2 - FIELD 110-115V
BSD-1614220091.A1
1614220091
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-1617200040.A7
1617200040
|
-
|
|
|
|
5 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.5mm H07 RN-F
BSD-1604460201.A44
1604460201
|
£37.27
|
£44.72
|
|
|
6 - GROMMET dia9.7-dia12x89 MM
BSD-1610703053.A50
1610703053
|
£2.61
|
£3.13
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A623
3600703011
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1611034020.A28
1611034020
|
-
|
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110480.A2
1611110480
|
£1.95
|
£2.34
|
|
|
13 - GROOVE BALL BEARING 9x26x8
BSD-1610905009.A6
1610905009
|
£14.72
|
£17.67
|
|
|
14 - GROOVE BALL BEARING 12x32x10
BSD-1610905008.A5
1610905008
|
-
|
|
|
|
15 - FAN
BSD-1616610067.A7
1616610067
|
-
|
|
|
|
17 - FRICTION WASHER
BSD-1610500013.A9
1610500013
|
-
|
|
|
|
18 - O-RING 16.0x5.0 MM
BSD-1610210040.A34
1610210040
|
-
|
|
|
|
20 - TOOLHOLDER
BSD-1618597054.A0
1618597054
|
-
|
|
|
|
21 - LOCKING BOLT
BSD-1613124014.A3
1613124014
|
-
|
|
|
|
22 - GUIDE BUSHING
BSD-1610506006.A5
1610506006
|
-
|
|
|
|
23 - COMPRESSION SPRING
BSD-1614616002.A7
1614616002
|
-
|
|
|
|
24 - GUIDE BUSHING
BSD-1610320002.A6
1610320002
|
-
|
|
|
|
26 - BIT HOLDER dia 19 MM
BSD-1618598150.A3
1618598150
|
-
|
|
|
|
27 - STOP DISC dia 26 MM
BSD-1610103018.A6
1610103018
|
-
|
|
|
|
28 - SUPPORTING DISC
BSD-1610113011.A1
1610113011
|
-
|
|
|
|
30 - DAMPING BUSHING
BSD-1610523001.A6
1610523001
|
-
|
|
|
|
31 - DAMPING BUSHING
BSD-1610309002.A3
1610309002
|
-
|
|
|
|
32 - SUPPORTING DISC 1.5 MM
BSD-1610101616.A22
1610101616
|
£1.75
|
£2.10
|
|
|
33 - CYLINDRICAL GEAR Z=57/8
BSD-1616317031.A2
1616317031
|
-
|
|
|
|
34 - HAMMER PIPE
BSD-1615806073.A6
1615806073
|
-
|
|
|
|
35 - STRIKER
BSD-1618710048.A6
1618710048
|
-
|
|
|
|
36 - COMPRESSION SPRING
BSD-1614616005.A3
1614616005
|
-
|
|
|
|
37 - HAMMER PISTON
BSD-1618700053.A5
1618700053
|
-
|
|
|
|
38 - COVERING HOOD
BSD-1615190010.A2
1615190010
|
-
|
|
|
|
39 - SEALING FRAME
BSD-1611015030.A5
1611015030
|
-
|
|
|
|
40 - BEARING COVER
BSD-1615808059.A5
1615808059
|
-
|
|
|
|
41 - PISTON PIN
BSD-1613219001.A30
1613219001
|
-
|
|
|
|
42 - BRUSH HOLDER
BSD-1614336005.A5
1614336005
|
£12.04
|
£14.45
|
|
|
43 - BEARING COVER
BSD-1615808068.A3
1615808068
|
-
|
|
|
|
44 - FRAME
BSD-1611015032.A5
1611015032
|
-
|
|
|
|
45 - HANDLE
BSD-1615133027.A8
1615133027
|
-
|
|
|
|
46 - HANDLE COVER
BSD-1615500269.A3
1615500269
|
-
|
|
|
|
48 - BEVEL GEAR Z=35
BSD-1616333018.A6
1616333018
|
-
|
|
|
|
49 - DRIVE BEARING
BSD-1615819011.A26
1615819011
|
-
|
|
|
|
52 - BEARING FLANGE
BSD-1615820086.A4
1615820086
|
-
|
|
|
|
53 - SEALING FRAME
BSD-1611015031.A25
1611015031
|
-
|
|
|
|
56 - TOOTHED SHAFT Z=10
BSD-1613060012.A21
1613060012
|
-
|
|
|
|
59 - PLUG
BSD-1610591010.A10
1610591010
|
-
|
|
|
|
60 - CLAMP HANDLE
BSD-1612026022.A0
1612026022
|
£9.49
