1 - MOTOR HOUSING
BSD-1619P07704.A10
1619P07704
|
£21.52
|
£25.83
|
|
|
2 - FIELD 115V
BSD-1614220200.A2
1614220200
|
£33.74
|
£40.49
|
|
|
4 - SWITCH
BSD-1619P10396.A1
1619P10396
|
£23.86
|
£28.63
|
|
|
5 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.5mm H07 RN-F
BSD-1604460201.A11
1604460201
|
£37.27
|
£44.72
|
|
|
6 - GROMMET
BSD-1619P07722.A7
1619P07722
|
£2.16
|
£2.59
|
|
|
7 - FASTENING CLAMP
BSD-1601302019.A58
1601302019
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-160111C1L3.A2
160111C1L3
|
-
|
|
|
|
10 - MANUFACTURER'S NAMEPLATE
BSD-160111C1L2.A0
160111C1L2
|
-
|
|
|
|
20 - TOOLHOLDER
BSD-1619P10164.A2
1619P10164
|
£48.38
|
£58.06
|
|
|
21 - PROTECTIVE CAP
BSD-1619P07829.A9
1619P07829
|
£4.26
|
£5.11
|
|
|
22 - PROTECTION SLEEVE
BSD-1619P10160.A3
1619P10160
|
£27.23
|
£32.68
|
|
|
25 - STOPPING DEVICE
BSD-1619P07742.A8
1619P07742
|
£8.67
|
£10.41
|
|
|
27 - AIR-DEFLECTOR RING
BSD-1619P07739.A9
1619P07739
|
£2.61
|
£3.13
|
|
|
28 - COMPRESSION SPRING
BSD-1614621000.A130
1614621000
|
£2.80
|
£3.36
|
|
|
29 - BUSHING
BSD-1619P10163.A3
1619P10163
|
£10.10
|
£12.12
|
|
|
30 - SUPPORTING DISC
BSD-1619P10162.A3
1619P10162
|
£5.30
|
£6.36
|
|
|
31 - SUPPORTING DISC
BSD-1619P07743.A3
1619P07743
|
£7.36
|
£8.83
|
|
|
34 - FLANGE
BSD-1619P10165.A3
1619P10165
|
£3.72
|
£4.47
|
|
|
35 - HAMMER PIPE
BSD-1619P10167.A3
1619P10167
|
£103.14
|
£123.77
|
|
|
37 - CYLINDRICAL ROLLER
BSD-1619P10377.A3
1619P10377
|
£2.61
|
£3.13
|
|
|
38 - COVERING HOOD
BSD-1619P10168.A3
1619P10168
|
£16.41
|
£19.69
|
|
|
42 - BRUSH HOLDER
BSD-1619P07754.A8
1619P07754
|
£21.68
|
£26.01
|
|
|
43 - FAN COVER
BSD-1619P10171.A3
1619P10171
|
£13.12
|
£15.75
|
|
|
44 - COMPRESSION SPRING
BSD-1619P10381.A3
1619P10381
|
£2.61
|
£3.13
|
|
|
45 - CONTROL BUSHING
BSD-1610499070.A14
1610499070
|
£18.96
|
£22.75
|
|
|
46 - PERFORATED RING
BSD-1619P10172.A3
1619P10172
|
£2.80
|
£3.36
|
|
|
47 - GEAR SLEEVE
BSD-1610300064.A29
1610300064
|
£6.52
|
£7.83
|
|
|
48 - CLUTCH SLEEVE
BSD-1616334012.A28
1616334012
|
£5.30
|
£6.36
|
|
|
51 - CROWN GEAR
BSD-1616333041.A31
1616333041
|
£36.63
|
£43.96
|
|
|
53 - SUPPORT DISC
BSD-1610290068.A1
1610290068
|
£3.72
|
£4.47
|
|
|
54 - GUIDE BUSHING
BSD-1610231002.A1
1610231002
|
-
|
|
|
|
57 - STRIKER
BSD-1618710091.A15
1618710091
|
£27.23
|
£32.68
|
|
|
69 - RETAINING BRACKET
BSD-1610099004.A17
1610099004
|
£2.80
|
£3.36
|
|
|
72 - ECCENTRIC COG WHEEL
BSD-1600A00ZZ3.A4
1600A00ZZ3
|
£70.24
|
£84.29
|
|
|
74 - GUIDE PLATE
BSD-1611921001.A17
1611921001
|
£2.61
|
£3.13
|
|
|
75 - HANDLE
BSD-1619P10176.A2
1619P10176
|
£37.27
|
£44.72
|
|
|
76 - CONNECTING TERMINAL
