3 - GROOVE BALL BEARING 10 MM DIN 625
BSD-2600905007.A144
2600905007
|
-
|
|
|
|
4 - CUPPED WASHER
BSD-2600500008.A169
2600500008
|
-
|
|
|
|
6 - RECEPTACLE
BSD-2600400020.A160
2600400020
|
-
|
|
|
|
7 - CLUTCH ELEMENT
BSD-2606446001.A9
2606446001
|
-
|
|
|
|
8 - GRINDING SPINDLE
BSD-2607001004.A5
2607001004
|
-
|
|
|
|
8/01 - SPINDLE HOUSING
BSD-2605806156.A5
2605806156
|
-
|
|
|
|
9 - GRINDING SPINDLE
BSD-2603523019.A5
2603523019
|
-
|
|
|
|
10 - OUTER RING
BSD-1900901006.A2
1900901006
|
-
|
|
|
|
11 - BALL CAGE
BSD-2600903001.A3
2600903001
|
-
|
|
|
|
12 - BALL 4.762 MM I DIN 5401
BSD-1903230200.A4
1903230200
|
-
|
|
|
|
13 - MEMBRANE
BSD-1600106900.A4
1600106900
|
-
|
|
|
|
14 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A502
2916660008
|
£2.16
|
£2.59
|
|
|
15 - SHIM 0.05 MM
BSD-1600101610.A7
1600101610
|
-
|
|
|
|
15 - SHIM 0.1 MM
BSD-1600101611.A2
1600101611
|
-
|
|
|
|
15 - SHIM 0.30 MM
BSD-1330101020.A3
1330101020
|
-
|
|
|
|
17 - COVER RING 8.5 mm
BSD-2600501001.A42
2600501001
|
-
|
|
|
|
18 - COLLET dia 6 MM
BSD-2608570129.A99
2608570129
|
£18.96
|
£22.75
|
|
|
18 - COLLET dia 6.35 MM = 1/4
BSD-2608570085.A14
2608570085
|
£29.38
|
£35.26
|
|
|
18 - COLLET dia 8 MM
BSD-2608570081.A3
2608570081
|
£21.68
|
£26.01
|
|
|
18 - COLLET dia 3 MM
BSD-2608570082.A13
2608570082
|
£29.38
|
£35.26
|
|
|
18 - COLLET dia 3.175 MM = 1/8
BSD-2608570083.A3
2608570083
|
£29.38
|
£35.26
|
|
|
20 - COMPRESSION SPRING
BSD-2604630001.A19
2604630001
|
£2.16
|
£2.59
|
|
|
21 - SOCKET HEAD CAP SCREW DIN 84-AM5x45-8.8
BSD-2910021172.A3
2910021172
|
-
|
|
|
|
22 - SPRING LOCK WASHER DIN 128-A5-FST
BSD-2916690004.A205
2916690004
|
£1.75
|
£2.10
|
|
|
23 - SOCKET HEAD CAP SCREW DIN 84-BM4x30-8.8
BSD-2910021134.A147
2910021134
|
£1.75
|
£2.10
|
|
|
24 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A304
2916690003
|
£1.75
|
£2.10
|
|
|
25 - ROUND NUT
BSD-3603342009.A18
3603342009
|
£14.91
|
£17.89
|
|
|
101 - GEAR HOUSING
BSD-2607010003.A10
2607010003
|
-
|
|
|
|
102 - COVER DISC
BSD-2600522009.A24
2600522009
|
-
|
|
|
|
104 - COMPRESSION SPRING
BSD-2604611024.A133
2604611024
|
£2.16
|
£2.59
|
|
|
105 - COMMUTATOR END SHIELD
BSD-2607010004.A47
2607010004
|
-
|
|
|
|
106 - SQUARE NUT M4
BSD-2603320001.A29
2603320001
|
£1.75
|
£2.10
|
|
|
108 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A429
2910021125
|
£1.75
|
£2.10
|
|
|
112 - FAN
BSD-2606610013.A6
2606610013
|
-
|
|
|
|
113 - SPIRAL SPRING
BSD-2604652000.A41
2604652000
|
-
|
|
|
|
115 - SOCKET HEAD CAP SCREW
BSD-2603410010.A114
2603410010
|
-
|
|
|
|
116 - NAMEPLATE
BSD-2601100038.A4
2601100038
|
-
|
|
|
|
118 - GROOVE BALL BEARING 6x19x6
BSD-1900905019.A69
1900905019
|
£14.91
|
£17.89
|
|
|
119 - SHIM
BSD-2600150003.A236
2600150003
|
£2.16
|
£2.59
|
|
|
120 - TAPPING SCREW DIN 7971-BZ2.9x6.5
BSD-2910211004.A392
2910211004
|
-
|
|
|
|
121 - SHIM 0.2 MM
BSD-2600101655.A59
2600101655
|
-
|
|
|
|
121 - SHIM 0.3 MM
BSD-2600101656.A122
2600101656
|
-
|
|
|
|
121 - SHIM 0.5 MM
BSD-2600101657.A59
2600101657
|
-
|
|
|
|
123 - SUPPRESSION CAPACITOR
BSD-2607329056.A14
2607329056
|
-
|
|
|
|
124 - ON-OFF SWITCH
BSD-2607200048.A40
2607200048
|
-
|
|
|
|
125 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A289
2603410001
|
£1.75
|
£2.10
|
|
|
126 - POWER SUPPLY CORD EU 2.65m 2 x 1.0mm H05 RN-F
BSD-1607000388.A79
1607000388
|
£12.04
|
£14.45
|
|
|
127 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A274
2600703011
|
£2.80
|
£3.36
|
|
|
127 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1155
2600703012
|
£2.80
|
£3.36
|
|
|
127 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A219
2600703013
|
£2.61
|
£3.13
|
|
|
128 - CABLE CLIP
BSD-2601035001.A111
2601035001
|
£1.75
|
£2.10
|
|
|
129 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A1889
2910211019
|
£1.75
|
£2.10
|
|
|
130 - MANUFACTURER'S NAMEPLATE
BSD-1601110013.A77
1601110013
|
-
|
|
|
|
131 - HOUSING COVER
BSD-2600508028.A19
2600508028
|
-
|
|
|
|
132 - REC CT-SUNK TAPPING SCREW BZ 3.9x19 DIN 7972
BSD-2910601020.A73
2910601020
|
-
|
|
|
|
653 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A820
2607950511
|
£4.26
|
£5.11
|
|
|
704 - ABRASIVE PENCIL dia 6 MM
BSD-2608620012.A8
2608620012
|
£5.47
|
£6.56
|
|
|
704 - ABRASIVE PENCIL dia6.4 MM=1/4
BSD-2608620013.A15
2608620013
|
-
|
|
|
|
704 - ABRASIVE PENCIL dia 6 MM
BSD-2608620014.A8
2608620014
|
£5.80
|
£6.96
|
|
|
704 - ABRASIVE PENCIL dia6.4 MM=1/4
BSD-2608620015.A15
2608620015
|
-
|
|
|
|
754 - WHETSTONE
BSD-1607929000.A32
1607929000
|
-
|
|
|
|
814 - CARBON-BRUSH SET
BSD-2604320902.A263
2604320902
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A579
160111A3H3
|
£2.61
|
£3.13
|
|