|
£11.39
|
|
|
61 - STRAIGHT PIN 5M6x70 RIKO DIN 6325
BSD-2917550138.A30
2917550138
|
-
|
|
|
|
62 - HOLDING SPRING
BSD-1614680003.A3
1614680003
|
-
|
|
|
|
63 - CONTROL FORK
BSD-1611329008.A6
1611329008
|
-
|
|
|
|
64 - SUPPORTING DISC 1.0 MM
BSD-1610102620.A3
1610102620
|
-
|
|
|
|
65 - SUPPORTING DISC 2.5 MM
BSD-1610101617.A8
1610101617
|
-
|
|
|
|
66 - SUPPORTING DISC 0.5 MM
BSD-1610101615.A3
1610101615
|
-
|
|
|
|
68 - SHIM 0.3 MM
BSD-1610101618.A22
1610101618
|
£1.75
|
£2.10
|
|
|
68 - SHIM 0.1 MM
BSD-1610101621.A8
1610101621
|
-
|
|
|
|
72 - SEALING CAP
BSD-1615500284.A2
1615500284
|
-
|
|
|
|
73 - CLAMPING RING
BSD-1610210082.A8
1610210082
|
£1.95
|
£2.34
|
|
|
74 - SPIRAL SPRING
BSD-1614652000.A61
1614652000
|
-
|
|
|
|
75 - SOCKET HOUSING
BSD-1615190011.A6
1615190011
|
-
|
|
|
|
76 - SUPPRESSION FILTER
BSD-1617328016.A23
1617328016
|
-
|
|
|
|
77 - SUPPRESSION FILTER
BSD-1617328017.A7
1617328017
|
£3.72
|
£4.47
|
|
|
78 - CONNECTING CABLE L=35 MM
BSD-1614431022.A5
1614431022
|
-
|
|
|
|
80 - CONTROL DEVICE 100-115V
BSD-1617233007.A1
1617233007
|
-
|
|
|
|
81 - COMPRESSION SPRING
BSD-1614616007.A2
1614616007
|
-
|
|
|
|
82 - COMPRESSION SPRING
BSD-1614616006.A7
1614616006
|
£1.32
|
£1.58
|
|
|
84 - AUXILIARY HANDLE
BSD-160202507H.A71
160202507H
|
£11.30
|
£13.56
|
|
|
84 - AUXILIARY HANDLE M8
BSD-1612025019.A392
1612025019
|
£6.52
|
£7.83
|
|
|
85 - SUPPORT CLAMP
BSD-1618040076.A11
1618040076
|
-
|
|
|
|
86 - STUD BOLT M8
BSD-1613521003.A2
1613521003
|
£9.49
|
£11.39
|
|
|
87 - CLAMPING BAND dia43 MM
BSD-1611316003.A58
1611316003
|
£2.61
|
£3.13
|
|
|
88 - STRAIGHT PIN
BSD-1613100012.A62
1613100012
|
£2.61
|
£3.13
|
|
|
89 - WING SCREW M6x25 MM
BSD-1613480009.A39
1613480009
|
£1.88
|
£2.25
|
|
|
90 - HEX NUT M6
BSD-1613300006.A54
1613300006
|
£1.32
|
£1.58
|
|
|
91 - CLAMPING PLATE
BSD-1611030009.A9
1611030009
|
-
|
|
|
|
92 - STRAIGHT PIN 5M6x12 RIKO DIN 6325
BSD-2917550118.A0
2917550118
|
-
|
|
|
|
98 - GROOVE BALL BEARING
BSD-1610900023.A29
1610900023
|
£12.04
|
£14.45
|
|
|
99 - NEEDLE BEARING
BSD-1610910068.A12
1610910068
|
-
|
|
|
|
100 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A3
2600910001
|
£4.26
|
£5.11
|
|
|
101 - NEEDLE BEARING
BSD-2600910000.A59
2600910000
|
-
|
|
|
|
103 - SPRING LOCK WASHER DIN 128-A8-FST
BSD-2916690007.A29
2916690007
|
£1.75
|
£2.10
|
|
|
105 - RETAINING RING
BSD-1614601004.A2
1614601004
|
-
|
|
|
|
107 - RETAINING RING DIN 9045-24
BSD-2916601012.A2
2916601012
|
£2.52
|
£3.02
|
|
|
108 - O-RING 8x2 MM
BSD-1900210104.A6
1900210104
|
£1.75
|
£2.10
|
|
|
110 - O-RING 54.0x3.0 MM
BSD-1600210004.A256
1600210004
|
£2.80
|
£3.36
|
|
|
111 - O-RING 26.0x3.0 MM
BSD-1610210078.A4
1610210078
|
-
|
|
|
|
112 - O-RING 22.0x4.0 MM
BSD-1610210079.A22
1610210079
|
£5.58
|
£6.70
|
|
|
113 - O-RING 27.5x10.5 MM
BSD-1610210080.A4
1610210080
|
-
|
|
|
|
114 - O-RING 41.0x3.0 MM
BSD-1610210077.A5
