Bosch GSR 12 VE-2 / 0601951503 / EU 12 Volt Spare Parts

An exploded drawing and listing for the Bosch GSR 12 VE-2 / 0601951503 / EU 12 Volt

	Ex VAT	Inc VAT
1 - HOUSING SECTION BSD-2605105027.A7 2605105027	£19.45	£23.34
2/1 - PINION BSD-2606316188.A20 2606316188	£2.16	£2.59
5 - ADJUSTING SLIDE BSD-2601099085.A31 2601099085	-
25 - KEYLESS CHUCK BSD-2608572160.A29 2608572160	-
32 - ADJUSTING SLIDE BSD-2601099086.A41 2601099086	£2.16	£2.59
50 - INTERMEDIATE FLANGE BSD-2605719901.A16 2605719901	-
91 - SLIDE-IN ACCU PACKAGE 12V.2.6Ah.NiMh BSD-2607335683.A15 2607335683	£154.03	£184.84
93 - SCREWDRIVER BLADE BSD-2608521018.A65 2608521018	£5.01	£6.01
96 - SUPPORT BSD-2608040131.A44 2608040131	£1.95	£2.34
101 - TORX OVAL-HEAD SCREW 3x18 BSD-2603490018.A562 2603490018	£1.75	£2.10
107 - COUNTERSUNK-HEAD SCREW BSD-2603421008.A61 2603421008	£1.75	£2.10
653 - FAST CHARGER EU 230/7.2-24V. 1h BSD-2607224425.A227 2607224425	£88.07	£105.68
802 - DC MOTOR 12V BSD-2607022876.A1 2607022876	£88.07	£105.68
804 - ON-OFF SWITCH BSD-2607200421.A10 2607200421	£48.38	£58.06
809 - MANUFACTURER'S NAMEPLATE BSD-2601116136.A1 2601116136	£4.26	£5.11
809 - MANUFACTURER'S NAMEPLATE GSR 12 PROFI BSD-2601116544.A1 2601116544	£4.26	£5.11
820 - NAMEPLATE BSD-2601116137.A9 2601116137	£4.26	£5.11
845 - PLANETARY GEAR TRAIN BSD-2606200917.A2 2606200917	£81.81	£98.17
899 - BATT-OPER SCREWDRIVER BSD-0601951520.A0 0601951520	-
