1 - MOTOR HOUSING
BSD-1605108124.A41
1605108124
|
-
|
|
|
|
2 - FIELD 115V
BSD-1604220247.A3
1604220247
|
-
|
|
|
|
2/8 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A36
1901350003
|
£1.75
|
£2.10
|
|
|
3 - ARMATURE 110-115V
BSD-1604012055.A1
1604012055
|
-
|
|
|
|
4/1 - ON-OFF SWITCH
BSD-1607200090.A1
1607200090
|
-
|
|
|
|
5 - POWER SUPPLY CORD GB 110V 4.15m 2 x 2.5mm H07 RN-F
BSD-1604460202.A17
1604460202
|
£45.67
|
£54.80
|
|
|
5/2/20 - END SPLICE DIN 46 228-A2.5-7
BSD-1900452003.A64
1900452003
|
£2.61
|
£3.13
|
|
|
6/1 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A134
1600703009
|
£5.58
|
£6.70
|
|
|
7 - FASTENING CLAMP
BSD-1601302013.A429
1601302013
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110003.A275
1601110003
|
-
|
|
|
|
11 - SUPPRESSION FILTER
BSD-1607328034.A186
1607328034
|
£4.26
|
£5.11
|
|
|
16 - BRUSH HOLDER
BSD-1604336008.A138
1604336008
|
£21.52
|
£25.83
|
|
|
19/8 - FELT WASHER
BSD-1600205019.A25
1600205019
|
£1.75
|
£2.10
|
|
|
20 - BEARING COVER
BSD-1605808054.A178
1605808054
|
-
|
|
|
|
21 - COVER DISC
BSD-1600102012.A187
1600102012
|
-
|
|
|
|
22 - GRINDING SPINDLE M14. L=101 MM
BSD-1603523090.A158
1603523090
|
-
|
|
|
|
23 - SEALING DISK
BSD-1600108055.A43
1600108055
|
£1.75
|
£2.10
|
|
|
27 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A502
2600910001
|
£4.26
|
£5.11
|
|
|
28 - RUBBER RING dia41xdia37x7.5 MM
BSD-1600206029.A15
1600206029
|
£2.61
|
£3.13
|
|
|
29 - GUIDE PULLEY
BSD-1600502013.A104
1600502013
|
-
|
|
|
|
30 - SPRING RETAINING RING
BSD-1600119004.A93
1600119004
|
£2.80
|
£3.36
|
|
|
31 - SPIRAL SPRING
BSD-1604652015.A555
1604652015
|
£2.80
|
£3.36
|
|
|
32 - ROTARY SHAFT LIP SEAL
BSD-1600290008.A25
1600290008
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A10
1600190004
|
-
|
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A274
1600190005
|
£1.32
|
£1.58
|
|
|
35 - TAB WASHER
BSD-1601030022.A594
1601030022
|
£1.75
|
£2.10
|
|
|
36 - RUBBER RING
BSD-1600206015.A141
1600206015
|
£2.16
|
£2.59
|
|
|
40 - SPRING WASHER dia32.3xdia43.5x0.6 MM
BSD-1600150009.A24
1600150009
|
£2.80
|
£3.36
|
|
|
41 - SEALING CAP
BSD-1605500089.A141
1605500089
|
-
|
|
|
|
42/1 - HANDLE
BSD-1605133038.A0
1605133038
|
-
|
|
|
|
45 - HOLDING BRACKET
BSD-1601331032.A64
1601331032
|
-
|
|
|
|
50 - GROOVE BALL BEARING 17x40x12
BSD-1900905203.A48
1900905203
|
-
|
|
|
|
52 - GROOVE BALL BEARING 37x12x12
BSD-1600900028.A47
1600900028
|
-
|
|
|
|
53 - GROOVE BALL BEARING
BSD-1600900029.A97
1600900029
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A978
2910021118
|
£1.75
|
£2.10
|
|
|
55 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A437
2910211021
|
£1.75
|
£2.10
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A517
2910011157
|
-
|
|
|
|
58 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A410
2910211020
|
£2.16
|
£2.59
|
|
|
59 - TAPPING SCREW B4.8x45 MM
BSD-1603412005.A16
1603412005
|
-
|
|
|
|
60/1 - TORX OVAL-HEAD SCREW
BSD-2914201529.A43
2914201529
|
£1.75
|
£2.10
