9 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A291
2600914010
|
£2.80
|
£3.36
|
|
|
12 - SHIM 0.3 MM
BSD-2600100607.A390
2600100607
|
£1.75
|
£2.10
|
|
|
14 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A199
1903201042
|
£2.16
|
£2.59
|
|
|
16 - FELT DISC
BSD-2600108000.A11
2600108000
|
-
|
|
|
|
17 - CUPPED WASHER
BSD-2600500030.A92
2600500030
|
-
|
|
|
|
18 - SEAL BUSHING
BSD-2600300049.A96
2600300049
|
-
|
|
|
|
19 - BALL BEARING 8x22x7
BSD-1900905029.A50
1900905029
|
£21.52
|
£25.83
|
|
|
24 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A117
2910211021
|
£1.75
|
£2.10
|
|
|
26 - SCREW AND WASHER ASSEMBLY DIN 84-BM 4x35-Z4-8.8
BSD-2914501027.A2
2914501027
|
-
|
|
|
|
27 - COVER DISC
BSD-2601328041.A75
2601328041
|
-
|
|
|
|
31 - ARMATURE WITH FAN 110-115V
BSD-2604010536.A2
2604010536
|
-
|
|
|
|
32 - FIELD 110-115V
BSD-2604222295.A6
2604222295
|
-
|
|
|
|
34 - HOUSING COVER
BSD-2605132017.A5
2605132017
|
-
|
|
|
|
35 - TAPPING SCREW DIN 7971-B 3.9x19
BSD-2910211220.A218
2910211220
|
-
|
|
|
|
36 - BALL BEARING 7x22x7
BSD-1900905018.A605
1900905018
|
£18.96
|
£22.75
|
|
|
38 - ON-OFF SWITCH
BSD-2607200043.A3
2607200043
|
-
|
|
|
|
39 - SOCKET HEAD CAP SCREW M3x10 MM
BSD-2603410023.A92
2603410023
|
-
|
|
|
|
40 - SUPPRESSION FILTER
BSD-2607329051.A32
2607329051
|
-
|
|
|
|
41 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A532
2910211011
|
£1.75
|
£2.10
|
|
|
42 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A640
2600703012
|
£2.80
|
£3.36
|
|
|
43 - POWER SUPPLY CORD GB 110V 2.65m 2 x 1.0mm H05 VV-F
BSD-3604460069.A63
3604460069
|
£37.72
|
£45.27
|
|
|
44 - CABLE CLIP
BSD-2601035001.A2325
2601035001
|
£1.75
|
£2.10
|
|
|
45 - TAPPING SCREW 2.2x6.5
BSD-2603435016.A9
2603435016
|
-
|
|
|
|
46 - SCREW AND WASHER ASSEMBLY DIN7985-M3x6-Z1-4.8
BSD-2914501011.A47
2914501011
|
£1.75
|
£2.10
|
|
|
47 - SPIRAL SPRING
BSD-2604652002.A110
2604652002
|
-
|
|
|
|
50 - REFERENCE PLATE
BSD-3601110066.A2
3601110066
|
-
|
|
|
|
51 - STICKER
BSD-3601110067.A2
3601110067
|
-
|
|
|
|
52 - SHIM
BSD-2600150004.A546
2600150004
|
£2.16
|
£2.59
|
|
|
53 - SHIM 0.3 MM
BSD-2600101023.A382
2600101023
|
£1.75
|
£2.10
|
|
|
53 - SHIM 0.2 MM
BSD-2600101022.A165
2600101022
|
£1.75
|
£2.10
|
|
|
53 - SHIM 0.5 MM
BSD-2600101020.A467
2600101020
|
£1.75
|
£2.10
|
|
|
56 - SPRING RETAINING RING
BSD-2600119000.A98
2600119000
|
£1.75
|
£2.10
|
|
|
57 - COMPRESSION SPRING
BSD-2604611026.A120
2604611026
|
-
|
|
|
|
60 - ECCENTRIC BUSHING
BSD-2602210005.A2
2602210005
|
£21.52
|
£25.83
|
|
|
61 - LOWER BLADE
BSD-2608635093.A2
2608635093
|
£116.15
|
£139.38
|
|
|
62 - HEX SOCKET HEAD CAP SCREW
BSD-2603414044.A5
2603414044
|
-
|
|
|
|
63 - BUSHING
BSD-2600300072.A0
2600300072
|
£5.30
|
£6.36
|
|
|
64 - UPPER BLADE
BSD-2608635094.A5
2608635094
|
-
|
|
|
|
65 - UPPER BLADE
BSD-2608635095.A2
2608635095
|
£54.42
|
£65.30
|
|
|
66 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x30-8.8
BSD-2910141166.A75
2910141166
|
£1.75
|
£2.10
|
|
|
67 - NEEDLE BEARING
BSD-2600914018.A58
2600914018
|
£8.67
|
£10.41
|
|
|
68 - SHIM
BSD-2600101672.A2
2600101672
|
-
|
|
|
|
69 - GEAR HOUSING
BSD-2605806348.A5
2605806348
|
£58.76
|
£70.51
|
|
|
70 - CENTERING SLEEVE
BSD-2600409013.A29
2600409013
|
-
|
|
|
|
75 - FAN
BSD-2606610021.A54
2606610021
|
-
|
|
|
|
653 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A537
2607950004
|
£1.75
|
£2.10
|
|
|
800 - GEAR HOUSING
BSD-2605806967.A2
2605806967
|
-
|
|
|
|
801 - INTERMEDIATE FLANGE
BSD-2605700927.A26
2605700927
|
-
|
|
|
|
802 - TOOTHED SHAFT Z=21/41
BSD-2606311902.A4
2606311902
|
-
|
|
|
|
803 - MOTOR HOUSING
BSD-2605104960.A2
2605104960
|
-
|
|
|
|
804 - CARBON-BRUSH SET
BSD-2604320902.A9
2604320902
|
-
|
|
|
|
805 - DRILLING SPINDLE
BSD-2603123010.A3
2603123010
|
-
|
|
|
|
806 - BEARING SLEEVE
BSD-2600290901.A1
2600290901
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3989
160111A3H3
|
£2.61
|
£3.13
|
|
