1 - MOTOR HOUSING
BSD-3600760022.A17
3600760022
|
£63.50
|
£76.20
|
|
2 - STATOR 120W
BSD-3604090017.A10
3604090017
|
£81.81
|
£98.17
|
|
3 - ROTOR
BSD-3604220013.A1
3604220013
|
£102.57
|
£123.08
|
|
5 - BEARING FLANGE
BSD-3605700023.A1
3605700023
|
£23.86
|
£28.63
|
|
6 - BALL BEARING 7x19x6
BSD-2600905032.A434
2600905032
|
£5.30
|
£6.36
|
|
7 - BEARING FLANGE
BSD-3605700022.A16
3605700022
|
£72.18
|
£86.62
|
|
8 - GROOVE BALL BEARING 7x14x5
BSD-1900905030.A6
1900905030
|
£33.74
|
£40.49
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A111
2916011012
|
£1.75
|
£2.10
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A121
2911061150
|
£2.61
|
£3.13
|
|
26 - PINION Z=15
BSD-3606300018.A0
3606300018
|
£27.31
|
£32.77
|
|
27 - STOP DISC
BSD-3600101008.A52
3600101008
|
£1.75
|
£2.10
|
|
28 - RING GEAR Z=42
BSD-3606334011.A17
3606334011
|
£63.50
|
£76.20
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337057.A17
3606337057
|
£48.38
|
£58.06
|
|
31 - CYLINDRICAL GEAR Z=13
BSD-3606316010.A27
3606316010
|
-
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A363
3600913000
|
£4.26
|
£5.11
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A220
3603201000
|
£1.75
|
£2.10
|
|
36 - GROOVE BALL BEARING 12x21x5
BSD-3600905002.A207
3600905002
|
£16.41
|
£19.69
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337030.A2
3606337030
|
-
|
|
|
39 - CYLINDRICAL GEAR
BSD-3606316114.A6
3606316114
|
£13.12
|
£15.75
|
|
41 - GROOVE BALL BEARING 8x22x7
BSD-1900905041.A11
1900905041
|
£13.12
|
£15.75
|
|
42 - O-RING 22x2 MM
BSD-1900210321.A65
1900210321
|
£5.30
|
£6.36
|
|
56 - VALVE HOUSING
BSD-3605190036.A0
3605190036
|
-
|
|
|
57 - HOUSING COVER
BSD-3605500006.A2
3605500006
|
£2.16
|
£2.59
|
|
59 - SILENCER
BSD-3600002002.A45
3600002002
|
£3.72
|
£4.47
|
|
60 - STRAINER
BSD-3600002001.A68
3600002001
|
£2.61
|
£3.13
|
|
62 - SUSPENSION LOOP
BSD-2604720004.A82
2604720004
|
£4.26
|
£5.11
|
|
63 - NEEDLE ROLLER
BSD-3603201023.A1
3603201023
|
£1.75
|
£2.10
|
|
66 - STRAIGHT PIN
BSD-3603201001.A28
3603201001
|
£4.26
|
£5.11
|
|
68 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A135
1903230013
|
£2.16
|
£2.59
|
|
69 - COMPRESSION SPRING
BSD-3604611006.A46
3604611006
|
£2.16
|
£2.59
|
|
76 - THREADED RING
BSD-3603344003.A2
3603344003
|
£2.61
|
£3.13
|
|
77 - CONTROL LEVER
BSD-3601902001.A73
3601902001
|
£6.52
|
£7.83
|
|
78 - GROOVED PIN DIN 1475-2x18-ST
BSD-2917700040.A22
2917700040
|
£2.80
|
£3.36
|
|
82 - O-RING 20.0x1.0 MM
BSD-3600210012.A60
3600210012
|
£2.80
|
£3.36
|
|
86 - COUNTERSUNK-HEAD SCREW M 3x10 DIN 963-5.8
BSD-2910771052.A3
2910771052
|
-
|
|
|
87 - SEALING PLATE
BSD-3600054000.A3
3600054000
|
£2.16
|
£2.59
|
|
88 - SILENCER
BSD-3601010002.A53
