-1604611019.A44
1604611019
|
£2.80
|
£3.36
|
|
|
701 - FASTENING FLANGE
BSD-3605700047.A6
3605700047
|
£102.57
|
£123.08
|
|
|
750 - SILENCER
BSD-3607000073.A230
3607000073
|
£18.96
|
£22.75
|
|
|
751 - HOSE FITTING
BSD-2603386002.A153
2603386002
|
£5.30
|
£6.36
|
|
|
801 - MOTOR SPARE PARTS SET
BSD-3607031098.A5
3607031098
|
£410.78
|
£492.94
|
|
|
802 - PARTS SET
BSD-3607010019.A8
3607010019
|
£14.91
|
£17.89
|
|
|
803 - PARTS SET
BSD-3607010022.A7
3607010022
|
£16.41
|
£19.69
|
|
|
804 - PARTS SET
BSD-3607030254.A6
3607030254
|
£27.23
|
£32.68
|
|
|
860 - O-RING 10x2 MM
BSD-1900210306.A105
1900210306
|
£1.75
|
£2.10
|
|
