2 - POLE HOUSING 24V
BSD-1615100007.A50
1615100007
|
-
|
|
|
|
3 - ARMATURE WITH FAN 220-240V
BSD-2604010904.A0
2604010904
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-1607000231.A132
1607000231
|
£18.96
|
£22.75
|
|
|
8 - NAMEPLATE
BSD-2601105051.A26
2601105051
|
-
|
|
|
|
9 - STICKER
BSD-2601110814.A0
2601110814
|
-
|
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A140
2600905021
|
£8.67
|
£10.41
|
|
|
16 - BRUSH HOLDER
BSD-2604329000.A4
2604329000
|
-
|
|
|
|
17 - BRUSH HOLDER
BSD-2604329001.A0
2604329001
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2303
2603410001
|
£1.75
|
£2.10
|
|
|
20 - STICKER
BSD-2601110447.A0
2601110447
|
-
|
|
|
|
21 - SOCKET-TERMINAL STRIP 1x1.5 MM/2
BSD-1901091012.A5
1901091012
|
£5.30
|
£6.36
|
|
|
22 - ELEC. CABLE W/CONNECTION
BSD-2604448080.A0
2604448080
|
-
|
|
|
|
23 - CABLE
BSD-2604448081.A4
2604448081
|
-
|
|
|
|
24 - REDUCTION SLEEVE
BSD-2600499012.A1
2600499012
|
-
|
|
|
|
27 - SCREW AND WASHER ASSEMBLY DIN7985-M4x18Z1-4.8
BSD-2914500009.A19
2914500009
|
-
|
|
|
|
29 - SHIM 0.5 MM
BSD-2600102014.A21
2600102014
|
-
|
|
|
|
30 - ECCENTRIC COG WHEEL Z=39
BSD-2606319900.A14
2606319900
|
-
|
|
|
|
32 - NEEDLE-ROLLER CAGE
BSD-2600913010.A0
2600913010
|
-
|
|
|
|
33 - NEEDLE ROLLER 1.5x5.8 MM
BSD-2603201037.A4
2603201037
|
£2.61
|
£3.13
|
|
|
34 - SPACER SLEEVE
BSD-2600203001.A9
2600203001
|
-
|
|
|
|
35 - SHIM 0.3 MM
BSD-2600100570.A120
2600100570
|
£1.75
|
£2.10
|
|
|
36 - LOCKING WASHER DIN 6799-5-FSt
BSD-2916080008.A42
2916080008
|
-
|
|
|
|
37 - SHIM 0.5 MM
BSD-2600100568.A84
2600100568
|
£1.75
|
£2.10
|
|
|
37 - SHIM 0.3 MM
BSD-2600100607.A317
2600100607
|
£1.75
|
£2.10
|
|
|
38 - NEEDLE BEARING
BSD-2600917900.A24
2600917900
|
£8.67
|
£10.41
|
|
|
39 - GUIDE SLEEVE
BSD-2600400024.A31
2600400024
|
£2.80
|
£3.36
|
|
|
40 - SUPPORTING DISC
BSD-2600103013.A80
2600103013
|
£1.32
|
£1.58
|
|
|
41 - SPACER SLEEVE
BSD-2600200024.A0
2600200024
|
-
|
|
|
|
42 - SHIM 0.3 MM
BSD-2600101083.A39
2600101083
|
-
|
|
|
|
43 - FORK LEVER
BSD-2601923003.A19
2601923003
|
-
|
|
|
|
44 - STRAIGHT PIN 4M6x12DIN6325
BSD-2917530095.A39
2917530095
|
-
|
|
|
|
45 - SUPPORT PLATE
BSD-2601098006.A39
2601098006
|
£1.75
|
£2.10
|
|
|
46 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A132
2603490017
|
£2.16
|
£2.59
|
|
|
48 - SEALING PLATE
BSD-2601015006.A0
2601015006
|
-
|
|
|
|
49 - SEALING PLATE
BSD-2601015900.A19
2601015900
|
-
|
|
|
|
51 - STRAIGHT PIN DIN 6325-4M6x24
BSD-2917530101.A60
2917530101
|
£2.80
|
£3.36
|
|
|
55 - LIFTING ROD