3601010002
|
£2.80
|
£3.36
|
|
89 - SILENCER
BSD-3601010001.A69
3601010001
|
£2.16
|
£2.59
|
|
95 - NAMEPLATE
BSD-160111A3HF.A124
160111A3HF
|
£3.72
|
£4.47
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A287
1601110481
|
£2.16
|
£2.59
|
|
97 - GROOVED NAIL
BSD-3603133000.A305
3603133000
|
£2.61
|
£3.13
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1369
3601119236
|
£3.72
|
£4.47
|
|
100 - HOUSING
BSD-3605125021.A2
3605125021
|
-
|
|
|
101 - CLUTCH ELEMENT
BSD-3606445034.A4
3606445034
|
£102.57
|
£123.08
|
|
102 - DRIVE SHAFT
BSD-3606122010.A8
3606122010
|
-
|
|
|
104 - LEAF SPRING
BSD-3601250002.A3
3601250002
|
£4.26
|
£5.11
|
|
106 - COMPRESSION SPRING
BSD-3604615004.A13
3604615004
|
£1.75
|
£2.10
|
|
109 - COMPRESSION SPRING
BSD-3604619007.A3
3604619007
|
£2.80
|
£3.36
|
|
110 - RETAINING RING
BSD-3604603000.A28
3604603000
|
-
|
|
|
113 - UNION NUT
BSD-3603343000.A17
3603343000
|
£11.30
|
£13.56
|
|
114 - BUSHING
BSD-3600311004.A1
3600311004
|
£16.41
|
£19.69
|
|
115 - SEALING PLATE
BSD-3600001003.A3
3600001003
|
-
|
|
|
116 - ADJUSTING DISC
BSD-3600134002.A29
3600134002
|
£1.75
|
£2.10
|
|
119 - SUPPORT DISC
BSD-3600114007.A3
3600114007
|
£10.10
|
£12.12
|
|
120 - ROUND NUT
BSD-3603340003.A28
3603340003
|
£23.86
|
£28.63
|
|
124 - COUPLING PLATE
BSD-3600114006.A6
3600114006
|
-
|
|
|
127 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A130
1903230004
|
£2.16
|
£2.59
|
|
128 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A296
1903230007
|
£1.75
|
£2.10
|
|
130 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A355
1903230003
|
£2.61
|
£3.13
|
|
131 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A356
1903230003
|
£2.61
|
£3.13
|
|
135 - STOP DISC
BSD-3600113003.A2
3600113003
|
£1.75
|
£2.10
|
|
140 - RETAINING RING 12 DIN 9045
BSD-2916600007.A159
2916600007
|
£2.80
|
£3.36
|
|
652 - HOSE FITTING
BSD-3603386002.A82
3603386002
|
£3.34
|
£4.01
|
|
653 - ANGLE PIECE
BSD-3601329007.A84
3601329007
|
£4.26
|
£5.11
|
|
702 - HANDLE
BSD-3600499002.A5
3600499002
|
£21.68
|
£26.01
|
|
703 - HEX NUT
BSD-3603458003.A36
3603458003
|
£4.26
|
£5.11
|
|
704 - HOSE FITTING
BSD-3607010011.A3
3607010011
|
-
|
|
|
705 - CLUTCH ELEMENT
BSD-3607031085.A1
3607031085
|
-
|
|
|
706 - HEXAGON-SOCKET KEY DIN 911 SW 7
BSD-1907950013.A2
1907950013
|
-
|
|
|
712 - HEXAGON-SOCKET KEY
BSD-3607950001.A224
3607950001
|
£2.80
|
£3.36
|
|
801 - OVERRIDING CLUTCH
BSD-3607031121.A3
3607031121
|
-
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031059.A0
3607031059
|
£306.65
|
£367.98
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030259.A43
3607030259
|
£31.64
|
£37.97
|
|
843 - SPRING RETAINING RING
BSD-3607010009.A1
3607010009
|
-
|
|
|
