1 - MOTOR HOUSING
BSD-1615102148.A7
1615102148
|
-
|
|
|
2 - FIELD 220-230V
BSD-1604220343.A51
1604220343
|
£33.74
|
£40.49
|
|
4 - SWITCH
BSD-1617200048.A61
1617200048
|
£18.96
|
£22.75
|
|
4/10 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x12-5.8
BSD-2910011088.A71
2910011088
|
£1.75
|
£2.10
|
|
6 - GROMMET dia9.7-dia12x89 MM
BSD-1610703053.A142
1610703053
|
£2.61
|
£3.13
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A679
3600703011
|
£2.80
|
£3.36
|
|
7 - FASTENING CLAMP
BSD-1601302018.A665
1601302018
|
£1.75
|
£2.10
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110594.A0
1611110594
|
-
|
|
|
13 - GROOVE BALL BEARING 7x22x7
BSD-1610900025.A116
1610900025
|
£16.41
|
£19.69
|
|
14 - GROOVE BALL BEARING 12x32x10
BSD-1610905007.A5
1610905007
|
-
|
|
|
15 - FAN
BSD-1616610071.A20
1616610071
|
£9.49
|
£11.39
|
|
17 - RETAINING SNAP RING
BSD-1610222008.A43
1610222008
|
-
|
|
|
18 - RETAINING SNAP RING
BSD-1610222008.A44
1610222008
|
-
|
|
|
19 - GUIDE TUBE
BSD-1615806090.A14
1615806090
|
-
|
|
|
20 - TOOLHOLDER
BSD-1618597060.A8
1618597060
|
-
|
|
|
21 - PROTECTIVE CAP
BSD-1610508017.A16
1610508017
|
£3.72
|
£4.47
|
|
22 - PROTECTION SLEEVE
BSD-1610591009.A14
1610591009
|
-
|
|
|
23 - STOP SLEEVE
BSD-1610520001.A70
1610520001
|
£12.04
|
£14.45
|
|
25 - STOPPING DEVICE
BSD-1612300027.A120
1612300027
|
£11.30
|
£13.56
|
|
26 - INDEXING DISK
BSD-1610290025.A72
1610290025
|
£6.52
|
£7.83
|
|
27 - RETAINING SNAP RING
BSD-1610222008.A45
1610222008
|
-
|
|
|
28 - COMPRESSION SPRING
BSD-1614621000.A9
1614621000
|
£2.80
|
£3.36
|
|
29 - COMPRESSION SPRING
BSD-1614616008.A4
1614616008
|
£2.61
|
£3.13
|
|
30 - BALL RACE
BSD-1610250007.A30
1610250007
|
-
|
|
|
31 - SPACER TUBE
BSD-1610390015.A45
1610390015
|
-
|
|
|
32 - CYLINDER SLEEVE
BSD-1610202016.A26
1610202016
|
-
|
|
|
34 - SUPPORTING DISC 1.5 MM
BSD-1610102622.A9
1610102622
|
£1.95
|
£2.34
|
|
35 - HAMMER PIPE
BSD-1615806089.A18
1615806089
|
-
|
|
|
38 - COVERING HOOD
BSD-1615190035.A0
1615190035
|
-
|
|
|
39 - CLUTCH RING
BSD-1610290024.A8
1610290024
|
-
|
|
|
41 - STRIKER PIN
BSD-1613124036.A22
1613124036
|
-
|
|
|
43 - BEARING COVER
BSD-1615808075.A3
1615808075
|
-
|
|
|
46 - SEALING FRAME
BSD-1611015036.A6
1611015036
|
-
|
|
|
47 - COVER
BSD-1610591012.A31
1610591012
|
£1.75
|
£2.10
|
|
51 - CROWN GEAR Z=37
BSD-1616333023.A8
1616333023
|
-
|
|
|
53 - STOP DISC
BSD-1610190023.A30
1610190023
|
£5.30
|
£6.36
|
|
54 - STOP DISC
BSD-1610101014.A35
1610101014
|
-
|
|
|
57 - STRIKER
BSD-1618710053.A4
1618710053
|
-
|
|
|
72 - ECCENTRIC COG WHEEL Z=35
BSD-1616337003.A14
1616337003
|
-
|
|
|
75 - HANDLE
BSD-1615132045.A2
1615132045
|
-
|
|
|
80 - SPEED GOVERNOR 220-240V
