1 - MOTOR HOUSING
BSD-1615102150.A5
1615102150
|
-
|
|
|
2 - FIELD 220-230V
BSD-1604220343.A36
1604220343
|
£33.74
|
£40.49
|
|
4 - SWITCH
BSD-1617200048.A0
1617200048
|
£18.96
|
£22.75
|
|
4/10 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x12-5.8
BSD-2910011088.A62
2910011088
|
£1.75
|
£2.10
|
|
5 - POWER SUPPLY CORD GB 230V 4.15m 2 x 1.0mm H07 RN-F
BSD-1604460144.A20
1604460144
|
£37.27
|
£44.72
|
|
6 - GROMMET dia9.7-dia12x89 MM
BSD-1610703053.A85
1610703053
|
£2.61
|
£3.13
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A694
3600703011
|
£2.80
|
£3.36
|
|
7 - FASTENING CLAMP
BSD-1601302018.A687
1601302018
|
£1.75
|
£2.10
|
|
13 - GROOVE BALL BEARING 7x22x7
BSD-1610900025.A95
1610900025
|
£16.41
|
£19.69
|
|
15 - FAN
BSD-1616610071.A0
1616610071
|
£9.49
|
£11.39
|
|
19 - GUIDE TUBE
BSD-1615806121.A18
1615806121
|
-
|
|
|
20 - TOOLHOLDER
BSD-1618597071.A12
1618597071
|
-
|
|
|
21 - PROTECTIVE CAP
BSD-1610508017.A49
1610508017
|
£3.72
|
£4.47
|
|
22 - PROTECTION SLEEVE
BSD-1610591009.A47
1610591009
|
-
|
|
|
23 - STOP SLEEVE
BSD-1610520001.A55
1610520001
|
£12.04
|
£14.45
|
|
25 - STOPPING DEVICE
BSD-1612300027.A95
1612300027
|
£11.30
|
£13.56
|
|
26 - INDEXING DISK
BSD-1610290025.A0
1610290025
|
£6.52
|
£7.83
|
|
27 - RETAINING SNAP RING
BSD-1610222008.A7
1610222008
|
-
|
|
|
28 - COMPRESSION SPRING
BSD-1614621000.A29
1614621000
|
£2.80
|
£3.36
|
|
29 - COMPRESSION SPRING
BSD-1614616008.A25
1614616008
|
£2.61
|
£3.13
|
|
30 - BALL RACE
BSD-1610250007.A7
1610250007
|
-
|
|
|
31 - SPACER TUBE
BSD-1610390015.A77
1610390015
|
-
|
|
|
32 - CYLINDER SLEEVE
BSD-1610202016.A41
1610202016
|
-
|
|
|
34 - SUPPORTING DISC 1.5 MM
BSD-1610102622.A37
1610102622
|
£1.95
|
£2.34
|
|
35 - HAMMER PIPE
BSD-1615806089.A0
1615806089
|
-
|
|
|
37 - RETAINING BRACKET
BSD-1617000291.A18
1617000291
|
-
|
|
|
38 - COVERING HOOD
BSD-1615190051.A5
1615190051
|
-
|
|
|
39 - CLUTCH RING
BSD-1610290024.A36
1610290024
|
-
|
|
|
41 - STRIKER PIN
BSD-1613124036.A0
1613124036
|
-
|
|
|
43 - BEARING COVER
BSD-1615808081.A2
1615808081
|
-
|
|
|
46 - SEALING FRAME
BSD-1611015036.A24
1611015036
|
-
|
|
|
47 - COVER
BSD-1610591012.A0
1610591012
|
£1.75
|
£2.10
|
|
51 - CROWN GEAR Z=37
BSD-1616333023.A31
1616333023
|
-
|
|
|
53 - STOP DISC
BSD-1610190023.A1
1610190023
|
£5.30
|
£6.36
|
|
54 - STOP DISC
BSD-1610101014.A10
1610101014
|
-
|
|
|
57 - STRIKER
BSD-1618710053.A32
1618710053
|
-
|
|
|
72 - ECCENTRIC COG WHEEL Z=35
BSD-1616337004.A7
1616337004
|
-
|
|
|
75 - HANDLE
BSD-1615132048.A6
1615132048
|
-
|
|
|
80 - SPEED GOVERNOR 220-240V
BSD-1617233026.A0
1617233026
|
£46.82
|
£56.18
|
|
81 - SWITCH-PAWL
BSD-1612026030.A0
