Fein RSs 638-7 (50/60Hz 230V) / 72322500232 Spare Parts

Fein RSs 638-7 ⡐/60Hz 230V) / 72322500232 Spare Parts

An exploded diagram and spare parts listing for the Fein RSs 638-7 (50/60Hz 230V) / 72322500232

	Ex VAT	Inc VAT
10 - MOTOR HOUSING FEI-31901103008.A17 31901103008	£62.53	£75.04
20 - SLIDE SWITCH FEI-32805128003.A10 32805128003	£3.42	£4.10
30 - CONTROL ROD FEI-32816040003.A12 32816040003	£2.88	£3.46
40 - STATOR FEI-51271007230.A0 51271007230	-
50 - SCREW FEI-43070004001.A38 43070004001	£1.60	£1.92
70 - AIR GUIDE RING FEI-31428075007.A20 31428075007	£4.18	£5.01
90 - SHEET METAL SCREW FEI-43046019009.A0 43046019009	-
100 - ELECTRONICS FEI-30762136008.A12 30762136008	-
110 - SPIRAL SPRING FEI-30902040004.A2 30902040004	£3.17	£3.80
120 - BRUSH HOLDER FEI-30712086011.A23 30712086011	£8.42	£10.11
130 - CARBON BRUSH (SOLD SINGLY) FEI-30711127007.A0 30711127007	£18.88	£22.65
140 - CABLE CLAMPING PIECE FEI-32431036008.A23 32431036008	£3.75	£4.50
150 - CABLE WITH PLUG FEI-30707174010.A1 30707174010	£14.58	£17.49
160 - CABLE GROMMET FEI-31413007007.A33 31413007007	£1.60	£1.92
170 - COVER FEI-31201072020.A12 31201072020	£10.81	£12.97
180 - SCREW FEI-43070001006.A84 43070001006	£1.60	£1.92
210 - CONNECTING CABLE FEI-30719340018.A16 30719340018	£1.60	£1.92
240 - HOLDER FEI-31428086009.A3 31428086009	£4.09	£4.91
250 - ARMATURE FEI-53270003236.A4 53270003236	£186.71	£224.05
300 - INTERMEDIATE GEAR BOX FEI-31506333009.A2 31506333009	£82.21	£98.65
330 - GROOVED BALL BEARING FEI-41701001172.A37 41701001172	£9.63	£11.56
350 - GROOVED BALL BEARING FEI-41701202018.A132 41701202018	£6.92	£8.30
400 - GEARBOX HOUSING FEI-31309062002.A1 31309062002	-
410 - CON ROD FEI-31309063006.A6 31309063006	-
420 - ECCENTRIC SHAFT FEI-31309064004.A1 31309064004	-
430 - BOLT FEI-31309035001.A2 31309035001	-
431 - PUNCH EXTENSION FEI-31309117009.A0 31309117009	-
432 - PUNCH EXTENSION FEI-31309118007.A1 31309118007	-
440 - PUNCH FEI-31309119001.A0 31309119001	£98.56	£118.27
450 - PUNCH GUIDE FEI-31309120003.A1 31309120003	£120.69	£144.83
460 - HOLDER EXTENSION FEI-31309127017.A1 31309127017	-
470 - WEARING PLATE FEI-31309121002.A5 31309121002	£23.16	£27.79
480 - DIE FEI-31309122005.A0 31309122005	£106.92	£128.30
490 - FILLISTER HEAD SCREW FEI-31309123009.A5 31309123009	-
500 - SEALING RING FEI-31309126004.A0 31309126004	£3.61	£4.33
510 - SET SCREW FEI-31309041001.A7 31309041001	-
520 - CIRCLIP FEI-42615104004.A0 42615104004	-
540 - GROOVED BALL BEARING FEI-41701207055.A3 41701207055	£21.58	£25.89
550 - NEEDLE CAGE FEI-41715043006.A0 41715043006	£25.42	£30.51
560 - GROOVED BALL BEARING FEI-41701210021.A28 41701210021	£8.89	£10.67
570 - CIRCLIP FEI-42616002008.A7 42616002008	-
580 - NEEDLE BEARING FEI-41706034001.A9 41706034001	£38.61	£46.33
590 - GEAR-WHEEL FEI-33657151008.A7 33657151008	-
600 - FEATHER KEY FEI-40221003006.A21 40221003006	£1.60	£1.92
610 - CIRCLIP FEI-42616034007.A12 42616034007	-
620 - SHAFT TOOTHED FEI-33757072009.A1 33757072009	-
630 - GEAR-WHEEL FEI-33657150009.A7 33657150009	-
631 - DISC FEI-32408185009.A6 32408185009	£2.94	£3.53
640 - SEALING RING FEI-32612056001.A9 32612056001	£2.69	£3.23
660 - SCREW FEI-43070010006.A2 43070010006	-
670 - CIRCLIP M5 FEI-42443004057.A378 42443004057	£1.60	£1.92
680 - CYLINDER HEAD SCREW FEI-43035019059.A0 43035019059	-
700 - STRAIGHT PIN FEI-40201036006.A17 40201036006	£1.60	£1.92
780 - SCREW FEI-43070004001.A20 43070004001	£1.60	£1.92
5000 - ALLEN KEY SW4 FEI-62907010000.A29 62907010000	£3.35	£4.02
6000 - LUBRICANT TUBE 0 085 KG FEI-32160003014.A143 32160003014	-
9020 - SAFETY INSTRUCTION FEI-34130054061.A621 34130054061	-