BSD-1611091006.A31
1611091006
|
£1.75
|
£2.10
|
|
|
79 - TORX OVAL-HEAD SCREW M5x12-TORX.T25
BSD-1613435015.A1
1613435015
|
£2.61
|
£3.13
|
|
|
80 - SPEED GOVERNOR
BSD-1619P09590.A0
1619P09590
|
£59.53
|
£71.44
|
|
|
81 - HANDLE COVER
BSD-1619P10177.A4
1619P10177
|
£27.23
|
£32.68
|
|
|
84 - AUXILIARY HANDLE
BSD-160202507H.A362
160202507H
|
£11.30
|
£13.56
|
|
|
85 - SUPPORT CLAMP
BSD-1619P07774.A5
1619P07774
|
£8.67
|
£10.41
|
|
|
86 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A131
1613490002
|
£4.26
|
£5.11
|
|
|
87 - CLAMPING BAND
BSD-1619P07776.A2
1619P07776
|
£3.72
|
£4.47
|
|
|
94 - FRICTION WASHER
BSD-1610102056.A6
1610102056
|
£2.80
|
£3.36
|
|
|
95 - O-RING 32.0x1.5 MM
BSD-1610210173.A18
1610210173
|
£2.16
|
£2.59
|
|
|
97 - LOCKING WASHER
BSD-1610031005.A31
1610031005
|
£3.72
|
£4.47
|
|
|
99 - SUPPORT DISC
BSD-1610102059.A29
1610102059
|
£2.61
|
£3.13
|
|
|
100 - DRIVING PIN
BSD-1613120022.A5
1613120022
|
£2.61
|
£3.13
|
|
|
101 - RETAINING SNAP RING
BSD-1610499073.A3
1610499073
|
£6.52
|
£7.83
|
|
|
102 - SHIM 0.3 MM
BSD-1610102057.A29
1610102057
|
£1.75
|
£2.10
|
|
|
102 - SHIM 0.2 MM
BSD-1610102058.A4
1610102058
|
£1.75
|
£2.10
|
|
|
104 - O-RING 52.0x2.0 MM
BSD-1610210160.A13
1610210160
|
£3.72
|
£4.47
|
|
|
111 - BUSHING
BSD-1610290064.A60
1610290064
|
£1.75
|
£2.10
|
|
|
112 - RING MAGNET
BSD-1619P10179.A3
1619P10179
|
£5.58
|
£6.70
|
|
|
113 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A255
1613435009
|
£1.75
|
£2.10
|
|
|
117 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913029.A28
1610913029
|
£4.26
|
£5.11
|
|
|
120 - STOP SLEEVE
BSD-1610590019.A3
1610590019
|
£18.96
|
£22.75
|
|
|
125 - TORX OVAL-HEAD SCREW M5x16-TORX.T25
BSD-1613435014.A28
1613435014
|
£2.16
|
£2.59
|
|
|
126 - SCREW 4x16
BSD-2603490022.A889
2603490022
|
£1.75
|
£2.10
|
|
|
129 - HOLDING SLEEVE
BSD-1619P10181.A3
1619P10181
|
£11.30
|
£13.56
|
|
|
130 - COVER
BSD-1619P10182.A3
1619P10182
|
£6.52
|
£7.83
|
|
|
138 - SEALING FRAME
BSD-1611015053.A12
1611015053
|
£12.04
|
£14.45
|
|
|
141 - ROTARY SHAFT LIP SEAL
BSD-1610290066.A60
1610290066
|
£10.10
|
£12.12
|
|
|
142 - ROTARY SHAFT LIP SEAL
BSD-1610290069.A29
1610290069
|
£5.58
|
£6.70
|
|
|
143 - RETAINING RING DIN 7993-28x2
BSD-1614601021.A92
1614601021
|
£7.36
|
£8.83
|
|
|
145 - SPRING RETAINING RING
BSD-1610119012.A46
1610119012
|
£2.61
|
£3.13
|
|
|
150 - SLOTTED SPRING PIN
BSD-2917790174.A1
2917790174
|
£1.75
|
£2.10
|
|
|
154 - SPRING RETAINING RING DIN 472 52x2MM
BSD-2916660023.A5
2916660023
|
£5.30
|
£6.36
|
|
|
158 - RETAINING RING
BSD-1614601070.A4
1614601070
|
£2.16
|
£2.59
|
|
|
160 - DAMPING RING
