1 - MOTOR HOUSING
BSD-3605108584.A13
3605108584
|
£36.63
|
£43.96
|
|
|
2 - FIELD 230V
BSD-2610941203.A3
2610941203
|
£59.53
|
£71.44
|
|
|
3 - ARMATURE 230V
BSD-2610941202.A10
2610941202
|
-
|
|
|
|
4 - SWITCH
BSD-2607200251.A0
2607200251
|
-
|
|
|
|
5 - POWER SUPPLY CORD EU 4.25m 2 x 1.0mm H07 RN-F
BSD-3604460557.A6
3604460557
|
£40.80
|
£48.96
|
|
|
6 - GROMMET
BSD-2610947359.A2
2610947359
|
£2.52
|
£3.02
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1358
2601035001
|
£1.75
|
£2.10
|
|
|
9 - REFERENCE PLATE
BSD-2610998943.A7
2610998943
|
£3.72
|
£4.47
|
|
|
12 - SUPPRESSION FILTER
BSD-1617328025.A72
1617328025
|
£5.58
|
£6.70
|
|
|
13 - BALL GUIDE
BSD-3600905513.A8
3600905513
|
£12.04
|
£14.45
|
|
|
14 - BALL BEARING
BSD-1600900088.A14
1600900088
|
-
|
|
|
|
19 - TAPPING SCREW
BSD-2610910566.A21
2610910566
|
£1.32
|
£1.58
|
|
|
22 - HOUSING
BSD-2610997096.A6
2610997096
|
£57.02
|
£68.42
|
|
|
23 - AIR-DEFLECTOR RING
BSD-3600590508.A6
3600590508
|
£3.34
|
£4.01
|
|
|
24 - RETAINING PLATE
BSD-3600034506.A2
3600034506
|
£5.87
|
£7.04
|
|
|
25 - HEX NUT
BSD-3603300502.A2
3603300502
|
£4.75
|
£5.70
|
|
|
27 - COVER PLATE
BSD-2610997099.A3
2610997099
|
£21.52
|
£25.83
|
|
|
28 - ROD
BSD-2610997093.A12
2610997093
|
£6.61
|
£7.93
|
|
|
29 - POINTER
BSD-2610997094.A3
2610997094
|
£5.87
|
£7.04
|
|
|
30 - HOUSING COVER
BSD-2610943199.A1
2610943199
|
£18.96
|
£22.75
|
|
|
33 - SWING-PLATE
BSD-3601021510.A3
3601021510
|
£6.61
|
£7.93
|
|
|
34 - TORSION SPRING
BSD-3604651502.A21
3604651502
|
£2.33
|
£2.80
|
|
|
35 - SHOULDER SCREW M4
BSD-3603415556.A41
3603415556
|
£2.33
|
£2.80
|
|
|
36 - KNOB
BSD-3603231539.A29
3603231539
|
£2.33
|
£2.80
|
|
|
37 - INDICATOR RING
BSD-3600209500.A35
3600209500
|
£3.80
|
£4.56
|
|
|
38 - SPRING WASHER
BSD-3600100528.A23
3600100528
|
£1.95
|
£2.34
|
|
|
39 - WASHER
BSD-3600100527.A16
3600100527
|
£2.52
|
£3.02
|
|
|
40 - ADJUSTING SLEEVE
BSD-3600360507.A33
3600360507
|
-
|
|
|
|
41 - LOCKING PIECE
BSD-3600400507.A16
3600400507
|
£2.80
|
£3.36
|
|
|
42 - SPRING LOCK WASHER B 4 DIN 127
BSD-2916680005.A2
2916680005
|
-
|
|
|
|
43 - LOCKING LEVER
BSD-3602000510.A16
3602000510
|
£2.61
|
£3.13
|
|
|
44 - LOCK BOLT
BSD-3603450504.A10
3603450504
|
£5.30
|
£6.36
|
|
|
45 - LOCK SPRING
BSD-3604651503.A25
3604651503
|
£2.33
|
£2.80
|
|
|
46 - DEPTH-GAUGE
BSD-2610997191.A10
2610997191
|
£13.41
|
£16.09
|
|
|
47 - RATCHET CAP
BSD-2600590006.A1398
2600590006
|
£1.75
|
£2.10
|
|
|
48 - SPRING WASHER
BSD-3916060500.A55
3916060500
|
£1.75
|
£2.10
|
|
|
49 - OVAL-HEAD SCREW DIN 7985-M4X12-4.8-H
BSD-2910641122.A16
2910641122
|
£2.16
|
£2.59
|
|
|
50 - WING SCREW M6x25 MM
BSD-1613480009.A99
1613480009
|
£1.88
|
£2.25
|
|
|
51 - COMPRESSION SPRING
BSD-2610997100.A15
2610997100
