1 - MOTOR HOUSING
BSD-3605102081.A4
3605102081
|
£156.22
|
£187.46
|
|
|
2 - STATOR 72V/200HZ
BSD-1604229100.A19
1604229100
|
-
|
|
|
|
3 - ROTOR
BSD-3604080010.A4
3604080010
|
-
|
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600209002.A62
1600209002
|
£5.30
|
£6.36
|
|
|
5 - INTERMEDIATE BEARING
BSD-3605700097.A2
3605700097
|
-
|
|
|
|
6 - GROOVE BALL BEARING 15x35x11
BSD-1900905228.A8
1900905228
|
£23.86
|
£28.63
|
|
|
7 - O-RING 22x2 MM
BSD-1900210321.A112
1900210321
|
£5.30
|
£6.36
|
|
|
8 - BALL BEARING 7x22x7
BSD-1900905018.A639
1900905018
|
£18.96
|
£22.75
|
|
|
8 - BALL BEARING 7x22x7
BSD-1900905018.A640
1900905018
|
£18.96
|
£22.75
|
|
|
9 - CLAMPING SADDLE
BSD-3601321001.A531
3601321001
|
£3.72
|
£4.47
|
|
|
10 - SPRING WASHER dia4.2 MM
BSD-3600150006.A634
3600150006
|
£2.61
|
£3.13
|
|
|
11 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A122
2910110120
|
£1.75
|
£2.10
|
|
|
12 - SET SCREW
BSD-1603402002.A211
1603402002
|
£1.75
|
£2.10
|
|
|
13 - SET SCREW
BSD-1603402004.A102
1603402004
|
£2.61
|
£3.13
|
|
|
15 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-8.8
BSD-2910021157.A40
2910021157
|
£1.32
|
£1.58
|
|
|
16 - SHIM 0.2 MM
BSD-1600100632.A34
1600100632
|
£1.75
|
£2.10
|
|
|
17 - SHIM 0.10 MM
BSD-1420100023.A1
1420100023
|
-
|
|
|
|
18 - SHIM 0.05 MM
BSD-1600100601.A59
1600100601
|
-
|
|
|
|
27 - STOP DISC
BSD-3600102014.A15
3600102014
|
-
|
|
|
|
56 - ON-OFF SWITCH
BSD-3607200015.A3
3607200015
|
-
|
|
|
|
58 - HANDLE
BSD-3605132043.A1
3605132043
|
£59.53
|
£71.44
|
|
|
59 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A887
3600703011
|
£2.80
|
£3.36
|
|
|
60 - HELICAL CONDUCTOR
BSD-3604462005.A21
3604462005
|
-
|
|
|
|
61 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x30-8.8
BSD-2910141166.A215
2910141166
|
£1.75
|
£2.10
|
|
|
62 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1432
2910021118
|
£1.75
|
£2.10
|
|
|
63 - FASTENING CLAMP
BSD-1601302014.A1174
1601302014
|
£2.61
|
£3.13
|
|
|
65 - SWITCH
BSD-3607200000.A46
3607200000
|
£21.52
|
£25.83
|
|
|
67 - END SPLICE
BSD-3604477008.A95
3604477008
|
£1.75
|
£2.10
|
|
|
68 - PVC-INSULATED CABLE
BSD-3604412003.A2
3604412003
|
-
|
|
|
|
69 - SEALING PLATE
BSD-1602388006.A24
1602388006
|
£5.58
|
£6.70
|
|
|
70 - GROMMET
BSD-1600306001.A335
1600306001
|
£2.61
|
£3.13
|
|
|
71 - SOCKET HEAD CAP SCREW DIN 84-AM5x6-5.8
BSD-2910011148.A29
2910011148
|
£1.75
|
£2.10
|
|
|
73 - PARTS SET
BSD-2609201067.A15
2609201067
|
-
|
|
|
|
76 - CONNECTOR PLUG
BSD-3604484003.A28
3604484003
|
-
|
|
|
|
78 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A797
2910211021
|
£1.75
|
£2.10
|
|
|
95 - NAMEPLATE
BSD-3601106053.A636
3601106053
|
£5.30
|
£6.36
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110047.A289
3601110047
|
£2.80
|
£3.36
|
|
|
97 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A546
3603133001
|
£2.61
|
£3.13