BSD-1610290095.A3
1610290095
|
£11.30
|
£13.56
|
|
|
161 - DAMPING RING
BSD-1610290094.A13
1610290094
|
£4.26
|
£5.11
|
|
|
162 - O-RING 22.5x3.5 MM
BSD-1610210204.A13
1610210204
|
£5.58
|
£6.70
|
|
|
163 - SEAL RING
BSD-1610290065.A1
1610290065
|
£8.13
|
£9.76
|
|
|
165 - O-RING 22.0x4.0 MM
BSD-1610210079.A29
1610210079
|
£5.58
|
£6.70
|
|
|
167 - ROTARY SHAFT LIP SEAL
BSD-1610283033.A29
1610283033
|
£6.52
|
£7.83
|
|
|
168 - O-RING 22.0x3.0 MM
BSD-1610210144.A40
1610210144
|
£5.30
|
£6.36
|
|
|
171 - TORX OVAL-HEAD SCREW M5x16-TORX. T25
BSD-1619P07816.A3
1619P07816
|
£1.75
|
£2.10
|
|
|
172 - TORX OVAL-HEAD SCREW M6x30-TORX.T30
BSD-1613435013.A1
1613435013
|
£2.16
|
£2.59
|
|
|
173 - SCREW 4x16
BSD-2603490022.A890
2603490022
|
£1.75
|
£2.10
|
|
|
174 - TORX OVAL-HEAD SCREW M4.8x25-TORX.T25
BSD-1613435012.A114
1613435012
|
£2.16
|
£2.59
|
|
|
175 - TAPPING SCREW DIN7981-ST3.9x13-C-Z
BSD-2912401018.A451
2912401018
|
£1.75
|
£2.10
|
|
|
176 - TORX OVAL-HEAD SCREW M4.8x25-TORX.T25
BSD-1613435012.A115
1613435012
|
£2.16
|
£2.59
|
|
|
177 - SCREW ST3.9x32
BSD-1619P07821.A8
1619P07821
|
£1.75
|
£2.10
|
|
|
178 - CONNECTING CABLE
BSD-1604412069.A15
1604412069
|
£7.36
|
£8.83
|
|
|
179 - SCREW
BSD-1619P07815.A8
1619P07815
|
£1.75
|
£2.10
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430010.A264
1615430010
|
£6.52
|
£7.83
|
|
|
691 - CARRYING CASE
BSD-16054381D1.A4
16054381D1
|
£45.67
|
£54.80
|
|
|
803 - ARMATURE
BSD-1604010BE0.A0
1604010BE0
|
-
|
|
|
|
803/13 - GROOVE BALL BEARING 8x24x8
BSD-1610900026.A60
1610900026
|
£12.04
|
£14.45
|
|
|
803/14 - GROOVE BALL BEARING 12x32x10
BSD-1610905041.A5
1610905041
|
£11.30
|
£13.56
|
|
|
808 - NAMEPLATE
BSD-160111A5YM.A0
160111A5YM
|
-
|
|
|
|
811 - CARBON-BRUSH SET
BSD-1617014138.A16
1617014138
|
£21.52
|
£25.83
|
|
|
817 - SPIRAL SPRING
BSD-1614652004.A72
1614652004
|
£7.36
|
£8.83
|
|
|
821 - BUSHING
BSD-1619P10749.A4
1619P10749
|
£21.68
|
£26.01
|
|
|
840 - IMPACT MECHANISM HOUSING
BSD-1619P10770.A3
1619P10770
|
£93.88
|
£112.65
|
|
|
841 - STRIKER PIN
BSD-1619P10752.A2
1619P10752
|
£40.80
|
£48.96
|
|
|
849 - CONTROL FORK
BSD-1617000839.A32
1617000839
|
£23.86
|
£28.63
|
|
|
854 - GUIDE BUSHING
BSD-1619P10847.A3
1619P10847
|
£54.42
|
£65.30
|
|
|
856 - HAMMER PISTON
BSD-1619P10765.A4
1619P10765
|
£31.64
|
£37.97
|
|
|
860 - SPUR WHEEL CLUTCH
BSD-1619P10766.A2
1619P10766
|
£72.18
|
£86.62
|
|
|
873 - HOUSING COVER
BSD-1619P10767.A4
1619P10767
|
£37.27
|
£44.72
|
|
|
884 - AUXILIARY HANDLE
BSD-1619P07778.A3
1619P07778
|
£16.41
|
£19.69
|
|
|
897 - WEAR AND TEAR PART SET
BSD-1619P10768.A2
1619P10768
|
£48.38
|
£58.06
|
|
