1 - MOTOR HOUSING
BSD-3605108059.A29
3605108059
|
£27.23
|
£32.68
|
|
|
2 - STATOR 400W
BSD-3604090046.A10
3604090046
|
£102.57
|
£123.08
|
|
|
3 - ROTOR
BSD-3604220047.A12
3604220047
|
£93.88
|
£112.65
|
|
|
5 - BEARING FLANGE
BSD-3605700076.A67
3605700076
|
£48.38
|
£58.06
|
|
|
7 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A339
3600905039
|
£12.04
|
£14.45
|
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A23
1900905028
|
£33.74
|
£40.49
|
|
|
10 - O-RING 25x2 MM
BSD-1900210124.A30
1900210124
|
£2.80
|
£3.36
|
|
|
11 - O-RING 20x2 MM
BSD-1900210118.A71
1900210118
|
£2.80
|
£3.36
|
|
|
12 - REDUCTION SLEEVE
BSD-3600421001.A12
3600421001
|
£8.67
|
£10.41
|
|
|
21 - O-RING 39.0x2.0 MM
BSD-3600210022.A23
3600210022
|
£3.72
|
£4.47
|
|
|
22 - STOP DISC
BSD-3600100022.A14
3600100022
|
£2.16
|
£2.59
|
|
|
23 - O-RING 33.0x2.0 MM
BSD-2600210019.A33
2600210019
|
£1.75
|
£2.10
|
|
|
24 - GUIDE SLEEVE
BSD-3600327001.A9
3600327001
|
£13.12
|
£15.75
|
|
|
31 - INTERMEDIATE RING
BSD-3600200058.A8
3600200058
|
£21.52
|
£25.83
|
|
|
55 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A839
2910211021
|
£1.75
|
£2.10
|
|
|
58 - CONNECTION COVER
BSD-3605500032.A28
3605500032
|
£8.67
|
£10.41
|
|
|
59 - FITTING
BSD-3603462011.A36
3603462011
|
£14.91
|
£17.89
|
|
|
60 - FILTER SCREEN
BSD-3600002004.A1
3600002004
|
£2.80
|
£3.36
|
|
|
61 - O-RING 6.0x2.0 MM
BSD-3600210023.A25
3600210023
|
£3.72
|
£4.47
|
|
|
62 - COMPRESSION SPRING
BSD-2604611025.A5
2604611025
|
£2.80
|
£3.36
|
|
|
63 - STRAIGHT PIN
BSD-3604710054.A20
3604710054
|
£3.72
|
£4.47
|
|
|
64 - O-RING 5.94x3.53 MM
BSD-3600210024.A31
3600210024
|
£2.16
|
£2.59
|
|
|
65 - O-RING 2.7x1.5 MM
BSD-3600210025.A25
3600210025
|
£2.16
|
£2.59
|
|
|
66 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A135
1903230004
|
£2.16
|
£2.59
|
|
|
69 - COMPRESSION SPRING
BSD-3604610024.A15
3604610024
|
£1.75
|
£2.10
|
|
|
70 - HEX SCREW
BSD-3603450006.A17
3603450006
|
£5.30
|
£6.36
|
|
|
71 - O-RING 15x2 MM
BSD-1900210112.A30
1900210112
|
£2.61
|
£3.13
|
|
|
77 - TOGGLE SWITCH
BSD-3602033001.A33
3602033001
|
£3.72
|
£4.47
|
|
|
78 - HOLDING PLATE
BSD-3601100021.A12
3601100021
|
£5.30
|
£6.36
|
|
|
79 - COMPRESSION SPRING
BSD-3604610008.A2
3604610008
|
£1.75
|
£2.10
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A117
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A290
1601110481
|
£2.16
|
£2.59
|
|
|
97 - STICKER
BSD-2601110055.A9
2601110055
|
£4.26
|
£5.11
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1376
3601119236
|
£3.72
|
£4.47
|
|
|
101 - GEAR HOUSING
BSD-3605808005.A0
3605808005
|
-
|
|
|
|
112 - SHIM 0.5 MM
BSD-2600101616.A455
2600101616
|
-
|
|
|
|
113 - NEEDLE-ROLLER CAGE
BSD-2600913036.A46
2600913036
|
£1.75
|
£2.10
|
|
|
114 - NEEDLE ROLLER 1.5x5.8 MM
BSD-2603201037.A140
2603201037
|
£2.61
|
£3.13
|
|
|
115 - ECCENTRIC COG WHEEL
BSD-1619P02581.A3
1619P02581
|
