2 - FIELD 230-240V
BSD-1614220101.A2
1614220101
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-1617200040.A12
1617200040
|
-
|
|
|
|
5 - POWER SUPPLY CORD GB 240V 4.15m 2 x 1.0mm H07RN-F
BSD-1614460058.A3
1614460058
|
£24.45
|
£29.34
|
|
|
6 - GROMMET dia9.7-dia12x89 MM
BSD-1610703053.A86
1610703053
|
£2.61
|
£3.13
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A689
3600703011
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1611034020.A18
1611034020
|
-
|
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110710.A7
1611110710
|
-
|
|
|
|
13 - GROOVE BALL BEARING 9x26x8
BSD-1610905009.A27
1610905009
|
£14.72
|
£17.67
|
|
|
14 - GROOVE BALL BEARING 15x35x11
BSD-1610905024.A7
1610905024
|
-
|
|
|
|
15 - FAN
BSD-1616610067.A12
1616610067
|
-
|
|
|
|
17 - FRICTION WASHER
BSD-1610500013.A12
1610500013
|
-
|
|
|
|
18 - PROTECTIVE CAP
BSD-1610508017.A39
1610508017
|
£3.72
|
£4.47
|
|
|
19 - CYLINDER SLEEVE
BSD-1610202016.A49
1610202016
|
-
|
|
|
|
20 - SPACER TUBE
BSD-1610390015.A64
1610390015
|
-
|
|
|
|
21 - STOP SLEEVE
BSD-1610520001.A63
1610520001
|
£12.04
|
£14.45
|
|
|
22 - STOPPING DEVICE
BSD-1612300027.A96
1612300027
|
£11.30
|
£13.56
|
|
|
23 - INDEXING DISK
BSD-1610290025.A13
1610290025
|
£6.52
|
£7.83
|
|
|
24 - COMPRESSION SPRING
BSD-1614616009.A4
1614616009
|
-
|
|
|
|
25 - PROTECTION SLEEVE
BSD-1610591009.A39
1610591009
|
-
|
|
|
|
27 - PROTECTIVE CAP
BSD-1615190028.A12
1615190028
|
-
|
|
|
|
28 - BEARING FLANGE
BSD-1615805062.A13
1615805062
|
-
|
|
|
|
29 - STRIKER PIN
BSD-1613124037.A12
1613124037
|
-
|
|
|
|
30 - STRIKER PIN
BSD-1613124038.A8
1613124038
|
-
|
|
|
|
32 - SUPPORTING DISC 1.5 MM
BSD-1610101616.A18
1610101616
|
£1.75
|
£2.10
|
|
|
33 - CYLINDRICAL GEAR Z=32/57
BSD-1616317041.A15
1616317041
|
-
|
|
|
|
35 - STRIKER
BSD-1618710055.A7
1618710055
|
-
|
|
|
|
36 - COMPRESSION SPRING
BSD-1614621001.A4
1614621001
|
-
|
|
|
|
37 - HAMMER PISTON
BSD-1618700060.A13
1618700060
|
-
|
|
|
|
38 - COVERING HOOD
BSD-1615190045.A3
1615190045
|
-
|
|
|
|
39 - SEALING FRAME
BSD-1611015030.A12
1611015030
|
-
|
|
|
|
40 - BEARING COVER
BSD-1615808059.A16
1615808059
|
-
|
|
|
|
41 - PISTON PIN
BSD-1613219001.A15
1613219001
|
-
|
|
|
|
42 - BRUSH HOLDER
BSD-1614336005.A16
1614336005
|
£12.04
|
£14.45
|
|
|
43 - BEARING COVER
BSD-1615808060.A8
1615808060
|
-
|
|
|
|
44 - FRAME
BSD-1611015032.A12
1611015032
|
-
|
|
|
|
45 - HANDLE
BSD-1615133027.A23
1615133027
|
-
|
|
|
|
46 - HANDLE COVER
BSD-1615500269.A30
1615500269
|
-
|
|
|
|
48 - CROWN GEAR Z=32
BSD-1616333032.A4
1616333032
|
-
|
|
|
|
49 - DRIVE BEARING
BSD-1615819011.A11
1615819011
|
-
|
|
|
|
53 - SEALING FRAME
BSD-1611015031.A17
1611015031
|
-
|
|
|
|
56 - TOOTHED SHAFT Z=10
BSD-1613060012.A1
1613060012
|
-
|
|
|
|
59 - PLUG
BSD-1610591010.A18
1610591010
|
-
|
|
|