1612026030
|
-
|
|
|
82 - LIGHT CONDUCTOR
BSD-1615510000.A52
1615510000
|
£2.16
|
£2.59
|
|
83 - WEB PLATE
BSD-1610009006.A11
1610009006
|
-
|
|
|
84 - AUXILIARY HANDLE M8
BSD-1612025041.A33
1612025041
|
£21.42
|
£25.71
|
|
85 - SUPPORT CLAMP dia70 MM
BSD-1618040055.A39
1618040055
|
-
|
|
|
86 - T-HEAD BOLT M8x80 MM
BSD-1613490001.A49
1613490001
|
£8.67
|
£10.41
|
|
87 - CLAMPING BAND dia70 MM
BSD-1611316008.A45
1611316008
|
-
|
|
|
94 - SPRING RETAINING RING
BSD-1610119007.A1
1610119007
|
-
|
|
|
95 - SEALING DISK 14.4-6201 ZJV NILOS
BSD-2916120023.A5
2916120023
|
£3.34
|
£4.01
|
|
96 - SPRING RETAINING RING 55x2MM. DIN 472
BSD-2916660024.A31
2916660024
|
£5.30
|
£6.36
|
|
97 - SHIM RING DIN 988-45x55
BSD-2916190284.A7
2916190284
|
-
|
|
|
98 - FRICTION WASHER 0.5 MM
BSD-1610101622.A24
1610101622
|
-
|
|
|
99 - HOLDING PLATE
BSD-1610190030.A12
1610190030
|
£3.72
|
£4.47
|
|
101 - O-RING 20.0x3.0 MM
BSD-1610210094.A12
1610210094
|
£2.80
|
£3.36
|
|
102 - O-RING 55.0x2.0 MM
BSD-1610210095.A25
1610210095
|
£2.61
|
£3.13
|
|
103 - O-RING 27.0x1.5 MM
BSD-1610210100.A33
1610210100
|
£3.72
|
£4.47
|
|
104 - O-RING 17.0x8.0 MM
BSD-1610210093.A73
1610210093
|
£1.75
|
£2.10
|
|
105 - O-RING 21.0x3.5 MM
BSD-1610210096.A12
1610210096
|
£2.80
|
£3.36
|
|
107 - O-RING 14.0x2.0 MM
BSD-1610210116.A14
1610210116
|
£2.80
|
£3.36
|
|
108 - O-RING 8.0x1.5 MM
BSD-1900210103.A43
1900210103
|
£2.80
|
£3.36
|
|
109 - ROTARY SHAFT LIP SEAL DIN 3760-BS. dia40x55x7 MM
BSD-1610283028.A0
1610283028
|
£5.58
|
£6.70
|
|
110 - SPRING RETAINING RING
BSD-1610116003.A1
1610116003
|
-
|
|
|
111 - O-RING 10.0x1.0 MM
BSD-1610210081.A34
1610210081
|
£3.72
|
£4.47
|
|
112 - THREADED RING M24x1.5MM. SW10
BSD-1613461001.A1
1613461001
|
-
|
|
|
113 - BUSHING
BSD-1610501036.A0
1610501036
|
£8.67
|
£10.41
|
|
116 - SPRING RETAINING RING
BSD-1610116004.A44
1610116004
|
£1.75
|
£2.10
|
|
117 - SPRING RETAINING RING
BSD-1610119008.A36
1610119008
|
£2.33
|
£2.80
|
|
118 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913009.A31
1610913009
|
-
|
|
|
119 - NEEDLE-ROLLER ASSEMBLY dia10 MM
BSD-1610913011.A55
1610913011
|
£6.52
|
£7.83
|
|
121 - GROOVE BALL BEARING
BSD-1610905014.A0
1610905014
|
-
|
|
|
122 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913029.A64
1610913029
|
£4.26
|
£5.11
|
|
124 - THRUST BEARING DISC 1.0 MM
BSD-1610101008.A20
1610101008
|
-
|
|
|
125 - TAPPING SCREW DIN7981-ST4.8x25-C-Z
BSD-2912401036.A32
2912401036
|
£1.32
|
£1.58
|
|
126 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A536
2910211019
|
£1.75
|
£2.10
|
|
127 - OVAL-HEAD SCREW DIN 7985-M5x30-8.8
BSD-2912311166.A1
2912311166
|
£1.75
|
£2.10
|
|
