2 - FIELD 220V
BSD-1604220134.A0
1604220134
|
-
|
|
|
|
2/10 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A103
1901350003
|
£1.75
|
£2.10
|
|
|
3 - ARMATURE 220V
BSD-1604010162.A2
1604010162
|
-
|
|
|
|
4/2 - SWITCH
BSD-1607200074.A3
1607200074
|
£31.64
|
£37.97
|
|
|
4/10 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A91
2910091118
|
£1.75
|
£2.10
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A404
3600703011
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A7
1600703009
|
£5.58
|
£6.70
|
|
|
7/1 - FASTENING CLAMP
BSD-1601302014.A213
1601302014
|
£2.61
|
£3.13
|
|
|
9 - STICKER
BSD-1601110046.A149
1601110046
|
£1.75
|
£2.10
|
|
|
11 - SUPPRESSION FILTER
BSD-1607328034.A118
1607328034
|
£4.26
|
£5.11
|
|
|
15 - GEAR HOUSING
BSD-1605806360.A0
1605806360
|
-
|
|
|
|
17 - BEARING FLANGE
BSD-1605805054.A25
1605805054
|
-
|
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1600502012.A0
1600502012
|
-
|
|
|
|
19 - SEALING CAP
BSD-1605500127.A7
1605500127
|
-
|
|
|
|
20 - COVER PLATE
BSD-1601037007.A2
1601037007
|
-
|
|
|
|
22 - INTERMEDIATE RING
BSD-1600502018.A7
1600502018
|
-
|
|
|
|
23/8 - FELT WASHER
BSD-1600205008.A260
1600205008
|
£1.75
|
£2.10
|
|
|
25 - TAB WASHER
BSD-1601030022.A470
1601030022
|
£1.75
|
£2.10
|
|
|
27 - INTERMEDIATE RING
BSD-1600206018.A51
1600206018
|
-
|
|
|
|
30 - SPACER BUSHING
BSD-1600500022.A0
1600500022
|
-
|
|
|
|
31 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A667
2916660013
|
£2.16
|
£2.59
|
|
|
32 - GRINDING SPINDLE M14
BSD-1603523086.A41
1603523086
|
-
|
|
|
|
35 - SHIM 0.1 MM
BSD-2600136002.A54
2600136002
|
-
|
|
|
|
35 - SHIM 0.2 MM
BSD-2600136003.A11
2600136003
|
-
|
|
|
|
37 - ROTARY SHAFT LIP SEAL
BSD-1600290011.A8
1600290011
|
-
|
|
|
|
38 - CROWN GEAR Z=33
BSD-1606333182.A7
1606333182
|
-
|
|
|
|
39 - SPIRAL SPRING
BSD-1604652006.A266
1604652006
|
£1.75
|
£2.10
|
|
|
40 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A215
2600910001
|
£4.26
|
£5.11
|
|
|
41 - CONNECTING CABLE L=260 MM
BSD-1604440008.A42
1604440008
|
-
|
|
|
|
41/10 - TERMINAL LUG
BSD-1601353003.A0
1601353003
|
-
|
|
|
|
43 - SEAL
BSD-1600113013.A5
1600113013
|
£1.32
|
£1.58
|
|
|
45 - GROOVE BALL BEARING 15x32x9
BSD-1600905004.A26
1600905004
|
-
|
|
|
|
46 - BALL BEARING 7x19x6
BSD-2600905032.A1454
2600905032
|
£5.30
|
£6.36
|
|
|
47 - GROOVE BALL BEARING 12x32x10
BSD-1600905006.A154
1600905006
|
£12.04
|
£14.45
|
|
|
50/1 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A75
2910211021
|
£1.75
|
£2.10
|
|
|
52/1 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A770
2910021116
|
£2.16
|
£2.59
|
|
|
53 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A215
2910021118
|
£1.75
|
£2.10
|
|
|
54 - COUNTERSUNK-HEAD SCREW M 4x16 DIN 963-5.8
BSD-2910771126.A23
2910771126
|
-
|
|
|
|
55 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A472
2910211011
|
£1.75
|
£2.10
|
|
|
56 - TAPPING SCREW B4.8x65 MM
BSD-1603435005.A2
1603435005
|
-
|
|
|
|
57 - TAPPING SCREW DIN 7971-ST4.8x38-F
BSD-2910211038.A78
2910211038
|
£1.75
|
£2.10
|
|
|
58 - SCREW B 4.8x45 MM
BSD-3603415560.A182
3603415560
|
£1.75
|
£2.10
|
|
|
59 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A95
2915011005
|
£1.75
|
£2.10
|
|
|
62 - RETAINING RING
BSD-1600116006.A2
1600116006
|
-
|
|
|
|
75/1 - CONNECTING TERMINAL
BSD-1601091009.A12
1601091009
|
-
|
|
|
|
76/1 - END SPLICE
BSD-3604477008.A467
3604477008
|
£1.75
|
£2.10
|
|
|
78/1 - END SPLICE
BSD-1600452001.A23
1600452001
|
-
|
|
|
|
90/1 - PVC HOSE
BSD-1600712026.A9
1600712026
|
-
|
|
|
|
95/1 - STICKER
BSD-1601110265.A330
1601110265
|
-
|
|
|
|
650/10 - AUXILIARY HANDLE M14
BSD-1602025022.A1545
1602025022
|
£13.41
|
£16.09
|
|
|
650/10 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1236
1602025030
|
£18.96
|
£22.75
|
|
|
650/11 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A333
2607950511
|
£4.26
|
£5.11
|
|
|
650/12 - ROUND NUT M14
BSD-1603340015.A4
1603340015
|
£3.87
|
£4.64
|
|
|
650/13 - PIN-TYPE FACE-WRENCH
BSD-1607950052.A568
1607950052
|
£3.72
|
£4.47
|
|
|
650/13/1 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A476
2607950004
|
£1.75
|
£2.10
|
|
|
652 - PROTECTIVE COVER dia 150 MM
BSD-1605510105.A5
1605510105
|
-
|
|
|
|
652/20 - SOCKET HEAD CAP SCREW DIN 84-M 6x16-8.8
BSD-2910022197.A90
2910022197
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014126.A140
1607014126
|
£16.41
|
£19.69
|
|
|
801 - PARTS SET
BSD-1607000145.A4
1607000145
|
-
|
|
|
|
803 - HANDLE
BSD-3605132054.A10
3605132054
|
£21.68
|
£26.01
|
|
|
822 - INTERMEDIATE RING
BSD-1600502011.A552
1600502011
|
£2.61
|
£3.13
|
|
|
824 - BRUSH HOLDER
BSD-1604336017.A90
1604336017
|
£7.36
|
£8.83
|
|
|
835 - POWER SUPPLY CORD EU 4.15m 2 x 1.5mm H07 RN-F
BSD-1607000228.A243
1607000228
|
£23.86
|
£28.63
|
|
|
840 - NEEDLE-ROLLER BEARING dia 17 MM
BSD-1600910009.A18
1600910009
|
-
|
|
|
|
861 - RETAINING RING dia18.4 MM
BSD-1604601022.A3
1604601022
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3753
160111A3H3
|
£2.61
|
£3.13
|
|
