3 - BRUSH
BDE-899568.A0
899568
|
-
|
|
|
4 - SWITCH
BDE-887454.A3
887454
|
-
|
|
|
6 - BRUSH HOLDER
BDE-694301.A3
694301
|
-
|
|
|
7 - CONTROL MODULE SA
BDE-N029762.A3
N029762
|
-
|
|
|
8 - DUST GUARD
BDE-887452.A2
887452
|
-
|
|
|
11 - BEARING
BDE-855216SV
855216SV
|
-
|
|
|
15 - BEARING
BDE-330003-64.A83
330003-64
|
£4.69
|
£5.63
|
|
16 - BEARING NEEDLE
BDE-93129-00.A53
93129-00
|
£1.50
|
£1.80
|
|
19 - BEARING
BDE-883096
883096
|
-
|
|
|
35 - IDLER ASSEMBLY
BDE-697674.A0
697674
|
-
|
|
|
38 - SPINDLE & GEAR
BDE-877787.A1
877787
|
-
|
|
|
39 - SPINDLE
BDE-A04176.A2
A04176
|
-
|
|
|
51 - CLAMSHELL
BDE-903845.A1
903845
|
-
|
|
|
52 - HOUSING MOTOR
BDE-876677
876677
|
-
|
|
|
53 - HOUSING GEAR
BDE-886654.A1
886654
|
-
|
|
|
59 - VACUUM ADAPTOR
BDE-885163.A1
885163
|
-
|
|
|
67 - TEMPLATE
BDE-697684.A1
697684
|
-
|
|
|
99 - RING
BDE-859769.A1
859769
|
£1.50
|
£1.80
|
|
100 - TUBE
BDE-885331SV
885331SV
|
-
|
|
|
102 - SCREW
BDE-694015
694015
|
-
|
|
|
103 - WASHER
BDE-802648.A1
802648
|
-
|
|
|
104 - WASHER
BDE-848741.A1
848741
|
-
|
|
|
105 - WASHER
BDE-852714.A3
852714
|
£1.50
|
£1.80
|
|
106 - GASKET
BDE-697203
697203
|
-
|
|
|
107 - SCREW
BDE-864136.A0
864136
|
-
|
|
|
108 - INSULATOR
BDE-694298.A0
694298
|
-
|
|
|
109 - CORD CLAMP
BDE-861434.A0
861434
|
£1.42
|
£1.70
|
|
110 - HOLDER BEARING
BDE-694432.A0
694432
|
£1.50
|
£1.80
|
|
111 - CLAMP
BDE-877772.A2
877772
|
-
|
|
|
112 - RING
BDE-877771.A1
877771
|
-
|
|
|
113 - TUBE GUIDE
BDE-877774.A1
877774
|
-
|
|
|
114 - TUBE SUPPORT
BDE-645825-00.A2
645825-00
|
-
|
|
|
115 - HEAD
BDE-879688.A3
879688
|
-
|
|
|
116 - HEAD
BDE-877725.A1
877725
|
-
|
|
|
117 - BUSHING
BDE-877730.A0
877730
|
-
|
|
|
118 - CASING
BDE-887979
887979
|
-
|
|
|
119 - CLAMP
BDE-877733.A2
877733
|
-
|
|
|
120 - HOUSING
BDE-889303.A1
889303
|
-
|
|
|
121 - CLAMP
BDE-884843.A0
884843
|
-
|
|
|
122 - PLATE
BDE-879737.A1
879737
|
-
|
|
|
123 - BELLOWS
BDE-879772.A1
879772
|
-
|
|
|
124 - RING
BDE-684179.A0
684179
|
£1.50
|
£1.80
|
|
125 - PIN
BDE-879685.A3
879685
|
-
|
|
|
126 - PIN
BDE-879686.A0
879686
|
-
|
|
|
127 - HOUSING
BDE-899234.A1
899234
|
-
|
|
|
128 - HOSE SA
BDE-A01929.A3
A01929
|
-
|
|
|
129 - RING
BDE-859382.A3
859382
|
-
|
|
|
130 - VACUUM ADAPTOR
BDE-887492.A1
887492
|
-
|
|
|
131 - RING
BDE-696667.A2
696667
|
-
|
|
|
132 - PAD
BDE-N346519.A0
N346519
|
-
|
|
|
134 - WASHER
BDE-877738.A1
877738
|
-
|
|
|
135 - SKIRT
BDE-877702.A2
877702
|
-
|
|
|
136 - NUT
BDE-877757.A0
877757
|
-
|
|
|
137 - CORD PROTECTOR
BDE-810716.A3
810716
|
-
|
|
|
138 - PLUG
BDE-879770.A2
879770
|
-
|
|
|
139 - SCREW
BDE-848565.A2
848565
|
-
|
|
|
140 - SCREW
BDE-882187.A9
882187
|
£1.50
|
£1.80
|
|
141 - SCREW
BDE-878813.A0
878813
|
-
|
|
|
142 - SCREW
BDE-859384.A0
859384
|
-
|
|
|
143 - LEAD
BDE-879829
879829
|
-
|
|
|
144 - O RING
BDE-879769.A1
879769
|
-
|
|
|
145 - SEAL
BDE-695620.A0
695620
|
-
|
|
|
146 - DRIVE SHAFT
BDE-877728
877728
|
-
|
|
|
147 - SCREW
BDE-882703.A0
882703
|
£1.50
|
£1.80
|
|
148 - RING
BDE-847564.A1
847564
|
-
|
|
|
149 - BAFFLE
BDE-811350.A3
811350
|
-
|
|
|
151 - SCREW
BDE-876651
876651
|
-
|
|
|
153 - SPRING
BDE-877755.A3
877755
|
-
|
|
|
154 - INSULATOR
BDE-877762.A2
877762
|
-
|
|
|
155 - CLIP
BDE-694980.A0
694980
|
-
|
|
|
156 - SCREW
BDE-864137.A3
864137
|
-
|
|
|
157 - PIVOT BLOCK
BDE-877778.A3
877778
|
-
|
|
|
158 - SCREW
BDE-892780.A0
892780
|
-
|
|
|
159 - CONNECTOR
BDE-682063.A2
682063
|
-
|
|
|
160 - WASHER
BDE-802214.A0
802214
|
-
|
|
|
161 - SCREW
BDE-883485
883485
|
-
|
|
|
162 - CONDENSOR
BDE-253207
253207
|
-
|
|
|
163 - SCREW
BDE-884950
884950
|
-
|
|
|
164 - NO LONGER AVAILABLE
BDE-000000-00.A96095
000000-00
|
-
|
|
|
165 - TERMINAL BLOCK
BDE-890249
890249
|
-
|
|
|
167 - HOSE SA
BDE-877751.A1
877751
|
-
|
|
|
168 - STRAP
BDE-877768
877768
|
-
|
|
|
169 - GREASE
BDE-878499.A0
878499
|
-
|
|
|
170 - GREASE 4LBS
BDE-879751.A2
879751
|
-
|
|
|
171 - NO LONGER AVAILABLE
BDE-000000-00.A96096
000000-00
|
-
|
|
|
172 - GREASE 4LBS
BDE-875667.A0
875667
|
£24.39
|
£29.27
|
|
173 - REDUCER
BDE-882428.A2
882428
|
-
|
|
|
174 - CONNECTOR
BDE-890961.A3
890961
|
-
|
|
|
178 - ADAPTOR
BDE-5140027-24.A1
5140027-24
|
-
|
|
|
856 - DUSTBAG
BDE-877752.A0
877752
|
£144.10
|
£172.92
|
|
