1 - MOTOR HOUSING
BSD-16051082JD.A33
16051082JD
|
-
|
|
|
|
2 - STATOR 180W
BSD-3604090050.A37
3604090050
|
£93.88
|
£112.65
|
|
|
3 - ROTOR
BSD-3604220080.A13
3604220080
|
£102.57
|
£123.08
|
|
|
5 - BEARING FLANGE
BSD-3605700107.A65
3605700107
|
£37.27
|
£44.72
|
|
|
6 - GROOVE BALL BEARING 7x19x6
BSD-1900905044.A116
1900905044
|
£7.36
|
£8.83
|
|
|
7 - BEARING FLANGE
BSD-3605700108.A8
3605700108
|
£45.67
|
£54.80
|
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A281
1900905028
|
£33.74
|
£40.49
|
|
|
26 - PINION Z=15
BSD-3606300018.A20
3606300018
|
£27.31
|
£32.77
|
|
|
27 - STOP DISC
BSD-3600101047.A148
3600101047
|
£2.16
|
£2.59
|
|
|
28 - RING GEAR dia19.5 MM
BSD-3606334085.A41
3606334085
|
£8.67
|
£10.41
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337181.A12
3606337181
|
£48.38
|
£58.06
|
|
|
31 - CYLINDRICAL GEAR Z=13
BSD-3606316010.A14
3606316010
|
-
|
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A115
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A250
3603201000
|
£1.75
|
£2.10
|
|
|
36 - GROOVE BALL BEARING 12x21x5
BSD-3600905002.A24
3600905002
|
£16.41
|
£19.69
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337015.A8
3606337015
|
£93.88
|
£112.65
|
|
|
39 - CYLINDRICAL GEAR
BSD-3606316114.A103
3606316114
|
£13.12
|
£15.75
|
|
|
41 - GROOVE BALL BEARING
BSD-3600905015.A55
3600905015
|
£16.41
|
£19.69
|
|
|
53 - O-RING
BSD-3600210092.A33
3600210092
|
£2.16
|
£2.59
|
|
|
54 - COMPRESSION SPRING
BSD-3604611017.A56
3604611017
|
£2.61
|
£3.13
|
|
|
56 - VALVE HOUSING
BSD-3605190174.A0
3605190174
|
£63.50
|
£76.20
|
|
|
58 - SEAL RING
BSD-2600206004.A20
2600206004
|
£7.36
|
£8.83
|
|
|
60 - STRAINER
BSD-3600002000.A33
3600002000
|
£3.72
|
£4.47
|
|
|
61 - O-RING 9.0x1.5 MM
BSD-2600210021.A86
2600210021
|
£1.75
|
£2.10
|
|
|
62 - FITTING
BSD-3603458016.A3
3603458016
|
£11.30
|
£13.56
|
|
|
66 - STRAIGHT PIN
BSD-3603201077.A3
3603201077
|
£11.30
|
£13.56
|
|
|
68 - BALL DIN 5401-8 MM III-ST
BSD-1903230014.A58
1903230014
|
£1.75
|
£2.10
|
|
|
71 - CONTROL PISTON
BSD-3608750038.A23
3608750038
|
£23.86
|
£28.63
|
|
|
72 - COILED SPRING PIN DIN 7343-1.5x10
BSD-2917800016.A88
2917800016
|
£1.75
|
£2.10
|
|
|
73 - VALVE BUSHING
BSD-3600340008.A39
3600340008
|
£45.67
|
£54.80
|
|
|
74 - COMPRESSION SPRING
BSD-3604611007.A40
3604611007
|
£2.16
|
£2.59
|
|
|
75 - STRAIGHT PIN DIN6325-2M6X6
BSD-2917550034.A42
2917550034
|
£1.75
|
£2.10
|
|
|
76 - O-RING
BSD-3600210094.A47
3600210094
|
£2.80
|
£3.36
|
|
|
77 - CONTROL LEVER
BSD-3601902001.A30
3601902001
|
£6.52
|
£7.83
|
|
|
78 - GROOVED PIN DIN 1475-2x18-ST
BSD-2917700040.A101
2917700040
|
£2.80
|
£3.36
|
|
|
79 - O-RING
BSD-3600210093.A24
3600210093
|
£1.75
|
£2.10
|
|
|
83 - CONTROL PIN
BSD-3608750048.A27
3608750048
|
£5.30
|
£6.36
|
|
|
85 - O-RING 4.0x1.0 MM
BSD-3600210015.A45
3600210015
|
£3.72
|
£4.47
|
|
|
86 - BUSHING
BSD-3600300064.A8
3600300064
|
£10.10
|
£12.12
|
|