£21.68
|
£26.01
|
|
|
116 - SHIM 1.0 MM
BSD-2600102653.A153
2600102653
|
£1.75
|
£2.10
|
|
|
117 - SHIM 0.3 MM
BSD-2600100515.A181
2600100515
|
£2.61
|
£3.13
|
|
|
117 - SHIM 0.5 MM
BSD-2600100516.A51
2600100516
|
£2.16
|
£2.59
|
|
|
118 - FORK LEVER
BSD-2601923004.A121
2601923004
|
£2.80
|
£3.36
|
|
|
119 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A342
2916080007
|
£2.61
|
£3.13
|
|
|
120 - SHIM 0.5 MM
BSD-2600102652.A74
2600102652
|
£1.75
|
£2.10
|
|
|
121 - SHIM 0.1 MM
BSD-2600100625.A160
2600100625
|
-
|
|
|
|
121 - SHIM 0.2 MM
BSD-2600100626.A68
2600100626
|
-
|
|
|
|
121 - SHIM 0.3 MM
BSD-2600100627.A188
2600100627
|
-
|
|
|
|
121 - SHIM 0.5 MM
BSD-2600100628.A92
2600100628
|
£1.75
|
£2.10
|
|
|
122 - COUNTERWEIGHT
BSD-2601098003.A56
2601098003
|
£8.67
|
£10.41
|
|
|
123 - SPACER SLEEVE
BSD-2600309009.A125
2600309009
|
£1.75
|
£2.10
|
|
|
124 - ECCENTRIC DISC
BSD-2601072901.A10
2601072901
|
£7.36
|
£8.83
|
|
|
125 - SHIM 0.2 MM
BSD-2600100575.A288
2600100575
|
£2.16
|
£2.59
|
|
|
125 - SHIM 0.3 MM
BSD-2600100576.A2
2600100576
|
-
|
|
|
|
125 - SHIM 0.5 MM
BSD-2600100577.A295
2600100577
|
£1.75
|
£2.10
|
|
|
126 - LOCKING WASHER DIN 6799-7-FSt
BSD-2916080910.A277
2916080910
|
£2.16
|
£2.59
|
|
|
129 - SHIM 0.5 MM
BSD-2600100568.A291
2600100568
|
£1.75
|
£2.10
|
|
|
129 - SHIM 1.0 MM
BSD-2600100569.A2
2600100569
|
£1.75
|
£2.10
|
|
|
129 - SHIM 0.3 MM
BSD-2600100607.A830
2600100607
|
£1.75
|
£2.10
|
|
|
130 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A809
2600914010
|
£2.80
|
£3.36
|
|
|
131 - BEARING SLEEVE
BSD-2600400012.A41
2600400012
|
£4.26
|
£5.11
|
|
|
131 - NEEDLE BEARING
BSD-2600917900.A301
2600917900
|
£8.67
|
£10.41
|
|
|
134 - RATCHET CAP
BSD-2600590006.A1011
2600590006
|
£1.75
|
£2.10
|
|
|
135 - ROTARY KNOB
BSD-2602026036.A133
2602026036
|
-
|
|
|
|
136 - LOCKING WASHER 5 DIN 6799
BSD-2916080908.A210
2916080908
|
£1.75
|
£2.10
|
|
|
139 - SEAL
BSD-2601015050.A57
2601015050
|
£2.61
|
£3.13
|
|
|
151 - SEALING PLATE
BSD-2601015055.A3
2601015055
|
£1.95
|
£2.34
|
|
|
152 - FIXING PLATE 0.6 MM
BSD-2601015008.A42
2601015008
|
£2.16
|
£2.59
|
|
|
160 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A1071
2912401020
|
£2.16
|
£2.59
|
|
|
161 - SEALING CAP
BSD-3605500035.A11
3605500035
|
£5.30
|
£6.36
|
|
|
162 - HEX NUT
BSD-3603435044.A46
3603435044
|
£2.16
|
£2.59
|
|
|
163 - BASE PLATE
BSD-2601016903.A140
2601016903
|
£16.41
|
£19.69
|
|
|
164 - PROFILE BEADING
BSD-2601030019.A79
2601030019
|
£2.61
|
£3.13
|
|
|
165 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x16-8.8
BSD-2910141197.A94
2910141197
|
£1.75
|
£2.10
|
|
|
166 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A491
1907950006
|
£4.26
|
£5.11
|
|
|
174 - MICROENCAPSULATED SCREW DIN 7985-M4x12MM
BSD-2914551176.A126
2914551176
|
£1.75
|
£2.10
|
|
|
176 - SCALE PLATE
BSD-2601328044.A166
2601328044
|
£2.61
|
£3.13
|
|
|
181 - HANDLE