|
60 - CLAMP HANDLE
BSD-1612026040.A5
1612026040
|
£6.61
|
£7.93
|
|
|
61 - STRAIGHT PIN 5M6x70 RIKO DIN 6325
BSD-2917550138.A18
2917550138
|
-
|
|
|
|
62 - HOLDING SPRING
BSD-1614680003.A30
1614680003
|
-
|
|
|
|
65 - SUPPORTING DISC 2.5 MM
BSD-1610101617.A11
1610101617
|
-
|
|
|
|
68 - SHIM 0.3 MM
BSD-1610101618.A18
1610101618
|
£1.75
|
£2.10
|
|
|
68 - SHIM 0.1 MM
BSD-1610101621.A12
1610101621
|
-
|
|
|
|
70 - STOP DISC
BSD-1610103019.A18
1610103019
|
£6.61
|
£7.93
|
|
|
71 - STOP DISC
BSD-1610101014.A2
1610101014
|
-
|
|
|
|
72 - SEALING CAP
BSD-1615500272.A6
1615500272
|
-
|
|
|
|
73 - CLAMPING RING
BSD-1610210082.A16
1610210082
|
£1.95
|
£2.34
|
|
|
74 - SPIRAL SPRING
BSD-1614652000.A45
1614652000
|
-
|
|
|
|
75 - SOCKET HOUSING
BSD-1615190011.A18
1615190011
|
-
|
|
|
|
76 - SUPPRESSION FILTER
BSD-1617328016.A16
1617328016
|
-
|
|
|
|
77 - SUPPRESSION FILTER
BSD-1617328017.A14
1617328017
|
£3.72
|
£4.47
|
|
|
78 - CONNECTING CABLE L=35 MM
BSD-1614431022.A29
1614431022
|
-
|
|
|
|
79 - SUPPORTING DISC 3.0 MM
BSD-1610102623.A5
1610102623
|
£2.52
|
£3.02
|
|
|
80 - CONTROL DEVICE 230-240V
BSD-1617233016.A10
1617233016
|
-
|
|
|
|
81 - SUPPORTING DISC 3.0 MM
BSD-1610102630.A6
1610102630
|
-
|
|
|
|
84 - AUXILIARY HANDLE
BSD-160202507H.A171
160202507H
|
£11.30
|
£13.56
|
|
|
85 - SUPPORT CLAMP dia70 MM
BSD-1618040055.A35
1618040055
|
-
|
|
|
|
86 - T-HEAD BOLT M8x80 MM
BSD-1613490001.A54
1613490001
|
£8.67
|
£10.41
|
|
|
87 - CLAMPING BAND dia70 MM
BSD-1611316008.A37
1611316008
|
-
|
|
|
|
92 - STRAIGHT PIN 5M6x12 RIKO DIN 6325
BSD-2917550118.A23
2917550118
|
-
|
|
|
|
95 - O-RING 15x3 MM
BSD-1900210114.A30
1900210114
|
£2.61
|
£3.13
|
|
|
97 - INNER RING
BSD-1610202014.A16
1610202014
|
-
|
|
|
|
98 - GROOVE BALL BEARING
BSD-1610900023.A15
1610900023
|
£12.04
|
£14.45
|
|
|
99 - NEEDLE BEARING
BSD-1610910068.A33
1610910068
|
-
|
|
|
|
100 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A23
2600910001
|
£4.26
|
£5.11
|
|
|
101 - NEEDLE BEARING
BSD-2600910000.A44
2600910000
|
-
|
|
|
|
102 - GROOVE BALL BEARING 30x55x13
BSD-1900900276.A13
1900900276
|
£14.91
|
£17.89
|
|
|
104 - SPRING RETAINING RING DIN 471 30x1.5 MM
BSD-2916650017.A13
2916650017
|
£1.75
|
£2.10
|
|
|
105 - SPRING RETAINING RING
BSD-1610116004.A52
1610116004
|
£1.75
|
£2.10
|
|
|
107 - SPRING RETAINING RING 55x2MM. DIN 472
BSD-2916660024.A40
2916660024
|
£5.30
|
£6.36
|
|
|
109 - O-RING 27.0x1.5 MM
BSD-1610210100.A42
1610210100
|
£3.72
|
£4.47
|
|
|
110 - O-RING 54.0x3.0 MM
BSD-1600210004.A279
1600210004
|
£2.80
|
£3.36
|
|
|
111 - O-RING 16.0x2.5 MM
BSD-1610210098.A12
1610210098
|
-
|
|
|
|
112 - O-RING 26.0x4.0 MM
BSD-1610210109.A33
1610210109
|
£4.26
|
£5.11
|
|
|
113 - O-RING 30.0x8.0 MM
BSD-1610210099.A8
1610210099
|
-
|
|
|
|
114 - O-RING 17.0x8.0 MM
BSD-1610210093.A68