|
87 - SILENCER
BSD-3601010010.A77
3601010010
|
£2.16
|
£2.59
|
|
|
88 - SILENCER
BSD-3601010037.A53
3601010037
|
£11.30
|
£13.56
|
|
|
89 - SILENCER
BSD-3601010044.A23
3601010044
|
£7.36
|
£8.83
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A599
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601119055.A141
3601119055
|
£3.72
|
£4.47
|
|
|
98 - STICKER
BSD-3601110204.A77
3601110204
|
£1.75
|
£2.10
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A402
3601119236
|
£3.72
|
£4.47
|
|
|
100 - HOUSING
BSD-3605125011.A8
3605125011
|
£48.38
|
£58.06
|
|
|
101 - CLUTCH ELEMENT
BSD-3606432006.A44
3606432006
|
£81.81
|
£98.17
|
|
|
102 - DRIVE SHAFT
BSD-3606122009.A8
3606122009
|
£81.81
|
£98.17
|
|
|
106 - COMPRESSION SPRING
BSD-3604615000.A40
3604615000
|
£1.75
|
£2.10
|
|
|
109 - COMPRESSION SPRING
BSD-3604619003.A86
3604619003
|
£5.58
|
£6.70
|
|
|
110 - RETAINING RING
BSD-3604601002.A31
3604601002
|
£1.75
|
£2.10
|
|
|
113 - UNION NUT
BSD-3603340000.A69
3603340000
|
£4.26
|
£5.11
|
|
|
114 - BUSHING
BSD-3600322002.A22
3600322002
|
£5.30
|
£6.36
|
|
|
115 - SEALING PLATE
BSD-3600001002.A25
3600001002
|
£3.72
|
£4.47
|
|
|
116 - ADJUSTING DISC
BSD-3600134003.A51
3600134003
|
£2.61
|
£3.13
|
|
|
119 - SUPPORT DISC
BSD-3600114002.A36
3600114002
|
£12.04
|
£14.45
|
|
|
120 - ROUND NUT
BSD-3603344009.A24
3603344009
|
£27.23
|
£32.68
|
|
|
121 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A13
1903230003
|
£2.61
|
£3.13
|
|
|
124 - COUPLING PLATE
BSD-3600220000.A7
3600220000
|
£10.10
|
£12.12
|
|
|
126 - LEAF SPRING
BSD-2601250001.A143
2601250001
|
£3.72
|
£4.47
|
|
|
127 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A805
1903230007
|
£1.75
|
£2.10
|
|
|
128 - BALL DIN 5401-5 G28
BSD-1903230009.A913
1903230009
|
£1.75
|
£2.10
|
|
|
129 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A14
1903230003
|
£2.61
|
£3.13
|
|
|
130 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A15
1903230003
|
£2.61
|
£3.13
|
|
|
140 - RETAINING RING 14 DIN 9045
BSD-2916600008.A252
2916600008
|
£2.80
|
£3.36
|
|
|
660 - SUSPENSION LOOP
BSD-2604720004.A38
2604720004
|
£4.26
|
£5.11
|
|
|
751 - GUIDE SLEEVE
BSD-3600329000.A68
3600329000
|
£7.36
|
£8.83
|
|
|
801 - OVERRIDING CLUTCH
BSD-3607031118.A4
3607031118
|
£251.67
|
£302.00
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031216.A0
3607031216
|
£357.27
|
£428.72
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607031304.A84
3607031304
|
£27.23
|
£32.68
|
|
|
808 - ASSEMBLY OF SERVICE PARTS
BSD-3607031359.A0
3607031359
|
£306.65
|
£367.98
|
|
|
809 - ASSEMBLY OF SERVICE PARTS
BSD-3607031417.A3
3607031417
|
-
|
|
|
|
843 - PARTS SET
BSD-3607010010.A23
3607010010
|
£7.36
|
£8.83
|
|
|
882 - O-RING
BSD-3607010006.A29
3607010006
|
£31.64
|
£37.97
|
|
|
890 - AUXILIARY HANDLE
BSD-3607031351.A28
3607031351
|
£72.18
|
£86.62
|
|
|
891 - AIR HOSE
BSD-3607000083.A27
3607000083
|
£59.53
|
£71.44
|
|