|
£2.33
|
£2.80
|
|
|
52 - HANDLE COVER
BSD-2610943197.A1
2610943197
|
£10.10
|
£12.12
|
|
|
53 - HANDLE COVER
BSD-2610943198.A2
2610943198
|
£11.30
|
£13.56
|
|
|
54 - SCREW
BSD-2610915161.A66
2610915161
|
£3.34
|
£4.01
|
|
|
55 - SPRING RETAINING RING DIN 471-12x1-FSt
BSD-2916650003.A279
2916650003
|
£1.75
|
£2.10
|
|
|
56 - CHIP DEFLECTOR
BSD-2610912599.A27
2610912599
|
-
|
|
|
|
57 - COMPRESSION SPRING
BSD-3604613508.A33
3604613508
|
£2.33
|
£2.80
|
|
|
58 - GUIDE PIECE
BSD-3603120502.A16
3603120502
|
£2.52
|
£3.02
|
|
|
59 - BELLOWS
BSD-3605510548.A14
3605510548
|
£5.58
|
£6.70
|
|
|
60 - INSERT
BSD-3601010519.A6
3601010519
|
£2.52
|
£3.02
|
|
|
61 - BLADE TERMINAL
BSD-1604477005.A146
1604477005
|
£2.61
|
£3.13
|
|
|
62 - RETAINING SNAP RING
BSD-3604680502.A25
3604680502
|
£2.33
|
£2.80
|
|
|
63 - TAPPING SCREW
BSD-2610991306.A21
2610991306
|
£1.75
|
£2.10
|
|
|
64 - O-RING
BSD-3600210507.A21
3600210507
|
£2.33
|
£2.80
|
|
|
65 - CABLE
BSD-2610945855.A2
2610945855
|
£2.61
|
£3.13
|
|
|
66 - CABLE
BSD-2610945856.A6
2610945856
|
£3.72
|
£4.47
|
|
|
67 - SPRING LOCK WASHER
BSD-3600150501.A6
3600150501
|
£2.33
|
£2.80
|
|
|
68 - CONTROL UNIT 230V
BSD-1607233153.A1
1607233153
|
£72.18
|
£86.62
|
|
|
69 - NAMEPLATE
BSD-2610912471.A7
2610912471
|
£3.34
|
£4.01
|
|
|
70 - SOCKET HEAD CAP SCREW
BSD-3603410504.A50
3603410504
|
£2.52
|
£3.02
|
|
|
71 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A63
1903230007
|
£1.75
|
£2.10
|
|
|
73 - SET RING
BSD-2610996090.A9
2610996090
|
-
|
|
|
|
74 - TAPPING SCREW DIN 7981-ST2.9x13-C-H
BSD-2910611006.A259
2910611006
|
£1.75
|
£2.10
|
|
|
77 - INSERT
BSD-3601010521.A16
3601010521
|
£3.34
|
£4.01
|
|
|
91 - O-RING 12.0x2.0 MM
BSD-1610210233.A9
1610210233
|
£2.80
|
£3.36
|
|
|
92 - PLAIN WASHER
BSD-2610913282.A2
2610913282
|
£1.75
|
£2.10
|
|
|
650/1 - SINGLE-HEAD ENG. WRENCH
BSD-2610992417.A24
2610992417
|
£16.41
|
£19.69
|
|
|
731 - COLLET 1/2
BSD-2608570108.A10
2608570108
|
£28.32
|
£33.99
|
|
|
731 - COLLET 12 MM
BSD-2608570107.A8
2608570107
|
£27.12
|
£32.54
|
|
|
731 - COLLET 3/8
BSD-2608570106.A28
2608570106
|
£27.99
|
£33.59
|
|
|
731 - COLLET 8 MM
BSD-2608570105.A6
2608570105
|
£27.12
|
£32.54
|
|
|
731 - COLLET 1/4
BSD-2608570104.A28
2608570104
|
£24.49
|
£29.39
|
|
|
731 - COLLET 6 MM
BSD-2608570103.A8
2608570103
|
£25.82
|
£30.99
|
|
|
731 - COLLET 10 MM
BSD-2608570125.A13
2608570125
|
-
|
|
|
|
808 - NAMEPLATE
BSD-2610948995.A0
2610948995
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-2610007957.A23
2610007957
|
£11.30
|
£13.56
|
|
|
816 - BRUSH HOLDER
BSD-2610013632.A5
2610013632
|
£30.28
|
£36.33
|
|
|
821 - SPRING
BSD-3604652501.A20
3604652501
|
£3.72
|
£4.47
|
|
|
826 - BASE
BSD-2610997115.A6
2610997115
|
£61.98
|
£74.38
|
|