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A241
2910011162
|
£1.75
|
£2.10
|
|
|
63 - TAPPING SCREW B4.8x85 MM
BSD-1603429001.A42
1603429001
|
-
|
|
|
|
66/1 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A919
2910211019
|
£1.75
|
£2.10
|
|
|
69 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A342
2910211011
|
£1.75
|
£2.10
|
|
|
73 - RETAINING SNAP RING
BSD-1600224033.A4
1600224033
|
-
|
|
|
|
77 - SOCKET-TERMINAL STRIP 1x1.5 MM/2
BSD-1901091012.A89
1901091012
|
£5.30
|
£6.36
|
|
|
78/1 - END SPLICE DIN 46 228-A2.5-7
BSD-1900452003.A66
1900452003
|
£2.61
|
£3.13
|
|
|
90/1 - HEX SCREW DIN 933-M14x28-8.8
BSD-2911061389.A0
2911061389
|
-
|
|
|
|
91 - SPACER BUSHING
BSD-1600322035.A1
1600322035
|
-
|
|
|
|
92/1 - CONNECTING CABLE
BSD-1604413003.A0
1604413003
|
-
|
|
|
|
93/1 - SOCKET-TERMINAL STRIP 2x2.5 MM
BSD-1601091010.A1
1601091010
|
-
|
|
|
|
94/1 - TAPPING SCREW DIN 7971-BZ2.9x19
BSD-2910211008.A6
2910211008
|
-
|
|
|
|
96/1 - LOCKING LEVER
BSD-1602099002.A0
1602099002
|
-
|
|
|
|
98/1 - COMPRESSION SPRING
BSD-1604625008.A5
1604625008
|
-
|
|
|
|
100 - GROOVED RING
BSD-1600390011.A0
1600390011
|
-
|
|
|
|
150 - END SPLICE DIN 46 228-A2.5-7
BSD-1900452003.A65
1900452003
|
£2.61
|
£3.13
|
|
|
650/1 - STRAP-SHAPED HANDLE
BSD-1600793004.A18
1600793004
|
-
|
|
|
|
651/10 - OFFSET SCREWDRIVER DIN 911 SW10
BSD-1907950009.A158
1907950009
|
£21.68
|
£26.01
|
|
|
651/11 - CLAMPING-FLANGE
BSD-1605703137.A3
1605703137
|
-
|
|
|
|
651/12 - ROUND NUT
BSD-2603345008.A15
2603345008
|
£54.42
|
£65.30
|
|
|
651/13 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A5
2607950511
|
£4.26
|
£5.11
|
|
|
651/15 - CONICAL SPRING WASHER
BSD-2605703022.A0
2605703022
|
£54.42
|
£65.30
|
|
|
652 - PROTECTIVE COVER dia 300 MM
BSD-2605510079.A1
2605510079
|
-
|
|
|
|
652/20 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x18-8.8
BSD-2910141240.A11
2910141240
|
£1.32
|
£1.58
|
|
|
652/21 - REFERENCE PLATE
BSD-1601110084.A4
1601110084
|
-
|
|
|
|
653 - GUIDE BLOCK
BSD-2608190024.A5
2608190024
|
-
|
|
|
|
653/1 - ROUND-HEAD BOLT M 8x30 DIN 603
BSD-2910281246.A3
2910281246
|
-
|
|
|
|
653/2 - WING NUT DIN 315-M8-GT-C
BSD-2915191007.A237
2915191007
|
£3.72
|
£4.47
|
|
|
653/3 - PLAIN WASHER 1.5 MM
BSD-1600100021.A3
1600100021
|
-
|
|
|
|
653/4 - COMPRESSION SPRING
BSD-1604643003.A90
1604643003
|
£6.52
|
£7.83
|
|
|
703 - PARTS SET
BSD-1607000140.A69
1607000140
|
-
|
|
|
|
703/11 - HEX SCREW M14x16x1.5 MM
BSD-2603450007.A314
2603450007
|
£5.58
|
£6.70
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A25
1607014103
|
£14.91
|
£17.89
|
|
|
801 - CONNECTING CABLE
BSD-1604440004.A13
1604440004
|
-
|
|
|
|
802 - CROWN GEAR Z=62. M8
BSD-1606333206.A10
1606333206
|
-
|
|
|
|
803 - BEVEL GEAR Z=13
BSD-1606333227.A18
1606333227
|
-
|
|
|
|
807 - PARTS SET
BSD-1607000917.A45
1607000917
|
-
|
|
|
|
813 - PARTS SET
BSD-1607000161.A76
1607000161
|
-
|
|
|
|
817 - BEARING FLANGE
BSD-1607000229.A192
1607000229
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A5244
160111A3H3
|
£2.61
|
£3.13
|
|
