2 - FASTENING FLANGE
BSD-2605700175.A0
2605700175
|
-
|
|
|
|
4 - SOCKET HEAD CAP SCREW
BSD-2910021131.A0
2910021131
|
-
|
|
|
|
5 - HOUSING COVER
BSD-2605500017.A27
2605500017
|
-
|
|
|
|
6 - SOCKET HEAD CAP SCREW DIN 84-AM4x10-8.8
BSD-2910021120.A59
2910021120
|
£1.75
|
£2.10
|
|
|
8 - SPRING LOCK WASHER M 4
BSD-2916693003.A4
2916693003
|
-
|
|
|
|
10 - CUPPED WASHER
BSD-2600500005.A0
2600500005
|
-
|
|
|
|
13 - FIXING PLATE
BSD-2601015002.A0
2601015002
|
-
|
|
|
|
14 - PINION Z=7
BSD-2606300058.A0
2606300058
|
-
|
|
|
|
15 - BEARING BOLT
BSD-2603123009.A14
2603123009
|
-
|
|
|
|
16 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1011
2910021118
|
£1.75
|
£2.10
|
|
|
17 - SHIM 0.5 MM
BSD-2600101616.A452
2600101616
|
-
|
|
|
|
18 - NEEDLE-ROLLER CAGE
BSD-2600913027.A0
2600913027
|
-
|
|
|
|
19 - NEEDLE ROLLER 1.5x5.8 MM
BSD-2603201037.A129
2603201037
|
£2.61
|
£3.13
|
|
|
20 - CYLINDRICAL GEAR Z=50
BSD-2606319037.A14
2606319037
|
-
|
|
|
|
21 - SHIM 1.0 MM
BSD-2600102653.A162
2600102653
|
£1.75
|
£2.10
|
|
|
22 - SHIM 0.5 MM
BSD-2600102652.A66
2600102652
|
£1.75
|
£2.10
|
|
|
23 - FORK LEVER
BSD-2601923000.A3
2601923000
|
-
|
|
|
|
24 - BEARING BOLT
BSD-2603105016.A0
2603105016
|
-
|
|
|
|
25 - SHIM 0.3 MM
BSD-2600100515.A177
2600100515
|
£2.61
|
£3.13
|
|
|
25 - SHIM 0.3 MM
BSD-2600100515.A178
2600100515
|
£2.61
|
£3.13
|
|
|
25 - SHIM 0.5 MM
BSD-2600100516.A54
2600100516
|
£2.16
|
£2.59
|
|
|
26 - PIN DIN 6325-5m-6x24
BSD-2917530151.A0
2917530151
|
-
|
|
|
|
27 - BEARING BOLT
BSD-2603105014.A0
2603105014
|
-
|
|
|
|
28 - SHIM 0.1 MM
BSD-2600100625.A150
2600100625
|
-
|
|
|
|
28 - SHIM 0.2 MM
BSD-2600100626.A78
2600100626
|
-
|
|
|
|
28 - SHIM 0.3 MM
BSD-2600100627.A178
2600100627
|
-
|
|
|
|
28 - SHIM 0.5 MM
BSD-2600100628.A102
2600100628
|
£1.75
|
£2.10
|
|
|
29 - COUNTERWEIGHT
BSD-2601015030.A3
2601015030
|
-
|
|
|
|
30 - ECCENTRIC DISC
BSD-2601072004.A0
2601072004
|
-
|
|
|
|
31 - SHIM 0.2 MM
BSD-2600100575.A285
2600100575
|
£2.16
|
£2.59
|
|
|
31 - SHIM 0.3 MM
BSD-2600100576.A5
2600100576
|
-
|
|
|
|
31 - SHIM 0.5 MM
BSD-2600100577.A292
2600100577
|
£1.75
|
£2.10
|
|
|
32 - LOCKING WASHER DIN 6799-7-FSt
BSD-2916080910.A282
2916080910
|
£2.16
|
£2.59
|
|
|
33 - LOCKING WASHER 5 DIN 6799
BSD-2916080908.A206
2916080908
|
£1.75
|
£2.10
|
|
|
34 - PLUG
BSD-2600508022.A0
2600508022
|
-
|
|
|
|
35 - ECCENTRIC DISC 0.3 MM
BSD-2601072006.A14
2601072006
|
-
|
|
|
|
35 - ECCENTRIC DISC 0.5 MM
BSD-2601072007.A0
2601072007
|
-
|
|
|
|
37 - NEEDLE-ROLLER CAGE
BSD-2600913010.A47
2600913010
|
-
|
|
|
|
