4 - SWITCH
BSD-2607200700.A7
2607200700
|
-
|
|
|
5 - POWER SUPPLY CORD GB 4.25m 2 x 1.00mm H005 RN-F
BSD-2610907607.A2
2610907607
|
-
|
|
|
7 - CABLE CLIP
BSD-2601035004.A182
2601035004
|
£2.16
|
£2.59
|
|
14 - GROOVE BALL BEARING
BSD-1619P13103.A40
1619P13103
|
£2.80
|
£3.36
|
|
15 - BRUSH HOLDER
BSD-2604337120.A16
2604337120
|
£3.72
|
£4.47
|
|
19 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A5
2603490021
|
£1.75
|
£2.10
|
|
20 - CLIP
BSD-2609004706.A10
2609004706
|
£1.75
|
£2.10
|
|
23 - HEX NUT M 6
BSD-2603300003.A2
2603300003
|
-
|
|
|
24 - PINION
BSD-2609110149.A36
2609110149
|
£4.26
|
£5.11
|
|
25 - COVER DISC
BSD-1600100033.A158
1600100033
|
£2.61
|
£3.13
|
|
26 - RUBBER RING
BSD-1600A004Z5.A6
1600A004Z5
|
-
|
|
|
27 - RUBBER RING
BSD-1600206025.A164
1600206025
|
£2.16
|
£2.59
|
|
28 - AIR DISTRIBUTOR
BSD-2606610147.A1
2606610147
|
-
|
|
|
29 - WASHER
BSD-1619P00987.A77
1619P00987
|
£1.75
|
£2.10
|
|
32 - AIR-DEFLECTOR RING
BSD-1619P02818.A40
1619P02818
|
£1.75
|
£2.10
|
|
34 - SPEED GOVERNOR
BSD-16072335CP.A0
16072335CP
|
-
|
|
|
35 - HOUSING COVER
BSD-2605132083.A1
2605132083
|
-
|
|
|
36 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A40
2603490023
|
£1.75
|
£2.10
|
|
37 - BRUSH-COVER
BSD-1619P02828.A29
1619P02828
|
£1.75
|
£2.10
|
|
38 - TORX OVAL-HEAD SCREW 3x8
BSD-2603490016.A67
2603490016
|
£1.75
|
£2.10
|
|
42 - WASHER
BSD-2600101131.A2
2600101131
|
-
|
|
|
54 - O-RING
BSD-2600210061.A7
2600210061
|
-
|
|
|
55 - SHIM 0.1 MM
BSD-1600A00S5P.A2
1600A00S5P
|
-
|
|
|
55 - SHIM 0.2 MM
BSD-1600A00S5R.A5
1600A00S5R
|
-
|
|
|
55 - SHIM 0.3 MM
BSD-1600A00S5S.A2
1600A00S5S
|
-
|
|
|
57 - SCREW
BSD-1603430044.A1
1603430044
|
-
|
|
|
58 - FRICTION RING
BSD-2600206033.A5
2600206033
|
-
|
|
|
60 - SPECIAL SCREW
BSD-1600A00RD6.A27
1600A00RD6
|
£1.75
|
£2.10
|
|
72 - THREAD-FORMING TAP. SCREW M4x12 MM
BSD-2603410049.A214
2603410049
|
£1.75
|
£2.10
|
|
74 - HOUSING SECTION
BSD-2605105219.A1
2605105219
|
-
|
|
|
76 - CAP-HANDLE
BSD-2602026214.A2
2602026214
|
-
|
|
|
78 - BACKING PAD dia150
BSD-2608614075.A2
2608614075
|
-
|
|
|
79 - HEX SOCKET HEAD CAP SCREW DIN 7984-M8x16-8.8
BSD-2910131238.A5
2910131238
|
-
|
|
|
80 - SUCTION SOCKET
BSD-2605730079.A1
2605730079
|
-
|
|
|
81 - LINK GUIDE
BSD-2602033901.A2
2602033901
|
-
|
|
|
88 - STICKER
BSD-160111C2K3.A6
160111C2K3
|
-
|
|
|
89 - STICKER
BSD-160111C2K4.A1
160111C2K4
|
-
|
|
|
92 - SUPPRESSOR BOX Entstörglied Box
BSD-2604465116.A2
2604465116
|
-
|
|
|
93 - GUIDE
BSD-2602033022.A5
2602033022
|
-
|
|
|
94 - PUSHER
BSD-2601990060.A3
2601990060
|
-
|
|
|
95 - DETENT PIN
BSD-2603102014.A4
2603102014
|
-
|
|
|
96 - COVER
BSD-2605132082.A6
2605132082
|
-
|
|
|
97 - RATCHET CAP
BSD-2600590006.A674
2600590006
|
£1.75
|
£2.10
|
|
98 - COMPRESSION SPRING
BSD-2609996608.A4
2609996608
|
-
|
|
|
661 - END STOP
BSD-2605191326.A3
2605191326
|
-
|
|
|
662 - AUXILIARY HANDLE
BSD-2602025213.A4
2602025213
|
-
|
|
|
663 - HEX SOCKET HEAD CAP SCREW DIN 7984-M8x25-8.8
BSD-1600A015G7.A10
1600A015G7
|
£1.75
|
£2.10
|
|
801 - HOUSING ASSEMBLY
BSD-1607000DD4.A0
1607000DD4
|
-
|
|
|
803 - ARMATURE ASSEMBLY 100-115V
BSD-1607000DD6.A0
1607000DD6
|
-
|
|
|
806 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A517
2600703012
|
£2.80
|
£3.36
|
|
808 - NAMEPLATE
BSD-160111A5UG.A0
160111A5UG
|
-
|
|
|
810 - CARBON-BRUSH SET
BSD-1619P02870.A44
1619P02870
|
£8.67
|
£10.41
|
|
849 - HOUSING ASSEMBLY
BSD-1607000DC3.A3
1607000DC3
|
-
|
|
|
856 - SUCTION HOOD
BSD-1607000DC4.A0
1607000DC4
|
-
|
|
|
864 - GEAR
BSD-1607000DC5.A3
1607000DC5
|
-
|
|
|
870 - CARRIER
BSD-1607000DC6.A0
1607000DC6
|
-
|
|
|