BSD-1617233026.A17
1617233026
|
£46.82
|
£56.18
|
|
81 - SWITCH-PAWL
BSD-1612026030.A10
1612026030
|
-
|
|
|
82 - LIGHT CONDUCTOR
BSD-1615510000.A85
1615510000
|
£2.16
|
£2.59
|
|
84 - AUXILIARY HANDLE
BSD-160202507H.A182
160202507H
|
£11.30
|
£13.56
|
|
85 - SUPPORT CLAMP dia70 MM
BSD-1618040055.A14
1618040055
|
-
|
|
|
86 - T-HEAD BOLT M8x80 MM
BSD-1613490001.A5
1613490001
|
£8.67
|
£10.41
|
|
87 - CLAMPING BAND dia70 MM
BSD-1611316008.A22
1611316008
|
-
|
|
|
89 - WING SCREW M6x30 MM
BSD-1613480010.A20
1613480010
|
£2.80
|
£3.36
|
|
90 - HEX NUT M6
BSD-1613300006.A24
1613300006
|
£1.32
|
£1.58
|
|
91 - CLAMPING PLATE
BSD-1611030010.A28
1611030010
|
£2.16
|
£2.59
|
|
94 - SPRING RETAINING RING
BSD-1610119007.A33
1610119007
|
-
|
|
|
95 - SEALING DISK 14.4-6201 ZJV NILOS
BSD-2916120023.A18
2916120023
|
£3.34
|
£4.01
|
|
96 - SPRING RETAINING RING 55x2MM. DIN 472
BSD-2916660024.A70
2916660024
|
£5.30
|
£6.36
|
|
97 - SHIM RING DIN 988-45x55
BSD-2916190284.A26
2916190284
|
-
|
|
|
98 - FRICTION WASHER 0.5 MM
BSD-1610101622.A9
1610101622
|
-
|
|
|
99 - HOLDING PLATE
BSD-1611329011.A9
1611329011
|
£6.52
|
£7.83
|
|
99/99 - HOLDING PLATE
BSD-1610190030.A28
1610190030
|
£3.72
|
£4.47
|
|
99/154 - RETAINING SNAP RING
BSD-1610222010.A9
1610222010
|
£9.49
|
£11.39
|
|
101 - O-RING 20.0x3.0 MM
BSD-1610210094.A25
1610210094
|
£2.80
|
£3.36
|
|
102 - O-RING 55.0x2.0 MM
BSD-1610210095.A12
1610210095
|
£2.61
|
£3.13
|
|
103 - O-RING 27.0x1.5 MM
BSD-1610210100.A9
1610210100
|
£3.72
|
£4.47
|
|
104 - O-RING 17.0x8.0 MM
BSD-1610210093.A44
1610210093
|
£1.75
|
£2.10
|
|
105 - O-RING 21.0x3.5 MM
BSD-1610210096.A34
1610210096
|
£2.80
|
£3.36
|
|
107 - O-RING 14.0x2.0 MM
BSD-1610210116.A38
1610210116
|
£2.80
|
£3.36
|
|
108 - O-RING 8.0x1.5 MM
BSD-1900210103.A53
1900210103
|
£2.80
|
£3.36
|
|
109 - ROTARY SHAFT LIP SEAL DIN 3760-BS. dia40x55x7 MM
BSD-1610283028.A36
1610283028
|
£5.58
|
£6.70
|
|
110 - SPRING RETAINING RING
BSD-1610116003.A33
1610116003
|
-
|
|
|
111 - O-RING 10.0x1.0 MM
BSD-1610210081.A8
1610210081
|
£3.72
|
£4.47
|
|
112 - CLAMPING RING
BSD-1610210090.A11
1610210090
|
£5.01
|
£6.01
|
|
113 - BACKUP RING
BSD-1610328013.A4
1610328013
|
-
|
|
|
116 - SPRING RETAINING RING
BSD-1610116004.A3
1610116004
|
£1.75
|
£2.10
|
|
117 - SPRING RETAINING RING
BSD-1610119008.A3
1610119008
|
£2.33
|
£2.80
|
|
118 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913009.A3
1610913009
|
-
|
|
|
119 - NEEDLE-ROLLER ASSEMBLY dia10 MM
BSD-1610913011.A9
1610913011
|
£6.52
|
£7.83
|
|
121 - GROOVE BALL BEARING
BSD-1610905014.A26
1610905014
|
-
|
|
|
122 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913029.A110
1610913029
|
