1 - MOTOR HOUSING
BSD-2605104309.A35
2605104309
|
£23.86
|
£28.63
|
|
|
2 - FIELD 100-115V
BSD-2604220482.A4
2604220482
|
-
|
|
|
|
3 - ARMATURE 110-115V
BSD-2604010793.A7
2604010793
|
£46.82
|
£56.18
|
|
|
3/60 - FAN
BSD-2606610029.A41
2606610029
|
£2.61
|
£3.13
|
|
|
4 - SWITCH
BSD-2607200210.A1
2607200210
|
£48.38
|
£58.06
|
|
|
5 - POWER SUPPLY CORD GB 110V 2.65m 2 x 1.0mm H05 VV-F
BSD-3604460069.A43
3604460069
|
£37.72
|
£45.27
|
|
|
6 - GROMMET dia6.9 MM
BSD-2600707059.A638
2600707059
|
£3.72
|
£4.47
|
|
|
6 - GROMMET dia11.6-dia12.5x84 MM
BSD-2600707060.A16
2600707060
|
£2.61
|
£3.13
|
|
|
6 - GROMMET dia8.8 MM
BSD-2600707061.A348
2600707061
|
£2.80
|
£3.36
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1251
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-2601110937.A3
2601110937
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A118
2607329114
|
-
|
|
|
|
13 - BALL BEARING 7x22x7
BSD-1900905018.A1092
1900905018
|
£18.96
|
£22.75
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-2600905039.A219
2600905039
|
£12.04
|
£14.45
|
|
|
16 - BRUSH HOLDER
BSD-2604337003.A156
2604337003
|
£2.16
|
£2.59
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A958
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A249
2603490022
|
£1.75
|
£2.10
|
|
|
20 - STICKER
BSD-2601110984.A0
2601110984
|
-
|
|
|
|
26 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A396
1900905163
|
£11.30
|
£13.56
|
|
|
27 - COMPRESSION SPRING
BSD-2604616002.A2
2604616002
|
£1.75
|
£2.10
|
|
|
28 - SPRING RETAINING RING DIN 471 17x1 MM
BSD-2916650008.A281
2916650008
|
£1.75
|
£2.10
|
|
|
29 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A468
2916660014
|
£1.75
|
£2.10
|
|
|
30 - CYLINDRICAL GEAR Z=39
BSD-2606317053.A2
2606317053
|
-
|
|
|
|
31 - CATCH DISK
BSD-2600190052.A207
2600190052
|
£7.78
|
£9.33
|
|
|
32 - SHIM WASHER 0.2 MM
BSD-2600000012.A70
2600000012
|
£1.75
|
£2.10
|
|
|
32 - SHIM WASHER 0.5 MM
BSD-2600000014.A71
2600000014
|
£1.75
|
£2.10
|
|
|
33 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A620
1903230010
|
£1.75
|
£2.10
|
|
|
35 - CATCH DISK
BSD-2600190057.A94
2600190057
|
-
|
|
|
|
36 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A454
2600917003
|
£2.80
|
£3.36
|
|
|
37 - ROTARY KNOB
BSD-2602026017.A25
2602026017
|
£7.36
|
£8.83
|
|
|
38 - SLOTTED SPRING PIN 4x30 MM DIN 7346
BSD-2917780105.A229
2917780105
|
£1.75
|
£2.10
|
|
|
39 - RATCHET CAP
BSD-2600590006.A1233
2600590006
|
£1.75
|
£2.10
|
|
|
40 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A774
2916660008
|
£2.16
|
£2.59
|
|
|
41 - CUPPED WASHER
BSD-2600500002.A157
2600500002
|
£1.75
|
£2.10
|
|
|
42 - FELT WASHER
BSD-2600108077.A66
2600108077
|
£1.75
|
£2.10
|
|
|
43 - RECEPTACLE
BSD-2600400008.A277
2600400008
|
£1.75
|
£2.10
|
|
|
44 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A433
2600914010
|
£2.80
|
£3.36
|
|
|
