1 - MOTOR HOUSING
BSD-1605108256.A2
1605108256
|
£14.72
|
£17.67
|
|
|
2 - FIELD 220-240V
BSD-1604220416.A0
1604220416
|
£31.64
|
£37.97
|
|
|
7 - CABLE CLIP
BSD-2601035001.A816
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601118K42.A0
1601118K42
|
£2.33
|
£2.80
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A653
2600905032
|
£5.30
|
£6.36
|
|
|
16 - BRUSH HOLDER
BSD-1601323025.A125
1601323025
|
£3.72
|
£4.47
|
|
|
17 - SPIRAL SPRING
BSD-1604652013.A723
1604652013
|
£1.75
|
£2.10
|
|
|
18 - ADJUSTING SLIDE
BSD-1602319021.A0
1602319021
|
£2.16
|
£2.59
|
|
|
19 - COMPRESSION SPRING
BSD-1604611041.A1
1604611041
|
£1.75
|
£2.10
|
|
|
20 - COMPRESSION SPRING
BSD-3604611039.A20
3604611039
|
£1.75
|
£2.10
|
|
|
22 - COVERING HOOD
BSD-1605500260.A18
1605500260
|
£3.72
|
£4.47
|
|
|
25 - HANDLE COVER
BSD-1605132010.A6
1605132010
|
£14.91
|
£17.89
|
|
|
26 - RUBBER RING
BSD-1600206036.A6
1600206036
|
£1.75
|
£2.10
|
|
|
28/32 - GRINDING SPINDLE
BSD-1607000D6A.A125
1607000D6A
|
£7.36
|
£8.83
|
|
|
28/80 - SEALING DISK
BSD-3600150021.A77
3600150021
|
£3.80
|
£4.56
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591025.A189
1600591025
|
£2.61
|
£3.13
|
|
|
33 - O-RING 46.0x1.1 MM
BSD-1600210035.A57
1600210035
|
£1.75
|
£2.10
|
|
|
35 - SHIM 0.1 MM
BSD-1600136013.A497
1600136013
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.15 MM
BSD-1600136020.A21
1600136020
|
£3.72
|
£4.47
|
|
|
35 - SHIM 0.2 MM
BSD-1600136014.A23
1600136014
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.3 MM
BSD-1600136015.A497
1600136015
|
£2.61
|
£3.13
|
|
|
38 - CROWN GEAR Z=38
BSD-1606333616.A90
1606333616
|
£9.49
|
£11.39
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A58
1603300016
|
£1.75
|
£2.10
|
|
|
47 - SCREW 4x16
BSD-2603490022.A506
2603490022
|
£1.75
|
£2.10
|
|
|
48 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A194
1613435034
|
£1.75
|
£2.10
|
|
|
49 - THREAD-FORMING TAP. SCREW
BSD-1603435026.A24
1603435026
|
£2.16
|
£2.59
|
|
|
50 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1380
2603490023
|
£1.75
|
£2.10
|
|
|
53 - TORX OVAL-HEAD SCREW
BSD-1603435078.A245
1603435078
|
£1.75
|
£2.10
|
|
|
54 - THREAD-FORMING TAP. SCREW M4x16
BSD-2914491410.A24
2914491410
|
£1.75
|
£2.10
|
|
|
108 - COVER
BSD-1600A00XC4.A22
1600A00XC4
|
£1.75
|
£2.10
|
|
|
109 - COVER
BSD-1605500263.A2
1605500263
|
£4.26
|
£5.11
|
|
|
304/6 - GROMMET
BSD-1600703040.A57
1600703040
|
£2.16
|
£2.59
|
|
|
304/56 - LENS HEAD SCREW
BSD-1603415004.A18
1603415004
|
£1.75
|
£2.10
|
|
|