£4.26
|
£5.11
|
|
124 - THRUST BEARING DISC 1.0 MM
BSD-1610101008.A40
1610101008
|
-
|
|
|
125 - TAPPING SCREW DIN7981-ST4.8x25-C-Z
BSD-2912401036.A12
2912401036
|
£1.32
|
£1.58
|
|
126 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A507
2910211019
|
£1.75
|
£2.10
|
|
127 - OVAL-HEAD SCREW DIN 7985-M5x30-8.8
BSD-2912311166.A37
2912311166
|
£1.75
|
£2.10
|
|
128 - TAPPING SCREW DIN 7971-BZ4.8x32
BSD-2910211037.A96
2910211037
|
£1.75
|
£2.10
|
|
129 - TAPPING SCREW DIN 7981-ST4.8x32C-Z
BSD-2912401037.A25
2912401037
|
£1.75
|
£2.10
|
|
130 - STICKER
BSD-1601110265.A398
1601110265
|
-
|
|
|
131 - MANUFACTURER'S NAMEPLATE
BSD-1611110595.A0
1611110595
|
-
|
|
|
132 - MICROENCAPSULATED SCREW DIN 912-M 5x12-8.8
BSD-2914551117.A75
2914551117
|
£1.75
|
£2.10
|
|
136 - TAPPING SCREW DIN 7971-ST4.8x25-C
BSD-2910211236.A69
2910211236
|
£1.75
|
£2.10
|
|
139 - FELT DISC dia39x15 MM
BSD-1610005002.A26
1610005002
|
-
|
|
|
148 - SHIM 0.2 MM
BSD-1610102627.A9
1610102627
|
-
|
|
|
148 - SHIM 0.3 MM
BSD-1610102633.A3
1610102633
|
-
|
|
|
149 - ADAPTING PIECE
BSD-1612388021.A3
1612388021
|
-
|
|
|
650 - CARRYING CASE
BSD-1615438262.A0
1615438262
|
-
|
|
|
661 - OIL SPRAY TIN
BSD-1615439012.A7
1615439012
|
£11.30
|
£13.56
|
|
800 - CLAMP HANDLE
BSD-1617000945.A1
1617000945
|
-
|
|
|
803 - ARMATURE 220-240V
BSD-1614010180.A9
1614010180
|
-
|
|
|
805 - POWER SUPPLY CORD
BSD-1617000723.A52
1617000723
|
£27.23
|
£32.68
|
|
808 - NAMEPLATE
BSD-160111A3H3.A3177
160111A3H3
|
£2.61
|
£3.13
|
|
824 - CYLINDRICAL ROLLER
BSD-1617000271.A23
1617000271
|
£4.26
|
£5.11
|
|
833 - CONTROL FORK
BSD-1617000949.A29
1617000949
|
-
|
|
|
837 - RETAINING BRACKET
BSD-1617000291.A41
1617000291
|
-
|
|
|
840 - IMPACT MECHANISM HOUSING
BSD-1617000811.A20
1617000811
|
-
|
|
|
842 - BRUSH HOLDER
BSD-1614336009.A3
1614336009
|
-
|
|
|
842/020 - BRUSH GUIDE
BSD-1614336043.A23
1614336043
|
-
|
|
|
842/040 - CARBON-BRUSH SET
BSD-1617014122.A22
1617014122
|
£18.96
|
£22.75
|
|
842/050 - RUBBER BUFFER
BSD-1613212004.A29
1613212004
|
£3.72
|
£4.47
|
|
842/080 - TAPPING SCREW DIN7981-ST2.9x9.5C-Z
BSD-2912401005.A196
2912401005
|
£1.75
|
£2.10
|
|
845 - GEAR HOUSING
BSD-1617000962.A20
1617000962
|
-
|
|
|
848 - CLUTCH SLEEVE
BSD-1617000415.A31
1617000415
|
-
|
|
|
856 - HAMMER PISTON
BSD-1617000999.A29
1617000999
|
-
|
|
|
860 - SPUR WHEEL CLUTCH
BSD-1617000818.A10
1617000818
|
-
|
|
|
879 - DEPTH-GAUGE SW 6x330 MM
BSD-1613001008.A130
1613001008
|
£8.67
|
£10.41
|
|
884 - AUXILIARY HANDLE dia70 MM
BSD-1612025035.A7
1612025035
|
-
|
|
|
897 - WEAR AND TEAR PART SET
BSD-1617000281.A2
1617000281
|
-
|
|
|
898 - WEAR AND TEAR PART SET
BSD-1617000282.A1
1617000282
|
-
|
|
|