BSD-2600780038.A18
2600780038
|
-
|
|
|
|
56 - CLAMP SCREW
BSD-2603400000.A42
2603400000
|
£4.26
|
£5.11
|
|
|
57 - SHIM 0.5 MM
BSD-2600101612.A248
2600101612
|
£1.75
|
£2.10
|
|
|
59 - COMPRESSION SPRING
BSD-2604613000.A48
2604613000
|
£1.75
|
£2.10
|
|
|
61 - GUIDE
BSD-2601000034.A10
2601000034
|
-
|
|
|
|
62 - SINTERED-METAL BUSHING
BSD-2600302006.A0
2600302006
|
-
|
|
|
|
63 - SWITCH HANDLE
BSD-2602026035.A43
2602026035
|
-
|
|
|
|
64 - RATCHET CAP
BSD-2600590006.A540
2600590006
|
£1.75
|
£2.10
|
|
|
65 - REFERENCE PLATE
BSD-2601110307.A9
2601110307
|
-
|
|
|
|
66 - FIXING PLATE
BSD-2601030006.A95
2601030006
|
-
|
|
|
|
67 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x12-8.8
BSD-2910141122.A214
2910141122
|
£2.16
|
£2.59
|
|
|
68 - PROFILE BEADING
BSD-2602317025.A65
2602317025
|
-
|
|
|
|
69 - BASE PLATE
BSD-2601016901.A0
2601016901
|
-
|
|
|
|
70 - OFFSET SCREWDRIVER DIN 911. SW3
BSD-1907950004.A101
1907950004
|
£5.58
|
£6.70
|
|
|
71 - DAMPING PLATE
BSD-2601022000.A116
2601022000
|
£1.75
|
£2.10
|
|
|
72 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A46
2912401020
|
£2.16
|
£2.59
|
|
|
73 - CROSS RECESSED-HEAD SCREW DIN 7981-ST 3.9x13-F-H
BSD-2910611418.A12
2910611418
|
-
|
|
|
|
74 - FAN
BSD-2606610047.A79
2606610047
|
-
|
|
|
|
75 - FELT WASHER
BSD-1600205023.A65
1600205023
|
£1.32
|
£1.58
|
|
|
76 - O-RING 8.0x2.5 MM
BSD-1610210014.A117
1610210014
|
-
|
|
|
|
77 - HOLDING SPRING
BSD-1619P09928.A0
1619P09928
|
£1.75
|
£2.10
|
|
|
78 - FIXING PLATE
BSD-2601030020.A4
2601030020
|
-
|
|
|
|
79 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-8.8
BSD-2910021162.A35
2910021162
|
-
|
|
|
|
80 - CONNECTION HOUSING
BSD-2605190003.A4
2605190003
|
-
|
|
|
|
81 - SLIDE FLAP
BSD-2601099024.A4
2601099024
|
-
|
|
|
|
82 - HOLDING SPRING
BSD-2601251001.A0
2601251001
|
-
|
|
|
|
83 - NEEDLE ROLLER A 3x15.8G2DIN5402
BSD-1903201044.A49
1903201044
|
£2.33
|
£2.80
|
|
|
84 - ACCUMULATOR BATTERY 12V. 1.2Ah. NiCd
BSD-2607335010.A18
2607335010
|
-
|
|
|
|
87 - STICKER
BSD-2601110461.A21
2601110461
|
-
|
|
|
|
780 - FAST CHARGER EU 230/7.2-24V. 1h
BSD-2607224425.A151
2607224425
|
£88.07
|
£105.68
|
|
|
801 - HOUSING SECTION
BSD-2605104974.A0
2605104974
|
-
|
|
|
|
813 - SINTERED-METAL BUSHING
BSD-1600301900.A48
1600301900
|
-
|
|
|
|
825 - BEARING BRACKET
BSD-2605807908.A14
2605807908
|
-
|
|
|
|
847 - ROLLER LEVER
BSD-2601321900.A20
2601321900
|
-
|
|
|
|
858 - SUPPORT PLATE
BSD-2602316900.A11
2602316900
|
-
|
|
|
|
890 - VW ACCU COMPASS SAW
BSD-0601922020.A0
0601922020
|
-
|
|
|
