1 - MOTOR HOUSING
BSD-16051082B0.A0
16051082B0
|
£27.23
|
£32.68
|
|
|
2 - FIELD 220-240V
BSD-1614220124.A2
1614220124
|
£31.64
|
£37.97
|
|
|
4 - SWITCH
BSD-160720031Z.A0
160720031Z
|
£31.64
|
£37.97
|
|
|
5 - POWER SUPPLY CORD
BSD-1614460098.A1
1614460098
|
£21.68
|
£26.01
|
|
|
6 - GROMMET dia9.7-dia12x89 MM
BSD-1610703053.A30
1610703053
|
£2.61
|
£3.13
|
|
|
7 - FASTENING CLAMP
BSD-1601302018.A127
1601302018
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-160111C0XN.A0
160111C0XN
|
-
|
|
|
|
13 - GROOVE BALL BEARING 8x24x8
BSD-1610900026.A80
1610900026
|
£12.04
|
£14.45
|
|
|
14 - NEEDLE-ROLLER BEARING
BSD-1610910089.A5
1610910089
|
-
|
|
|
|
15 - FAN
BSD-1616610109.A14
1616610109
|
£16.41
|
£19.69
|
|
|
21 - PROTECTIVE CAP
BSD-1610508038.A47
1610508038
|
£8.13
|
£9.76
|
|
|
22 - PROTECTION SLEEVE
BSD-1610591051.A11
1610591051
|
£12.04
|
£14.45
|
|
|
23 - STOP SLEEVE
BSD-1610520006.A9
1610520006
|
£18.96
|
£22.75
|
|
|
24 - HEADED BUSH
BSD-1610500025.A11
1610500025
|
£10.10
|
£12.12
|
|
|
25 - STOPPING DEVICE
BSD-1612300027.A2
1612300027
|
£11.30
|
£13.56
|
|
|
26 - INDEXING DISK
BSD-1600A019WL.A8
1600A019WL
|
£5.01
|
£6.01
|
|
|
27 - AIR-DEFLECTOR RING
BSD-160059105C.A2
160059105C
|
£2.61
|
£3.13
|
|
|
28 - COMPRESSION SPRING
BSD-1614621010.A16
1614621010
|
£4.26
|
£5.11
|
|
|
31 - DAMPING RING
BSD-1610290129.A0
1610290129
|
£6.52
|
£7.83
|
|
|
35 - HAMMER PIPE
BSD-1615806249.A9
1615806249
|
£98.11
|
£117.73
|
|
|
37 - CONTROL BUSHING
BSD-1610322018.A15
1610322018
|
£7.36
|
£8.83
|
|
|
38 - COVERING HOOD
BSD-1600A004G3.A0
1600A004G3
|
£31.64
|
£37.97
|
|
|
38/1 - STICKER
BSD-160111C0XP.A0
160111C0XP
|
£2.80
|
£3.36
|
|
|
38/2 - STICKER
BSD-160111C0XR.A0
160111C0XR
|
£2.80
|
£3.36
|
|
|
42 - BRUSH HOLDER
BSD-1614336090.A2
1614336090
|
£45.67
|
£54.80
|
|
|
43 - BRUSH-COVER
BSD-1615500435.A11
1615500435
|
£11.30
|
£13.56
|
|
|
44 - COMPRESSION SPRING
BSD-1614621020.A0
1614621020
|
£2.61
|
£3.13
|
|
|
45 - HOLDING-DOWN-APPLIANCE
BSD-1610591052.A5
1610591052
|
£2.16
|
£2.59
|
|
|
47 - GEAR SLEEVE
BSD-1610300076.A2
1610300076
|
£8.67
|
£10.41
|
|
|
48 - CLUTCH SLEEVE
BSD-1619990177.A3
1619990177
|
£10.10
|
£12.12
|
|
|
52 - RETAINING SNAP RING
BSD-1610224015.A15
1610224015
|
£1.75
|
£2.10
|
|
|
54 - SPACER TUBE
BSD-1610190071.A9
1610190071
|
£5.87
|
£7.04
|
|
|
58 - CYLINDRICAL GEAR
BSD-1616317620.A5
1616317620
|
£13.12
|
£15.75
|
|
|
59 - BEARING PEDESTAL
BSD-1615805074.A10
1615805074
|
£10.10
|
£12.12
|
|
|
72 - ECCENTRIC COG WHEEL
BSD-1616317090.A11
1616317090
|
£68.42
|
£82.10
|
|
|
80 - SPEED GOVERNOR
BSD-1607233459.A2
1607233459
|
£57.02
|
£68.42
|
|
|
84 - AUXILIARY HANDLE
BSD-160202507H.A441
160202507H
|
£11.30
|
£13.56
|
|
|
85 - SUPPORT CLAMP
BSD-1618040095.A3
1618040095
|
£5.58
|
£6.70
|
|
|
94 - SUPPORTING DISC
BSD-1610290111.A8
1610290111
|
£2.16
|
£2.59
|
|
|
95 - DRIVING PIN
BSD-1613120023.A2
