- Compact light weight, suitable also for one-handed transport
- Sliding function for wide work pieces.
- Easy transport thanks to ergonomically-designed handles and saw head lock
- Robust die-cast aluminium design for highest demands
- Effective dust extraction via integrated dust scoop.
- Fast and precise setting of common angles using stop points
- Laser for exact display of the cutting line (mains powered, no batteries required)
- Infinitely extendable table width extension, removable to put long panels, slabs etc. underneath
- Bright LED work light for illumination of the cutting line (mains powered, no batteries required)
- High sliding rear fence profiles for safe sawing
- Material clamp for secure fixing of the work piece from the top or front
- Depth stop for easy creation of grooves
- Saw head can be inclined to the left, with additional angle range for undercuts
- All scales and operating elements are visible from the working position and can be operated intuitively
- Easy saw blade change by means of spindle lock: No dismantling of the pendulum protective cover required
Specification:
Dimensions L x W x H : 760 x 475 x 340 mm
Maximum cutting width 90°/45° : 305 mm/205 mm
Maximum cutting depth at 90°/45° : 65 mm/36 mm
Maximum cross-section of the workpiece
- Straight cut 90°/90° : 305 x 65 mm
- Double mitre 45°/45° : 205 x 36 mm
Turntable setting left/right : 47 °/47 °
Saw blade tilt left/right : 47 °/2 °
Saw blade : Ø 216 x 30 mm
Rated input power S1 100% : 1.200 W
Rated input power S6 20% : 1.500 W
Idle revolution : 5.000 /min
Revolutions at rated load : 3.750 /min
Weight : 13,5 kg
Cable length : 2 m
Includes:
Carbide saw blade (40 teeth)
2 Table length extensions
Length guide
Material clamp
Tool for saw blade change
Cable winder
Chip collection bags
