2 - FIELD 230V
BSD-1619P02042.A1
1619P02042
|
£23.86
|
£28.63
|
|
|
4 - SWITCH
BSD-1617200532.A32
1617200532
|
£21.68
|
£26.01
|
|
|
5 - POWER SUPPLY CORD CH 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1604460450.A28
1604460450
|
£21.68
|
£26.01
|
|
|
6 - GROMMET dia7.3-dia8.6x76 MM
BSD-2600703018.A88
2600703018
|
£2.61
|
£3.13
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1619P31077.A1
1619P31077
|
£2.61
|
£3.13
|
|
|
10 - REFERENCE PLATE
BSD-1619P02477.A3
1619P02477
|
£2.61
|
£3.13
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905031.A1
1610905031
|
£6.52
|
£7.83
|
|
|
16 - BRUSH PLATE
BSD-1614336061.A3
1614336061
|
£18.96
|
£22.75
|
|
|
17 - SUPPRESSION FILTER
BSD-1614465011.A118
1614465011
|
£6.52
|
£7.83
|
|
|
21 - RATCHET SLEEVE
BSD-2608670730.A16
2608670730
|
-
|
|
|
|
22 - CYLINDRICAL GEAR
BSD-1616312003.A22
1616312003
|
£7.36
|
£8.83
|
|
|
26 - HAMMER PISTON
BSD-1618700075.A20
1618700075
|
£12.04
|
£14.45
|
|
|
27 - STRIKER
BSD-1618710080.A17
1618710080
|
£7.36
|
£8.83
|
|
|
28 - STRIKER PIN dia7.5 MM
BSD-1613124077.A27
1613124077
|
£7.36
|
£8.83
|
|
|
29 - PISTON PIN
BSD-1613105012.A80
1613105012
|
£3.72
|
£4.47
|
|
|
34 - SUPPORTING DISC
BSD-1610190067.A60
1610190067
|
£2.16
|
£2.59
|
|
|
36 - TENSIONING BRACKET
BSD-1601329040.A14
1601329040
|
£1.75
|
£2.10
|
|
|
38 - CATCH DISK
BSD-1610190045.A29
1610190045
|
£5.30
|
£6.36
|
|
|
41 - HOUSING COVER
BSD-1615500334.A1
1615500334
|
£8.67
|
£10.41
|
|
|
42 - BACKUP RING
BSD-1610422017.A13
1610422017
|
£4.26
|
£5.11
|
|
|
44 - PROTECTIVE CAP
BSD-1610508047.A139
1610508047
|
£2.29
|
£2.75
|
|
|
45 - AIR-DEFLECTOR RING
BSD-1610522012.A17
1610522012
|
£1.75
|
£2.10
|
|
|
48 - SHIFT PLATE
BSD-1601021005.A22
1601021005
|
£2.16
|
£2.59
|
|
|
50 - COMPRESSION SPRING
BSD-1604611037.A8
1604611037
|
£2.80
|
£3.36
|
|
|
54 - RUBBER BUSHING
BSD-1610502012.A23
1610502012
|
£1.75
|
£2.10
|
|
|
55 - SEAL RING 53.0x7.0 MM
BSD-1610290226.A78
1610290226
|
£3.72
|
£4.47
|
|
|
56 - O-RING
BSD-1616B00086.A7
1616B00086
|
£2.16
|
£2.59
|
|
|
57 - O-RING 24.0x2.5 MM
BSD-1610210068.A412
1610210068
|
£1.75
|
£2.10
|
|
|
59 - O-RING 9.0x2.0 MM
BSD-1610210177.A4
1610210177
|
£2.16
|
£2.59
|
|
|
65 - GROOVE BALL BEARING
BSD-1600900037.A25
1600900037
|
£7.36
|
£8.83
|
|
|
66 - PLAIN BEARING
BSD-1610202020.A20
1610202020
|
£2.16
|
£2.59
|
|
|
67 - NEEDLE BEARING dia7 MM
BSD-1610913019.A1
1610913019
|
£2.80
|
£3.36
|
|
|
68 - ROTARY SHAFT LIP SEAL
BSD-1610283017.A17
1610283017
|
£7.36
|
£8.83
|
|
|
70 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A72
1903230013
|
£2.16
|
£2.59
|
|
|
71 - SHIM WASHER 1.2 MM
BSD-1610101011.A400
1610101011
|
£1.75
|
£2.10
|
|
|
72 - RETAINING RING
BSD-1604601027.A18
1604601027
|
£1.75
|
£2.10
|
|
|
73 - RETAINING RING
BSD-1614601057.A19
1614601057
|
£1.75
|
£2.10
|
|
|
74 - RETAINING RING
BSD-1614601027.A42
1614601027
|
£1.75
|
£2.10
|
|
|
75 - RETAINING WASHER
BSD-1610101629.A78
1610101629
|
£1.75
|
£2.10
|
|
|
76 - SCREW
BSD-1619P02043.A2
1619P02043
|
£1.75
|
£2.10
|
|
|
77 - SCREW
BSD-1619P00106.A3
1619P00106
|
£1.75
|
£2.10
|
|
|
79 - THREAD-FORMING TAP. SCREW
BSD-1613435023.A4
1613435023
|
£1.75
|
£2.10
|
|
|
80 - THREAD-FORMING TAP. SCREW DIN 7981-ST3.5x9.5-F
BSD-1613435007.A15
1613435007
|
£1.75
|
£2.10
|
|
|
87 - RETAINING RING DIN 7993-A22
