3/50 - FAN
BSD-3606610002.A51
3606610002
|
£2.33
|
£2.80
|
|
|
4 - SWITCH
BSD-3607200066.A16
3607200066
|
£11.30
|
£13.56
|
|
|
5 - POWER SUPPLY CORD I / BR 4.15m 2 x 1.0mm H05 RN-F
BSD-2604460284.A16
2604460284
|
-
|
|
|
|
6 - GROMMET dia7.2-dia9.5x81 MM
BSD-1600703026.A64
1600703026
|
£2.16
|
£2.59
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1919
2601035001
|
£1.75
|
£2.10
|
|
|
8 - NAMEPLATE
BSD-3601110314.A0
3601110314
|
-
|
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-3601110261.A4
3601110261
|
£3.80
|
£4.56
|
|
|
11 - RUBBER BUFFER
BSD-1603100036.A53
1603100036
|
£1.75
|
£2.10
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A381
1607328028
|
£5.30
|
£6.36
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A320
1610905025
|
£6.52
|
£7.83
|
|
|
14 - GROOVE BALL BEARING
BSD-1600900042.A71
1600900042
|
£5.58
|
£6.70
|
|
|
15 - CONTACT SPRING
BSD-3604680003.A5
3604680003
|
£1.75
|
£2.10
|
|
|
16 - BRUSH HOLDER
BSD-3604336002.A5
3604336002
|
£11.30
|
£13.56
|
|
|
18 - HOUSING COVER
BSD-3605500130.A0
3605500130
|
£9.49
|
£11.39
|
|
|
19 - TAPPING SCREW TORX ST 3.9x19-C-Z
BSD-3603435009.A0
3603435009
|
-
|
|
|
|
20 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A431
2910211006
|
£1.75
|
£2.10
|
|
|
21 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1438
2603410001
|
£1.75
|
£2.10
|
|
|
23 - CONNECTING CABLE L=280 MM
BSD-3604411036.A7
3604411036
|
£3.72
|
£4.47
|
|
|
24 - CONNECTING CABLE L=180 MM
BSD-3604411038.A4
3604411038
|
£2.52
|
£3.02
|
|
|
25 - REJECTION SLIDE
BSD-3602329028.A15
3602329028
|
£1.75
|
£2.10
|
|
|
26 - COMPRESSION SPRING
BSD-3604610041.A16
3604610041
|
£1.75
|
£2.10
|
|
|
32 - SCREW 4x16
BSD-2603490022.A1660
2603490022
|
£1.75
|
£2.10
|
|
|
33 - GEAR COVER
BSD-3605500133.A15
3605500133
|
£12.04
|
£14.45
|
|
|
34 - PLAIN BEARING
BSD-3600929027.A13
3600929027
|
£6.52
|
£7.83
|
|
|
35 - PLAIN BEARING
BSD-3600929030.A6
3600929030
|
£5.30
|
£6.36
|
|
|
36 - NEEDLE BEARING
BSD-3600913008.A28
3600913008
|
£3.72
|
£4.47
|
|
|
37 - FRICTION WASHER
BSD-3600102045.A13
3600102045
|
£1.75
|
£2.10
|
|
|
38 - SPRING RETAINING RING DIN 471-12x1-FSTM
BSD-2916650903.A15
2916650903
|
£1.75
|
£2.10
|
|
|
39 - SPRING RETAINING RING DIN 472-26x1.2 MM
BSD-2916660010.A117
2916660010
|
£1.75
|
£2.10
|
|
|
45 - CLAMP SPRING
BSD-3604651020.A2
3604651020
|
£2.61
|
£3.13
|
|
|