321/14 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A409
1600905032
|
£5.58
|
£6.70
|
|
|
321/27 - RUBBER RING
BSD-1600206025.A509
1600206025
|
£2.16
|
£2.59
|
|
|
321/30 - AIR-DEFLECTOR RING
BSD-1600591014.A303
1600591014
|
£2.61
|
£3.13
|
|
|
321/39 - BEVEL GEAR Z=11
BSD-1606333617.A30
1606333617
|
-
|
|
|
|
321/40 - RETAINING CLIP
BSD-1600119011.A218
1600119011
|
£2.16
|
£2.59
|
|
|
321/41 - PLAIN BEARING
BSD-1600200029.A162
1600200029
|
£4.26
|
£5.11
|
|
|
321/104 - O-RING 4.5x1.0 MM
BSD-1600210044.A46
1600210044
|
£1.75
|
£2.10
|
|
|
343 - CATCH LEVER
BSD-1607000742.A2
1607000742
|
£7.36
|
£8.83
|
|
|
343/44 - COMPRESSION SPRING
BSD-1604611042.A215
1604611042
|
£1.75
|
£2.10
|
|
|
651 - PROTECTIVE COVER
BSD-1600A00XK9.A4
1600A00XK9
|
£14.72
|
£17.67
|
|
|
803 - ARMATURE WITH FAN 220-240V
BSD-1604010A21.A14
1604010A21
|
£51.22
|
£61.47
|
|
|
804 - ON-OFF SWITCH
BSD-1607000A85.A10
1607000A85
|
£12.04
|
£14.45
|
|
|
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A228
1607000227
|
£23.86
|
£28.63
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A179
160111A3H3
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014176.A158
1607014176
|
£13.12
|
£15.75
|
|
|
810 - CARBON-BRUSH SET 10 x 1 607 014 176
BSD-1607000482.A33
1607000482
|
£93.88
|
£112.65
|
|
|
813 - PARTS SET
BSD-1607000378.A1
1607000378
|
£6.52
|
£7.83
|
|
|
821 - GEAR HOUSING
BSD-1605806524.A0
1605806524
|
£33.74
|
£40.49
|
|
|
828 - BEARING FLANGE
BSD-1607000D6C.A5
1607000D6C
|
£12.04
|
£14.45
|
|
|
828/04 - O-RING 47.0x1.5 MM
BSD-3600210109.A190
3600210109
|
£2.16
|
£2.59
|
|
|
831 - SPRING ELEMENT
BSD-1601290013.A73
1601290013
|
£1.75
|
£2.10
|
|
|
835 - FAN
BSD-1606610129.A113
1606610129
|
£2.16
|
£2.59
|
|
|
840 - PUSH-BUTTON
BSD-1603231032.A19
1603231032
|
£4.26
|
£5.11
|
|
|
851 - SPEED GOVERNOR
BSD-1607233233.A0
1607233233
|
£48.38
|
£58.06
|
|
|
852 - CONNECTING CABLE
BSD-1604448025.A11
1604448025
|
£2.16
|
£2.59
|
|
|
890 - O-RING 20.35x1.78 MM
BSD-1600210039.A184
1600210039
|
£2.16
|
£2.59
|
|
|
891 - AUXILIARY HANDLE M10 ANTI-VIBRATION
BSD-16020250A0.A21
16020250A0
|
£21.42
|
£25.71
|
|
|
891 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A1012
160202509T
|
£3.72
|
£4.47
|
|
|
892 - ROUND NUT M14
BSD-1603345043.A641
1603345043
|
£8.67
|
£10.41
|
|
|
893 - PIN-TYPE FACE-WRENCH
BSD-1607950052.A228
1607950052
|
£3.72
|
£4.47
|
|
|
895 - CLAMPING FLANGE dia22.3xdia42 MM
BSD-2605703014.A1027
2605703014
|
£7.36
|
£8.83
|
|
|
896 - FAST LOCKING FLANGE M14. SDS-CLIC
BSD-1603340027.A513
1603340027
|
£46.82
|
£56.18
|
|