1613120023
|
£4.26
|
£5.11
|
|
|
98 - SHIM RING 1.0 MM
BSD-1610101015.A35
1610101015
|
£1.75
|
£2.10
|
|
|
99 - BACKUP RING
BSD-1600220029.A1
1600220029
|
£2.80
|
£3.36
|
|
|
104 - STOP DISC
BSD-1610190027.A28
1610190027
|
£5.58
|
£6.70
|
|
|
110 - SEAL RING
BSD-1610190073.A7
1610190073
|
£1.75
|
£2.10
|
|
|
111 - BUSHING
BSD-1610290046.A8
1610290046
|
£2.80
|
£3.36
|
|
|
112 - HEX NUT
BSD-1613300007.A3
1613300007
|
£1.75
|
£2.10
|
|
|
113 - TAPPING SCREW B 4.8x68 MM
BSD-1613412001.A105
1613412001
|
£1.75
|
£2.10
|
|
|
115 - BUSHING
BSD-1610300086.A1
1610300086
|
£5.58
|
£6.70
|
|
|
116 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913029.A14
1610913029
|
£4.26
|
£5.11
|
|
|
117 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913023.A10
1610913023
|
£18.96
|
£22.75
|
|
|
119 - NEEDLE-ROLLER BEARING
BSD-1610910081.A3
1610910081
|
£14.91
|
£17.89
|
|
|
120 - SPACER TUBE
BSD-1610190080.A1
1610190080
|
£12.04
|
£14.45
|
|
|
122 - SPACER RING
BSD-1610290128.A16
1610290128
|
£7.36
|
£8.83
|
|
|
125 - TORX OVAL-HEAD SCREW
BSD-1613435040.A14
1613435040
|
£2.16
|
£2.59
|
|
|
126 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1021
2603490023
|
£1.75
|
£2.10
|
|
|
127 - BUSHING
BSD-1610300079.A6
1610300079
|
£4.26
|
£5.11
|
|
|
129 - BUSHING
BSD-1610300080.A2
1610300080
|
£4.26
|
£5.11
|
|
|
138 - SEALING FRAME
BSD-1611015064.A10
1611015064
|
£6.52
|
£7.83
|
|
|
142 - ROTARY SHAFT LIP SEAL
BSD-1610290112.A8
1610290112
|
£4.26
|
£5.11
|
|
|
143 - RETAINING RING
BSD-1614601072.A8
1614601072
|
£2.61
|
£3.13
|
|
|
144 - SUPPORTING DISC
BSD-1610103025.A0
1610103025
|
£3.72
|
£4.47
|
|
|
151 - O-RING
BSD-1610210222.A16
1610210222
|
£1.75
|
£2.10
|
|
|
152 - RETAINING RING
BSD-1614601073.A8
1614601073
|
£1.75
|
£2.10
|
|
|
153 - RETAINING RING DIN 7993 A 30
BSD-2916540017.A9
2916540017
|
£2.16
|
£2.59
|
|
|
154 - SPRING RETAINING RING DIN 472 62x2 MM
BSD-2916660027.A9
2916660027
|
£4.26
|
£5.11
|
|
|
155 - RETAINING RING
BSD-1614601074.A8
1614601074
|
£1.75
|
£2.10
|
|
|
157 - O-RING 33.0x2.0 MM
BSD-1610210103.A41
1610210103
|
£2.61
|
£3.13
|
|
|
158 - O-RING
BSD-1610210224.A0
1610210224
|
£1.75
|
£2.10
|
|
|
160 - O-RING
BSD-1610210246.A9
1610210246
|
£1.75
|
£2.10
|
|
|
161 - DAMPING RING
BSD-1610210227.A16
1610210227
|
£8.67
|
£10.41
|
|
|
162 - O-RING
BSD-1600210080.A8
1600210080
|
£2.61
|
£3.13
|
|
|
165 - SEAL RING
BSD-1610290125.A0
1610290125
|
£11.30
|
£13.56
|
|
|
166 - CYLINDRICAL ROLLER
BSD-1613200020.A1
1613200020
|
£2.80
|
£3.36
|
|
|
167 - ROTARY SHAFT LIP SEAL
BSD-161029012A.A16
161029012A
|
£4.26
|
£5.11
|
|
|
168 - PACKING WASHER
BSD-1610206027.A0
1610206027
|
£2.61
|
£3.13
|
|
|
171 - TORX SOCKET BUTTON SCREW
BSD-1613414026.A23
1613414026
|
£2.61
|
£3.13
|
|
|
172 - TORX OVAL-HEAD SCREW
BSD-1613435041.A17
1613435041
|
£1.75
|
£2.10
|
|
|
175 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A352
