1 - VALVE PISTON
BSD-3609200286.A0
3609200286
|
-
|
|
|
|
2 - STATOR
BSD-3609200320.A0
3609200320
|
£93.88
|
£112.65
|
|
|
3 - HOUSING
BSD-3609200321.A1
3609200321
|
-
|
|
|
|
4 - CONTROL PISTON
BSD-3609200287.A1
3609200287
|
-
|
|
|
|
5 - VALVE BUSHING
BSD-3609200288.A0
3609200288
|
-
|
|
|
|
6 - ROTOR
BSD-3609202799.A1
3609202799
|
-
|
|
|
|
7 - BACKING PAD
BSD-3609200325.A1
3609200325
|
-
|
|
|
|
7/1 - BACKING PAD
BSD-3609202475.A2
3609202475
|
£93.88
|
£112.65
|
|
|
9 - ROTOR LAMELLA
BSD-3609200290.A2
3609200290
|
£5.58
|
£6.70
|
|
|
10 - CONTROL LEVER
BSD-3609200291.A0
3609200291
|
-
|
|
|
|
11 - BEARING FLANGE
BSD-3609200292.A2
3609200292
|
£27.23
|
£32.68
|
|
|
12 - FLYWEIGHT
BSD-3609200293.A0
3609200293
|
-
|
|
|
|
14 - SUCTION FRAME
BSD-3609200294.A0
3609200294
|
-
|
|
|
|
15 - COVER
BSD-3609200308.A0
3609200308
|
-
|
|
|
|
17 - ROTOR SHAFT
BSD-3609200296.A0
3609200296
|
£18.96
|
£22.75
|
|
|
18 - WOODRUFF KEY
BSD-3609200297.A1
3609200297
|
£5.30
|
£6.36
|
|
|
21 - FITTING
BSD-3609200298.A1
3609200298
|
-
|
|
|
|
23 - GROOVE BALL BEARING
BSD-3609200279.A3
3609200279
|
£24.45
|
£29.34
|
|
|
24 - O-RING
BSD-3609200300.A2
3609200300
|
£2.80
|
£3.36
|
|
|
25 - O-RING
BSD-3609201046.A5
3609201046
|
£5.30
|
£6.36
|
|
|
26 - O-RING
BSD-3609200303.A2
3609200303
|
£2.80
|
£3.36
|
|
|
27 - SPRING RETAINING RING
BSD-3609200304.A0
3609200304
|
-
|
|
|
|
28 - SPRING RETAINING RING
BSD-3609200305.A2
3609200305
|
£2.80
|
£3.36
|
|
|
29 - OVAL-HEAD SCREW
BSD-3609200280.A0
3609200280
|
-
|
|
|
|
30 - HEX SOCKET HEAD CAP SCREW
BSD-3609200281.A1
3609200281
|
-
|
|
|
|
31 - SLOTTED SPRING PIN
BSD-3609200307.A2
3609200307
|
£2.80
|
£3.36
|
|
|
32 - SLOTTED SPRING PIN
BSD-3609200306.A0
3609200306
|
£2.80
|
£3.36
|
|
|
33 - COMPRESSION SPRING
BSD-3609200299.A1
3609200299
|
£2.80
|
£3.36
|
|
|
35 - PROTECTIVE CAP
BSD-3609200295.A0
3609200295
|
-
|
|
|
|
36 - RAISED COUNTERS HEAD SCRE
BSD-3609200282.A0
3609200282
|
-
|
|
|
|
44 - COVER DISC
BSD-3609200284.A0
3609200284
|
-
|
|
|
|
45 - O-RING
BSD-3609200301.A0
3609200301
|
-
|
|
|
|
46 - TOOTHED LOCK WASHER
BSD-3609200310.A1
3609200310
|
-
|
|
|
|
47 - COVER DISC
BSD-3609200312.A2
3609200312
|
-
|
|
|
|
48 - COVER RING
BSD-3609200313.A0
3609200313
|
-
|
|
|
|
49 - INTERMEDIATE BEARING
BSD-3609200314.A0
3609200314
|
-
|
|
|
|
50 - RETAINING SNAP RING
BSD-3609200315.A0
3609200315
|
-
|
|
|
|
51 - OVAL-HEAD SCREW
BSD-3609200285.A0
3609200285
|
-
|
|
|
|
95 - NAMEPLATE
BSD-3609200317.A0
3609200317
|
-
|
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A256
3603133000
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1417
3601119236
|
£3.72
|
£4.47
|
|
|
650 - HOSE FITTING
BSD-3609200316.A0
3609200316
|
-
|
|
|
|
651 - DUST BAG
BSD-3609200324.A1
3609200324
|
-
|
|
|
|
652 - AIR HOSE
BSD-3609200323.A0
3609200323
|
-
|
|
|
|
653 - STRAIGHT PIN
BSD-3609200283.A0
3609200283
|
£3.72
|
£4.47
|
|