1610210093
|
£1.75
|
£2.10
|
|
|
115 - O-RING 12.0x2.0 MM
BSD-1610210135.A4
1610210135
|
£2.80
|
£3.36
|
|
|
116 - ROTARY SHAFT LIP SEAL
BSD-1610283020.A8
1610283020
|
£6.52
|
£7.83
|
|
|
117 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x80-8.8
BSD-2910141262.A15
2910141262
|
£1.75
|
£2.10
|
|
|
118 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x25-8.8
BSD-2910141244.A132
2910141244
|
£1.75
|
£2.10
|
|
|
120 - TAPPING SCREW DIN 7971-ST4.8x38-F
BSD-2910211038.A64
2910211038
|
£1.75
|
£2.10
|
|
|
122 - TAPPING SCREW BZ4.8x63 MM
BSD-1603435008.A153
1603435008
|
£1.32
|
£1.58
|
|
|
123 - TAPPING SCREW DIN 7971-ST4.8x25-C
BSD-2910211236.A93
2910211236
|
£1.75
|
£2.10
|
|
|
125 - TAPPING SCREW DIN 7972-B3.9x13
BSD-2910601118.A49
2910601118
|
£1.75
|
£2.10
|
|
|
126 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A598
2910211011
|
£1.75
|
£2.10
|
|
|
128 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A80
2910021118
|
£1.75
|
£2.10
|
|
|
129 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2921
2603410001
|
£1.75
|
£2.10
|
|
|
131 - MANUFACTURER'S NAMEPLATE
BSD-1611110710.A8
1611110710
|
-
|
|
|
|
132 - COMPRESSION SPRING
BSD-1614619009.A8
1614619009
|
-
|
|
|
|
133 - GUIDE BUSHING
BSD-1610390028.A7
1610390028
|
-
|
|
|
|
134 - RETAINING SNAP RING
BSD-1610200018.A11
1610200018
|
£5.87
|
£7.04
|
|
|
135 - REFERENCE PLATE
BSD-1611110387.A37
1611110387
|
£1.75
|
£2.10
|
|
|
143 - SEALING DISK
BSD-1610109017.A3
1610109017
|
-
|
|
|
|
149 - FELT DISC
BSD-1610108014.A15
1610108014
|
£2.80
|
£3.36
|
|
|
650 - CARRYING CASE
BSD-1615438269.A0
1615438269
|
-
|
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430009.A47
1615430009
|
£13.12
|
£15.75
|
|
|
751 - DEPTH-GAUGE SW 6x330 MM
BSD-1613001003.A48
1613001003
|
£4.25
|
£5.10
|
|
|
784 - AUXILIARY HANDLE dia 70 MM. M8
BSD-2602025062.A11
2602025062
|
£42.02
|
£50.42
|
|
|
801 - MOTOR HOUSING
BSD-1617000997.A2
1617000997
|
-
|
|
|
|
803 - ARMATURE 115V
BSD-1614011063.A1
1614011063
|
-
|
|
|
|
803 - ARMATURE 230-240V
BSD-1614011054.A10
1614011054
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3HC.A107
160111A3HC
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-1617014110.A85
1617014110
|
£18.96
|
£22.75
|
|
|
819 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x25-10.9
BSD-1617000123.A23
1617000123
|
-
|
|
|
|
826 - TOOLHOLDER
BSD-1617000958.A2
1617000958
|
-
|
|
|
|
834 - HAMMER PIPE
BSD-1617000960.A8
1617000960
|
-
|
|
|
|
850 - SPUR WHEEL CLUTCH
BSD-1617000934.A16
1617000934
|
-
|
|
|
|
852 - BEARING FLANGE
BSD-1617000803.A16
1617000803
|
-
|
|
|
|
894 - NEEDLE-ROLLER ASSEMBLY
BSD-1617000169.A11
1617000169
|
-
|
|
|
|
897 - WEAR AND TEAR PART SET
BSD-1617000255.A1
1617000255
|
-
|
|
|
|
898 - WEAR AND TEAR PART SET
BSD-1617000256.A0
1617000256
|
-
|
|
|