|
|
|
98 - STICKER
BSD-3601103012.A18
3601103012
|
-
|
|
|
|
99 - STICKER
BSD-3601119066.A0
3601119066
|
£1.95
|
£2.34
|
|
|
226 - PINION
BSD-3606300059.A3
3606300059
|
-
|
|
|
|
227 - STOP DISC
BSD-3600101004.A57
3600101004
|
£2.61
|
£3.13
|
|
|
228 - RING GEAR Z=46
BSD-3606334045.A2
3606334045
|
-
|
|
|
|
229 - PLANETARY-GEAR CARRIER
BSD-3606337087.A3
3606337087
|
-
|
|
|
|
230 - CYLINDRICAL GEAR Z=20
BSD-3606316051.A8
3606316051
|
£33.74
|
£40.49
|
|
|
231 - NEEDLE-ROLLER ASSEMBLY
BSD-3600910000.A33
3600910000
|
£4.26
|
£5.11
|
|
|
232 - NEEDLE ROLLER
BSD-3603201005.A29
3603201005
|
£2.80
|
£3.36
|
|
|
234 - NEEDLE ROLLER
BSD-3603201031.A6
3603201031
|
£2.61
|
£3.13
|
|
|
235 - GROOVE BALL BEARING 25x37x7
BSD-3600905001.A8
3600905001
|
£31.64
|
£37.97
|
|
|
236 - PLANETARY-GEAR CARRIER
BSD-3606337090.A5
3606337090
|
-
|
|
|
|
237 - CYLINDRICAL GEAR
BSD-3606316105.A24
3606316105
|
£37.27
|
£44.72
|
|
|
238 - SPACER RING
BSD-3600101012.A26
3600101012
|
£18.96
|
£22.75
|
|
|
239 - GROOVE BALL BEARING
BSD-3600905057.A76
3600905057
|
£21.68
|
£26.01
|
|
|
246 - O-RING 47.0x1.5 MM
BSD-3600210109.A238
3600210109
|
£2.16
|
£2.59
|
|
|
247 - RETAINING WASHER
BSD-3600102002.A7
3600102002
|
-
|
|
|
|
248 - STOP DISC
BSD-3600100006.A23
3600100006
|
£5.58
|
£6.70
|
|
|
249 - NEEDLE ROLLER
BSD-3603201030.A28
3603201030
|
£2.80
|
£3.36
|
|
|
250 - GROOVE BALL BEARING
BSD-3600905103.A24
3600905103
|
£23.86
|
£28.63
|
|
|
251 - SEALING WASHER
BSD-2916090009.A17
2916090009
|
-
|
|
|
|
339 - SPINDLE HOUSING
BSD-3605106032.A8
3605106032
|
-
|
|
|
|
341 - UNION NUT
BSD-3603340015.A5
3603340015
|
-
|
|
|
|
342 - RETAINING RING
BSD-3600224017.A7
3600224017
|
£2.61
|
£3.13
|
|
|
343 - THREADED RING
BSD-3603490007.A8
3603490007
|
-
|
|
|
|
344 - SUPPORT DISC 15X28X2.75
BSD-3600150003.A28
3600150003
|
£12.04
|
£14.45
|
|
|
345 - THRUST NEEDLE RIM
BSD-1610913000.A38
1610913000
|
£2.80
|
£3.36
|
|
|
346 - O-RING 45x2.5MM
BSD-1900210145.A61
1900210145
|
£1.75
|
£2.10
|
|
|
347 - NEEDLE-ROLLER BEARING
BSD-1410920001.A10
1410920001
|
-
|
|
|
|
350 - BEVEL GEAR SET
BSD-3608871857.A1
3608871857
|
-
|
|
|
|
352 - BEARING FLANGE
BSD-3603490006.A0
3603490006
|
-
|
|
|
|
353 - O-RING 25x2.5 MM
BSD-1900210125.A1
1900210125
|
£7.36
|
£8.83
|
|
|
354 - NEEDLE-ROLLER ASSEMBLY
BSD-3600917021.A6
3600917021
|
-
|
|
|
|
355 - SUPPORT DISC 1.0 MM
BSD-1610102617.A57
1610102617
|
£2.16
|
£2.59
|
|
|
356 - ROLLER-CAGE ASSEMBLY
BSD-1610920002.A63
1610920002
|
£3.72
|
£4.47
|
|
|
357 - NEEDLE BEARING
BSD-3600917020.A6
3600917020
|
£14.91
|
£17.89
|
|
|
358 - BEARING BOLT
BSD-3603100007.A0
3603100007
|
-
|
|
|
|
359 - SHIM
BSD-3600100018.A7
3600100018
|
£2.80
|
£3.36
|
|
|
359 - SHIM
BSD-3600100019.A1
3600100019
|
-
|
|
|
|
363 - O-RING 41.0x1.78 MM
BSD-3600210006.A32
3600210006
|
£2.16
|
£2.59
|
|
|
650 - SUSPENSION LOOP
BSD-3604720023.A11
3604720023
|
-
|
|
|