1610210077
|
-
|
|
|
|
115 - O-RING 10.0x1.0 MM
BSD-1610210081.A43
1610210081
|
£3.72
|
£4.47
|
|
|
117 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x80-8.8
BSD-2910141262.A5
2910141262
|
£1.75
|
£2.10
|
|
|
118 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x25-8.8
BSD-2910141244.A111
2910141244
|
£1.75
|
£2.10
|
|
|
120 - TAPPING SCREW DIN 7971-ST4.8x38-F
BSD-2910211038.A5
2910211038
|
£1.75
|
£2.10
|
|
|
122 - TAPPING SCREW BZ4.8x63 MM
BSD-1603435008.A184
1603435008
|
£1.32
|
£1.58
|
|
|
123 - TAPPING SCREW DIN 7971-ST4.8x25-C
BSD-2910211236.A53
2910211236
|
£1.75
|
£2.10
|
|
|
125 - TAPPING SCREW DIN 7972-B3.9x13
BSD-2910601118.A34
2910601118
|
£1.75
|
£2.10
|
|
|
126 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A592
2910211011
|
£1.75
|
£2.10
|
|
|
128 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A57
2910021118
|
£1.75
|
£2.10
|
|
|
129 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2715
2603410001
|
£1.75
|
£2.10
|
|
|
131 - MANUFACTURER'S NAMEPLATE
BSD-1611110481.A4
1611110481
|
£1.95
|
£2.34
|
|
|
135 - REFERENCE PLATE
BSD-1611110387.A19
1611110387
|
£1.75
|
£2.10
|
|
|
149 - FELT DISC
BSD-1610108014.A9
1610108014
|
£2.80
|
£3.36
|
|
|
150 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A158
1900452012
|
£1.75
|
£2.10
|
|
|
650 - CARRYING CASE
BSD-1615438148.A3
1615438148
|
-
|
|
|
|
655/10 - PROTECTIVE CAP
BSD-1610508014.A2
1610508014
|
-
|
|
|
|
655/10 - SEALING CAP dia15xdia27.5x36 MM
BSD-1610508001.A25
1610508001
|
-
|
|
|
|
655/20 - PROTECTIVE CAP
BSD-1610508013.A14
1610508013
|
-
|
|
|
|
655/20 - PROTECTIVE CAP
BSD-1610508009.A8
1610508009
|
-
|
|
|
|
801 - ASSEMBLY OF SERVICE PARTS
BSD-1617000938.A5
1617000938
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-1617014110.A78
1617014110
|
£18.96
|
£22.75
|
|
|
812 - SUPPRESSION FILTER
BSD-1617328015.A1
1617328015
|
£5.01
|
£6.01
|
|
|
819 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x25-10.9
BSD-1617000123.A4
1617000123
|
-
|
|
|
|
820 - TOOL HOLDER SET
BSD-1617000912.A5
1617000912
|
-
|
|
|
|
821 - LOCKING BOLT SET
BSD-1617000014.A110
1617000014
|
£24.45
|
£29.34
|
|
|
830 - ARMATURE 100-115V
BSD-1614011039.A1
1614011039
|
-
|
|
|
|
850 - PARTS SET
BSD-1617000927.A0
1617000927
|
-
|
|
|
|
879 - DEPTH-GAUGE SW 6x330 MM
BSD-1613001008.A101
1613001008
|
£8.67
|
£10.41
|
|
|
880 - MODIFICATION SET 100-115V
BSD-1617000160.A0
1617000160
|
-
|
|
|
|
884 - AUXILIARY HANDLE
BSD-1612025039.A8
1612025039
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3166
160111A3H3
|
£2.61
|
£3.13
|
|
|
894 - NEEDLE-ROLLER ASSEMBLY
BSD-1617000169.A4
1617000169
|
-
|
|
|
|
895 - THRUST BEARING DISC 1.0 MM
BSD-1610101008.A4
1610101008
|
-
|
|
|
|
897 - WEAR AND TEAR PART SET
BSD-1617000181.A7
1617000181
|
-
|
|
|
|
898 - WEAR AND TEAR PART SET
BSD-1617000182.A2
1617000182
|
-
|
|
|
|
899 - NEEDLE BEARING
BSD-1610910068.A10
1610910068
|
-
|
|
|