128 - TAPPING SCREW DIN 7971-BZ4.8x32
BSD-2910211037.A71
2910211037
|
£1.75
|
£2.10
|
|
129 - TAPPING SCREW DIN 7981-ST4.8x32C-Z
BSD-2912401037.A5
2912401037
|
£1.75
|
£2.10
|
|
132 - MICROENCAPSULATED SCREW DIN 912-M 5x12-8.8
BSD-2914551117.A48
2914551117
|
£1.75
|
£2.10
|
|
136 - TAPPING SCREW DIN 7971-ST4.8x25-C
BSD-2910211236.A101
2910211236
|
£1.75
|
£2.10
|
|
139 - FELT DISC dia39x15 MM
BSD-1610005002.A7
1610005002
|
-
|
|
|
139 - RETAINING BRACKET
BSD-1617000291.A16
1617000291
|
-
|
|
|
148 - SHIM 0.3 MM
BSD-1610102633.A24
1610102633
|
-
|
|
|
148 - SHIM 0.2 MM
BSD-1610102627.A24
1610102627
|
-
|
|
|
149 - ADAPTING PIECE
BSD-1612388021.A24
1612388021
|
-
|
|
|
151 - O-RING 21.0x2.0 MM
BSD-2600210028.A22
2600210028
|
£1.32
|
£1.58
|
|
152 - COVER
BSD-1610508030.A17
1610508030
|
-
|
|
|
154 - RETAINING SNAP RING
BSD-1610222010.A27
1610222010
|
£9.49
|
£11.39
|
|
650 - CARRYING CASE
BSD-1615438213.A3
1615438213
|
-
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430010.A4
1615430010
|
£6.52
|
£7.83
|
|
715 - DEPTH-GAUGE SW 6x330 MM
BSD-1613001003.A39
1613001003
|
£4.25
|
£5.10
|
|
784 - AUXILIARY HANDLE dia 70 MM. M8
BSD-2602025062.A17
2602025062
|
£42.02
|
£50.42
|
|
800 - CLAMP HANDLE
BSD-1617000808.A7
1617000808
|
-
|
|
|
800 - CLAMP HANDLE
BSD-1617000956.A0
1617000956
|
-
|
|
|
803 - ARMATURE 220-240V
BSD-1614010186.A5
1614010186
|
£103.14
|
£123.77
|
|
808 - NAMEPLATE
BSD-160111A3H3.A3228
160111A3H3
|
£2.61
|
£3.13
|
|
814 - GROOVE BALL BEARING
BSD-1617000822.A19
1617000822
|
-
|
|
|
824 - CYLINDRICAL ROLLER
BSD-1617000271.A1
1617000271
|
£4.26
|
£5.11
|
|
833 - CONTROL FORK
BSD-1617000949.A12
1617000949
|
-
|
|
|
837 - RETAINING BRACKET
BSD-1617000291.A15
1617000291
|
-
|
|
|
840 - IMPACT MECHANISM HOUSING
BSD-1617000811.A5
1617000811
|
-
|
|
|
842 - BRUSH HOLDER
BSD-1614336009.A24
1614336009
|
-
|
|
|
842/020 - BRUSH GUIDE
BSD-1614336043.A13
1614336043
|
-
|
|
|
842/040 - CARBON-BRUSH SET
BSD-1617014122.A1
1617014122
|
£18.96
|
£22.75
|
|
842/050 - RUBBER BUFFER
BSD-1613212004.A8
1613212004
|
£3.72
|
£4.47
|
|
842/080 - TAPPING SCREW DIN7981-ST2.9x9.5C-Z
BSD-2912401005.A268
2912401005
|
£1.75
|
£2.10
|
|
845 - GEAR HOUSING
BSD-1617000823.A0
1617000823
|
-
|
|
|
845 - GEAR HOUSING
BSD-1617000962.A1
1617000962
|
-
|
|
|
848 - CLUTCH SLEEVE
BSD-1617000415.A5
1617000415
|
-
|
|
|
856 - HAMMER PISTON
BSD-1617000999.A0
1617000999
|
-
|
|
|
860 - SPUR WHEEL CLUTCH
BSD-1617000817.A7
1617000817
|
-
|
|
|
897 - WEAR AND TEAR PART SET
BSD-1617000287.A1
1617000287
|
-
|
|
|
898 - WEAR AND TEAR PART SET
BSD-1617000288.A4
1617000288
|
-
|
|
|
899 - HOLDING PLATE
BSD-1617000293.A16
1617000293
|
-
|
|
|
