1 - MOTOR HOUSING
BSD-3605108145.A134
3605108145
|
£27.23
|
£32.68
|
|
|
2 - SWITCH
BSD-1607200065.A24
1607200065
|
-
|
|
|
|
3 - INSULATING STRIP 33x10x6 MM
BSD-1602381001.A43
1602381001
|
-
|
|
|
|
4 - END SPLICE DIN 46 228-A2.5-7
BSD-1900452003.A84
1900452003
|
£2.61
|
£3.13
|
|
|
5 - SUPPRESSION CAPACITOR
BSD-1607328012.A137
1607328012
|
-
|
|
|
|
5/20 - END SPLICE
BSD-3604477009.A175
3604477009
|
£2.61
|
£3.13
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A99
3600703011
|
£2.80
|
£3.36
|
|
|
7 - POWER SUPPLY CORD
BSD-1604460097.A3
1604460097
|
-
|
|
|
|
8 - TAPPING SCREW DIN 7971-3.9x38
BSD-2910215093.A22
2910215093
|
-
|
|
|
|
9 - FELT DISC
BSD-1600108003.A267
1600108003
|
£1.32
|
£1.58
|
|
|
10 - HANDLE
BSD-1605133029.A7
1605133029
|
-
|
|
|
|
11 - RETAINING RING 35 DIN 9045
BSD-2916600018.A52
2916600018
|
£1.75
|
£2.10
|
|
|
12 - ARMATURE 220-230V
BSD-1604010175.A3
1604010175
|
-
|
|
|
|
14 - TAPPING SCREW B4.8x50 MM
BSD-1603435012.A68
1603435012
|
£1.75
|
£2.10
|
|
|
15 - FIELD 220-230V
BSD-1604220159.A5
1604220159
|
-
|
|
|
|
16 - SEALING CAP
BSD-1605500127.A12
1605500127
|
-
|
|
|
|
17 - SPIRAL SPRING
BSD-1604652006.A314
1604652006
|
£1.75
|
£2.10
|
|
|
18 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A903
2910021118
|
£1.75
|
£2.10
|
|
|
18 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A975
2910211019
|
£1.75
|
£2.10
|
|
|
19 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A262
2915011005
|
£1.75
|
£2.10
|
|
|
20 - INTERMEDIATE RING
BSD-1600202036.A5
1600202036
|
-
|
|
|
|
21 - INTERMEDIATE RING
BSD-1600206018.A81
1600206018
|
-
|
|
|
|
22 - GROOVE BALL BEARING 15x32x9
BSD-1600905004.A18
1600905004
|
-
|
|
|
|
23 - AIR-DEFLECTOR RING
BSD-1600502015.A64
1600502015
|
-
|
|
|
|
24 - SOCKET HEAD CAP SCREW DIN 84-BM 6x50-8.8
BSD-2910021213.A13
2910021213
|
£1.32
|
£1.58
|
|
|
25 - TAPPING SCREW DIN 7971-BZ3.9x25
BSD-2910211022.A68
2910211022
|
£1.75
|
£2.10
|
|
|
27 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A381
2910211011
|
£1.75
|
£2.10
|
|
|
28 - BALL BEARING 7x19x6
BSD-2600905032.A1959
2600905032
|
£5.30
|
£6.36
|
|
|
29 - RUBBER BUSHING
BSD-1600502020.A304
1600502020
|
£2.61
|
£3.13
|
|
|
30 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A478
2910021116
|
£2.16
|
£2.59
|
|
|
31 - FASTENING CLAMP
BSD-1601302014.A618
1601302014
|
£2.61
|
£3.13
|
|
|
32 - STICKER
BSD-1601110046.A106
1601110046
|
£1.75
|
£2.10
|
|
|
34 - TAB WASHER
BSD-1601030022.A642
1601030022
|
£1.75
|
£2.10
|
|
|
36 - TORX OVAL-HEAD SCREW
BSD-2914201529.A33
2914201529
|
£1.75
|
£2.10
|
|
|
38 - TAPPING SCREW 79 MM
BSD-2603435012.A47
2603435012
|
-
|
|
|
|
42 - SEALING PLATE
BSD-1601015013.A36
1601015013
|
£1.75
|
£2.10
|
|
|
43 - SPRING LOCK WASHER M6
BSD-2916690005.A189
2916690005
|
-
|
|
|
|
44 - RETAINING SNAP RING
BSD-1610500004.A73
1610500004
|
-
|
|
|
|
82 - SPRING WASHER DIN 137-A5-FST
BSD-2916060006.A300
2916060006
|
£1.32
|
£1.58
|
|
|
101 - GEAR COVER
BSD-3605806007.A1
3605806007
|
£70.24
|
£84.29
|
|
|
102 - GEAR HOUSING
BSD-3605110024.A10
3605110024
|
£103.14
|
£123.77
|
|
|
103 - NEEDLE-ROLLER BEARING