2603490021
|
£1.75
|
£2.10
|
|
|
189 - HANDLE
BSD-161513213A.A0
161513213A
|
£14.91
|
£17.89
|
|
|
190 - HANDLE COVER
BSD-1600A004JR.A0
1600A004JR
|
£16.41
|
£19.69
|
|
|
192 - ROCKER FOOT
BSD-1614611028.A16
1614611028
|
£5.58
|
£6.70
|
|
|
194 - SCREW PLATE
BSD-1610099018.A0
1610099018
|
£2.16
|
£2.59
|
|
|
195 - SCREW PLATE
BSD-1610099019.A12
1610099019
|
£2.16
|
£2.59
|
|
|
196 - DAMPING RUBBER
BSD-1610026004.A4
1610026004
|
£1.75
|
£2.10
|
|
|
197 - LEAF SPRING
BSD-1616232000.A14
1616232000
|
£11.30
|
£13.56
|
|
|
204 - REAR HOUSING SECTION
BSD-1615102162.A4
1615102162
|
£21.52
|
£25.83
|
|
|
206 - HOLDING STRIP
BSD-1612386006.A8
1612386006
|
£1.75
|
£2.10
|
|
|
240 - COUNTERWEIGHT
BSD-1600A000K3.A0
1600A000K3
|
£10.10
|
£12.12
|
|
|
241 - GUIDE PIECE
BSD-1615190181.A0
1615190181
|
£2.61
|
£3.13
|
|
|
242 - GUIDE PIECE
BSD-1615190182.A4
1615190182
|
£2.61
|
£3.13
|
|
|
243 - COMPRESSION SPRING
BSD-1614621013.A0
1614621013
|
£2.61
|
£3.13
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430009.A5
1615430009
|
£13.12
|
£15.75
|
|
|
800 - SHIM 0.2 MM
BSD-1600A0037C.A0
1600A0037C
|
-
|
|
|
|
801 - SHIM 0.45 MM
BSD-1610102096.A8
1610102096
|
£1.75
|
£2.10
|
|
|
802 - SHIM 0.30 MM
BSD-1610102095.A0
1610102095
|
£1.75
|
£2.10
|
|
|
803 - ARMATURE 230V
BSD-1614010267.A0
1614010267
|
£179.37
|
£215.24
|
|
|
808 - NAMEPLATE
BSD-160111A3H5.A402
160111A3H5
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-1617014145.A0
1617014145
|
£18.96
|
£22.75
|
|
|
820 - TOOLHOLDER
BSD-1618597102.A0
1618597102
|
£120.11
|
£144.13
|
|
|
821 - PLAIN BEARING
BSD-1610508058.A8
1610508058
|
£27.23
|
£32.68
|
|
|
840 - IMPACT MECHANISM HOUSING
BSD-1617000A29.A3
1617000A29
|
£179.37
|
£215.24
|
|
|
841 - STRIKER PIN
BSD-1617000A4R.A3
1617000A4R
|
£54.42
|
£65.30
|
|
|
849 - CONTROL FORK
BSD-1617000A31.A5
1617000A31
|
£7.36
|
£8.83
|
|
|
853 - GUIDE BUSHING
BSD-1610231004.A3
1610231004
|
£27.23
|
£32.68
|
|
|
856 - HAMMER PISTON
BSD-1617000A32.A11
1617000A32
|
£48.38
|
£58.06
|
|
|
857 - STRIKER
BSD-1617000A33.A5
1617000A33
|
£27.23
|
£32.68
|
|
|
860 - SPUR WHEEL CLUTCH
BSD-1607000C3S.A4
1607000C3S
|
£171.57
|
£205.88
|
|
|
863 - O-RING
BSD-1610210229.A0
1610210229
|
£2.16
|
£2.59
|
|
|
872 - ECCENTRIC
BSD-1617000A35.A11
1617000A35
|
£103.14
|
£123.77
|
|
|
873 - HOUSING COVER
BSD-1605500293.A0
1605500293
|
£54.42
|
£65.30
|
|
|
884 - AUXILIARY HANDLE
BSD-1612025004.A0
1612025004
|
£45.67
|
£54.80
|
|
|
887 - CLAMPING BAND dia87 MM
BSD-1617000807.A19
1617000807
|
£18.96
|
£22.75
|
|
|
891 - ROCKER ARM
BSD-1612099005.A4
1612099005
|
£11.30
|
£13.56
|
|
|
895 - DIAPHRAGM
BSD-1613120024.A8
1613120024
|
£31.64
|
£37.97
|
|
|
897 - BELLOWS
BSD-1610415005.A4
1610415005
|
£10.10
|
£12.12
|
|
|
898 - BELLOWS
BSD-1610415004.A8
1610415004
|
£10.10
|
£12.12
|
|
|
899 - SERVICE PACKAGE
BSD-1600A004E6.A8
1600A004E6
|
£59.53
|
£71.44
|
|