BSD-2916540012.A46
2916540012
|
-
|
|
|
|
94 - FELT SEAL
BSD-1610205010.A19
1610205010
|
£1.75
|
£2.10
|
|
|
96 - SWITCH BUTTON
BSD-1612026035.A255
1612026035
|
£1.75
|
£2.10
|
|
|
97 - NEEDLE ROLLER
BSD-1903201118.A7
1903201118
|
£1.75
|
£2.10
|
|
|
98 - O-RING 10.5x2.7 MM
BSD-1610210046.A376
1610210046
|
£2.16
|
£2.59
|
|
|
99 - COMPRESSION SPRING
BSD-1614611006.A69
1614611006
|
£3.72
|
£4.47
|
|
|
101 - CONNECTING CABLE
BSD-1614449014.A146
1614449014
|
£2.16
|
£2.59
|
|
|
102 - CONNECTING CABLE
BSD-1614449015.A4
1614449015
|
£1.75
|
£2.10
|
|
|
103 - TORX OVAL-HEAD SCREW 3x10
BSD-1619P00220.A60
1619P00220
|
£1.75
|
£2.10
|
|
|
190 - MANUFACTURER'S NAMEPLATE
BSD-1619P31078.A2
1619P31078
|
£2.61
|
£3.13
|
|
|
651 - FRICTION RING
BSD-1619P04548.A1
1619P04548
|
£3.72
|
£4.47
|
|
|
691/895 - LOCK
BSD-1619P06200.A2
1619P06200
|
£5.87
|
£7.04
|
|
|
801 - MOTOR HOUSING
BSD-1617000523.A15
1617000523
|
£37.27
|
£44.72
|
|
|
803 - ARMATURE WITH FAN 230V
BSD-1619P06110.A0
1619P06110
|
£63.50
|
£76.20
|
|
|
806 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A488
1900452012
|
£1.75
|
£2.10
|
|
|
808 - NAMEPLATE
BSD-1619P30224.A0
1619P30224
|
£2.61
|
£3.13
|
|
|
811 - CARBON-BRUSH SET
BSD-1617000525.A143
1617000525
|
£11.30
|
£13.56
|
|
|
811 - CARBON-BRUSH SET 10 x 1 617 000 525
BSD-1607000485.A16
1607000485
|
£72.18
|
£86.62
|
|
|
814 - GROOVE BALL BEARING 9x24x7
BSD-1610905048.A47
1610905048
|
£8.67
|
£10.41
|
|
|
820 - INTERMEDIATE FLANGE
BSD-1617000526.A7
1617000526
|
£27.23
|
£32.68
|
|
|
821 - RATCHET SLEEVE
BSD-1619P06111.A3
1619P06111
|
£80.61
|
£96.73
|
|
|
822 - AUXILIARY HANDLE
BSD-1619P06104.A1
1619P06104
|
£16.41
|
£19.69
|
|
|
824 - TOOTHED SHAFT
BSD-1617000892.A22
1617000892
|
£58.76
|
£70.51
|
|
|
826 - HAMMER PISTON
BSD-1617000534.A8
1617000534
|
£21.68
|
£26.01
|
|
|
832 - GUIDE SLEEVE
BSD-1617000529.A23
1617000529
|
£12.04
|
£14.45
|
|
|
840 - GEAR HOUSING
BSD-1619P06112.A1
1619P06112
|
£45.67
|
£54.80
|
|
|
843 - PROTECTION SLEEVE
BSD-1617000531.A22
1617000531
|
£11.30
|
£13.56
|
|
|
846 - CLAMP HANDLE
BSD-1612026097.A18
1612026097
|
£3.72
|
£4.47
|
|
|
850 - INTAKE MANIFOLD MODULE
BSD-1618190014.A1
1618190014
|
£68.42
|
£82.10
|
|
|
850/14 - HOUSING
BSD-1619P02029.A0
1619P02029
|
£45.67
|
£54.80
|
|
|
850/16 - SEALING BLOCK
BSD-1619P02031.A3
1619P02031
|
£12.04
|
£14.45
|
|
|
850/24 - FILTER
BSD-1619P04479.A0
1619P04479
|
£18.96
|
£22.75
|
|
|
851 - DUST CAP
BSD-1619P06107.A2
1619P06107
|
£18.96
|
£22.75
|
|
|
851/3 - SEALING CAP
BSD-1619P02020.A3
1619P02020
|
£1.75
|
£2.10
|
|
|
852 - GUIDE BAR
BSD-1619P06052.A1
1619P06052
|
£48.38
|
£58.06
|
|
|
853 - CROSS-CONNECTOR
BSD-1619P06106.A1
1619P06106
|
£12.04
|
£14.45
|
|
|
854 - DUST CONTAINER
BSD-1619P06105.A2
1619P06105
|
£40.80
|
£48.96
|
|
|
855 - CONNECTION PART
BSD-1619P06103.A2
1619P06103
|
£21.52
|
£25.83
|
|
|
856 - BUTTON
BSD-1619P06051.A2
1619P06051
|
£2.61
|
£3.13
|
|
|
864 - PLAIN BEARING
BSD-1610202026.A4
1610202026
|
£5.30
|
£6.36
|
|
|
870 - DRILL CHUCK SHANK 1/2. SDS-Plus
BSD-1613523011.A39
1613523011
|
-
|
|
|
|
870/2 - COUNTERSUNK-HEAD SCREW M6x27-Kdia11
BSD-2603421207.A72
2603421207
|
£1.75
|
£2.10
|
|
|
871 - CHUCK dia1.5-13 MM. 1/2
BSD-1608571069.A110
1608571069
|
£23.86
|
£28.63
|
|
|
872 - CHUCK WRENCH SG2
BSD-2607950007.A1720
2607950007
|
£6.52
|
£7.83
|
|