38 - NEEDLE BEARING
BSD-2600917900.A297
2600917900
|
£8.67
|
£10.41
|
|
|
39 - SEAL
BSD-2601015031.A0
2601015031
|
-
|
|
|
|
40 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A442
1903201042
|
£2.16
|
£2.59
|
|
|
41 - GEAR COVER
BSD-2605808044.A0
2605808044
|
-
|
|
|
|
43 - COMPRESSION SPRING
BSD-2604613000.A143
2604613000
|
£1.75
|
£2.10
|
|
|
44 - GUIDE
BSD-2601032014.A24
2601032014
|
-
|
|
|
|
46 - CLAMP SCREW
BSD-2603400000.A200
2603400000
|
£4.26
|
£5.11
|
|
|
47 - CLAMPING SADDLE
BSD-2602329011.A266
2602329011
|
£4.75
|
£5.70
|
|
|
48 - SLIDING PIECE 31/35 MM
BSD-2601321022.A92
2601321022
|
-
|
|
|
|
49 - COUNTERSUNK-HEAD SCREW DIN 7962-M3.5x8-10.9
BSD-2603421040.A122
2603421040
|
£1.75
|
£2.10
|
|
|
50 - SHIM 0.5 MM
BSD-2600101612.A87
2600101612
|
£1.75
|
£2.10
|
|
|
51 - SEAL RING 0.5 MM
BSD-2600290017.A122
2600290017
|
£1.75
|
£2.10
|
|
|
52 - SUPPORTING DISC 0.5 MM
BSD-2600112031.A5
2600112031
|
£1.75
|
£2.10
|
|
|
53 - SEALING PLATE
BSD-2601015032.A0
2601015032
|
-
|
|
|
|
54 - PIVOT PIN
BSD-2603105015.A0
2603105015
|
-
|
|
|
|
55 - GUIDE ROLLER
BSD-2607001018.A1
2607001018
|
-
|
|
|
|
56 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A340
2916080007
|
£2.61
|
£3.13
|
|
|
60 - GUIDE ROLLER
BSD-2600326013.A0
2600326013
|
-
|
|
|
|
61 - STUD BOLT
BSD-2603105022.A3
2603105022
|
-
|
|
|
|
62 - SHIM 0.5 MM
BSD-2600100510.A1
2600100510
|
£2.61
|
£3.13
|
|
|
63 - LOCKING WASHER DIN 6799-3.2
BSD-2916080906.A49
2916080906
|
£1.75
|
£2.10
|
|
|
64 - SWITCH HANDLE
BSD-2607200042.A0
2607200042
|
-
|
|
|
|
66 - COMPRESSION SPRING
BSD-2604611023.A0
2604611023
|
-
|
|
|
|
67 - RATCHET SLEEVE
BSD-2600506002.A0
2600506002
|
-
|
|
|
|
68 - SHIM 0.5 MM
BSD-2600100568.A288
2600100568
|
£1.75
|
£2.10
|
|
|
68 - SHIM 1.0 MM
BSD-2600100569.A5
2600100569
|
£1.75
|
£2.10
|
|
|
68 - SHIM 0.3 MM
BSD-2600100570.A336
2600100570
|
£1.75
|
£2.10
|
|
|
69 - BASE PLATE
BSD-2601016038.A0
2601016038
|
-
|
|
|
|
70 - COUNTERSUNK-HEAD SCREW
BSD-2910511152.A0
2910511152
|
-
|
|
|
|
71 - MANUFACTURER'S NAMEPLATE
BSD-1601110013.A115
1601110013
|
-
|
|
|
|
72 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A485
2910021122
|
£2.16
|
£2.59
|
|
|
73 - SOCKET HEAD CAP SCREW DIN 84-AM4x25-8.8
BSD-2910021132.A1
2910021132
|
£1.75
|
£2.10
|
|
|
74 - NAMEPLATE
BSD-2601105041.A2
2601105041
|
-
|
|
|
|
75 - GROOVED NAIL
BSD-3603133000.A281
3603133000
|
£2.61
|
£3.13
|
|
|
76 - PLUG
BSD-2600508005.A0
2600508005
|
-
|
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1327
3601119236
|
£3.72
|
£4.47
|
|
|
100 - MOTOR HOUSING