BSD-3600910001.A10
3600910001
|
-
|
|
|
|
104 - SPRING RETAINING RING DIN 471 25x1.2
BSD-2916650014.A38
2916650014
|
£1.75
|
£2.10
|
|
|
106 - GROOVE BALL BEARING
BSD-3600905011.A21
3600905011
|
£14.72
|
£17.67
|
|
|
107 - DISC SPRING
BSD-3600550000.A10
3600550000
|
-
|
|
|
|
108 - SPRING LOCK WASHER 14-FST
BSD-2916690010.A1
2916690010
|
£1.75
|
£2.10
|
|
|
110 - CYLINDRICAL GEAR Z=35
BSD-3606316015.A10
3606316015
|
£24.45
|
£29.34
|
|
|
111 - NEEDLE ROLLER A 2.5x9.8 G2 DIN 5402
BSD-1903201021.A1
1903201021
|
£1.75
|
£2.10
|
|
|
112 - SHIM 1.2 MM
BSD-1600100611.A52
1600100611
|
£1.75
|
£2.10
|
|
|
113 - LOCKING WASHER 5 DIN 6799
BSD-2916080908.A90
2916080908
|
£1.75
|
£2.10
|
|
|
114 - RING GEAR Z=75
BSD-3606334009.A21
3606334009
|
£120.11
|
£144.13
|
|
|
115 - NEEDLE ROLLER A 3x15.8G2DIN5402
BSD-1903201044.A84
1903201044
|
£2.33
|
£2.80
|
|
|
116 - CONNECTING ROD
BSD-3602001001.A2
3602001001
|
£80.61
|
£96.73
|
|
|
117 - NEEDLE-ROLLER ASSEMBLY
BSD-3600913001.A14
3600913001
|
£11.30
|
£13.56
|
|
|
118 - RETAINING RING
BSD-3600224005.A1
3600224005
|
£1.75
|
£2.10
|
|
|
119 - LIFTING ROD
BSD-3603070000.A9
3603070000
|
£61.98
|
£74.38
|
|
|
120 - STRAIGHT PIN
BSD-3603100000.A11
3603100000
|
£5.01
|
£6.01
|
|
|
121 - BEARING SLEEVE
BSD-3600422000.A10
3600422000
|
£33.45
|
£40.14
|
|
|
122 - ADJUSTING SCREW
BSD-3603463003.A16
3603463003
|
-
|
|
|
|
123 - STRAIGHT PIN DIN 6325-5m6x20
BSD-2917550122.A10
2917550122
|
£1.75
|
£2.10
|
|
|
124 - UPPER BLADE
BSD-3608635000.A3
3608635000
|
£23.70
|
£28.44
|
|
|
125 - LOWER BLADE
BSD-3608635002.A2
3608635002
|
£23.62
|
£28.34
|
|
|
127 - SPRING LOCK WASHER M6
BSD-2916690005.A190
2916690005
|
-
|
|
|
|
128 - HEX SOCKET HEAD CAP SCREW DIN 6912 M6x12-8.8
BSD-2910375193.A49
2910375193
|
-
|
|
|
|
130 - SEAL
BSD-3601015003.A10
3601015003
|
£3.72
|
£4.47
|
|
|
131 - COUNTERWEIGHT
BSD-3603120001.A1
3603120001
|
£4.75
|
£5.70
|
|
|
132 - HEX SOCKET HEAD CAP SCREW DIN 912-M 14x35-8.8
BSD-2910145392.A16
2910145392
|
-
|
|
|
|
133 - SET SCREW M 6x12 DIN 551-5.8
BSD-2912031193.A1
2912031193
|
-
|
|
|
|
134 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x16-8.8
BSD-2910141197.A446
2910141197
|
£1.75
|
£2.10
|
|
|
135 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A454
2916011014
|
£1.75
|
£2.10
|
|
|
650 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A974
1907950006
|
£4.26
|
£5.11
|
|
|
651 - FEELER GAUGE
BSD-1607970015.A3
1607970015
|
-
|
|
|
|
652 - SLIDING TEE BAR
BSD-1607990001.A7
1607990001
|
-
|
|
|
|
653 - GRINDING GAUGE
BSD-1607970016.A2
1607970016
|
-
|
|
|
|
801 - SHEARING ATTACHMENT
BSD-3607020033.A1
3607020033
|
-
|
|
|
|
802 - BLADE HOLDER
BSD-3608042002.A11
3608042002
|
£357.27
|
£428.72
|
|
|
803 - ECCENTRIC SHAFT
BSD-3606110002.A1
3606110002
|
-
|
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607031160.A4
3607031160
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014126.A158
1607014126
|
£16.41
|
£19.69
|
|
|
833 - BRUSH HOLDER
BSD-1604336017.A45
1604336017
|
£7.36
|
£8.83
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A5440
160111A3H3
|
£2.61
|
£3.13
|
|