45 - SHIM 0.3 MM
BSD-2600100607.A1035
2600100607
|
£1.75
|
£2.10
|
|
|
48 - SHIM
BSD-2600150004.A315
2600150004
|
£2.16
|
£2.59
|
|
|
49 - SHIM WASHER 0.3 MM
BSD-2600101027.A183
2600101027
|
£1.75
|
£2.10
|
|
|
49 - SHIM WASHER 0.5 MM
BSD-2600101667.A113
2600101667
|
£1.75
|
£2.10
|
|
|
50 - SCREW
BSD-2603435034.A2
2603435034
|
-
|
|
|
|
51 - HEADLESS SCREW 65 MM
BSD-2603435071.A146
2603435071
|
-
|
|
|
|
52 - STICKER
BSD-2601110076.A76
2601110076
|
-
|
|
|
|
53 - CHANGE-OVER SWITCH
BSD-2607200231.A350
2607200231
|
£16.41
|
£19.69
|
|
|
54 - EARTH CONDUCTOR
BSD-2604448097.A101
2604448097
|
£1.75
|
£2.10
|
|
|
55 - COVER DISC
BSD-2601328033.A124
2601328033
|
-
|
|
|
|
56 - TAPPING SCREW
BSD-2603435086.A332
2603435086
|
£1.75
|
£2.10
|
|
|
57 - HOUSING COVER
BSD-2605132049.A8
2605132049
|
£7.36
|
£8.83
|
|
|
58 - CABLE L=130 MM
BSD-2604448005.A477
2604448005
|
£1.75
|
£2.10
|
|
|
59 - SUPPRESSION FILTER L=126 MM
BSD-2604465097.A132
2604465097
|
£5.58
|
£6.70
|
|
|
60 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1636
2603490017
|
£2.16
|
£2.59
|
|
|
61 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A116
2603490024
|
£1.75
|
£2.10
|
|
|
63 - SHIM 0.5 MM
BSD-2600101616.A194
2600101616
|
-
|
|
|
|
63 - SHIM 0.3 MM
BSD-2600101617.A125
2600101617
|
£1.75
|
£2.10
|
|
|
64 - COUNTERSUNK-HEAD SCREW M6x38/12(dia11)
BSD-2603421208.A26
2603421208
|
-
|
|
|
|
65/800 - CHUCK WRENCH SG2
BSD-2607950007.A970
2607950007
|
£6.52
|
£7.83
|
|
|
66 - GASKET
BSD-2601073012.A11
2601073012
|
£1.75
|
£2.10
|
|
|
67 - RETAINING RING
BSD-2604601004.A452
2604601004
|
£1.75
|
£2.10
|
|
|
68 - CONNECTING CABLE L=98 MM
BSD-2604448074.A2
2604448074
|
£2.16
|
£2.59
|
|
|
69 - CONNECTING CABLE L=68 MM
BSD-2604448100.A38
2604448100
|
£1.75
|
£2.10
|
|
|
70 - CONNECTING CABLE L=110 MM
BSD-2604448146.A42
2604448146
|
£1.75
|
£2.10
|
|
|
85 - SUPPRESSION FILTER L=148 MM
BSD-2604465086.A64
2604465086
|
£5.58
|
£6.70
|
|
|
753 - AUXILIARY HANDLE dia43 MM
BSD-1619P10682.A303
1619P10682
|
£12.49
|
£14.99
|
|
|
753/20 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A913
2915011007
|
-
|
|
|
|
753/30 - WING SCREW M6x(15)55
BSD-1613480007.A277
1613480007
|
£1.75
|
£2.10
|
|
|
753/50 - CLAMPING PLATE M6
BSD-2608040014.A338
2608040014
|
-
|
|
|
|
753/60 - WING SCREW M6x20 MM
BSD-1613480008.A145
1613480008
|
£1.75
|
£2.10
|
|
|
754 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001005.A75
1613001005
|
-
|
|
|
|
765 - CHUCK dia1.5-13 MM. 1/2
BSD-1608571069.A204
1608571069
|
£23.86
|
£28.63
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A471
2604321905
|
£11.30
|
£13.56
|
|
|
825 - GEAR HOUSING
BSD-2605806993.A2
2605806993
|
-
|
|
|
|
834 - INTERMEDIATE FLANGE
BSD-2605700936.A32
2605700936
|
£46.82
|
£56.18
|
|
|
846 - TOOTHED SHAFT
BSD-2606309911.A2
2606309911
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2275
160111A3H3
|
£2.61
|
£3.13
|
|