BSD-2603231002.A30
2603231002
|
£14.91
|
£17.89
|
|
|
182 - FLANGED FITTING
BSD-3605703051.A4
3605703051
|
-
|
|
|
|
183 - RATCHET SLEEVE
BSD-2600421000.A17
2600421000
|
£7.36
|
£8.83
|
|
|
184 - COMPRESSION SPRING
BSD-2604616001.A46
2604616001
|
£1.75
|
£2.10
|
|
|
185 - SCREW AND WASHER ASSEMBLY DIN 7985-M 5x10 MM-4.8
BSD-2914501022.A2
2914501022
|
£1.75
|
£2.10
|
|
|
304 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A439
1903201042
|
£2.16
|
£2.59
|
|
|
333 - NEEDLE BEARING
BSD-2600917000.A12
2600917000
|
£5.58
|
£6.70
|
|
|
340 - GEAR COVER
BSD-2605808072.A1
2605808072
|
-
|
|
|
|
341 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A297
2603410048
|
£1.75
|
£2.10
|
|
|
342 - COMPRESSION SPRING
BSD-2604613000.A132
2604613000
|
£1.75
|
£2.10
|
|
|
343 - GUIDE BRACKET
BSD-1616B00224.A202
1616B00224
|
£11.32
|
£13.58
|
|
|
345 - CLAMPING SADDLE
BSD-2602329011.A269
2602329011
|
£4.75
|
£5.70
|
|
|
346 - SLIDING PIECE 31/35 MM
BSD-2601321022.A96
2601321022
|
-
|
|
|
|
347 - COUNTERSUNK-HEAD SCREW DIN 7962-M3.5x8-10.9
BSD-2603421040.A125
2603421040
|
£1.75
|
£2.10
|
|
|
348 - SUPPORTING DISC 0.5 MM
BSD-2600112031.A16
2600112031
|
£1.75
|
£2.10
|
|
|
349 - SEAL RING 0.5 MM
BSD-2600290017.A124
2600290017
|
£1.75
|
£2.10
|
|
|
350 - SHIM 0.5 MM
BSD-2600101612.A86
2600101612
|
£1.75
|
£2.10
|
|
|
353 - CLAMP SCREW
BSD-2603400000.A198
2603400000
|
£4.26
|
£5.11
|
|
|
354 - ROLLER LEVER
BSD-2601321044.A0
2601321044
|
-
|
|
|
|
355 - GUIDE ROLLER
BSD-2600326019.A16
2600326019
|
£5.58
|
£6.70
|
|
|
356 - BEARING BOLT
BSD-2603105089.A8
2603105089
|
£1.75
|
£2.10
|
|
|
357 - LOCKING WASHER
BSD-2600116011.A121
2600116011
|
£2.16
|
£2.59
|
|
|
358 - STRAIGHT PIN DIN 6325-4M6x24
BSD-2917530101.A16
2917530101
|
£2.80
|
£3.36
|
|
|
359 - LOCKING WASHER
BSD-2916080905.A16
2916080905
|
£1.75
|
£2.10
|
|
|
371 - SINTERED-METAL BUSHING
BSD-2600301046.A67
2600301046
|
£3.72
|
£4.47
|
|
|
372 - BUSHING
BSD-2600301045.A160
2600301045
|
£2.80
|
£3.36
|
|
|
377 - SHIM 0.2 MM
BSD-2600100032.A107
2600100032
|
£1.75
|
£2.10
|
|
|
650 - SAW BLADE SET
BSD-2607010403.A45
2607010403
|
£7.78
|
£9.33
|
|
|
652 - HOSE FITTING
BSD-3603386068.A42
3603386068
|
£21.52
|
£25.83
|
|
|
653 - SILENCER
BSD-3607000073.A117
3607000073
|
£18.96
|
£22.75
|
|
|
810 - PISTON ASSEMBLY GROUP
BSD-3607030494.A25
3607030494
|
£18.96
|
£22.75
|
|
|
815 - ROTOR LAMELLA
BSD-3607030030.A2
3607030030
|
£31.64
|
£37.97
|
|
|
826 - ASSEMBLY OF SERVICE PARTS
BSD-3607030130.A5
3607030130
|
-
|
|
|
|
828 - ASSEMBLY OF SERVICE PARTS
BSD-3607030129.A1
3607030129
|
-
|
|
|
|
829 - BASE PLATE
BSD-3607030131.A2
3607030131
|
£23.86
|
£28.63
|
|
|
840 - GEAR COVER
BSD-2605808916.A28
2605808916
|
-
|
|
|
|
844 - LIFTING ROD
BSD-2600780913.A26
2600780913
|
-
|
|
|
|
854 - ROLLER LEVER
BSD-2601321902.A2
2601321902
|
-
|
|
|
|
855 - ROLLER SET
BSD-1619P01375.A73
1619P01375
|
£11.30
|
£13.56
|
|