BSD-2605110051.A3
2605110051
|
-
|
|
|
|
102 - THRUST RING
BSD-2600221001.A0
2600221001
|
-
|
|
|
|
103 - DISC SPRING
BSD-2600550009.A4
2600550009
|
-
|
|
|
|
105 - FELT DISC
BSD-2600108011.A0
2600108011
|
-
|
|
|
|
108 - SEAL
BSD-2600117000.A0
2600117000
|
-
|
|
|
|
111 - DAMPING PLATE
BSD-2601010050.A1
2601010050
|
-
|
|
|
|
144 - SEAL RING
BSD-2600206006.A0
2600206006
|
-
|
|
|
|
145 - SEAL RING
BSD-2600508020.A4
2600508020
|
-
|
|
|
|
146 - SEAL RING
BSD-2600206004.A19
2600206004
|
£7.36
|
£8.83
|
|
|
147 - BALL 7.5 MM IIIDIN5401-ST
BSD-1903230024.A9
1903230024
|
£2.80
|
£3.36
|
|
|
148 - SCREW PLUG
BSD-3603463009.A5
3603463009
|
£31.64
|
£37.97
|
|
|
149 - COMPRESSION SPRING
BSD-2604610016.A0
2604610016
|
-
|
|
|
|
150 - MOUNTING DEVICE
BSD-2600309000.A1
2600309000
|
£2.16
|
£2.59
|
|
|
152 - HOSE FITTING
BSD-2603386001.A1
2603386001
|
£7.36
|
£8.83
|
|
|
153 - STRAINER
BSD-2600002006.A0
2600002006
|
£4.26
|
£5.11
|
|
|
154 - CONTROL LEVER
BSD-2601902000.A0
2601902000
|
-
|
|
|
|
155 - STRAIGHT PIN DIN 7-3H8x24-ST
BSD-2917500083.A0
2917500083
|
£2.16
|
£2.59
|
|
|
156 - PRESSURE SPINDLE
BSD-2603105006.A0
2603105006
|
-
|
|
|
|
157 - O-RING 2.4x1.9 MM
BSD-2600210007.A48
2600210007
|
£2.16
|
£2.59
|
|
|
160 - ROTOR
BSD-2604090010.A0
2604090010
|
-
|
|
|
|
161 - STATOR
BSD-2605110020.A4
2605110020
|
-
|
|
|
|
162 - COVER DISC
BSD-2600114002.A4
2600114002
|
-
|
|
|
|
163 - SHIM
BSD-2600102626.A0
2600102626
|
-
|
|
|
|
164 - GROOVE BALL BEARING 6300-Z/C3 DIN 625
BSD-1900905315.A6
1900905315
|
£31.64
|
£37.97
|
|
|
165 - PLAIN WASHER
BSD-2600100070.A4
2600100070
|
-
|
|
|
|
166 - HEX SCREW M 6x10 DIN 933-8.8
BSD-2911051191.A0
2911051191
|
-
|
|
|
|
167 - SHIM
BSD-2600101621.A4
2600101621
|
-
|
|
|
|
168 - SPACER RING
BSD-2600200007.A36
2600200007
|
£10.10
|
£12.12
|
|
|
169 - ROTOR LAMELLA
BSD-2601073000.A4
2601073000
|
-
|
|
|
|
800 - GEAR HOUSING
BSD-2605808903.A0
2605808903
|
-
|
|
|
|
802 - PNEUMATIC MOTOR
BSD-2607219008.A2
2607219008
|
-
|
|
|
|
803 - GEAR COVER
BSD-2607001017.A0
2607001017
|
-
|
|
|
|
804 - GEAR COVER
BSD-2607001016.A0
2607001016
|
-
|
|
|
|
805 - GUIDE ROLLER
BSD-2607001018.A0
2607001018
|
-
|
|
|
|
807 - VALVE HOUSING
BSD-2605110005.A0
2605110005
|
-
|
|
|
|
808 - SEALING PLATE
BSD-2601015900.A0
2601015900
|
-
|
|
|
|
809 - SHIM
BSD-2600101071.A0
2600101071
|
-
|
|
|
|
810 - SINTERED-METAL BUSHING
BSD-2600301046.A70
2600301046
|
£3.72
|
£4.47
|
|
|
811 - BUSHING
BSD-2600301045.A157
2600301045
|
£2.80
|
£3.36
|
|
|
845 - LIFTING ROD
BSD-2600780913.A23
2600780913
|
-
|
|
|