46 - THREAD-FORMING TAP. SCREW M3x8
BSD-3603391003.A34
3603391003
|
£2.16
|
£2.59
|
|
|
47 - HEX SOCKET HEAD CAP SCREW M 6x16 MM
BSD-3603410020.A6
3603410020
|
£1.75
|
£2.10
|
|
|
50 - BASE BODY
BSD-3602319021.A6
3602319021
|
£12.04
|
£14.45
|
|
|
51 - BASE BODY
BSD-3602319022.A13
3602319022
|
£12.04
|
£14.45
|
|
|
52 - BOW
BSD-3601921005.A3
3601921005
|
£5.58
|
£6.70
|
|
|
53 - ACTUATING ELEMENT
BSD-3600522002.A6
3600522002
|
£3.72
|
£4.47
|
|
|
54 - COMPRESSION SPRING
BSD-3604682004.A15
3604682004
|
£2.16
|
£2.59
|
|
|
55 - LOCKING WASHER
BSD-3600112002.A16
3600112002
|
£1.75
|
£2.10
|
|
|
56 - SUPPRESSION FILTER
BSD-3604463010.A9
3604463010
|
£5.87
|
£7.04
|
|
|
66 - HEX SOCKET HEAD CAP SCREW M6
BSD-3603386041.A16
3603386041
|
£1.75
|
£2.10
|
|
|
70 - AUXILIARY HANDLE
BSD-3605132063.A6
3605132063
|
£18.96
|
£22.75
|
|
|
71 - DISTANCE PIPE
BSD-3600723012.A4
3600723012
|
£7.36
|
£8.83
|
|
|
72 - ROUND-HEAD BOLT
BSD-3603300015.A12
3603300015
|
£2.80
|
£3.36
|
|
|
73 - HANDWHEEL M6
BSD-3602317021.A16
3602317021
|
£4.26
|
£5.11
|
|
|
74 - HANDWHEEL M6
BSD-3602317020.A3
3602317020
|
£4.26
|
£5.11
|
|
|
75 - HEX NUT
BSD-3603435044.A16
3603435044
|
£2.16
|
£2.59
|
|
|
76 - CLAMPING PIECE
BSD-3601329018.A16
3601329018
|
£1.75
|
£2.10
|
|
|
79 - SUCTION CHANNEL
BSD-3602317017.A16
3602317017
|
£21.52
|
£25.83
|
|
|
81 - REFERENCE PLATE
BSD-3601110332.A6
3601110332
|
£2.61
|
£3.13
|
|
|
763/2 - SAW BLADE SET 350 MM
BSD-2608632120.A6
2608632120
|
£22.56
|
£27.07
|
|
|
763/3 - SAW BLADE SET 350 MM
BSD-2608632123.A4
2608632123
|
£45.12
|
£54.14
|
|
|
802 - FIELD 230V
BSD-1607000711.A3
1607000711
|
£61.98
|
£74.38
|
|
|
803 - ARMATURE 220-230V
BSD-3604010077.A0
3604010077
|
-
|
|
|
|
816/02 - CARBON BRUSH
BSD-3604321012.A5
3604321012
|
£12.04
|
£14.45
|
|
|
816/03 - SPIRAL SPRING
BSD-3604652500.A16
3604652500
|
£1.75
|
£2.10
|
|
|
829 - GEAR HOUSING
BSD-3605109010.A4
3605109010
|
£81.81
|
£98.17
|
|
|
830 - LIFT GEAR Z=78
BSD-3602319020.A12
3602319020
|
£120.11
|
£144.13
|
|
|
840 - INSULATING PLATE 20x20x50 MM
BSD-1602381006.A189
1602381006
|
£1.75
|
£2.10
|
|
|
844 - SEAL KIT
BSD-3600929039.A6
3600929039
|
£16.41
|
£19.69
|
|
|
845 - LATERAL GUIDE
BSD-3600929034.A13
3600929034
|
-
|
|
|
|
863/01 - SWORD 350 MM
BSD-2608045017.A8
2608045017
|
£33.74
|
£40.49
|
|
|
863/09 - GUARD PROFILE 350 MM
BSD-2601329049.A4
2601329049
|
£2.80
|
£3.36
|
|
